Sunroof Ford Taurus X I

Sun Roof/t-Top/convertible Top 7 illustrations ~7050 words

GENERAL SPECIFICATIONS

ItemSpecification
Roof opening panel glass clearance - front edge1.0 mm to 0.0 mm (-0.04 in to 0.0 in) flush at front
Roof opening panel glass clearance - rear edge0.0 mm to 1.00 mm (0.0 to 0.04 in) flush at rear

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS TABLE

DescriptionNm
Roof opening panel frame bolt6
Roof opening panel glass screw4
Roof opening panel motor mounting screws2

TORQUE SPECIFICATIONS TABLE

Roof Opening Panel

The roof opening panel is equipped with an automatic, one-touch, express opening and closing feature. One-touch operation can be stopped at any time by pressing the roof opening panel switch a second time.

To open the roof opening panel, press and release the rear portion of the control switch. To close the roof opening panel, press and release the front portion of the control switch. To tilt the roof opening panel into the VENT position (when the glass panel is closed), press and hold the front portion of the control switch. To close the roof opening panel from the VENT position, press and hold the rear portion of the control switch until the glass panel stops moving.

When an obstacle has been detected in the roof opening panel as the sliding glass is closing, the roof opening panel will automatically open and stop at a prescribed position. To override obstacle detection, press and hold the front portion of the control switch.

The roof opening panel system consists of the following components

  1. Roof opening panel glass
  2. Roof opening panel shield (sunshade)
  3. Roof opening panel switch
  4. Roof opening panel motor and module assembly
  5. Roof opening panel trough
  6. Roof opening panel frame drain hoses
  7. Roof opening panel assembly

Special Tools Illustration Tool Name Tool Number 73III Automotive Meter 105-R0057 or equivalent

Principles of Operation

Roof Opening Panel - The roof opening panel assembly uses an integrated motor and module to operate the roof opening panel. The roof opening panel motor and module are installed new as an assembly. The roof opening panel is an electronically operated glass panel that can be opened, closed or vented by the roof opening panel switch. Actuating the switch in either a forward or rearward motion supplies a ground to the roof opening panel motor/module. The roof opening panel has an express open feature that is activated when the switch is momentarily pressed to the double detent OPEN position. This function is controlled by the roof opening panel motor/module.

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed.

Inspection and Verification

  1. Verify the customer concern by operating the system.
  2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Roof opening panel Roof opening panel frame Roof opening panel drain hoses Roof opening panel lifter assemblies Roof opening panel water trough Roof opening panel air deflector assembly Roof opening panel seal Roof opening panel shield Smart junction box (SJB) fuse(s): 19 (25A) 41 (15A) Circuitry Accessory delay relay Roof opening panel motor and module assembly Roof opening panel switch
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the concern is not visually evident, determine the symptom. Go to «Symptom Chart - Roof Opening Panel»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) or Go to «Symptom Chart - Noise, Vibration and Harshness (NVH)»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) .

Symptom Chart - Roof Opening Panel

ConditionPossible SourcesAction
The roof opening panel leaksRoof opening panel adjustment Front rail seal Drain tube attachment points Roof opening panel water trough and seal Roof opening panel drain hose Roof opening panel weatherstrip/sealsGo to Pinpoint Test B .
The roof opening panel does not open or closeRoof opening panel adjustment Fuse(s) Circuitry Roof opening panel switch Roof opening panel motor/module assembly Roof opening panel lifter assemblies Roof opening panel motor not initializedGo to Pinpoint Test E .
The roof opening panel does not open or close in VENT positionCircuitry Overhead console jumper harness Roof opening panel switch Roof opening panel motor/module assemblyGo to Pinpoint Test F .
The express open is inoperativeRoof opening panel motor not initialized Roof opening panel motor/moduleINITIALIZE the roof opening panel motor/module. REFER to Roof Opening Panel Initialization in this article. If concern is still present after initialization, INSTALL a new roof opening panel motor/module. REFER to Roof Opening Panel - Exploded View and Roof Opening Panel Motor . TEST the system for normal operation.
The roof opening panel does not stop in FLUSH from any positionIncorrect roof opening panel adjustmentREFER to Roof Opening Panel Alignment .

Symptom Chart - Roof Opening Panel

Symptom Chart - Noise, Vibration and Harshness (NVH)

Note. Noise, vibration and harshness (NVH) symptoms should be identified using the diagnostic tools that are available. For a list of these tools, an explanation of their uses and a glossary of common terms, refer to NOISE, VIBRATION AND HARSHNESS article. Since it is possible any one of multiple systems may be the cause of a symptom, it may be necessary to use a process of elimination type of diagnostic approach to pinpoint the responsible system. If this is not the causal system for the symptom, refer back to NOISE, VIBRATION AND HARSHNESS article for the next likely system and continue diagnosis.

ConditionPossible SourcesAction
The roof opening panel has excessive wind noiseIncorrect adjustment Roof opening panel weatherstrip/sealsGo to Pinpoint Test A .
The roof opening panel rattlesRoof opening panel Roof opening panel tracks Roof opening panel air deflector assembly Roof opening panel water trough Roof opening panel lifter assemblies Roof opening panel water trough guide Headliner Motor pad Rear side bracketsGo to Pinpoint Test C .
The roof opening panel is noisy during operationRoof opening panel Roof opening panel tracks Roof opening panel lifter assemblies Roof opening panel adjustment Roof opening panel motor/module assemblyGo to Pinpoint Test D .

Symptom Chart - Noise, Vibration and Harshness (NVH)

Normal Operation

When the roof opening panel glass is completely closed, it is flush with the roof panel.

This pinpoint test is intended to diagnose the following

  1. Roof opening panel adjustment
  2. Roof opening panel seal/weatherstrip
  3. Roof opening panel and motor/module

PINPOINT TEST A: THE ROOF OPENING PANEL HAS EXCESSIVE WIND NOISE

  1. A1 VERIFY ROOF OPENING PANEL NOISE Road test the vehicle with the roof opening panel in the CLOSED and OPEN positions. Is the wind noise present only in the OPEN position? YES : Go to A4 . NO : Go to A2 .
  2. A2 CHECK THE ROOF OPENING PANEL WEATHERSTRIP NOTE: Make sure the weatherstrip is secured to the glass, not cut, cracked, pinched, loose or obstructed in CLOSED, VENT and OPEN positions. Check the roof opening panel weatherstrip. Is the roof opening panel weatherstrip OK? YES : Go to A3 . NO : INSTALL a new roof opening panel weatherstrip. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) . TEST the system for normal operation.
  3. A3 CHECK ROOF OPENING PANEL ADJUSTMENT Check the roof opening panel adjustment. Is the adjustment OK? YES : CHECK for correct installation of the roof opening panel and motor/module. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) , «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Motor»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation.
  4. A4 CHECK THE AIR DEFLECTOR Make sure the air deflector is securely attached and check for damaged or unsecured springs. Is the air deflector OK? YES : PARTIALLY close the roof opening panel until the noise is eliminated. If the noise is eliminated, INFORM the customer that changing glass location will eliminate the wind noise. If the wind noise is not eliminated, READJUST panel. TEST the system for normal operation. NO : INSTALL new air deflector assembly. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Air Deflector»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.

When the roof opening panel glass is completely closed, it should be within specifications. Refer to SPECIFICATIONS .

This pinpoint test is intended to diagnose the following

  1. Roof opening panel adjustment
  2. Roof opening panel drain hose(s)
  3. Roof opening panel seal/weatherstrip
  4. Roof opening panel frame
  5. Roof opening panel trough

PINPOINT TEST B: THE ROOF OPENING PANEL LEAKS

  1. B1 CHECK THE ADJUSTMENT OF THE ROOF OPENING PANEL NOTE: Make sure the roof opening panel weatherstrip is not cracked or loose. Check the roof opening panel weatherstrip. Does the roof opening panel seal correctly? YES : Go to B2 . NO : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation.
  2. B2 CHECK THE ROOF OPENING PANEL DRAIN HOSES NOTE: Make sure the roof opening panel drain hoses are not cracked, slit, pinched or obstructed. Check the 4 roof opening panel drain hoses for correct operation. Are the roof opening panel drain hoses OK? YES : Go to B3 . NO : REPAIR or INSTALL a new roof opening panel drain hose(s). TEST the system for normal operation.
  3. B3 CHECK THE ROOF OPENING PANEL DRAIN HOSE ATTACHMENT POINTS NOTE: Make sure the roof opening panel drain hose attachment points are not damaged or obstructed. Check the roof opening panel drain hose attachment points for correct attachment. Are the roof opening panel drain hose attachment points OK? YES : Go to B4 . NO : REPAIR or INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  4. B4 CHECK THE ROOF OPENING PANEL REAR TROUGH CONDITION Check the roof opening panel rear trough for damage and make sure it is correctly attached. Is the roof opening panel trough OK? YES : Go to B5 . NO : REPAIR or INSTALL a new roof opening rear trough. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) , «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) , «Trough Assembly - Taurus, Sable»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) or «Trough Assembly - Taurus X»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  5. B5 CHECK THE CONDITION OF THE ROOF OPENING GLASS PANEL Check the roof opening panel frame for damage that may cause the roof opening panel glass seal to seat incorrectly. Is the roof opening panel frame OK? YES : INSTALL a new roof opening panel glass. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Glass»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation NO : REPAIR or INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.

When the roof opening panel glass is completely closed, it should be within specifications. Refer to SPECIFICATIONS . All components should be secured correctly.

This pinpoint test is intended to diagnose the following

  1. Roof opening panel glass
  2. Roof opening panel air deflector assembly
  3. Roof opening panel trough
  4. Roof opening panel lifter assemblies
  5. Headliner
  6. Roof opening panel motor/module pad
  7. Roof opening panel frame

PINPOINT TEST C: THE ROOF OPENING PANEL RATTLES

  1. C1 CHECK THE ROOF OPENING PANEL TIGHTNESS With the roof opening panel in the CLOSED position, manually push up and fore/aft on the glass panel. Is the roof opening panel glass loose? YES : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation. NO : Go to C2 .
  2. C2 CHECK THE ROOF OPENING PANEL TRACKS Open the roof opening panel. Check the roof opening panel tracks for obstructions and damage. Are the roof opening panel tracks OK? YES : Go to C3 . NO : REMOVE all the roof opening panel track obstructions and REPAIR the roof opening panel tracks. If the roof opening panel tracks cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  3. C3 CHECK THE ROOF OPENING PANEL WATER TROUGH AND TROUGH GUIDES Check the roof opening panel water trough and trough guides for any loose obstructions. Are the roof opening panel water trough and trough guides installed securely and free from obstructions? YES : Go to C4 . NO : REMOVE all obstructions from the roof opening panel water trough guides and install securely. INSTALL a new roof opening panel frame if the water trough guides are damaged. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  4. C4 CHECK THE ROOF OPENING PANEL SHIELD (SUNSHADE) Check the roof opening panel shield for correct installation. Is the roof opening panel shield installed correctly? YES : Go to C5 . NO : INSTALL the roof opening panel shield correctly. REFER to «Roof Opening Panel Shield»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  5. C5 CHECK THE ROOF OPENING PANEL AIR DEFLECTOR ASSEMBLY Check the roof opening panel air deflector assembly for obstructions and damage. Is the roof opening panel air deflector assembly OK? YES : Go to C6 . NO : REMOVE all obstructions and REPAIR or INSTALL a new roof opening panel air deflector assembly. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  6. C6 CHECK THE ROOF OPENING PANEL LIFTER ASSEMBLIES Verify the roof opening panel lifter assemblies are free from obstructions and damage. Are the roof opening panel lifter assemblies OK? YES : Go to C7 . NO : REMOVE all obstructions from the roof opening panel lifter assemblies and REPAIR any damage. If the roof opening panel lifter assemblies cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  7. C7 CHECK ROOF OPENING PANEL FRAME INSTALLATION Lower the headliner and check all roof opening fasteners for correct torque and verify correct installation of the roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . Is the roof opening panel correctly installed and tightened to specification? YES : Go to C8 . NO : TIGHTEN the loose fasteners or REINSTALL the roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  8. C8 CHECK THE ROOF OPENING PANEL FRAME FOR RATTLES Check the roof opening panel frame assembly for any loose parts or for any condition that will cause rattles. Is there a condition that will cause rattles? YES : INSTALL a suitable sound damper material to correct the condition. If the rattle still persists, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.

The roof opening panel operates smoothly and quietly while opening and closing.

This pinpoint test is intended to diagnose the following

  1. Roof opening panel lifter assemblies
  2. Roof opening panel adjustment
  3. Roof opening panel motor/module assembly

PINPOINT TEST D: THE ROOF OPENING PANEL IS NOISY DURING OPERATION

  1. D1 CHECK THE ROOF OPENING PANEL FOR OBSTRUCTIONS OR DAMAGE Check the roof opening panel for any obstructions and damage. Are there any obstructions and/or damage? YES : REMOVE all obstructions. REPAIR any damage. If the damage cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : Go to D2 .
  2. D2 CHECK THE ROOF OPENING PANEL OPERATION Check the roof opening panel during operation. Is the roof opening panel loose or incorrectly adjusted? YES : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation. NO : Go to D3 .
  3. D3 CHECK THE ROOF OPENING PANEL TRACKS Open the roof. Check the roof opening panel tracks for obstructions and damage. Are the roof opening panel tracks OK? YES : Go to D4 . NO : REMOVE all obstructions and REPAIR any damage. If the roof opening panel tracks cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  4. D4 CHECK THE ROOF OPENING PANEL SHIELD (SUNSHADE) Check the roof opening panel shield for correct movement. Is the roof opening panel shield moving correctly? YES : Go to D5 . NO : REMOVE and REINSTALL the roof opening panel shield. REFER to «Roof Opening Panel Shield»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  5. D5 CHECK THE ROOF OPENING PANEL LIFTER ASSEMBLIES Check the roof opening panel lifter assemblies for obstructions and damage. Are the roof opening panel lifter assemblies OK? YES : Go to D6 . NO : REMOVE all obstructions and REPAIR any damage. If the roof opening panel lifter assemblies cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) (Sunshade) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  6. D6 CHECK THE ROOF OPENING PANEL MOTOR/MODULE Remove the roof opening panel motor/module and leave the electrical connector connected. Operate the roof opening panel to the full OPEN and CLOSED position. Does the motor/module make excessive noise? YES : INSTALL a new roof opening panel motor/module. REFER to «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Motor»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : REINSTALL the roof opening panel motor/module. TEST the system for normal operation. If the roof opening panel is still noisy, INSTALL a new roof opening panel frame. «Roof Opening Panel - Exploded View»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «Roof Opening Panel Frame»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . If the roof opening panel is no longer noisy, the system is operating correctly. The concern may have been caused by an incorrectly installed roof opening panel motor.

Pinpoint Test E: The Roof Opening Panel Does Not Open or Close

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Roof Opening Panel for schematic and connector information.

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

The roof opening panel uses a integrated motor and module to operate the roof opening panel. A new roof opening panel motor/module is installed as an assembly.

The roof opening panel motor/module receives voltage from the accessory delay relay through circuit CBP41 (BU) when the key is in the ACC or RUN position and voltage at all times through circuit SBP19 (BU/RD). The roof opening panel motor/module provides ground to the roof opening panel switch through circuit CPR39 (VT/WH). When the roof opening panel switch is pressed to the CLOSE position, a ground signal is sent to the roof opening panel motor/module through circuit CPR40 (YE/OG), which causes the roof opening panel to close. When the roof opening panel switch is pressed to the OPEN position, a ground signal is sent to the roof opening panel motor/module through circuit CPR31 (VT/BN), which causes the roof opening panel to open.

  1. Fuse(s)
  2. Wiring, terminals or connectors
  3. Roof opening panel switch
  4. Roof opening panel motor/module assembly
  5. Accessory delay relay

Scheme 1

Scheme 1: PINPOINT TEST E: THE ROOF OPENING PANEL DOES NOT OPEN OR CLOSE
Scheme 1: PINPOINT TEST E: THE ROOF OPENING PANEL DOES NOT OPEN OR CLOSE

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. E1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Carry out the roof opening panel motor initialization procedure. Refer to «Roof Opening Panel Motor Initialization»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) . Is the concern still present? YES : Go to E2 . NO : The system is operating normally at this time. The roof opening panel motor was not initialized.
  2. E2 CHECK THE POWER WINDOWS Key in ON position. Verify the power windows operate. Do the power windows operate? YES : Go to E3 . NO : REFER to «GLASS, FRAMES AND MECHANISMS»(/ford/taurus-x/i-2007-2009/remont/heated-glassdefoggers/#windows-and-glass) article to diagnose the accessory delay relay circuit.
  3. E3 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch Carry out the Roof Opening Panel Switch Component Test. Refer to appropriate appropriate COMPONENT TESTING article article. Is the roof opening panel switch OK? YES : Go to E4 . NO : INSTALL a new roof opening panel switch. TEST the system for normal operation.
  4. E4 CHECK VOLTAGE TO THE ROOF OPENING PANEL MOTOR/MODULE - CIRCUITS CBP41 (BU) AND SBP19 (BU/RD) Key in OFF position. Disconnect: Roof Opening Panel Motor/Module C921 Key in ON position. Measure the voltage between roof opening panel motor/module C921-3, circuit CBP41 (BU) and C921-6, circuit SBP19 (BU/RD), harness side and ground. Are the voltages greater than 10 volts, but less than 16 volts? YES : Go to E5 . NO : VERIFY SJB fuse 19 (25A) and fuse 41 (15A) are OK. If OK, REPAIR the circuit. TEST the system for normal operation.
  5. E5 CHECK THE ROOF OPENING PANEL GROUND - CIRCUIT GD133 (BK) Key in OFF position. Measure the resistance between roof opening panel motor/module C921-1, circuit GD133 (BK), harness side and ground. Is the resistance less than 5 ohms? YES : Go to E6 . NO : REPAIR the circuit. TEST the system for normal operation.
  6. E6 CHECK CIRCUIT CPR39 (VT/WH) FOR AN OPEN Measure the resistance between overhead console C930-4, circuit CPR39 (VT/WH), and roof opening panel motor/module C921-2, circuit CPR39 (VT/WH) harness side. Is the resistance less than 5 ohms? YES : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit CPR39 (VT/WH) between the roof opening panel switch socket and overhead console C930-4. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, go to E7 . NO : REPAIR the circuit. TEST the system for normal operation.
  7. E7 CHECK CIRCUIT CPR40 (YE/OG) FOR AN OPEN Measure the resistance between overhead console C930-3, circuit CPR40 (YE/OG), and roof opening panel motor/module C921-10, circuit CPR40 (YE/OG) harness side. Is the resistance less than 5 ohms? YES : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit CPR40 (YE/OG) between the roof opening panel switch socket and overhead console C930-3. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, go to E8 . NO : REPAIR the circuit. TEST the system for normal operation.
  8. E8 CHECK CIRCUIT CPR31 (VT/BN) FOR AN OPEN Measure the resistance between overhead console C930-7, circuit CPR31 (VT/BN), and roof opening panel motor/module C921-5, circuit CPR31 (VT/BN) harness side. Is the resistance less than 5 ohms? YES : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit CPR31 (VT/BN) between the roof opening panel switch socket and overhead console C930-7. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness, and TEST the system for normal operation. If the overhead console jumper harness is OK, go to E9 . NO : REPAIR the circuit. TEST the system for normal operation.
  9. E9 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent pins. pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new roof opening panel motor/module. REFER to «Roof Opening Panel Motor»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.

Pinpoint Test F: The Roof Opening Panel Does Not Open or Close in VENT Position

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Roof Opening Panel for schematic and connector information.

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

The roof opening panel uses a integrated motor and module to operate the roof opening panel. A new roof opening panel motor/module is installed as an assembly.

The roof opening panel motor/module receives voltage from the accessory delay relay through circuit CBP41 (BU) when the key is in the ACC or RUN position. The roof opening panel motor/module provides ground to the roof opening panel switch through circuit CPR39 (VT/WH). When the roof opening panel switch is pressed to the VENT position, a ground signal is sent to the roof opening panel motor/module through circuit CPR38 (WH/BU), which causes the roof opening panel to open to the vent position. When the roof opening panel switch is pressed to the CLOSE position, a ground signal is sent to the roof opening panel motor/module through circuit CPR40 (YE/OG), which causes the roof opening panel to close.

  1. Wiring, terminals or connectors
  2. Roof opening panel switch
  3. Roof opening panel motor/module assembly

Scheme 6

Scheme 6: PINPOINT TEST F: THE ROOF OPENING PANEL DOES NOT OPEN OR CLOSE IN VENT POSITION
Scheme 6: PINPOINT TEST F: THE ROOF OPENING PANEL DOES NOT OPEN OR CLOSE IN VENT POSITION
  1. F1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Attempt to carry out the roof opening panel motor initialization procedure. Refer to «Roof Opening Panel Motor Initialization»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) . Is the concern still present, or does the roof opening panel motor fail to initialize? YES : Go to F2 . NO : The system is operating normally at this time. The roof opening panel motor was not initialized.
  2. F2 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch Carry out the Roof Opening Panel Switch Component Test. Refer to appropriate COMPONENT TESTING article. Is the roof opening panel switch OK? YES : Go to F3 . NO : INSTALL a new roof opening panel switch. TEST the system for normal operation.
  3. F3 CHECK CIRCUIT CPR38 (WH/BU) FOR AN OPEN Measure the resistance between overhead console C930-2, circuit CPR38 (WH/BU), and roof opening panel motor/module C921-4, circuit CPR38 (WH/BU) harness side. Is the resistance less than 5 ohms? YES : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit CPR38 (WH/BU) between the roof opening panel switch socket and overhead console C930-2. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, go to F4 . NO : REPAIR the circuit. TEST the system for normal operation.
  4. F4 CHECK CIRCUIT CPR40 (YE/OG) FOR AN OPEN Measure the resistance between overhead console C930-3, circuit CPR40 (YE/OG), and roof opening panel motor/module C921-10, circuit CPR40 (YE/OG) harness side. Is the resistance less than 5 ohms? YES : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit CPR40 (YE/OG) between the roof opening panel switch socket and overhead console C930-3. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, go to F5 . NO : REPAIR the circuit. TEST the system for normal operation.
  5. F5 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent pins. pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new roof opening panel motor/module. REFER to «Roof Opening Panel Motor»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.

Roof Opening Panel Manual Operation

  1. Remove the LH and RH A-pillar trim panels.
  2. Remove the LH and RH sun visor assemblies.
  3. Remove the overhead console. Open the bin and remove the screws. Disconnect the overhead console electrical connector.
  4. If equipped, disconnect the auto-dimming electrical connector from the interior rear view mirror.
  5. Pull down front of headliner to gain access to the roof opening panel motor.
  6. Insert an Allen wrench into the center of the manual drive hole. Rotate the Allen wrench counterclockwise until the roof opening panel is closed.

Timing Adjustment

Note. Any time a roof opening panel motor is removed, the cables/mechanisms can experience free-play movement. It is important that the cables do not move. They are timed to be parallel with each other. If one or both are moved in either direction, they must be re-timed.

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. For additional information, refer to Roof Opening Panel Motor Initialization .

  1. Remove the roof opening panel glass. For additional information, refer to «Roof Opening Panel Glass»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) .
  2. With the roof opening panel glass removed, position the roof opening panel to the CLOSED position.
  3. Remove the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) .
  4. Pull the trough assembly arms outward to release the trough assembly guide arm pins from the roof opening panel frame.
  5. Slide the trough assembly rearward to gain access to the alignment holes.
  6. Use a small Allen wrench or pick to confirm timing as shown. Move the affected cables by hand until the timing holes are aligned with each other. There is a hole in the lifter arm and a hole in the cable link. They will only align in one position.
  7. With the timing holes aligned, install the roof opening panel motor. Tighten the motor screws to 2 Nm (18 lb-in).
  8. Reinstall the trough assembly. For additional information, refer to «Trough Assembly - Taurus, Sable»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) or «Trough Assembly - Taurus X»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) .
  9. Reinstall the roof opening panel glass. For additional information, refer to «Roof Opening Panel Glass»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) .
  10. Initialize the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor Initialization»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .

Roof Opening Panel Alignment

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. For additional information, refer to Roof Opening Panel Motor Initialization .

  1. Position the roof opening panel to the CLOSED position.
  2. Loosen the 4 roof opening panel glass screws.
  3. Make sure the roof opening panel is centered in the roof opening. Adjust the roof opening panel glass height to specification.
  4. Tighten the roof opening panel glass screws to 4 N.m (35 lb-in).
  5. Initialize the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor Initialization»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .

Roof Opening Panel Motor Initialization

WARNINGKeep objects and body parts clear of the glass panel when carrying out the initialization procedure. During the initialization procedure, the glass panel closes with high force and cannot detect objects in its path. Failure to follow this instruction may result in serious personal injury.

Note. A new roof opening panel motor will only vent and must be initialized.

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed.

Pinpoint Test F

F2 For an existing roof opening panel motor,
F3 For a new roof opening panel motor,
  1. For an existing motor, press and hold the close switch (for approximately 10 seconds) until the roof opening panel glass moves past full VENT and suddenly back to full VENT.

Roof Opening Panel - Exploded View

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. For additional information, refer to Roof Opening Panel Motor Initialization .

Note. Roof opening panel with rear entertainment system shown, roof opening panel without rear entertainment system similar.

Scheme 7

Scheme 7: Roof Opening Panel - Exploded View
Scheme 7: Roof Opening Panel - Exploded View
ItemPart NumberDescription
1Roof opening panel glass screw (4 required)
2500A18Roof opening panel glass
3500A26Air deflector assembly
4Air deflector assembly spring
5Roof opening panel motor screw (3 required)
658689Roof opening panel motor
7Roof opening panel end cap
8519A02Roof opening panel shield
954022Trough assembly
10500A66Roof opening panel side shield (2 required)
11W702928-S303Roof opening panel frame bolt (12 required)
12502B98Roof opening panel assembly
135451884Weatherstrip
14Family entertainment system bracket
  1. For additional information, refer to the procedures in this article.

REMOVAL AND INSTALLATION

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. For additional information, refer to Roof Opening Panel Motor Initialization .

  1. Open the roof opening panel to the VENT position.
  2. Remove the 4 roof opening panel glass screws. To access the glass screws, unclip the top portion of the concertina blind and position aside as shown. To install, tighten to 4 Nm (35 lb-in) and make sure concertina blind is clipped correctly back in place.
  3. From the outside of the vehicle, remove the roof opening panel glass assembly.
  4. To install, reverse the removal procedure. Check for correct alignment of the roof opening panel. For additional information, refer to «Roof Opening Panel Alignment»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) .
  5. Initialize the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor Initialization»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .
  1. Remove the roof opening panel glass. For additional information, refer to «Roof Opening Panel Glass»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) .
  2. Slide the roof opening panel shield forward halfway.
  3. Disengage the roof opening panel shield guide feet. Lift the front portion of the roof opening panel shield upward at center until able to disengage one of the front guide feet.
  4. With one of the guide feet released, carefully rotate the roof opening panel shield in a clockwise manner to disengage the remaining guide feet.
  5. To install, reverse the removal procedure. Initialize the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor Initialization»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .

Note. Any time a roof opening panel motor is removed, the cables/mechanisms can experience free-play movement. It is important that the cables do not move. They are timed to be parallel with each other. If one or both are moved in either direction, they must be re-timed. For additional information, refer to Timing Adjustment .

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. For additional information, refer to Roof Opening Panel Motor Initialization .

  1. Remove the overhead console. Open the bin and remove the screws. Disconnect the overhead console electrical connector.
  2. Remove the roof opening panel motor screws. To install, tighten to 2 Nm (18 lb-in).
  3. Remove the roof opening panel motor.
  4. To install, reverse the removal procedure. Initialize the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor Initialization»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. For additional information, refer to Roof Opening Panel Motor Initialization .

Note. Anytime a roof opening panel motor is removed, the cables/mechanisms can experience free-play movement. It is important that the cables do not move. They are timed to be parallel with each other. If one or both are moved in either direction, they must be re-timed. For additional information, refer to Timing Adjustment .

  1. Remove the headliner. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
  2. Disconnect the 4 roof opening panel drain hoses from the corners of the roof opening panel frame.
  3. Remove the 12 roof opening panel frame bolts. To install, tighten to 6 Nm (53 lb-in).
  4. Remove the roof opening panel frame.
  5. To install, reverse the removal procedure. Initialize the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor Initialization»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .
  1. Remove the roof opening panel glass. For additional information, refer to «Roof Opening Panel Glass»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) .
  2. With roof opening glass removed, position the roof opening panel to the CLOSED position.
  3. If equipped, remove the rear entertainment system. For additional information, refer to «INFORMATION AND ENTERTAINMENT SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) article.
  4. Remove the A-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
  5. Remove the LH and RH B-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
  6. Remove the LH and RH C-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
  7. Remove the LH and RH D-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
  8. Remove the 3 assist handles.
  9. Remove the LH and RH sun visors and sun visor clips.
  10. If equipped, disconnect the interior auto-dimming electrical connector.
  11. If equipped, disconnect the compass sensor electrical connector.
  12. Partially lower the front of the headliner and disconnect the roof opening panel electrical connector.
  13. Disconnect the electrical connector located on the A-pillar. Remove the wiring harness pin-type retainers.
  14. Disconnect the electrical connector located on the LH and RH A-pillars. Remove the wiring harness pin-type retainers.
  15. Disconnect the rear window washer hose connector located on the RH A-pillar.
  16. Disconnect the rear window washer hose connector and the electrical connector located on the RH D-pillar.
  17. Disconnect the electrical connector located on the LH D-pillar.
  18. Position aside the liftgate opening weatherstrip.
  19. Remove the 3 headliner pin-type retainers from the rear of the headliner. Remove the center retaining clip, using a pushpin puller and the 2 outer clips, using a thin-blade screwdriver to depress the engagement tabs.
  20. Lower the headliner.
  21. Remove the LH and RH plastic roof opening panel end caps. From above the roof opening panel track frame, release the plastic tabs and gently pull the end cap downward to release.
  22. From inside the vehicle, carefully slide the sunshade rearward and completely out of the roof opening panel tracks.
  23. Pull the trough assembly arms outward to release the trough assembly guide arm pins from the roof opening panel frame.
  24. Carefully slide the trough assembly rearward and completely out of the roof opening panel tracks.
  25. To install, reverse the removal procedure.
  1. Remove the roof opening panel glass. For additional information, refer to «Roof Opening Panel Glass»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof) .
  2. With roof opening glass removed, position the roof opening panel to the CLOSED position.
  3. If equipped, remove the rear entertainment system. For additional information, refer to «INFORMATION AND ENTERTAINMENT SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) article.
  4. Remove the LH and RH A-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
  5. Remove the LH and RH B-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
  6. Remove the LH and RH C-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
  7. Remove the 3 assist handles.
  8. Remove the LH and RH sun visors and sun visor clips.
  9. Disconnect the roof opening panel trim ring from the roof opening panel.
  10. Disconnect the roof opening panel electrical connector.
  11. If equipped, disconnect the interior auto-dimming electrical connector.
  12. If equipped, disconnect the compass sensor electrical connector.
  13. Disconnect the electrical connector located on the A-pillar. Remove the wiring harness pin-type retainers.
  14. If equipped, disconnect the safety canopy bridge resistor electrical connector.
  15. Remove the 3 trim panel retaining clips from the rear of the headliner. Remove the center retaining clip using a pushpin puller, and the 2 outer clips using a thin-blade screwdriver to depress the engagement tabs.
  16. Lower the headliner.
  17. Remove the LH and RH plastic roof opening panel end caps. From above the roof opening panel track frame, release the plastic tabs and gently pull the end cap downward to release.
  18. From inside the vehicle, carefully slide the sunshade rearward and completely out of the roof opening panel tracks.
  19. Pull the trough assembly arms outward to release the trough assembly guide arm pins from the roof opening panel frame.
  20. Carefully slide the trough assembly rearward and completely out of the roof opening panel tracks.
  21. To install, reverse the removal procedure.
  1. Place the roof opening panel glass in the full OPEN position.
  2. From top of vehicle, depress spring steel locating tab downward on each side with flat-blade screwdriver while pushing deflector toward rear of vehicle. To install, make sure locating tabs are firmly locked in place.
  3. Tilt the air deflector upward and pull forward to remove.
  4. To install, reverse the removal procedure. Initialize the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor Initialization»(/ford/taurus-x/i-2007-2009/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .
