Video (If Equipped)
The rear video camera system consists of the following
- Video camera (located in the rear spoiler (vehicles with rear spoiler))
- Video camera (located in the decklid (vehicles without rear spoiler))
- Auto-dimming interior mirror (without navigation)
- Front Display Interface Module (FDIM) (with navigation)
The video camera is activated when the vehicle is in REVERSE (R). The image from the rear video camera is displayed in the LH side of the auto-dimming interior mirror (without navigation) or the FDIM (with navigation). The displayed video image is horizontally inverted and is viewed from the video camera perspective to mimic a conventional mirror image.
PAM Network Communication Messages
Note. Both the Medium Speed Controller Area Network (MS-CAN) and the HS-CAN are used for intermodule communication. A gateway message is transferred from one network to another network through the IPC . Refer to MODULE COMMUNICATIONS NETWORK for network communication information.
| Broadcast Message | Originating Module | Network Type | Receiving Module |
|---|---|---|---|
| Cross traffic alert status | Instrument Panel Cluster (IPC) | HS-CAN | PAM |
| Ignition switch position (gateway) | IPC | HS-CAN | PAM |
| Parking aid distance to target | PAM | HS-CAN | IPC |
| Parking aid enabled status | PAM | HS-CAN | IPC |
| Parking aid fault status | PAM | HS-CAN | IPC |
| Parking aid sounder status | PAM | HS-CAN | IPC |
| Parking aid volume cutback request | PAM | HS-CAN | IPC |
| Transmission selector (PRNDL) status | PCM | HS-CAN | PAM |
| Vehicle speed | PCM | HS-CAN | PAM |
PAM NETWORK COMMUNICATION MESSAGES CHART
Elevation System Check
Pinpoint Test J
Scheme 47
| Item | Part Number | Description |
|---|---|---|
| 1 | W706350 | Pin-type retainers (2 required) |
| 2 | 15K866 | Parking Aid Module (PAM) |
| 3 | PAM electrical connector (part of 14A005) |
ITEM DESCRIPTION CHART
