Identification Codes: Other Ford Taurus IV рестайлинг

Vehicle Certification (VC) Label

Vehicle Certification (VC) Label Locator

Scheme 11

The vehicle certification (VC) label contains the manufacturer name, the month and year of manufacture, the certification statement, and the VIN. It also includes gross vehicle weight ratings (GVWR).

Scheme 12

Scheme 13

The first set of paint code numbers/letters listed indicate the vehicle primary body color. The second set of numbers/letters listed (if applicable) indicate a two-tone or accent body color. All colors are base coat/clear coat.

1. AQ - Arizona Beige
2. C2 - Gold Ash Metallic
3. CX - Dark Shadow Gray
4. DV - Light Tundra/Titanium Green
5. FX - Merlot
6. P3 - Windveil Blue
7. TS - Silver Frost
8. UA - Ebony
9. WT - Performance White

Scheme 14

1. 2 - Anti-lock brake system (ABS)
2. 5 - Anti-lock brake system (ABS) and Traction Control

Scheme 15

The interior trim codes are listed below. The first character listed indicates the seat and fabric style. The second character listed indicates the interior trim color.

Trim Codes

1. H - Prescott/Kent cloth
2. K - Fairfax/Kent cloth
3. L - Imola leather
4. M - Imola leather
5. N - Split hide leather
6. P - Euro Perforated leather

Interior Trim Color Code

1. 2 - Medium Graphite
2. H - Medium Parchment
3. W - Midnight Black

Scheme 16

Tape and paint pinstripe codes do not apply.

Scheme 17

1. 5 - Electronic premium AM/FM stereo with compact disc (CD) player
2. H - Electronic AM/FM stereo with cassette

Scheme 18

The following lists the axle ratios.

1. 6R - 3.96

Scheme 19

1. X - Four-speed automatic overdrive AF50N

Scheme 20

Spring codes list both front and rear spring codes. The first set of characters identify the front springs. The second set of characters identify the rear springs.

Front Springs

1. Base part number - 5310

Rear Springs

1. Base part number - 5560

Scheme 21

Note. Powertrain calibration information is limited to a maximum of five characters per line on the Vehicle Certification (VC) label. Because of this, calibration identification consisting of more than five characters will wrap to the second line on the VC label.

Powertrain calibration information is printed in the lower right corner of the VC label. Only the base calibration information is printed. Revision levels will not appear, however, they can be found in On Line Automotive Service Information System (OASIS). For the current model year, Ford Motor Company is using three different protocols which describe powertrain base calibration. These protocols are designed to provide worldwide standardization for vehicle calibration. If the electronic calibration strategy has been used since 1998 and carried into the current model year, Protocol 1 will be used. Refer to PROTOCOL 1 below. If the electronic calibration strategy has been used since 1999 and is carried into the current model year, Protocol 2 will be used. Refer to PROTOCOL 2 below. For electronic calibration strategies introduced in 2000 or later model years, Protocol 3 will be used. Refer to PROTOCOL 3 below.

Scheme 22

Scheme 23

Scheme 24

Protocol 3

The following offers a more detailed explanation of the coding strategy used for Protocol 3.

Model Year

Model year code indicates the year in which the calibration code was introduced.

1. 0 - 2000
2. 1 - 2001
3. 2 - 2002
4. 3 - 2003
5. 4 - 2004
6. 5 - 2005

Vehicle Code

The vehicle code indicates the vehicle line to which the code applies.

1. DD - Taurus/Sable

Transmission Code

The transmission code identifies the type of transmission used.

1. 1 - Automatic transmission

Fleet Coding

Identifies the fleet to which the vehicle belongs.

1. 0 - Certification (U.S. 4K, final sale in export markets)
2. 1 - HDGE/Dyno
3. 2 - Fast AMA U.S.
4. 3 - ADP U.S.
5. 4 - Not assigned
6. 5 - Not assigned
7. 6 - Evaporative emissions
8. 7 - MACAA
9. 8 - On-board diagnostics (OBD)
10. 9 - Not assigned

Certification Region

When instances where multiple regions are included in one calibration, the lead region will be listed.

1. 5 - U.S. fifty states
2. A - U.S. federal, including altitude, may include Canada and/or Mexico
3. B - U.S. California standard, includes U.S. green states
4. C - Canada
5. D - China
6. E - European Community (Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, Netherlands, Portugal, Spain, Sweden and United Kingdom)
7. F - European Extended Community (E plus Croatia, Czech Republic, Estonia, Hungary, Norway, Poland, Romania, Russian Federation, Slovakia, Slovenia, Switzerland and Yugoslavia)
8. G - Gulf Cooperative Council (Bahrain, Kuwait, Oman, Qatar, Saudi Arabia and UAE)
9. H - Hong Kong
10. J - Japan
11. K - Korea
12. L - Malaysia
13. M - Mexico
14. N - New Zealand
15. P - Australia
16. Q - South America (Brazil)
17. S - Singapore
18. T - Taiwan
19. U - South America (unleaded fuel regions)
20. V - Vietnam
21. X - Rest of World (ROW)
22. Y - Military
23. Z - Israel

Revision Level (not printed on label)

1. 91-99 - Hardware and certification levels
2. 01-04 - Preliminary levels
3. 00 - Job 1 production (initial certification)
4. 05-09 - Pre-job 1 revisions to calibrations
5. 10-89 - Post-job 1 revisions to calibrations
6. 0B - Durability test level
7. BD - On-board diagnostics (OBD) intermediate level (pre-05)
