Special Tool(s)
SPECIAL TOOLS CHART - CLUTCH AND CLUTCH FIELD COIL Installer, A/C Clutch 412-136 Protector, A/C Compressor Shaft 412-137
Scheme 26
Scheme 27
| Item | Part Number | Description |
|---|---|---|
| 1 | A/C clutch disc and hub bolt (part of 19D784) | |
| 2 | A/C clutch disc and hub (part of 19D784) | |
| 3 | A/C clutch hub disc and hub spacer (part of 19D784) | |
| 4 | A/C compressor pulley snap ring (part of 19D784) | |
| 5 | A/C compressor pulley (part of 19D784) | |
| 6 | A/C clutch field coil screw (part of 19D784) (4 required) | |
| 7 | A/C clutch field coil (part of 19D784) |
ITEM DESCRIPTION CHART - CLUTCH AND CLUTCH FIELD COIL
Scheme 28
Scheme 29
- Remove the A/C compressor. For additional information, refer to «AIR CONDITIONING (A/C) COMPRESSOR»(ref-356792-S40562785132010022700000) .
- Remove the A/C clutch disc and hub bolt. Using a suitable spanner-type wrench, hold the A/C clutch disc and hub. Remove the A/C clutch disc and hub bolt.
- Remove the A/C clutch disc and hub and the spacer(s).
- Remove the A/C compressor pulley snap ring.
- Remove the A/C compressor pulley. Install the A/C Compressor Shaft Protector. Install a suitable 3 jaw puller on the A/C Compressor Shaft Protector and A/C compressor pulley. Remove the A/C compressor pulley.
- Remove the 4 A/C clutch field coil screws.
- Remove the A/C clutch field coil.
SPECIAL TOOLS CHART - EVAPORATOR CORE ORIFICE Remover, Broken Orifice 412-035 (T83L-19990-B) Remover/Installer, Fixed Orifice 412-034 (T83L-19990-B)
