Removal & Installation
- Disconnect negative battery cable. Remove armrest and door trim panel. Unplug power window switch connector. Pull water deflector away sufficiently to access window-to-regulator bolts. Remove window-to-regulator bolts and lift window from door.
- Remove inner door brace. Remove 3 regulator mount bolts. Remove motor/regulator assembly. (Scheme 1) To install, reverse removal procedure.
Scheme 1
Removal & Installation (Master Switch)
Disconnect negative battery cable. Unclip armrest pad from armrest. Remove armrest mounting screws. Carefully pull armrest away from door trim panel. Unplug power window master/door lock switch connectors. Unclip and remove power window master/door lock switch assembly from armrest. To install, reverse removal procedure.
Removal & Installation (Passenger's Switch)
Disconnect negative battery cable. Remove armrest mounting screws and armrest. Remove door handle bezel. Release snap ring and remove window regulator handle. Unclip control rod from inside door handle. Unplug power window switch connector. Remove door trim panel. Remove power window switch from door trim panel. To install, reverse removal procedure.
