Cigar Lighter Receptacle or 12-Volt Accessory Power Receptacle Replacement
Tools Required
J 42059 Cigar Lighter Socket Remover
Scheme 245
Scheme 246
- Remove the auxiliary power outlet fuse from the fuse block.
- Remove the receptacle: Look into the receptacle. There are two 3 mm (0.11 in) tab windows 12 mm (0.47 in) from the front of the receptacle. The J 42059 cigar lighter socket remover pushes the plastic latches from these tab windows and the receptacle can be pulled straight out. Place one side of the "T" portion of the J 42059 cigar lighter socket remover into the tab window. The J 42059 cigar lighter socket remover will not fit straight into the receptacle. Angle the J 42059 cigar lighter socket remover slightly for insertion into the receptacle. Insert the other side of the "T" into the opposite tab window. You must move the J 42059 cigar lighter socket remover handle toward horizontal to engage the other tab window. Use the J 42059 cigar lighter socket remover to pull the receptacle straight out.
- If J 42059 cigar lighter socket remover tool fails to release the lighter socket from the retainer, perform the following alternate method: Insert a small grinding tool with a cutoff wheel into the socket. Remove the plastic latches in the 3 mm (0.11 in) square windows. Use the J 42059 cigar lighter socket remover as directed above to remove the socket.
Scheme 247
- Route the connector through the retainer. Align the accessory power receptacle retainer to the slot in the opening.
- Install the retainer by pressing into place fully seated.
- Connect the electrical connector to the receptacle.
- Align the tabs on the receptacle to the slots in the retainer. Install the accessory power receptacle by pressing into place until fully seated.
- Install the accessory power receptacle fuse.
Scheme 248
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the quarter lower rear trim panel. Refer to Quarter Lower Rear Trim Panel Replacement (Traverse with TB5) , Quarter Lower Rear Trim Panel Replacement (Traverse with TB4) , Quarter Lower Rear Trim Panel Replacement (Enclave with TB5) , Quarter Lower Rear Trim Panel Replacement (Enclave with TB4) , Quarter Lower Rear Trim Panel Replacement (Acadia with TB5) and Quarter Lower Rear Trim Panel Replacement (Acadia with TB4) . | |
| 1 | Accessory AC/DC Power Control Module Assembly Procedure Disconnect the electrical connections. Remove the jack assembly. |
Accessory AC and DC Power Control Module Replacement
Scheme 249
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the front floor console rear trim panel. Refer to Front Floor Console Rear Trim Panel Replacement . | |
| 1 | Accessory Power Receptacle Assembly Procedure Push in the 4 tabs to release the accessory power receptacle from the rear console trim plate. |
120-Volt Accessory Power Receptacle Replacement
