MANUAL OVERRIDE SYSTEM
If the shoulder belt does not move or stops before reaching the B-pillar position, perform the following steps before driving the vehicle.
Scheme 14
- Open and close door(s). Make sure the door is completely closed.
- Using a coin or screwdriver, remove cover at lower end of the B-pillar interior trim panel, next to the rear seat on either side. Turn override knob clockwise to move shoulder belt manually until it stops at the B-pillar. (Scheme 14) WARNING: For Fig. (Scheme 14) if it is necessary to use the override knob to put the shoulder belt in position, have the system serviced by a qualified technician as soon as possible.
- If the belt does not mover to the B-pillar, the belt may be broken or the motor drive gear stripped. Grasp the belt and pull it towards the B-pillar while turning the knob on the motor clockwise. This should move the belt to the lowest position on the B-pillar. This will allow the occupant(s) to position the belt manually over the shoulder until the system can be serviced properly.
Scheme 15
SEAT BELT FUNCTIONALITY CHECK
| Action | Result |
|---|---|
| Door Closed, Ignition Off | No Belt Movement |
| Ignition On, Door Closed | Belt moves to B-Pillar |
| Door Open, Ignition On | Belt moves to A-Pillar |
| Door Closed, Ignition On | Belt moves to B-Pillar |
| Ignition On, Door Open | No Belt Movement |
| Door Open, Ignition Off | Belt moves to A-Pillar |
| Door Open, Ignition On, & Inertia Switch Open | No Belt Movement |
| Door Open, Ign. Off & Inertia Switch Open | Belt moves to A-Pillar |
SEAT BELT FUNCTIONALITY CHECK
WARNING INDICATORS FUNCTIONALITY CHECK
| Action | Result |
|---|---|
| Belt Doesn't Properly Reach the B-Pillar After 7.5 Seconds. | Fasten Belt Indicator on Instrument Panel Flashes |
| Release Lever in the UP Position, With Ignition On | 1 - Fasten Belt Indicator Flashes |
| " | 2 - Release Lever Warning Indicator Flashes |
| " | 3 - Chime Sounds Continuously |
WARNING INDICATORS FUNCTIONALITY CHECK
PASSIVE RESTRAINT PIN & CIRCUIT I.D. CHART
| Pin No | Circuit | Description | Color |
|---|---|---|---|
| 1 | 159 | Door Jamb Switch to Buzzer (Lamps On/Key Warning Buzzer) | Black/Pink Black/White |
| 2 | 861 | Left Motor - Driver - R Relay | Black/White |
| 3 | 860 | Left Motor - Driver - F Relay | Black/Orange (Or (Purple/Yellow) |
| 4 | 860 | Left Motor - Driver - F Relay | Black/Orange (Or (Purple/Yellow) |
| 5 | 862 | Left Limit A - Driver | Brown/Yellow |
| 6 | 57 | Ground Circuit | Black |
| 7 | 38 | Power Supply to Battery | Black/Orange |
| 8 | 863 | Right Door Open - Passenger | Red |
| 9 | 865 | Right Motor - Passenger - R | Purple/White |
| 10 | 864 | Right Motor - Passenger - F | Orange |
| 11 | 864 | Right Motor - Passenger - F | Orange |
| 12 | 866 | Inertia Switch to Module | White |
| 13 | 867 | Left Door Open - Driver | Dark Blue |
| 14 | 868 | Emergency Release Levers | Red |
| 15 | 450 | Safety Belt Warning Indicator Light Feed | Dark Green/Light Green |
| 16 | 871 | Safety Belt Indicator Light To Module | Yellow |
| 17 | 861 | Left Motor - Driver - R | Black/White |
| 18 | 872 | Left Limit B - Driver | Light Green |
| 19 | 57 | Ground Circuit | Black |
| 20 | 38 | Power Supply to Battery | Black/Orange |
| 21 | 873 | Right Limit B - Passenger | Tan |
| 22 | 865 | Right Motor - Passenger - R | Purple/White |
| 23 | 874 | Right Limit A - Passenger | Gray |
| 24 | 875 | Ground Logic Module | Black/Light Blue |
| 25 | 640 | Run/Start/Door Ajar | Red/Yellow |
| 26 | Not Used | Not Used | Not Used |
PASSIVE RESTRAINT PIN & CIRCUIT IDENTIFICATION CHART
DOOR AJAR SWITCH
Note. No removal procedures are provided by manufacturer. Refer to Fig. (Scheme 16): for reference.
