Inspection and Verification
Note. The FEM and instrument cluster must be reconfigured upon installation. Refer to MODULE CONFIGURATION .
- Verify the customer concern by operating the horn.
- Visually inspect for obvious signs of mechanical and electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Damaged horn Damaged horn switch Damaged horn relay Damaged clockspring (14A664) C2 Central junction box (CJB) fuses: 202 (5A) 213 (5A) 217 (5A) 220 (10A) Auxiliary junction box fuse(s): 104 (15A) Damaged circuitry Damaged horn relay Loose or corroded connections Damaged clockspring (14A664)
- If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
- If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
- Carry out the DATA LINK DIAGNOSTICS TEST. If the diagnostic tool responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to «MODULE COMMUNICATIONS NETWORK»(ref-204591) . NO RESP/NOT EQUIP for instrument cluster, refer to «INSTRUMENT CLUSTER»(ref-204577) . NO RESP/NOT EQUIP for FEM, refer to «MULTIFUNCTION ELECTRONIC MODULE»(ref-204602) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out self-test diagnostics for the instrument cluster and FEM.
- If the DTCs retrieved are related to the concern, go to «INSTRUMENT CLUSTER DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(ref-204577-S24567488312005111300000) or go to «FEM DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(ref-204577-S15896828362005111300000) to continue diagnostics.
- If no DTCs related to the concern are retrieved, proceed to the Symptom Chart to continue diagnostics.
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the front electronic module (FEM) | Central junction box (CJB) fuses: 233 (10A) 220 (10A) 230 (5A) Circuitry. J1850 communication network (SCP). Front electronic module (FEM). | REFER to MULTIFUNCTION ELECTRONIC MODULE . |
| No communication with the instrument cluster module | Circuitry. CJB fuses: 202 (5A) 213 (5A) 217 (5A) 220 (10A) J1850 communication network (SCP). Instrument cluster. | REFER to INSTRUMENT CLUSTER . |
| The horn does not sound | Auxiliary junction box fuse 104 (15A). Circuitry. Horn relay. Horn switch. Horn. FEM. Instrument cluster. | Go To PINPOINT TEST A: THE HORN DOES NOT SOUND . |
| The horn sounds continuously | Instrument cluster. Horn relay. Circuitry. Horn switch. FEM. | Go To PINPOINT TEST B: THE HORN SOUNDS CONTINUOUSLY . |
SYMPTOM CHART
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
- Raise and support the vehicle. For additional information, refer to «JACKING & HOISTING»(ref-232595-S06496072622006051700000) .
- Remove the valence panel. Remove the bolts.
- Remove the air deflector shield.
- Remove the horn. Disconnect the electrical connector. Remove the bolt.
- To install, reverse the removal procedure.
Scheme 16
Scheme 17
- Remove the air bag module. Refer to «AIR BAG RESTRAINT SYSTEMS»(ref-150664) .
- Remove the horn switch pad. Remove the bolts.
- Remove the horn switch. Remove the springs. Disconnect the steering wheel controls.
- To install, reverse the removal procedure.
