MATERIAL SPECIFICATIONS
| Item | Specification | Fill Capacity |
|---|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | ESE-M12A4-A |
MATERIAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | N.m | Lb-ft | Lb-in |
|---|---|---|---|
| Lower arm forward bolt | 185 | 136 | |
| Lower arm rearward nuts | 99 | 73 | |
| Lower ball joint nut | 200 | 148 | |
| Stabilizer bar bracket bolts | 55 | 41 | |
| Stabilizer bar link nuts | 150 | 111 | |
| Steering gear nuts and bolts Electronic Power Assist Steering (EPAS) | 165 | 122 | |
| Steering gear nuts and bolts Hydraulic Power Assist Steering (HPAS) | 117 | 86 | |
| Strut rod nut | 133 | 98 | |
| Strut-to-wheel knuckle nut | 175 | 129 | |
| Subframe bracket bolts | 55 | 41 | |
| Subframe forward bolts | 200 | 148 | |
| Subframe rearward bolts EPAS | 150 | 111 | |
| Subframe rearward bolts HPAS | 175 | 130 | |
| Tie-rod end nut | 150 | 111 | |
| Upper strut mount nuts | 30 | 22 | |
| Wheel bearing and wheel hub bolts (1) | |||
| Wheel hub nut (1) | |||
| Wheel speed sensor bolt | 15 | 133 | |
| (1) Refer to the Wheel Bearing and Wheel Hub . | |||
| (1) | Refer to the Wheel Bearing and Wheel Hub . |
TORQUE SPECIFICATIONS
The front suspension consists of the following components
- Wheel bearing and wheel hubs
- Wheel studs
- Lower arms
- Stabilizer bar
- Stabilizer bar links
- Struts
- Springs
- Wheel knuckles
The front suspension utilizes a MacPherson strut system.
This suspension system incorporates a strut assembly that takes the place of the upper arm and ball joint. The strut carries out the function of a shock absorber and is encompassed by a coil spring. The strut and spring assembly supports the weight of the vehicle and is also the pivot point for the steering knuckle. This system uses a lower control arm and ball joint for the lower (unloaded) pivot point of the steering knuckle.
Refer to SUSPENSION SYSTEM - GENERAL INFORMATION .
Scheme 19
| Item | Part Number | Description |
|---|---|---|
| 1 | W705967 | Wheel hub nut |
| 2 | 2C300 | Wheel bearing and wheel hub |
| 3 | 1107 | Wheel stud (also part of 1104) (5 required) |
| 4 | 3K171 LH/3K170 RH | Wheel knuckle |
| 5 | W710015 | Tie-rod end nut |
| 6 | W714331 | Wheel bearing and wheel hub bolt (4 required) |
| 7 | W520215 | Strut-to-wheel knuckle nut |
| 8 | W710396 | Strut-to-wheel knuckle flag bolt |
| 9 | 3051 LH/3042 RH | Lower control arm |
| 10 | W714890 | Lower ball joint nut |
| 11 | W710174 | Lower arm forward bolt |
| 12 | W520515 | Lower arm rearward nuts (2 required) |
| 13 | W708848 | Lower arm rearward bolt (2 required) |
| 14 | 3C339 LH/3C403 RH | Lower arm rearward bushing |
PART DESCRIPTION CHART
Scheme 20
| Item | Part Number | Description |
|---|---|---|
| 1 | W713968 | Stabilizer bar link upper nut |
| 2 | 5B421 LH/5B420 RH | Strut and spring assembly |
| 3 | W520215 | Strut-to-wheel knuckle nut |
| 4 | W714812 | Strut upper mount nut (4 required) |
| 5 | W710396 | Strut-to-wheel knuckle flag bolt |
| 6 | 3B439 LH/3B438 RH | Stabilizer bar link |
PART DESCRIPTION CHART
Scheme 21
| Item | Part Number | Description |
|---|---|---|
| 1 | W505274 | Stabilizer bar bracket bolts (4 required) |
| 2 | W520215 | Stabilizer bar link lower nut (2 required) |
| 3 | W713968 | Stabilizer bar link upper nut (2 required) |
| 4 | 5482 | Stabilizer bar assembly |
| 5 | 3B439 LH/3B438 RH | Stabilizer bar link (2 required) |
PART DESCRIPTION CHART
- For additional information, refer to the appropriate procedure in this information.
