Front
- Adjust front wheel toe-in by changing tie rod length. Loosen rack boot clamps (small end), and slide clamps from boot. Loosen right and left tie rod end lock nuts.
- Turn right and left tie rods same amount to adjust toe-in to specification. See «ALIGNMENT SPECIFICATIONS»(ref-52879-S12838727672001011800000). Tighten tie rod end nuts to specification. See «TORQUE SPECIFICATIONS»(ref-52879-S08073365752001011800000). Dimension "A" should be the same on left and right tie rods. (Scheme 1)
Scheme 1
Rear
- Adjust rear wheel toe-in by rotating control rod inside bolt (cam bolt). (Scheme 2) Loosen right and left control rod inside nuts. Turn right and left control rod inside bolts same amount to set toe-in to specification. See «ALIGNMENT SPECIFICATIONS»(ref-52879-S12838727672001011800000) table.
- After adjustment, tighten right and left control rod inside nuts to specification while holding control rod inside bolts. See «TORQUE SPECIFICATIONS»(ref-52879-S08073365752001011800000).
Scheme 2
| Application | Preferred | Range |
|---|
| Camber (Front & Rear) (1) (2) | 0 | 0.5 To 0.5 |
| Caster (Front) (1) (2) | 3 | 2 To 4 |
| Toe-In (2) |
| Front | 0.16 | 0 To 0.32 |
| Rear | 0.16 | 0 To 0.32 |
| Toe-In (3) |
| Front | 0.08 (2.0) | 0 To 0.16 (0 To 4.0) |
| Rear | 0.08 (2.0) | 0 To 0.16 (0 To 4.0) |
| Toe-Out On Turns (2) |
| Inner | 38 | N/A |
| Outer | 32 | N/A |
| (1) Caster and camber are not adjustable. (2) Measurement in degrees. (3) Measurement in inches (mm). |
| (1) | Caster and camber are not adjustable. |
| (2) | Measurement in degrees. |
| (3) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS
