Parking Aid System: Removal & Installation Ford Taurus VI

Warning System 3 illustrations ~216 words

Removal and Installation

Pinpoint Test J

J1 PAM
J4 PAM
J5 PAM

Scheme 41

Scheme 41: Parking Aid Speaker
ItemPart NumberDescription
1W705635Parking aid speaker push pins (2 required)
215K864Parking aid speaker
3Parking aid speaker electrical connector (part of 14A005)

ITEM DESCRIPTION CHART

  1. Remove the parcel shelf. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-355729) .
  2. Remove the 2 push pins and the parking aid speaker. Disconnect the electrical connector.
  3. To install, reverse the removal procedure.

Scheme 42

Scheme 42: Parking Aid Sensor
ItemPart NumberDescription
1Parking aid sensor electrical connectors (part of 14A464)
215K859Parking aid sensors (4 required)
315K870Parking aid sensor bezels (4 required)

ITEM DESCRIPTION CHART

  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-355694) .
  2. Remove the rear bumper cover. For additional information, refer to «BUMPERS»(ref-355751) .
  3. Disconnect the parking aid sensor electrical connectors.
  4. Remove the parking aid sensor(s).
  5. To install, reverse the removal procedure. Carry out the azimuth and elevation system check. For additional information, refer to «AZIMUTH SYSTEM CHECK»(ref-355764-S13354323792010012800000) and «ELEVATION SYSTEM CHECK»(ref-355764-S23124986842010012800000) .

Scheme 43

Scheme 43: Video Camera
ItemPart NumberDescription
119G490Video camera
2Video camera cover
3Video camera cover screw
4W711225Video camera screw push cover

ITEM DESCRIPTION CHART

  1. Remove the rear spoiler. For additional information, refer to «EXTERIOR TRIM AND ORNAMENTATION»(ref-355768) .
  2. Remove the video camera screw push cover.
  3. Remove the video camera cover screw.
  4. Remove the video camera from the spoiler and video cover.
  5. To install, reverse the removal procedure.
