BELT TENSION
Vehicles are equipped with automatic drive belt tensioner. Drive belt does not require adjustment. Inspect condition and tension of generator drive belt prior to performing any on-vehicle charging system tests. Replace belt and/or repair tensioner mechanism if necessary.
PRELIMINARY CHECKS
- Verify battery condition and state of charge.
- Inspect accessory drive belt and tensioner.
- Inspect MEGA FUSE FB (175-amp) in Battery Junction Box (BJB).
- Inspect fuse No. 126 (30-amp) in Battery Junction Box (BJB).
- Inspect fuse No. 227 (105-amp) Central Junction Box (CJB).
- Check all connections for looseness or corrosion.
3.0L 2-VALVE
| Application | Ft. Lbs. (N.m) |
|---|---|
| Generator Mounting Bolt (Left Side) | 18 (25) |
| Generator Mounting Bolt (Right Side) | 35 (48) |
| INCH Lbs. (N.m) | |
| Generator Terminal B+ Nut | 89 (10) |
TORQUE SPECIFICATIONS (3.0L 2-VALVE)
3.0L 4-VALVE
| Application | Ft. Lbs. (N.m) |
|---|---|
| Generator Mounting Bolts | 18 (25) |
| INCH Lbs. (N.m) | |
| Generator Terminal B+ Nut | 89 (10) |
TORQUE SPECIFICATIONS (3.0L 4-VALVE)
