Mirror System: Other GMC Acadia I

Circuit/System Verification

Command the left and right outside mirror to move up, down, left and right using the mirror directional switch. The mirror should move in the commanded direction.

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Outside Rearview Mirror Motor Replacement»(ref-365278-S30934473492010070600000)
2. «Control Module References»(ref-365276-S01454229382010070600000) for DDS or PDS replacement, setup, and programming

Ignition ON, observe the scan tool Mirror Horizontal Position and Mirror Vertical Position parameters. The reading should be between 0.2-4.8 volts and change as the mirror is moved, left, right, up, and down.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Outside Rearview Mirror Motor Replacement»(ref-365278-S30934473492010070600000)
2. «Control Module References»(ref-365276-S01454229382010070600000) for DDS or PDS replacement, setup, and programming

Ignition ON, press the rear window defogger switch. The rear window defogger and both heated mirrors should become warm.

1. If the rear window defogger is inoperative, refer to «Rear Window Defogger Malfunction»(ref-365234-S23506282892010070600000) .

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Outside Rearview Mirror Glass Replacement»(ref-365278-S15466338612010070600000)
2. «Control Module References»(ref-365276-S01454229382010070600000) for DDS or PDS replacement, setup and programming

Reference Information

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Outside Mirror Description and Operation (Heated Mirrors) or Outside Mirror Description and Operation (Power Mirrors)

Electrical Information Reference

1. «Circuit Testing»(ref-365275-S00040570812010070600000)
2. «Connector Repairs»(ref-365275-S19060558252010070600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-365275-S00287822652010070600000)
4. «Wiring Repairs»(ref-365275-S21384576672010070600000)

Scan Tool References

Control Module References for scan tool information

Ignition ON, using the folding mirror switch, the left and right rearview mirrors should extend and retract as commanded.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Power Mirror Replacement»(ref-365278-S37044040202010070600000)
2. «Control Module References»(ref-365276-S01454229382010070600000) for DDM or PDM replacement, setup, and programming

Symptoms - Mirrors

1. Perform the «Diagnostic System Check - Vehicle»(ref-365273-S03182733772010070600000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to the following system descriptions: «Outside Mirror Description and Operation (Heated Mirrors)»(ref-365278-S18167065722010070600000) «Outside Mirror Description and Operation (Power Mirrors)»(ref-365278-S02667081222010070600000) «Automatic Day-Night Mirror Description and Operation»(ref-365278-S41742197322010070600000)

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Outside Mirror Description and Operation (Heated Mirrors) or Outside Mirror Description and Operation (Power Mirrors)

Electrical Information Reference

1. «Circuit Testing»(ref-365275-S00040570812010070600000)
2. «Connector Repairs»(ref-365275-S19060558252010070600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-365275-S00287822652010070600000)
4. «Wiring Repairs»(ref-365275-S21384576672010070600000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, press the rear window defogger switch. Verify the rear window defogger indicator illuminates. If the rear window defogger indicator does not illuminate, refer to «Rear Window Defogger Malfunction»(ref-365234-S23506282892010070600000) .
2. Press the rear window defogger switch. Verify both the left and right outside mirror glass become warm.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Outside Rearview Mirror Glass Replacement»(ref-365278-S15466338612010070600000)
2. «Control Module References»(ref-365276-S01454229382010070600000) for DDS or PDS replacement, setup, and programming

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Outside Mirror Description and Operation (Heated Mirrors) or Outside Mirror Description and Operation (Power Mirrors)

Electrical Information Reference

1. «Circuit Testing»(ref-365275-S00040570812010070600000)
2. «Connector Repairs»(ref-365275-S19060558252010070600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-365275-S00287822652010070600000)
4. «Wiring Repairs»(ref-365275-S21384576672010070600000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, press the rear window defogger switch. Verify the rear window defogger turns ON and the rear window becomes warm. If the rear window defogger does not turn on, refer to «Rear Window Defogger Malfunction»(ref-365234-S23506282892010070600000) .
2. Press the rear window defogger switch. Verify both the left and right outside mirror glass become warm.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Outside Rearview Mirror Glass Replacement»(ref-365278-S15466338612010070600000)
2. «Control Module References»(ref-365276-S01454229382010070600000) for DDS or PDS replacement, setup and programming

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Outside Mirror Description and Operation (Heated Mirrors) or Outside Mirror Description and Operation (Power Mirrors)

Electrical Information Reference

1. «Circuit Testing»(ref-365275-S00040570812010070600000)
2. «Connector Repairs»(ref-365275-S19060558252010070600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-365275-S00287822652010070600000)
4. «Wiring Repairs»(ref-365275-S21384576672010070600000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, press the rear window defogger switch. Verify the rear window defogger indicator illuminates. If the rear window defogger indicator does not illuminate, refer to «Rear Window Defogger Malfunction»(ref-365234-S23506282892010070600000) .
2. Press the rear window defogger switch. Verify both the left and right outside mirror glass become warm.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Outside Rearview Mirror Glass Replacement»(ref-365278-S15466338612010070600000)
2. «Control Module References»(ref-365276-S01454229382010070600000) for DDS or PDS replacement, setup, and programming

Schematic Reference

1. «Inside Rearview Mirror Schematics»(ref-365278-S33561083602010070600000)
2. «Outside Rearview Mirror Schematics»(ref-365278-S22461516762010070600000)

Connector End View Reference

Component Connector End Views

Description and Operation

Automatic Day-Night Mirror Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-365275-S00040570812010070600000)
2. «Connector Repairs»(ref-365275-S19060558252010070600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-365275-S00287822652010070600000)
4. «Wiring Repairs»(ref-365275-S21384576672010070600000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, vehicle in PARK, cover the front light sensor with a towel or other suitable item. Shine a flashlight at the rear light sensor while observing the inside rearview mirror face. The inside rearview mirror face should dim. If the mirror face does not dim, test or replace the inside rearview mirror.
2. Place the transmission in REVERSE. The inside rearview mirror face should transition from dim to bright. If the mirror does not transition from dim to bright, refer to «Inside Review Mirror Dimming Malfunction»(ref-365278-S42310369112010072700000) .
3. Vehicle in PARK, the left outside rearview mirror face should dim. If the left outside rearview mirror face does not dim, refer to «Outside Rearview Mirror Dimming Malfunction»(ref-365278-S09229291622010072700000) .
4. Place the transmission in REVERSE. The outside rearview mirror face should transition from dim to bright. If the mirror does not transition between the bright and dim states, refer to «Outside Rearview Mirror Dimming Malfunction»(ref-365278-S09229291622010072700000) .

Inside Review Mirror Dimming Malfunction

1. Ignition OFF, disconnect the harness connector at the inside rearview mirror.
2. Verify that a test lamp illuminates between B+ and the ground circuit terminal 8. If the test lamp does not illuminate, test the ground circuit for an open/high resistance.
3. Ignition ON, verify that a test lamp illuminates between the ignition circuit terminal 13 and ground. If the test lamp does not illuminate, test the ignition circuit for a short to ground or an open/high resistance.
4. Park brake applied, vehicle in REVERSE, verify that a test lamp illuminates between the backup lamp control circuit terminal 9 and ground. If the test lamp does not illuminate, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, refer to «Backup Lamps Malfunction»(ref-365239-S24674449192010070600000) .
5. If all circuits test normal, test or replace the inside rearview mirror.

Outside Rearview Mirror Dimming Malfunction

1. Ignition OFF, disconnect the X2 harness connector at the driver outside rearview mirror.
2. Verify that a test lamp illuminates between B+ and the ground circuit terminal 4. If the test lamp does not illuminate, test the ground circuit for an open/high resistance. If the circuit tests normal, test or replace the inside rearview mirror.
3. Ignition ON, test for less than 1 volt between the control circuit terminal 9 and ground. If greater than the specified range, test the control circuit for a short to voltage. If the circuit tests normal, test or replace the inside rearview mirror.
4. Headlamps ON, vehicle in PARK, cover the front light sensor with a towel or other suitable item. Shine a flashlight at the rear light sensor. Test for greater than 1 volt between the control circuit terminal 9 and ground. If less than the specified range, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, test or replace the inside rearview mirror.
5. If all circuits test normal, test or replace the driver outside rearview mirror face.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Inside Rearview Mirror Replacement»(ref-365278-S03952412692010070600000)
2. «Outside Rearview Mirror Glass Replacement»(ref-365278-S15466338612010070600000)

Schematic Reference

Inside Rearview Mirror Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Automatic Day-Night Mirror Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-365275-S00040570812010070600000)
2. «Connector Repairs»(ref-365275-S19060558252010070600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-365275-S00287822652010070600000)
4. «Wiring Repairs»(ref-365275-S21384576672010070600000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, vehicle in PARK, cover the front light sensor with a towel or other suitable item. Shine a flashlight at the rear light sensor while observing the inside rearview mirror face. The inside rearview mirror face should dim.
2. Place the transmission in REVERSE. The inside rearview mirror face should transition from dim to bright.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Inside Rearview Mirror Replacement

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Outside Mirror Description and Operation (Heated Mirrors) or Outside Mirror Description and Operation (Power Mirrors)

Electrical Information Reference

1. «Circuit Testing»(ref-365275-S00040570812010070600000)
2. «Connector Repairs»(ref-365275-S19060558252010070600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-365275-S00287822652010070600000)
4. «Wiring Repairs»(ref-365275-S21384576672010070600000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, observe the scan tool DDS Mirror Fold Switch parameter while cycling the mirror fold switch between the extend and retract positions. The parameter should change between Idle, Extend, and Retract. If the parameter does not cycle between the specified values, replace the DDS.
2. Command the power folding mirrors to extend and retract using the mirror fold switch. Both mirrors should extend and retract as commanded.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Power Mirror Replacement»(ref-365278-S37044040202010070600000)
2. «Control Module References»(ref-365276-S01454229382010070600000) for DDS or PDS replacement, setup, and programming

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Outside Mirror Description and Operation (Heated Mirrors) or Outside Mirror Description and Operation (Power Mirrors)

Electrical Information Reference

1. «Circuit Testing»(ref-365275-S00040570812010070600000)
2. «Connector Repairs»(ref-365275-S19060558252010070600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-365275-S00287822652010070600000)
4. «Wiring Repairs»(ref-365275-S21384576672010070600000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, observe the scan tool Mirror Select Switch parameter while cycling the mirror select switch between the left and right positions. The parameter should change between Idle, Right, and Left. If the parameter does not cycle between the specified values, replace the DDS.
2. Observe the scan tool Mirror Motor parameter while cycling the mirror directional switch between the up, down, left and right positions. The parameter should change between Idle, Up, Down, Left, and Right. If the parameter does not cycle between the specified values, replace the DDS.
3. Using the mirror directional switch operate the left and right outside mirrors to move up, down, left and right. The mirrors should move in the commanded directions. If a mirror does not move in all the commanded directions refer to, Mirror Motor Circuit Test.
4. Operate the memory 1 and 2 recall switches. The outside rearview mirrors should adjust to the stored memory settings. If a mirror does not adjust to the stored memory setting refer to, Mirror Position Sensor Circuit Test.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Outside Rearview Mirror Motor Replacement»(ref-365278-S30934473492010070600000)
2. «Control Module References»(ref-365276-S01454229382010070600000) for DDS or PDS replacement, setup, and programming

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Outside Mirror Description and Operation (Heated Mirrors) or Outside Mirror Description and Operation (Power Mirrors)

Electrical Information Reference

1. «Circuit Testing»(ref-365275-S00040570812010070600000)
2. «Connector Repairs»(ref-365275-S19060558252010070600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-365275-S00287822652010070600000)
4. «Wiring Repairs»(ref-365275-S21384576672010070600000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, with the mirror selector switch in the DRIVER position, command the mirrors UP, DOWN, LEFT, and RIGHT using the mirror directional switch. The driver mirror should move in the commanded direction.
2. With the mirror selector switch in the PASSENGER position, command the mirrors UP, DOWN, LEFT, and RIGHT using the mirror directional switch. The passenger mirror should move in the commanded direction.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Outside Rearview Mirror Motor Replacement»(ref-365278-S30934473492010070600000)
2. «Control Module References»(ref-365276-S01454229382010070600000) for DDS or PDS replacement, setup and programming

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Outside Mirror Description and Operation (Heated Mirrors) or Outside Mirror Description and Operation (Power Mirrors)

Electrical Information Reference

1. «Circuit Testing»(ref-365275-S00040570812010070600000)
2. «Connector Repairs»(ref-365275-S19060558252010070600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-365275-S00287822652010070600000)
4. «Wiring Repairs»(ref-365275-S21384576672010070600000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, observe the scan tool Mirror Select Switch parameter while cycling the mirror select switch between the left and right positions. The parameter should change between Idle, Right, and Left. If the parameter does not cycle between the specified values, replace the DDS.
2. Observe the scan tool Mirror Motor parameter while cycling the mirror directional switch between the up, down, left and right positions. The parameter should change between Idle, Up, Down, Left, and Right. If the parameter does not cycle between the specified values, replace the DDS.
3. Command the left and right outside mirror to move up, down, left and right using the mirror directional switch. The mirror should move in the commanded direction.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Outside Rearview Mirror Motor Replacement»(ref-365278-S30934473492010070600000)
2. «Control Module References»(ref-365276-S01454229382010070600000) for DDS or PDS replacement, setup, and programming

Scheme 8

Scheme 9

Heated Outside Rearview Mirror - RPO DNP and DS3

The Driver Door Switch (DDS) and Passenger Door Switch (PDS) control the activation of the heated mirrors. Upon receiving a serial data message indicating a request for rear window defogging, the DDS and PDS will activate the mirror heater output. The mirror heaters will remain active until a new message is received indicating rear window defogger is deactivated, either by driver input or by expiration of a calibrated timer.

Heated Outside Rearview Mirror - RPO DG6

The rear window defogger systems controls the operation of the driver and passenger rearview mirror heaters. When the rear window defogger switch is depressed, the RR DEFOG relay is activated, sending B+ to the driver and passenger rearview mirror heaters. Each heater also receives an individual ground.

The power mirror system consists of the following components

1. Driver Door Switch (DDS)-An electronic control module with integrated switches and requires programming when replaced
2. Passenger Door Switch (PDS)-An electronic control module that requires programming when replaced
3. Power Mirror Direction Switch-Integrated into DDS and is a 4 position momentary switch that provides a signal input to the DDM for up, down, left and right with mirror switch activation
4. Folding Mirror Switch-Integrated into DDS and is a 3 position switch that allows the operator to extend or retract the mirrors
5. Mirror Select Switch-Integrated into DDS and is a 3 position switch that allows the operator to select the left or right mirror and also a neutral position
6. Left Outside Power Mirror-Contains both the vertical and horizontal mirror motors
7. Right Outside Power Mirror-Contains both the vertical and horizontal mirror motors
8. Horizontal and Vertical Position Sensors-Supplied a 5-volt and low reference by the DDS/PDS and provides a variable voltage signal to the DDS/PDS that is proportional to mirror position
9. Fold Motor-Provides extend and retract movements of the mirror and is serviced as a complete mirror assembly

Each of the outside power mirrors contains 2 reversible motors to provide horizontal and vertical movement of the mirror glass. The vertical motor operates the up and down directions and the horizontal motor operates the left and right directions. Each outside power mirror also contains a reversible fold motor to operate the extend and retract functions.

The power mirror switch incorporates a 2-position mirror select switch and a 4-position mirror direction switch. The mirror select switch allows the operator to select the mirror to be moved by selecting the L position for the left power mirror, selecting the R position for the right power mirror or the center which is the neutral/fold position. The mirror direction switch is a 4-position switch that allows the operator to move the selected mirror up, down, left or right.

The power mirror switch is integrated into the DDS. The left and right mirror positions of the select switch and 4 positions of the direction switch, when active, will provide a signal to the DDS. Upon receipt of these signals, the DDS will provide battery voltage to the mirror motor up/right control circuit and ground to the mirror motor down control circuit and the mirror will move up. The remainder of the driver mirror functions operate in the same manner as described above except the DDS will supply battery voltage and ground to the appropriate control circuits for the direction selected. If the passenger mirror is selected and a direction switch is activated, the DDM sends a serial data message to the PDS indicating that the passenger mirror was selected and the direction to be commanded. The PDS will then supply battery voltage and ground to the appropriate control circuits for the direction selected.

The DDS and PDS are capable of storing mirror positions and controlling the mirrors to these positions to the preferred settings of 2 different drivers. Each driver will be able to personalize the memory system by positioning the mirrors and seats to their preferred settings. Then press and hold the memory 1 or memory 2 button until an audible chime is heard and the current mirror positions will be stored into memory of the DDS and PDS. Seat position will be stored in the memory seat module (MSM). Once the mirror and seat positions have been stored into memory, a momentary memory 1 or memory 2 switch activation will supply the DDS a battery voltage signal. The DDS, upon receipt of the memory switch signal, with the transmission in park or neutral, will then drive the driver mirror to the corresponding stored memory position. The DDS will also send a serial data message to the PDS indicating that a memory switch activation occurred. The PDS will then drive the passenger mirror to the corresponding stored memory position.

Upon receipt of the required switch input, the DDS will supply battery voltage and ground to the folding mirror motor control circuits to perform the requested extend or retract function. The DDS will also send a serial data message to the PDS indicating the requested function. The PDS will supply battery voltage and ground to the folding mirror motor control circuits to perform the requested extend or retract function.

The power mirror system consists of the following components

1. Driver Door Switch (DDS)-An electronic control module with integrated switches and requires programming when replaced
2. Passenger Door Switch (PDS)-An electronic control module that requires programming when replaced
3. Power Mirror Direction Switch-Integrated into DDS and is a 4 position momentary switch that provides a signal input to the DDM for up, down, left and right with mirror switch activation
4. Mirror Select Switch-Integrated into DDS and is a 3 position switch that allows the operator to select the left or right mirror and also a neutral position
5. Left Outside Power Mirror-Contains both the vertical and horizontal mirror motors
6. Right Outside Power Mirror-Contains both the vertical and horizontal mirror motors

Each of the outside power mirrors contains 2 reversible motors to provide horizontal and vertical movement of the mirror glass. The vertical motor operates the up and down directions and the horizontal motor operates the left and right directions. Each outside power mirror also contains a reversible fold motor to operate the extend and retract functions.

The power mirror switch incorporates a 2-position mirror select switch and a 4-position mirror direction switch. The mirror select switch allows the operator to select the mirror to be moved by selecting the L position for the left power mirror, selecting the R position for the right power mirror or the center which is the neutral/fold position. The mirror direction switch is a 4-position switch that allows the operator to move the selected mirror up, down, left or right.

The power mirror switch is integrated into the DDS. The left and right mirror positions of the select switch and 4 positions of the direction switch, when active, will provide a signal to the DDS. Upon receipt of these signals, the DDS will provide battery voltage to the mirror motor up/right control circuit and ground to the mirror motor down control circuit and the mirror will move up. The remainder of the driver mirror functions operate in the same manner as described above except the DDS will supply battery voltage and ground to the appropriate control circuits for the direction selected. If the passenger mirror is selected and a direction switch is activated, the DDM sends a serial data message to the PDS indicating that the passenger mirror was selected and the direction to be commanded. The PDS will then supply battery voltage and ground to the appropriate control circuits for the direction selected.

The power mirror system consists of the following components

1. Outside Rearview Mirror Switch
2. Mirror Select Switch
3. Left Outside Power Mirror
4. Right Outside Power Mirror

Each of the outside rearview mirrors contains two motors. The vertical motor operates the mirror in the up and down directions, and the horizontal motor operates the mirror in the left and right directions.

The outside rearview mirror switch is a four position directional switch: Up, Down, Left and Right. The mirror select switch is a three position switch: L for left, Off for none, and R for right.

The outside rearview mirror switch receives power through the battery positive voltage circuit from the power mirror fuse. The power mirror switch also receives a constant ground. The four positions of the direction switch have dual switch contacts. Each of the contacts are connected to opposing sides of the appropriate power mirror motors through the selector switch. The selector switch completes these circuits depending on the position of the selector switch, L or R. If the selector switch is placed in the L position and the up switch is depressed, battery positive voltage will be supplied to the left outside rearview mirror vertical motor through the left mirror motor down control circuit and ground through the left mirror motor left control circuit. If the down switch is depressed, battery positive voltage will be supplied to the left outside rearview mirror vertical motor through the left mirror motor left control circuit and ground through the left mirror motor down control circuit. The remainder of the mirror functions operate in the same manner as described above. Placing the power mirror switch in opposing positions, left/right or up/down, will reverse the polarity to the mirror motor, reversing the direction of movement.
