Engine Cooling System: Removal & Installation Ford Taurus IV facelift

Removal and Installation

Note. The RH and LH cooling fans can be serviced individually. The LH cooling fan is shown, the RH is similar.

Scheme 19

Scheme 20

Scheme 21

1. Remove the distribution box and position aside.
2. Disconnect the fan electrical connector and detach the retainer.
3. Remove the bolt and the electrical cooling fan.
4. To install, reverse the removal procedure.

Scheme 22

Scheme 23

Scheme 24

1. Drain the coolant below the degas bottle. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-212100-S06677154962005122300000) .
2. Disconnect the upper hoses.
3. Disconnect the lower hose.
4. Remove the bolt and the nut, remove the degas bottle.
5. To install, reverse the removal procedure.
