GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Drive belt - coolant pump 3.0L (4V) 3K poly V belt | |
| 3.0L, 6K poly V belt |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Belt tensioner bolt 3.0L - (2V) | 47 |
| Belt tensioner bolt 3.0L - (4 V) | 25 |
| Belt tensioner - coolant pump, 3.0L (4V) | 10 |
| Low pressure A/C hose mounting nut | 9 |
| High pressure A/C hose mounting bolts | 9 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
Scheme 4
This vehicle is equipped with
- a V-ribbed serpentine accessory drive belt(s).
- automatic drive belt tensioner(s).
- a V-ribbed coolant pump belt.
New drive belts should be of the same type as originally installed.
Drive belt chirp is a regularly occurring chirping noise that occurs due to
- pulley misalignment.
- excessive pulley runout.
- worn out belt.
- incorrect tension.
It can be a result of a damaged pulley or an incorrectly installed pulley that was not correctly aligned.
To correct drive belt chirp
- determine the area from where the noise comes.
- check each of the pulleys in that area with a straightedge to the crankshaft pulley for front accessory drive.
- look for the accessory pulley to be out of position in the fore/aft direction or at an angle to the straightedge.
- inspect the drive belt.
- inspect the belt tensioner.
Drive belt squeal is an intermittent noise that occurs when the drive belt slips on a pulley during certain conditions such as
- engine start-up.
- rapid engine acceleration.
- A/C clutch engagement.
