Engine Controls - Electronic Engine Controls: Other Ford Transit VII

Material

MATERIAL SPECIFICATIONS

Scheme 8

ITEM DESCRIPTION CHART

General Equipment

GENERAL EQUIPMENT SPECIFICATION

Scheme 9

ITEM DESCRIPTION CHART

Scheme 10

Scheme 11

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-356737) .
2. Remove the 2 bolts and the accessory drive belt splash shield.
3. Disconnect the Crankshaft Position (CKP) sensor electrical connector.
4. Turn the crankshaft clockwise until the hole in the crankshaft pulley is in the 3 o'clock position.
5. Remove the cylinder block plug.
6. Install the Crankshaft TDC Timing Peg. Turn the crankshaft clockwise until the crankshaft contacts the Crankshaft TDC Timing Peg.
7. Remove the CKP sensor retaining bolts and the sensor.
8. Install a 6 mm x 18 mm standard bolt.

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Install the CKP sensor, but do not tighten the 2 bolts at this time.
2. Using the Crankshaft Sensor Aligner, adjust the CKP sensor. Tighten the 2 CKP sensor bolts to 7 Nm (62 lb-in).
3. Connect the CKP sensor electrical connector.
4. Remove the 6 mm x 18 mm bolt.
5. Remove the Crankshaft TDC Timing Peg.
6. Install the cylinder block plug. Tighten to 20 Nm (177 lb-in).
7. Install the accessory drive belt splash shield and the 2 bolts. Tighten to 9 Nm (80 lb-in).

Scheme 17

ITEM DESCRIPTION CHART

MATERIAL SPECIFICATIONS

Scheme 18

Scheme 19

1. Disconnect the electrical connector and detach the wiring retainer.
2. Using the Exhaust Gas Oxygen Sensor Socket, remove the Heated Oxygen Sensor (HO2S). Calculate the correct torque wrench setting for the following torque. Refer to the appropriate Torque Wrench Adapter Formulas information. To install, tighten to 48 Nm (35 lb-ft).
3. To install, reverse the removal procedure.

MATERIAL SPECIFICATIONS

Scheme 20

Scheme 21

Scheme 22

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-356737) .
2. Disconnect the Catalyst Monitor Sensor (CMS) electrical connector and detach the wiring retainer.
3. Detach the 3 CMS wiring retainers.
4. Using the Exhaust Gas Oxygen Sensor Socket, remove the Catalyst Monitor Sensor (CMS). Calculate the correct torque wrench setting for the following torque. Refer to the appropriate Torque Wrench Adapter Formulas information. To install, tighten to 48 Nm (35 lb-ft).
5. To install, reverse the removal procedure.

Scheme 23

ITEM DESCRIPTION CHART
