Torque Specifications
| Description | N.m |
|---|---|
| Shifter assembly bolts | 7 |
| Shift lock actuator bolts | 9 |
| Transmission shift cable and bracket bolts | 27 |
| Bolt retaining the instrument panel steering column opening cover reinforcement to the instrument panel | 3-5 |
| Bolts retaining the exhaust heat shield | 10 |
TORQUE SPECIFICATIONS
The transmission shift cable transfers the transmission operating mode from the transmission range selector lever to the automatic transmission. The indicated position of the lever is transferred to the transmission through the cable and down to the manual control lever on the transmission.
The lever has eight positions: P, R, N, D5, D4, 3, 2 and 1.
Scheme 82
