Fuse Identification

  1. 1 - Power Mirror 10 Amp Power Mirrors, Data Link Connector (DLC)
  2. 2 - Prove Out 5 Amp GEM, Start Interrupt Relay
  3. 3 - Dimmer Illumination 5 Amp Instrument Illumination
  4. 4 - Headlamp 15 Amp LH Headlamp (Low Beam)
  5. 5 - Trailer Tow 15 Amp Trailer Park Lamps
  6. 6 - Not Used
  7. 7 - Stoplamp 15 Amp Brake On/Off (BOO) Switch, Stoplamps, Trailer RH & LH Relay, Brake Shift Interlock, RAP Module, Speed Control Module, Trailer Electric Brake Module, ABS Module, PCM
  8. 8 - Audio/Amp 25 Amp Radio Amplifier, Subwoofer Amplifier
  9. 9 - Park Lamps 10 Amp Park Lamps, Side Marker Lamps, License Lamp, Trailer Park Lamp Relay, Electric Brake Module
  10. 10 - Headlamp 15 Amp RH Headlamp (Low Beam)
  11. 11 - Fusing 15 Amp I/P Fuses 3 & 9
  12. 12 - Run/Acc 10 Amp GEM, RAP Module, Auxiliary Warning Module, Air Bag
  13. 13 - Audio 15 Amp Radio, Remote Headphone, CD Disk Changer
  14. 14 - Run/Start 5 Amp Instrument Cluster, Auxiliary Warning Module, Air Bag
  15. 15 - Not Used
  16. 16 - Horn 20 Amp Horns
  17. 17 - Fog Lamp 15 Amp Fog Lamps
  18. 18 - Front Wiper 25 Amp Windshield Wiper/Washer System
  19. 19 - GEM 15 Amp GEM, RAP System
  20. 20 - Ignition 25 Amp Ignition Coil, Ignition Capacitor, PCM Power Relay
  21. 21 - Run 10 Amp Shiftlock Actuator, Rear Window Defrost, GEM, Air Bag Module, A/C Heater Control Switch, Blend Door Actuator
  22. 22 - Power Access 20 Amp Rear Cigarette Lighter, Power Plug
  23. 23 - Flash To Pass 15 Amp Flash To Pass
  24. 24 - Rear Wiper 20 Amp Rear Wiper/Rear Washer System
  25. 25 - Hazards 15 Amp Instrument Cluster, Turn Signal Lamps
  26. 26 - Trailer 15 Amp Trailer Turn, Stop, Hazard Lamps
  27. 27 - Turn Lamps 15 Amp Electronic Flasher
  28. 28 - Front Cigar 20 Amp Front Cigar Lighter
  29. 29 - Interior Illumination 15 Amp Interior Lamps, Battery Saver Relay, Delayed Accessory Relay
  30. 30 - Speed Control 15 Amp ABS Module, Speed Control Module, Brake Pressure Switch
  31. 31 - Load Leveling 10 Amp Rear Air Suspension
  32. 32 - Not Used
  33. 33 - ABS 15 Amp ABS Lamp Relay, Back-Up Lamps, GEM, RAP Module, Day/Night Mirror Daytime Running Lamp (DRL) Module
  34. 34 - Not Used
  35. 35 - Keep-Alive 10 Amp Instrument Cluster, PCM Relay
  36. 36 - Blower 30 Amp Front Blower Motor
  37. 37 - Power Door Locks 20 Amp Power Door Lock
  38. 38 - High Beam 15 Amp LH & RH High Beams
  39. 39 - Not Used
  40. 40 - Not Used
  41. 41 - Autolamps 5 Amp Autolamp Relay, Day/Night Mirror

Underhood Fuse Panel Identification

The "high-Current Fuse panel is located in the engine compartment on the left-hand fender apron.

WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Scheme 1

Scheme 1

Scheme 2

Scheme 2

Relay Identification

  1. A - Trailer Tow 50 Amp Trailer Adapter
  2. B - Fan-Hi 60 Amp Engine Cooling Fans (HI Speed)
  3. C - Start 60 Amp Start Motor Solenoid, Ignition Switch, I/P Fuse Panel Fuses 2,30,36)
  4. D - Ignition 60 Amp Ignition Switch, I/P Fuse Panel Fuses 8,12,14,18,20,21,24,27,33)
  5. E - Rear Blower 40 Amp Auxiliary Blower Motor
  6. F - Seat 60 Amp Power Seats
  7. G - Windows 30 Amp (Circuit Breaker) Power Windows
  8. H - Fan-Lo 40 Amp Engine Cooling Fans (LO Speed)
  9. J - Battery 60 Amp Power Accessory, I/P Fuse Panel (Fuses 1,7,13,19,25,31,37)
  10. K - Lights 60 Amp Headlamps, I/P Fuse Panel (Fuses 10,11,23,29,35,41)
  11. L - ABS 60 Amp ABS
  12. M - Heated Backlight 60 Amp Heated Backlight, I/P Fuse Panel (Fuses 22,28,16)
  13. N - Fuel 20 Amp Fuel Pump
  14. P - Air Bag 10 Amp Air Bag Module
  15. R - PCM 30 Amp PCM
  16. S - Not Used
  17. T - Not Used
  18. U - Not Used
  19. V - Trans Light 10 Amp Transmission Control Switch, Canister Vent Solenoid
  20. W - Not Used
  21. AA - Air Ride 60 Amp Air Ride Suspension
  22. AB - Not Used
  23. Diode - Circuit Protection D1 - Hood Switch

Scheme 3

Scheme 3: Interior Relay Fuse Box Identification

The fuse identification for the interior fuse box is not available from the dealer. Look under the cover for relay identificaions.
