HVAC System - Control Components: Removal & Installation Ford Taurus IV facelift

Automatic HVAC System 6 illustrations ~225 words

Removal and Installation

  1. Working through the driver footwell, remove the two screws and the shield.
  2. Label and disconnect the two vacuum hoses. Remove the screw. Lift, rotate and remove the panel/floor door vacuum control motor (18A318) from the door lever.
  3. To install, reverse the removal procedure.

Scheme 26

Scheme 26: Removal and Installation
  1. Remove the passenger air bag module. For additional information, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-170325) .
  2. Remove the defrost door vacuum control motor (18A318). Disconnect the vacuum line. Remove the screws.
  3. Rotate and remove the vacuum control motor from the defrost door lever.
  4. To install, reverse the removal procedure.

Scheme 27

Scheme 27: Removal and Installation

Scheme 28

Scheme 28
  1. Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-212149) .
  2. Remove the right-side instrument panel insulator (046A24).
  3. Working the passenger footwell, remove the floor console register duct vacuum control motor (18A318). Disconnect the vacuum hose. Remove the screws.
  4. Rotate and remove the vacuum control motor from the floor console register duct door.
  5. To install, reverse the removal procedure.

Scheme 29

Scheme 29: Removal and Installation

Scheme 30

Scheme 30

Scheme 31

Scheme 31
  1. Remove the right front tire and wheel assembly. For additional information, refer to «WHEELS & TIRES»(ref-212090) .
  2. Remove the rear half of the right front fender splash shield.
  3. Remove the bolt.
  4. Disconnect the vacuum hose. Remove the vacuum reservoir and bracket (19A566).
  5. To install, reverse the removal procedure.
