INTERIOR FUSE PANEL IDENTIFICATION (1989-93 MODELS)
On all models, the fuse panel is located under the instrument panel, left of the steering column.
Scheme 4
Fuse & Circuit Breaker Identification
- 1 - 20-Amp Circuit Breaker Deck Lid Solenoid, Power Windows, Moon Roof Motor
- 2 - 20-Amp Circuit Breaker Fuel Door Release Solenoid, Power Seats, Power Door Locks
- 3 - 20-Amp Circuit Breaker Cigarette Lighter, High Beams
- 4 - 10 Amp Radio LCD, Auto Light Dim Control, Anti-Theft Module, Chime, Voltmeter
- 5 - 15 Amp Power Antenna Motor, Radio, CD Player (89-92)
- 6 - 15 Amp Stoplights, High Mount Stoplights, Electronic Engine Control (89-92), Anti-Lock Module (89-92)
- 7 - 8.25-Amp Circuit Breaker Wiper/Washer Motor, Interval Washer Module
- 8 - 15 Amp Foglights
- 9 - 10 Amp Heated Oxygen Sensor (HEGO 1 & 2)
- 10 - 10 Amp Back-Up Lights, Flasher
- 11 - 30 Amp Blower Motor
- 12 - 15 Amp A/C Clutch, Heated Back Light Switch, VMM Module, Coolant Level Sensor, Electronic Instrument Feed, Electronic Instrument LCD (89-92), Performance Cluster Ride Light, EVO Test, Steering Sensor, Ride Control Switch, Ride Control Module, Ride Control Relay, Washer Level Sensor, Day/Night Mirror, Parking Brake Light (89-92), Keyless Entry Module, Daytime Running Lights, Brake Shift Indicator
- 13 - 10 Amp Anti-Lock Motor Relay Coil
- 14 - 5 Amp PRNDL Light & VMM, Electronic Instrument Control Switch, Instrument Panel Illumination, Compact Disc LCD, Radio, Radio LCD, Ashtray Light, Rear Defrost Switch, A/C Heat Selector Switch
- 15 - Not Used
- 16 - 10 Amp License & Rear Park Lights
- 17 - 15 Amp LCD Illumination Relay, Front Park Lights & Chime, Ride Control Module, Electronic Climate Control Module, Auto Shock Module
- 18 - 15 Amp Instrument Panel & Map Lights, Glove Box & Trunk Lights, Anti-Theft Light In Cluster, Daytime Running Light Module, Power Mirrors, Keyless Entry Module, Door Courtesy & Vanity Lights, "C" Pillar & Dome Lights
- 19 - 10 Amp Cluster, Chime, Auto Light Sensor, Anti-Lock Module, Cluster
UNDERHOOD FUSE PANEL IDENTIFICATION (1989-93 MODELS)
The "high-current" fuse panel is located in the engine compartment on the L/H fender apron.
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
Scheme 5
Fuse & Relay Identification
- A - 40 Amp Rear Window Defroster
- B - 40 Amp Anti-Lock Motor
- C - 40 Amp Fuse Panel
- D - 60 Amp Headlights
- E - 40 Amp Passive Restraints
- F - 30 Amp Ignition Coil
- G - 30 Amp Powertrain Control Module (1993), EEC (1989-92)
- H - 30 Amp Fuel Pump Motor
- I - 30 Amp Auto Shock
- J - 80 Amp Ignition Switch, Blower Motor
- K - 30 Amp Anti-Lock Module
- L - 20 Amp Horn/Hazard
- M - 5 Amp Memory
