INSPECTION
Note. Perform all testing procedures with engine at normal operating temperature.
- Disconnect negative battery cable. Remove air cleaner. Disconnect electrical connector from TP sensor. Loosen TP sensor retaining screws.
- To check proper TP sensor operation, using ohmmeter, check resistance or continuity with selected feeler gauge thickness between throttle lever and stop screw. (Scheme 1)and (Scheme 2). Refer to the «THROTTLE POSITION (TP) SENSOR RESISTANCE»(ref-19462-S00367065052001010200000) table.
- If TP sensor resistances are not as specified, adjust or replace TP sensor. See procedure under ADJUSTMENTS. Once properly adjusted, reconnect electrical connector and install air cleaner.
| Application | Ohms |
|---|
| Between Terminals 1 & 2 (1) | 0-5000 |
| Between Terminals 1 & 2 (2) | Infinity |
| Between Terminals 1 & 2 (3) | 0-5000 |
| Between Terminals 1 & 3 (3) | 240-1140 |
| Between Terminals 1 & 3 (4) | 3170-6600 |
| Between Terminals 1 & 4 | 4370-8130 |
| (1) With .012" (.30 mm) feeler gauge installed between throttle stop screw and lever. (2) With .035" (.89 mm) feeler gauge installed between throttle stop screw and lever. (3) Throttle valve at idle position. (4) Throttle valve at fully open position. |
| (1) | With .012" (.30 mm) feeler gauge installed between throttle stop screw and lever. |
| (2) | With .035" (.89 mm) feeler gauge installed between throttle stop screw and lever. |
| (3) | Throttle valve at idle position. |
| (4) | Throttle valve at fully open position. |
THROTTLE POSITION (TP) SENSOR RESISTANCE
Note. Perform all testing procedures with engine at normal operating temperature.
| CAUTION | DO NOT use throttle stop screw to adjust throttle position sensor. |
- Disconnect negative battery cable. Remove air cleaner. Disconnect electrical connector from TP sensor. Loosen TP sensor retaining screws. Insert a.012" (.30 mm) feeler gauge between throttle lever and stop screw. (Scheme 1) Connect ohmmeter between TP sensor terminals No. 1 and 2. (Scheme 2)
- Rotate throttle position sensor fully clockwise, then slowly rotate counterclockwise until ohmmeter indicates continuity. Hold TP sensor, and tighten retaining screws to 18 INCH lbs. (2 N.m). Remove feeler gauge. Ohmmeter should still indicate continuity.
- Insert a.035" (.89 mm) feeler gauge between throttle lever and stop screw. Ohmmeter should indicate no continuity. Remove feeler gauge. Reconnect electrical connector and install air cleaner.
Scheme 1
Scheme 2
