Wheels & Tires Ford Taurus X I

Material

Material

GENERAL SPECIFICATIONS

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

a Torque specifications are for clean, dry bolt and nut threads. Never use oil or grease on wheel bolts or nuts.

b Refer to the appropriate procedure in this article.

Safety Precautions

Note. Do not clean aluminum wheels with steel wool, abrasive-type cleaners or strong detergents or damage to the wheel finish may occur. Use Wheel and Tire Cleaner ZC-27-A or -B or equivalent.

Factory-installed tires and wheels are designed to operate satisfactorily with loads up to and including full-rated load capacity when inflated to recommended inflation pressures.

Correct tire pressure and driving techniques have an important influence on tire life. Heavy cornering, excessively rapid acceleration and unnecessary sharp braking increase tire wear.

To equalize tire wear, the tires should be rotated at recommended intervals.

Tire Pressure Monitoring System (TPMS)

Note. The Smart Junction Box (SJB) is also identified as the Generic Electronic Module (GEM).

The Tire Pressure Monitoring System (TPMS) includes

1. the SJB, TPMS functionality is integrated within the SJB.
2. four tire pressure sensors.
3. four tire pressure sensor cradles.
4. four tire pressure sensor straps.
5. an instrument cluster indicator.
6. a message center (if equipped).

Tire Pressure Monitoring System (TPMS) Module

The SJB contains the TPMS functionality. Refer to Tire Pressure Monitoring System in Diagnosis and Testing for TPMS fault diagnosis and repair.

The SJB compares the information of each tire pressure sensor transmission against a pressure limit. If the SJB determines that the tire pressure has fallen below the low limit, the SJB communicates this to the instrument cluster on the vehicle communication bus.

Tire Pressure Monitoring System (TPMS) Pressure Sensor

The SJB monitors the air pressure in the 4 road tires with tire pressure sensors. The sensors transmit radio frequency signals to the SJB approximately every 60 seconds when the vehicle speed exceeds 32 km/h (20 mph).

The tire pressure sensors are battery operated and are mounted to metal brackets (called cradles) on the wheels inside the tires. The sensors are mounted 180 degrees from the valve stem.

The tire pressure sensor can be serviced separately from the cradle and the strap.

Tire Pressure Monitoring System (TPMS) Pressure Sensor Cradle

The tire pressure sensor cradles are mounted to the wheels with metal straps and have an adhesive strip to aid in their retention to the wheel.

The sensor cradle is available with the strap in a kit. To service the sensor cradle, the strap must be removed and discarded.

Tire Pressure Monitoring System (TPMS) Pressure Sensor Strap

The sensor strap keeps the sensor and the cradle retained to the wheel. A factory-installed strap is joined together with a one-time-use buckle and a dealer-installed strap is joined together with a worm gear (similar to a radiator hose clamp). Both straps should be discarded after removal and should not be reused.

The cradle and strap are available as a strap kit. There are several different strap kits available based on wheel diameter.

Instrument Cluster and Message Center

The instrument cluster illuminates the TPMS indicator when it receives a message from the SJB to do so and displays the appropriate message(s) in the message center (if equipped).

The instrument cluster and message center are diagnosed and serviced in their own respective workshop manual articles. Refer to the appropriate Instrumentation and Warning Systems article for the procedure.

Wheels And Tires

Special Tools Illustration Tool Name Tool Number Activation Tool, Tire Pressure Monitor 204-363 Digital Tire Gauge 204-354

Inspection and Verification

Be sure to follow all warnings when carrying out Inspection and Verification.

Verify the customer concern by carrying out a road test on a smooth road. If any vibrations are apparent, go to NVH .

To maximize tire performance, inspect for signs of incorrect inflation and uneven wear, which may indicate a need for balancing, rotation or front suspension alignment.

Correct tire pressure and driving techniques have an important influence on tire life. Heavy cornering, excessively rapid acceleration and unnecessary sharp braking increase tire wear.

Replacement tires must follow the recommended

1. tire sizes.
2. speed rating.
3. load range.
4. tire construction type.

The use of any other tire/wheel size, load range or type can seriously affect

1. ride.
2. handling.
3. speedometer/odometer calibration.
4. vehicle ground clearance.
5. tire clearance between the body and chassis.
6. wheel bearing life.
7. braking performance.

New wheels need to be installed when the vehicle wheels

1. are bent.
2. are cracked.
3. are dented.
4. are heavily corroded.
5. are leaking.
6. have elongated wheel hub bolt holes.
7. have excessive lateral or radial runout.

It is mandatory to use only the tire sizes recommended on the tire label located on the driver door or door pillar attached to the vehicle. Larger or smaller tires can damage the vehicle, affect durability and require changing the speedometer calibration. Make sure wheel size and offsets match those recommended for the tire in use.

1. Inspect the tires for signs of uneven wear. Refer to the following descriptions to identify the type of wear and Go to «Tire Wear»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) for the appropriate repair action to be carried out.
2. Check the tires for: cuts. stone bruises. abrasions. blisters. embedded objects.
3. Tread wear indicators are molded into the bottom of the tread grooves. Install a new tire when the indicator bands become less than 1.58 mm (0.062 in).

Tire Wear

Tire wear is commonly defined as a loss of tread depth. Tire tread wear occurs due to friction with the contact surface (road/pavement). The tread should wear down uniformly all the way around the circumference of the tire and all the way across the tread face. When this does not occur, the tire may have abnormal/incorrect wear.

Normal Tire Wear

Normal tire wear is identified as even wear around and across the tread. Because there are many factors (driving style, road surfaces, type of vehicle, type of tire) that can affect tire wear, there is no absolute mileage expectation for a normal wear condition. A tire is considered worn-out when the tread has worn to the level of the tread-wear indicators.

Abnormal/Incorrect Tire Wear

Abnormal/incorrect tire wear is identified as tire wear that is not even around or across the tread and that creates performance-related issues.

Abnormal/incorrect wear can be caused by numerous factors, some of which include driving style (aggressive, passive), climate (hot, cold), road conditions, vehicle loading and maintenance (correct tire pressure, rotation intervals and balance). It is important to determine the root cause of wear on a vehicle before carrying out repair. Tires exhibiting abnormal/incorrect tire wear may still be serviceable provided that the minimum tread depth is greater than 1.58 mm (0.062 in) and the tire is not causing a vehicle performance (noise/vibration) concern.

Some abnormal/incorrect wear patterns look the same all the way around the tread of the tire, other wear patterns are not consistent and can occur in various spots on the tread area. The underlying causes of the 6 wear categories are different. Refer to the following descriptions to identify the type of wear and Go to Tire Wear for the appropriate repair action to be carried out.

Inner Edge/Shoulder Wear

Inner edge (or shoulder) wear occurs on the inside edge of the tire and is usually caused by excessive toe-out and/or excessive negative camber. If the tread depth of the outer shoulder is at least 50% greater than the tread depth of the inner shoulder, the tire is experiencing inner edge/shoulder wear. To determine whether tires have this type of wear, visually inspect the tires. In some instances, it may be necessary to measure the tread depth of each rib and compare it to that of the shoulder.

Note. RF tire shown, others similar.

Scheme 1

Outer Edge/Shoulder Wear

Outer edge (or shoulder) wear occurs on the outside edge of the tire and is usually caused by excessive toe-in and/or excessive positive camber. If the tread depth of the inner shoulder is at least 50% greater than the tread depth of the outer shoulder, the tire is experiencing outer edge/shoulder wear. To determine whether tires have this type of wear, visually inspect the tires. In some instances, it may be necessary to measure the tread depth of each rib and compare it to that of the shoulder.

Note. RF tire shown, others similar.

Scheme 2

Heel/Toe Wear

Heel/toe wear (also known as feathering) occurs along the outside or inside edge/shoulder of the tire. To determine whether tires have this type of wear, visually inspect the tires in both the inside and outside shoulder ribs. In some instances, it may be necessary to measure the difference in tread depth of leading versus trailing edge of each lug in the inside and outside shoulder rib.

Scheme 3

Diagonal Wear

Diagonal wear occurs diagonally across the tread area and around the circumference of the tire. To determine whether tires have this type of wear, visually inspect the tires to determine if the wear pattern runs diagonally across the tread and around the circumference of the tire. In some instances, the difference in tread depth along the diagonal wear pattern may need to be measured.

Scheme 4

Symptom Chart - Tire Wear

Note. For suspension system and additional alignment diagnosis, refer to SUSPENSION SYSTEM - GENERAL INFORMATION article.

Symptom Chart - Tire Wear

Symptom Chart - NVH

Note. NVH symptoms should be identified using the diagnostic tools that are available. For a list of these tools, an explanation of their uses and a glossary of common terms, refer to NOISE, VIBRATION AND HARSHNESS article. Since it is possible any one of multiple systems may be the cause of a symptom, it may be necessary to use a process of elimination type of diagnostic approach to pinpoint the responsible system. If this is not the causal system for the symptom, refer back to NOISE, VIBRATION AND HARSHNESS article for the next likely system and continue diagnosis.

Symptom Chart - NVH

Pinpoint Tests

For a description of the various tire wear patterns, refer to Inspection and Verification.

Pinpoint Test A: Inner Edge/Shoulder Wear

This pinpoint test is intended to diagnose the following

1. Excessive toe out
2. Incorrect wheel and tire rotation

1. A1 MEASURE THE TREAD DEPTH Using a tread depth gauge or similar tool, measure the inside edge/shoulder tread depth. Is the tread depth greater than 1.58 mm (0.062 in)? YES : ROTATE the wheel and tire assemblies. CHECK and ADJUST the toe to nominal +0.15 degrees (toe in). CHECK and ADJUST caster and camber to nominal. REFER to «SUSPENSION SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/suspension-front/#suspension-system-general-information) article. NO : INSTALL a new tire(s). CHECK and ADJUST the toe to nominal. CHECK and ADJUST caster and camber to nominal. REFER to «SUSPENSION SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/suspension-front/#suspension-system-general-information) article.

Pinpoint Test B: Outer Edge/Shoulder Wear

This pinpoint test is intended to diagnose the following

1. Excessive toe in
2. Incorrect wheel and tire rotation

1. B1 MEASURE THE TREAD DEPTH Using a tread depth gauge or similar tool, measure the outside edge/shoulder tread depth. Is the tread depth greater than 1.58 mm (0.062 in)? YES : ROTATE the wheel and tire assemblies. CHECK and ADJUST the toe to nominal -0.15 degrees (toe out). CHECK and ADJUST caster and camber to nominal. REFER to «SUSPENSION SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/suspension-front/#suspension-system-general-information) article. NO : INSTALL a new tire(s). CHECK and ADJUST the toe to nominal. CHECK and ADJUST caster and camber to nominal. REFER to «SUSPENSION SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/suspension-front/#suspension-system-general-information) article.

Pinpoint Test C: Diagonal Wear

This pinpoint test is intended to diagnose the following

1. Incorrect wheel and tire rotation
2. Excessive toe in/out
3. Incorrect tire inflation
4. Loose, worn or damaged suspension components

1. C1 MEASURE THE TREAD DEPTH Using a tread depth gauge or similar tool, measure the tread depth of the wear pattern. Is the tread depth greater than 1.58 mm (0.062 in)? YES : If no performance concerns (noise/vibration) are present, the tire can remain in service. CHECK the air pressure in the tires, ADJUST as necessary. ROTATE the wheel and tire assemblies. INSPECT for loose, worn or damaged suspension components. INSTALL new components as necessary. CHECK the alignment and ADJUST as necessary. REFER to «SUSPENSION SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/suspension-front/#suspension-system-general-information) article. NO : INSTALL a new tire(s). CHECK the air pressure in the tires, ADJUST as necessary. ROTATE the wheel and tire assemblies. INSPECT for loose, worn or damaged suspension components. INSTALL new components as necessary. CHECK the alignment and ADJUST as necessary. REFER to «SUSPENSION SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/suspension-front/#suspension-system-general-information) article.

Component Tests

Some vehicles may exhibit a wheel and tire vibration caused by excessive runout. Runout measurements of the wheel and tire assembly can be taken both on and off the vehicle. Runout measurements can be taken both radially and laterally using a runout gauge. The runout gauge is a delicate, precision instrument and should be handled as such. The runout gauge should be mounted on a heavy solid base to eliminate gauge movement when measuring runouts. The measurements are taken using a runout gauge, which defines total runout in 64th or thousandths of an inch (depending on the brand of gauge used) and locates the high and low points of the runout.

Radial Runout

Radial runout is the egg-shaped deviation from a perfect circle and is measured perpendicular on a circumference. On a wheel and tire assembly, this usually means measuring the center tire tread rib, although other tread ribs can be measured as well. The center rib is usually a solid rib, easy to measure and normally indicative of the condition of the tire as a whole. It is important to keep in mind that any rib with excessive runout can cause a concern. Total runout is the reading from the gauge. The high spot is the location of maximum runout.

Scheme 5

Note. Warm up the tires prior to taking any measurements, this will eliminate slight flat spotting. This is done during a road test.

1. Make sure that the tire pressures are set to the correct pressure as indicated on the vehicle label.
2. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING AND LIFTING»(/ford/taurus-x/i-2007-2009/remont/hoistjack/#jacking-and-lifting) article.
3. Make sure that all 4 positions can be measured. If measurements are to be taken with the wheel and tire assembly off the vehicle, mount each assembly on a suitable dynamic balancing machine.
4. For future reference of the original wheel and tire assembly's position on the wheel hub, index-mark the wheel and a wheel stud.
5. Position the runout gauge to take a radial measurement. Rotate the wheel and tire assembly (or wheel) to locate the low spot. Adjust the runout gauge to read 0. Rotate the wheel and tire assembly (or wheel) one complete revolution to make sure that the low spot has been found and that the runout gauge dial returns to a 0 reading.
6. While slowly and constantly rotating the wheel and tire assembly (or wheel), measure the radial runout. Note the variance (runout) from 0 on the dial of the gauge. If the runout reading of a wheel and tire assembly is not within 1.27 mm (0.050 in), locate and mark the high spot and proceed to Match Mounting Step 1 to correct the concern. If the runout reading of a wheel is not within 1.27 mm (0.050 in), install a new wheel.

Lateral Runout

Lateral runout is a sideways variation causing a twist or wobble and is measured on a side surface. On the wheel and tire assembly, the lateral runout measurement should be taken as close to the tread shoulder as possible. Total runout is the reading from the gauge.

Scheme 6

1. Position the runout gauge to take a lateral measurement. Rotate the wheel and tire assembly (or wheel) to locate the low spot. Adjust the runout gauge to read 0. Rotate the wheel and tire assembly (or wheel) one complete revolution to make sure that the low spot has been found and that the dial returns to a 0 reading.
2. While slowly and constantly rotating the wheel and tire assembly (or wheel), measure the lateral runout. Note the variance (runout) from 0 on the dial of the gauge. If the runout reading of a wheel and tire assembly is not within 1.27 mm (0.050 in), locate and mark the high spot and proceed to Match Mounting Step 1 to correct the concern. If the runout reading of a wheel is not within 1.27 mm (0.050 in), install a new wheel.

Match Mounting

Match mounting is a technique used to reduce radial and lateral runouts on wheel and tire assemblies. Excessive runout is a source of ride quality complaints and match mounting can be used to minimize the runout. Match mounting can be accomplished by changing the position of the tire on the wheel or by changing the position of the wheel and tire assembly on the hub.

Tire Pressure Monitoring System

Special Tools Illustration Tool Name Tool Number Activation Tool, Tire Pressure Monitor 204-363 Digital Tire Gauge 204-354 Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 7

Principles of Operation

Note. The Smart Junction Box (SJB) is also referred to as the Generic Electronic Module (GEM).

The Tire Pressure Monitoring System (TPMS) monitors the air pressure of all 4 road tires. The wheel-mounted tire pressure sensors transmit via radio frequency signals, to the SJB. TPMS functionality is integral to the SJB. These transmissions are sent approximately every 60 seconds when the vehicle speed exceeds 32 km/h (20 mph). The TPMS function compares each tire pressure sensor transmission against a low-pressure limit. If it has been determined that the tire pressure has fallen below this limit, the SJB communicates this on the vehicle communication bus to the instrument cluster. The instrument cluster then illuminates the TPMS indicator and displays the appropriate message(s) in the message center (if equipped).

For vehicles with different front and rear tire pressures (such as the E-Series and certain F-Series), the tire pressures must be adjusted and the tire pressure sensors must be trained following a tire rotation. Failure to train the sensors will cause the TPMS indicator to illuminate.

For vehicles with the same tire pressures for front and rear tires, tire rotation will not affect the system.

Ambient Temperature Change and Tire Pressure

Tire pressures fluctuate with temperature changes. For this reason, tire pressure must be set to specification when tires are at outdoor ambient temperatures. If the vehicle is allowed to warm up to shop temperatures, and the outside temperature is less than shop temperature, the tire inflation pressure must be adjusted accordingly.

If the tires are inflated to specification at shop temperatures, and the vehicle is moved outdoors when the outdoor ambient temperature is significantly lower, the tire pressure may drop enough to be detected by the TPMS and activate the TPMS warning lamp.

As the ambient temperature decreases by 6°C (10°F), tire pressure decreases 7 kPa (1 psi). Adjust the tire pressure by 7 kPa (1 psi) for each 6°C (10°F) ambient temperature drop as necessary to keep the tire at the specified Vehicle Certification (VC) label pressure. Refer to the following tables to adjust the tire pressure indoors for colder outside temperatures.

Scheme 8

Tire Pressure Monitoring System (TPMS) Indicator and Message Center Messages

The TPMS indicator and vehicle message center (if equipped) sometimes displays faults that cannot be resolved by the customer. Treat these messages as TPMS faults that must be serviced.

Tire Pressure Monitoring System (TPMS) Indicator Illuminates Continuously

Note. If the spare tire is in use, the damaged road tire must be repaired and installed on the vehicle to restore complete TPMS functionality before carrying out any diagnosis.

Note. For vehicles with different front and rear tire pressures (such as E-Series and certain F-Series), the tire pressure sensors must be trained following a tire rotation. Failure to train the sensors will result in a false low tire pressure event, which will cause the TPMS indicator to illuminate.

1. The TPMS indicator remains on continuously for the following condition: Low Tire Pressure - The TPMS indicator is illuminated solid and the message center displays LOW TIRE PRESSURE (if equipped). This is displayed when any of the tire pressures are low. When this condition exists, the tire pressure must be adjusted to the recommended cold pressure as indicated on the VC label.
2. If the vehicle has been stationary for more than 30 minutes, carry out the «Tire Pressure Monitoring System (TPMS) Sensor Activation»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires__tire-pressure-monitoring-system-tpms-sensor) procedure.

Tire Pressure Monitoring System (TPMS) Indicator Flashes

The TPMS indicator flashes for 70 seconds, then remains ON solid when the ignition switch is turned to the ON position, for the following conditions

1. Tire Pressure Sensor Fault - If equipped, the message center will display TIRE PRESSURE SENSOR FAULT when a tire pressure sensor is malfunctioning. Go to «Symptom Chart»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .
2. No communication with the SJB (TPMS is integral to the SJB) - The TPMS indicator is illuminated when the instrument cluster has not received any signals from the SJB for more than 5 seconds. If equipped, the message center displays TIRE PRESSURE MONITOR FAULT. Go to «Symptom Chart»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .
3. Tire Pressure Monitor Fault - If equipped, the message center will display TIRE PRESSURE MONITOR FAULT when the tire pressure monitoring system is malfunctioning or communication with the instrument cluster has been lost. Go to «Symptom Chart»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .

1. Verify the customer concern by inspecting the vehicle and observing the message center (if equipped) and the TPMS indicator.
2. Inspect to determine if one of the following mechanical or electrical concerns apply: VISUAL INSPECTION CHART Mechanical Electrical Low tire pressure Tire Pressure Monitoring System (TPMS) sensor damaged or missing Spare tire installed as a road wheel Incorrect TPMS sensor installed TPMS sensor installed incorrectly Sensors not trained after a tire rotation on vehicles with different front and rear tire pressures Non-OEM wheels installed (aftermarket rims) Non-OEM equipped run-flat tires installed Other non-OEM modifications (roll cages, service barriers, part racks, ladder racks) Wiring, terminals or connectors Smart Junction Box (SJB) damaged Aftermarket electronic accessories
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
5. If the scan tool does not communicate with the VCM: check the VCM connection to the vehicle. check the scan tool connection to the VCM. refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article, No Power To The Scan Tool, to diagnose no power to the scan tool.
6. If the scan tool does not communicate with the vehicle: verify the ignition key is in the ON position. verify the scan tool operation with a known good vehicle. refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article to diagnose no response from the PCM.
7. Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article. If the network test passes, retrieve and record continuous memory DTCs.
8. Clear the continuous DTCs and carry out the self test diagnostics for the SJB (the TPMS is part of the SJB).
9. If the DTCs retrieved are related to the concern, go to the «TIRE PRESSURE MONITORING SYSTEM (TPMS) DTC TABLE»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) . For all other DTCs, refer to the Master DTC Table in «MULTIFUNCTION ELECTRONIC MODULES»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) article.
10. If no DTCs related to the concern are retrieved, go to «Symptom Chart»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .

TIRE PRESSURE MONITORING SYSTEM (TPMS) DTC TABLE

Symptom Chart

Note. For vehicles with different front and rear tire pressure (such as E-Series and certain F-Series), the tire pressures must be adjusted and the tire pressure sensors must be trained following a tire rotation. Failure to train the sensors will result in a false low tire pressure event, which will cause the Tire Pressure Monitoring System (TPMS) indicator to illuminate. For vehicles with the same tire pressure for front and rear tires, tire rotation will not affect the system. Failure of a TPMS component may not cause the message center to display a fault message or a DTC to be stored. The Symptom Chart is a starting point to begin diagnosis of these concerns.

Symptom Chart

Normal Operation

The Tire Pressure Monitoring System (TPMS) monitors the air pressure of all 4 road tires. The wheel-mounted tire pressure sensors transmit via radio frequency signals, to the Smart Junction Box (SJB). TPMS functionality is integral to the SJB. These transmissions are sent approximately every 60 seconds when the vehicle speed exceeds 32 km/h (20 mph). The TPMS function (integral to the SJB) compares each tire pressure sensor transmission against a low-pressure limit. If it has been determined that the tire pressure has fallen below this limit, the SJB communicates this on the vehicle communication bus to the instrument cluster. The instrument cluster then illuminates the TPMS indicator and displays the appropriate message(s) in the message center (if equipped).

This symptom can also be caused by a spare tire currently being used in place of a road tire. Make sure that the spare tire is not currently in use. On vehicles with different front and rear tire pressures, if the sensors are not trained following a tire rotation, this symptom will also be present. Advise the customer that on vehicles with different front and rear tire pressures, the sensors must be trained as directed in the Owner's Literature.

This pinpoint test is intended to diagnose the following

1. Low air pressure in tire(s)
2. Tire pressure sensor(s)

PINPOINT TEST D: Tire Pressure Monitoring System (TPMS) INDICATOR ON SOLID AND MESSAGE CENTER (IF EQUIPPED) DISPLAYS LOW TIRE PRESSURE

Note. Use only the Digital Tire Gauge any time tire pressures are measured to be sure that accurate values are obtained.

Note. If a warranty case is opened for an actual TPMS fault, document and include the actual tire pressure data in all warranty communications.

1. D1 CHECK THE TIRE PRESSURE Measure and record the air pressure in all 4 road tires. Adjust the air pressure for those found to be below the specification listed on the Vehicle Certification (VC) label. NOTE: If the vehicle has been stationary for more than 30 minutes, activate each TPMS sensor. Refer to «Tire Pressure Monitoring System (TPMS) Sensor Activation»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires__tire-pressure-monitoring-system-tpms-sensor) . The TPMS sensor does not transmit when the vehicle is stationary. Verify system operation. Have the TPMS indicator and the message center (if equipped) warnings gone out? YES : The system is functioning normally, diagnosis is complete. INFORM the customer of correct tire pressure maintenance as instructed in the scheduled maintenance guide and the Owner's Literature. NO : Go to D2 .
2. D2 CHECK THE SYSTEM COMPONENTS Train all 4 tire pressure sensors. Refer to «Tire Pressure Monitoring System (TPMS) Sensor Training»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires__tire-pressure-monitoring-system-tpms-sensor) . Connect the scan tool. Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DataLogger SJB Read and record the following PIDs: Left Front Tire Pressure (LF_PRES) Right Front Tire Pressure (RF_PRES) Left Rear Outer Tire Pressure (LRO_PRES) Right Rear Outer Tire Pressure (RRO_PRES) Compare the air pressure readings recorded from the function test to those recorded in D1. Do the compared tire pressure values match within ±5 psi, and have the TPMS indicator and the message center (if equipped) warnings gone out? YES : The system is functioning normally, diagnosis complete. NO : Before installing a new sensor(s): If a sensor(s) does not respond to the Tire Pressure Monitor Activation Tool, ATTEMPT to activate the same sensor(s) with the Tire Pressure Monitor Activation Tool. If the sensor(s) still does not respond, MOVE the vehicle to rotate the wheels at least one-fourth turn and ATTEMPT to activate the same sensor(s) again. INSTALL new tire pressure sensors for those with discrepancies or those that fail to activate. REFER to «Tire Pressure Monitoring System (TPMS) Sensor»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .

For the Smart Junction Box (SJB) to enter Tire Pressure Monitoring System (TPMS) sensor training mode, the SJB must receive valid inputs from the Brake Pedal Position (BPP) switch (OFF-ON-OFF) and ignition switch (both OFF and RUN), and it must receive valid vehicle speed sensor input (0 km/h [0 mph]). Refer to Tire Pressure Monitoring System (TPMS) Sensor Training in this article for the complete sensor training procedure.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Brake ON/OFF switch
3. Ignition switch
4. SJB

PINPOINT TEST E: Smart Junction Box (SJB) WILL NOT ENTER SENSOR TRAINING MODE WHEN USING THE Tire Pressure Monitoring System (TPMS) SENSOR TRAINING PROCEDURE

1. E1 CHECK THE SJB BRAKE ON/OFF (GEM_BOO) PID Connect the scan tool. Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DataLogger SJB Monitor the GEM_BOO PID (SJB reads the brake switch directly). Press and release the brake pedal while monitoring the PID. Do the brake pedal PID values match the brake pedal positions? YES : Go to E2 . NO : REFER to «EXTERIOR LIGHTING»(/ford/taurus-x/i-2007-2009/remont/exterior-lights/#exterior-lighting-system) article to continue diagnosis of the stoplamp switch.
2. E2 CHECK THE SJB IGNITION SWITCH PIDs Monitor the following ignition switch PIDs: Ignition Switch Off (IGN_O_ECU) Ignition Switch RUN (IGN_R_ECU) Cycle the ignition switch to the RUN and OFF position while monitoring the PIDs (SJB reads the ignition switch directly). Do the ignition switch status PID values match the ignition switch positions? YES : Go to E3 . NO : REFER to «STEERING COLUMN SWITCHES»(/ford/taurus-x/i-2007-2009/remont/steering-column-switches/#steering-column-switches) article to continue diagnosis of the ignition switch.
3. E3 CHECK THE SJB VEHICLE SPEED (VSS_GEM) PID Monitor the VSS_GEM PID (SJB receives vehicle speed from the instrument cluster). Does the vehicle speed PID value match the speed of the vehicle? YES : Go to E4 . NO : REFER to «INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES»(/ford/taurus-x/i-2007-2009/remont/gauges-instrument-panels/#information-center) article to diagnosis of the instrument cluster/vehicle speed concern.
4. E4 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check the connectors for: corrosion. pushed-out pins. spread terminals. Connect all the SJB connectors and make sure that they are seated correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) article. CLEAR the DTCs. REPEAT the self test. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self test.

If there is a fault with 1, 2 or 3 of the Tire Pressure Monitoring System (TPMS) sensors, DTC B2872 will be set, the TPMS warning indicator will flash for 70 seconds and then remain ON solid when the ignition switch is turned to the ON position and the message center (if equipped) will display TIRE PRESSURE SENSOR FAULT.

If the Smart Junction Box (SJB) does not get a response from all 4 of the TPMS sensors, DTC B287A will be set and the message center (if equipped) will display TIRE PRESSURE MONITOR FAULT.

1. B2872 Tire Pressure Sensor Fault - When 1, 2 or 3 of the tire pressure sensors are faulted or not responding, the SJB will set DTC B2872.
2. B287A Tire Pressure Monitor Fault - When all 4 of the tire pressure sensors are faulted, not responding or not heard by the SJB, the SJB will set DTC B287A.

This pinpoint test is intended to diagnose the following

1. TPMS sensor(s) missing
2. TPMS sensor(s) not trained to the vehicle
3. TPMS sensor(s) swapped due to wheel swap
4. TPMS sensor(s) damaged
5. Vehicle communication issue
6. SJB

PINPOINT TEST F: Tire Pressure Monitoring System (TPMS) INDICATOR FLASHES FOR 70 SECONDS AND THEN REMAINS ON SOLID WHEN THE IGNITION KEY IS TURNED TO THE ON POSITION, THE MESSAGE CENTER (IF EQUIPPED) DISPLAYS TIRE PRESSURE SENSOR OR MONITOR FAULT AND DTC B2872 OR B287A IS PRESENT

Note. If a warranty case is opened for an actual TPMS fault, document and include the actual tire pressure data in all warranty communications.

1. F1 CHECK THE SENSOR IDs AND SYSTEM STATUS PIDs Connect the scan tool. Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DataLogger SJB Read and record the following PIDs: Left Front Tire Transmitter Identifier (LF_ID) Right Front Tire Transmitter Identifier (RF_ID) Left Rear Tire Transmitter Identifier (LR_ID) Right Rear Tire Transmitter Identifier (RR_ID) Monitor the TPMS system status (TP_STAT) PID. Does the TP_STAT PID display SENSOR FAULT? YES : Go to F2 . NO : If the TP_STAT PID displays SYSTEM FAULT, go to F3 .
2. F2 CARRY OUT THE SENSOR TRAINING PROCEDURE Train all 4 tire pressure sensors. Refer to «Tire Pressure Monitoring System (TPMS) Sensor Training»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires__tire-pressure-monitoring-system-tpms-sensor) . Did all of the tire pressure sensors transmit correctly and did the horn sound when each tire pressure sensor transmitted to the SJB? YES : Using the scan tool, LOCATE the updated TPMS sensor identifiers trained to the SJB module. COMPARE these values to those recorded prior to the TPMS sensor training procedure. Disregarding sensor position, any sensor identifiers that do not match those retrieved from the module were changed, but not retrained. The sensors are now trained to the vehicle, diagnosis is complete. DOCUMENT all TPMS sensor identifiers on the applicable warranty claim. VERIFY system operation. NO : Before installing a new sensor(s) : If a sensor(s) does not respond to the Tire Pressure Monitor Activation Tool, ATTEMPT to activate the same sensor(s) with the Tire Pressure Monitor Activation Tool. If the sensor(s) still does not respond, MOVE the vehicle to rotate the wheels at least one-fourth of a turn and ATTEMPT to activate the same sensor(s) again. If the sensor(s) fails to train a second time, INSTALL a new tire pressure sensor(s). REFER to «Tire Pressure Monitoring System (TPMS) Sensor»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .
3. F3 TP_STAT PID EQUALS SYSTEM FAULT WITH DTC B287A PRESENT Train all 4 tire pressure sensors. Refer to «Tire Pressure Monitoring System (TPMS) Sensor Training»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires__tire-pressure-monitoring-system-tpms-sensor) . Did all of the tire pressure sensors transmit correctly and did the horn sound when each tire pressure sensor transmitted to the SJB? YES : Using the scan tool, LOCATE the updated TPMS sensor identifiers trained to the SJB module. COMPARE these values to those recorded prior to the TPMS sensor training procedure. Disregarding sensor position, any sensor identifiers that do not match those retrieved from the module were changed, but not retrained. The sensors are now trained to the vehicle, diagnosis is complete. DOCUMENT all TPMS sensor identifiers on the applicable warranty claim. VERIFY system operation. NO : Before diagnosing the SJB : If the sensors do not respond to the Tire Pressure Monitor Activation Tool, ATTEMPT to activate the same sensors with the Tire Pressure Monitor Activation Tool a second time. If the sensors still do not respond, MOVE the vehicle to rotate the wheels at least one-fourth of a turn and ATTEMPT to activate the same sensors again. If the sensors fail to train a second time, go to F4 .
4. F4 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB electrical connectors. Check the connectors for: corrosion. pushed-out pins. spread terminals. Connect all the SJB connectors and make sure that they are seated correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : NOTE: The sensors may not be present. DISMOUNT the tire. REFER to «Wheel and Tire»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) . VERIFY that the sensors are present and mounted to the wheels. If missing, INSTALL new sensors. If the sensors are present, INSTALL a new SJB module. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) article. CLEAR the DTCs. REPEAT the self test. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self test.

This DTC may be encountered if a sensor designed for a different application is installed. Low pressure applications utilize a black- or blue-colored sensor, while heavy duty applications utilize a green-colored sensor. The Smart Junction Box (SJB) will only allow one type of sensor to be trained using the Tire Pressure Monitoring System (TPMS) sensor training procedure. Make sure the correct sensors are used to avoid compatibility issues.

1. B106A Pressure Sensor Range Bit Incorrect State - When an attempt has been made to train a non-compatible sensor, the SJB will set DTC B106A.

This pinpoint test is intended to diagnose the following

1. Incorrect tire pressure sensor(s) installed

PINPOINT TEST G: DTC B106A - PRESSURE SENSOR RANGE BIT INCORRECT STATE

1. G1 DETERMINE IF THE VEHICLE IS EQUIPPED WITH AN INCORRECT SENSOR Train all 4 tire pressure sensors. Refer to «Tire Pressure Monitoring System (TPMS) Sensor Training»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires__tire-pressure-monitoring-system-tpms-sensor) . Did all of the tire pressure sensors transmit correctly and did the horn sound when each tire pressure sensor transmitted to the SJB? YES : CLEAR the DTCs. REPEAT the self test. VERIFY system operation. NO : Before installing a new sensor(s) : If a sensor(s) does not respond to the Tire Pressure Monitor Activation Tool, ATTEMPT to activate the same sensor(s) with the Tire Pressure Monitor Activation Tool. If the sensor(s) still does not respond, MOVE the vehicle to rotate the wheels at least one-fourth of a turn and ATTEMPT to activate the same sensor(s) again. If the sensor(s) fails to train a second time, INSTALL a new tire pressure sensor(s). REFER to «Tire Pressure Monitoring System (TPMS) Sensor»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .

If there is a fault in the Tire Pressure Monitoring System (TPMS), such as a damaged or missing sensor(s), damaged module or a communication issue within the vehicle, DTCs are set in the Smart Junction Box (SJB), the TPMS warning indicator will flash for 70 seconds and then remain ON solid when the ignition switch is turned to the ON position and the message center (if equipped) will display TIRE PRESSURE SENSOR FAULT.

The tire pressure sensor is battery powered.

This DTC may be set when attempting to train a tire pressure sensor(s) with a low battery.

This pinpoint test is intended to diagnose the following

1. Tire pressure sensor battery
2. Tire pressure sensor(s)

PINPOINT TEST H: DTC B106B - TIRE PRESSURE SENSOR LOW BATTERY

1. H1 DETERMINE WHICH SENSOR HAS A LOW BATTERY Train all 4 tire pressure sensors. Refer to «Tire Pressure Monitoring System (TPMS) Sensor Training»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires__tire-pressure-monitoring-system-tpms-sensor) . Did all of the tire pressure sensors transmit correctly and did the horn sound when each tire pressure sensor transmitted to the SJB? YES : CLEAR the DTCs. REPEAT the self test. VERIFY system operation. NO : Before installing a new sensor(s) : If a sensor(s) does not respond to the Tire Pressure Monitor Activation Tool, ATTEMPT to activate the same sensor(s) with the Tire Pressure Monitor Activation Tool. If the sensor(s) still does not respond, MOVE the vehicle to rotate the wheels at least one-fourth of a turn and ATTEMPT to activate the same sensor(s) again. If the sensor(s) fails to train a second time, INSTALL a new tire pressure sensor(s). REFER to «Tire Pressure Monitoring System (TPMS) Sensor»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .

Wheel Leaks

1. Remove the tire and wheel assembly and inspect the wheel for structural damage. If the wheel is damaged, install a new wheel.

Tire Pressure Monitoring System (TPMS) Sensor Training

Special Tools Illustration Tool Name Tool Number Activation Tool, Tire Pressure Monitor 204-363 Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Note. If the vehicle has been stationary for more than 30 minutes, the sensors will go into a "sleep mode" to conserve battery power. It will be necessary to wake them up so they will transmit the latest tire pressure information to the Smart Junction Box (SJB). For additional information, refer to Tire Pressure Monitoring System (TPMS) Sensor Activation .

Note. The tire pressure sensor training procedure must be done on a single vehicle, in an area without radio frequency noise and at least 1 m (3 ft) away from other vehicles equipped with a Tire Pressure Monitoring System (TPMS). Radio frequency noise is generated by electrical motors and appliance operation, cellular telephones, remote transmitters, power inverters and portable entertainment equipment.

Note. If a sensor does not respond to the Tire Pressure Monitor Activation Tool, attempt to activate the same sensor with the Tire Pressure Monitor Activation Tool. If the sensor still does not respond, move the vehicle to rotate the wheels at least one-fourth of a turn and attempt to activate the same sensor again.

Note. The SJB has a 2-minute time limit between sensor responses. If the SJB does not recognize any 1 of the 4 tire pressure sensors during this time limit, the horn will sound twice and the message center (if equipped) will display TIRE NOT TRAINED REPEAT and the entire procedure must be repeated.

Note. For vehicles with different front and rear tire pressures (such as the E-Series and certain F-Series), the tire pressure sensors must be trained following a tire rotation. Failure to train the sensors will cause the TPMS indicator to illuminate. For vehicles with the same tire pressure for front and rear tires, tire rotation will not affect the system.

1. Turn the ignition switch to the OFF position, then press and release the brake pedal.
2. Cycle the ignition switch from the OFF position to the RUN position 3 times, ending in the RUN position.
3. Press and release the brake pedal.
4. Turn the ignition switch to the OFF position.
5. Turn the ignition switch from the OFF position to the RUN position 3 times, ending in the RUN position. The horn will sound once and the TPMS indicator will flash if the training mode has been entered successfully. If equipped, the message center will display TRAIN LF TIRE.
6. Place the Tire Pressure Monitor Activation Tool on the LF tire sidewall opposite (180 degrees) from the valve stem. Press and release the test button on the Tire Pressure Monitor Activation Tool. The horn will sound briefly to indicate that the tire pressure sensor has been recognized by the SJB.
7. Within 2 minutes of the horn sounding, place the Tire Pressure Monitor Activation Tool on the RF tire sidewall opposite (180 degrees) from the valve stem and press and release the test button to train the RF tire pressure sensor.
8. Repeat Step 7 for the RR and LR tires. The procedure is completed after the last tire has been trained. When the training procedure is complete, the message center (if equipped) will display TIRE TRAINING COMPLETE. For vehicles not equipped with a message center, successful completion of the training procedure will be verified by turning the ignition switch to the OFF position without the horn sounding. If the horn sounds twice when the switch is turned to the OFF position, the training procedure was not successful.
9. Using the scan tool, locate the updated TPMS sensor identifiers trained to the SJB and document them on the applicable warranty claim.
10. If the sensors are being trained due to the installation of a new SJB, clear any DTCs and carry out the SJB On-Demand Self Test.

Tire Pressure Monitoring System (TPMS) Sensor Activation

Special Tools Illustration Tool Name Tool Number Activation Tool, Tire Pressure Monitor 204-363

Note. The tire pressure sensors will go into a "sleep mode" after 30 minutes of inactivity to conserve battery power. The sensors do not transmit information while in sleep mode. It will be necessary to wake them up so they will transmit the latest tire pressure information.

1. Turn the ignition switch to the ON position.
2. Position the Tire Pressure Monitor Activation Tool against the LF tire sidewall, 180 degrees from the tire valve stem.
3. Press the test button on the Tire Pressure Monitor Activation Tool to activate the sensor, activate the sensor at least 2 times.
4. Repeat Steps 2 and 3 for the remaining tires.
5. If the Tire Pressure Monitoring System (TPMS) indicator remains illuminated after adjusting and activating each sensor, refer to the Symptom Chart in Diagnosis and Testing.

Wheel and Tire

Material

Scheme 9

1. If equipped, remove the center cap or wheel cover.
2. With the weight of the vehicle on the wheels, loosen the wheel nuts.
3. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(/ford/taurus-x/i-2007-2009/remont/hoistjack/#jacking-and-lifting) article.
4. Remove the wheel nuts and the wheel and tire.
5. Use the following procedure to prevent the sticking condition from recurring once the wheels are removed. Clean the brake disc flange/hub flange and wheel bore of corrosion with a wire brush, steel wool or any other suitable material. Coat the wheel bore with a thin layer of grease. Do not apply grease to wheel hub bolt nut seats or the wheel stud.

INSTALLATION

1. To install, position the wheel and tire on the vehicle.
2. Install the wheel nuts hand-tight, then lower the vehicle. Tighten the wheel nuts to 133 Nm (98 lb-ft) in a star-pattern sequence.
3. If removed, install the center cap or wheel cover.

Special Tools Illustration Tool Name Tool Number Digital Tire Gauge 204-354

Scheme 10

DISASSEMBLY

Note. Failure to follow the instructions below may result in damage to the Tire Pressure Monitoring System (TPMS) sensor.

Note. Use only the Digital Tire Gauge any time tire pressures are measured to be sure that accurate values are obtained.

Note. A wheel and tire equipped with a Tire Pressure Monitoring System (TPMS) sensor will have the following verbiage stamped or cast on the wheel: SENSOR MAY BE INSIDE.

Note. The TPMS sensor is mounted to the wheel 180 degrees opposite of the valve stem and is held in place by a stainless steel strap. The sensor is not mounted to the valve stem.

1. Remove the wheel and tire. For additional information, refer to «Wheel and Tire»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires__wheel-and-tire) .
2. Position the wheel and tire assembly on a suitable tire machine and separate both beads of the tire from the wheel. For a paddle-type tire machine, position the valve stem at the 12 o'clock or 6 o'clock position and the paddle at the 3 o'clock position. For a roller-type tire machine, align the valve stem with the roller at any position.
3. Place the wheel and tire assembly on the turntable of the tire machine with the valve stem between the 5 o'clock and 6 o'clock positions and the machine arm at the 12 o'clock position and dismount the outer bead from the wheel.
4. Reset the wheel and tire assembly on the turntable of the tire machine with the valve stem between the 5 o'clock and 6 o'clock positions and the machine arm at the 12 o'clock position and dismount the inner bead from the wheel.
5. Inspect the TPMS sensor, cradle and strap for damage. Install new parts as necessary. For information on removal and installation of the TPMS sensor, refer to «Tire Pressure Monitoring System (TPMS) Sensor»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) . When installing a new wheel, reuse the TPMS sensor from the previous wheel if possible. The TPMS will not have to be trained if the sensor is reused. The new wheel will not come with a sensor strap. A sensor strap kit will need to be ordered with the new wheel.

ASSEMBLY

Note. Damage to the Tire Pressure Monitoring System (TPMS) sensor may result if the tire mounting is not carried out as instructed.

Scheme 11

Note. Tire pressure sensors are equipped with Lithium-ion batteries and must be disposed of accordingly.

Note. Tire pressure sensors are manufactured in multiple colors based on their application. When installing a new sensor, make sure the color of the sensor being installed matches the color of the sensor that was removed. The different colored sensors are not interchangeable.

Note. The sensor can be removed and installed without removing the strap or the cradle.

1. Remove the tire from the wheel. For additional information, refer to «Wheel and Tire»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .
2. Using a pocket screwdriver or similar tool, detach the sensor from the cradle.
3. Remove the sensor.

1. Position the sensor into the cradle by inserting the hinge end of the sensor into the hook end of the cradle and pushing the opposite end of the sensor down onto the cradle.
2. Insert a new locking clip into the sensor.
3. Install the tire onto the wheel. For additional information, refer to «Wheel and Tire»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .
4. Train the tire pressure sensor(s). For additional information, refer to «Tire Pressure Monitoring System (TPMS) Sensor Training»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires__tire-pressure-monitoring-system-tpms-sensor) .

Tire Pressure Monitoring System (TPMS) Strap and Cradle

Material

Scheme 12

Note. Tire pressure sensors are equipped with Lithium-ion batteries and must be disposed of accordingly.

Note. Tire pressure sensors are manufactured in multiple colors based on their application. When installing a new sensor, make sure the color of the sensor being installed matches the color of the sensor that was removed. The different colored sensors are not interchangeable.

Note. The sensor is available separately, the cradle and strap are available as a strap kit. There are several different strap kits available based on wheel diameter, but all strap kits share the same base part number.

1. Remove the Tire Pressure Monitoring System (TPMS) sensor. For additional information, refer to «Tire Pressure Monitoring System (TPMS) Sensor»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .
2. Remove a factory-installed strap in the following sequence: Locate the strap buckle and secure the strap to the wheel using duct tape or a similar item on both sides of the buckle, approximately 25 mm (0.98 in) from the buckle. Using a large screwdriver and a twisting motion, unbuckle the strap. Discard the strap.
3. To remove a dealer-installed strap, turn the worm gear screw until the strap is fully released from the worm gear. Discard the strap.
4. Using a screwdriver, or similar tool, remove the cradle by inserting the screwdriver under the cradle and prying up.

1. Position the sensor into the new cradle by inserting the hinge end of the sensor into the hook end of the cradle and pushing the opposite end of the sensor down onto the cradle.
2. Using wheel and tire cleaner, clean the area where the sensor and cradle are to be installed.
3. Remove the adhesive tape liner from the cradle and position the sensor and cradle into the wheel drop well 180 degrees from the valve stem.
4. Install the tapered end of the strap through the opening of the cradle on the hinge side of the sensor. This will position the worm gear on the locking clip side of the sensor.
5. Position the worm gear 13-26 mm (0.5-1.0 in) away from the sensor and tighten the worm gear. Tighten to 3 Nm (27 lb-in).
6. Install the tire onto the wheel. For additional information, refer to «Wheel and Tire»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) .
7. Train the tire pressure sensor(s). For additional information, refer to «Tire Pressure Monitoring System (TPMS) Sensor Training»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires__tire-pressure-monitoring-system-tpms-sensor) .

See also:
• SUSPENSION SYSTEM - GENERAL INFORMATION
• NOISE, VIBRATION AND HARSHNESS
• JACKING AND LIFTING
• MODULE COMMUNICATIONS NETWORK
• MULTIFUNCTION ELECTRONIC MODULES
• MODULE CONFIGURATION
• EXTERIOR LIGHTING
• STEERING COLUMN SWITCHES
• INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES
• Tire Pressure Monitoring System
• NVH
• Pinpoint Test A
• Pinpoint Test B
• Pinpoint Test C
• Wheel and Tire
• Tire Pressure Monitoring System (TPMS) Sensor Activation
• Pinpoint Test G
• Pinpoint Test H
• Pinpoint Test F
• Pinpoint Test D
• Pinpoint Test E
