Rear View Mirror System Ford Taurus X I

Mirrors 40 illustrations ~8458 words

TORQUE SPECIFICATIONS TABLE

DescriptionNm
Exterior rear view mirror nuts9

TORQUE SPECIFICATIONS TABLE

Rear View Mirrors

The main components of the exterior rear view mirrors are

  1. Exterior mirror control switch
  2. Exterior mirror cover
  3. Exterior mirror glass
  4. Exterior mirror glass adjustment motors
  5. Exterior mirror plastic housing
  6. Heated exterior mirror glass (optional)
  7. LH exterior auto-dimming mirror glass (optional)
  8. Memory exterior mirrors (optional)
  9. Puddle lamps (optional)

For information on the puddle lamps, refer to EXTERIOR LIGHTING article.

Exterior Mirror

Power Exterior Mirrors - Power mirrors allow the driver or passenger mirror glass to be positioned electronically. The position of the power mirror glass is controlled by the exterior rear view mirror control switch. Adjusting the exterior rear view mirror control switch to the LH or RH position determines which power mirror glass will be controlled.

Heated Exterior Rear View Mirrors - The power exterior rear view mirrors are available with a heated mirror glass feature, which heats the mirror glass to remove frost, snow, ice and condensation. The rear window defrost switch controls the operation of the heated exterior rear view mirrors. The heated exterior rear view mirrors only operate when the heated rear window is on.

Memory Exterior Mirrors - The memory mirror function recalls the preferred positioning of the LH and RH exterior mirror glass. The preferred positioning of the exterior mirror glass is retained in the Driver Seat Module (DSM). Memory is activated by the door mounted switches or the Remote Keyless Entry (RKE) transmitter. When a memory position is recalled by the operator, the LH and RH exterior mirror glass will automatically adjust to the preferred position. The DSM is capable of setting a DTC for the memory mirror system when a system concern exists.

For information on the DSM and Memory Position Programming, refer to SEATING article.

Interior Mirror

The interior rear view mirror can be equipped with the following

  1. Interior auto-dimming rear view mirror with compass
  2. Interior auto-dimming rear view mirror (optional) with compass with microphone

Interior Auto-Dimming Rear View Mirror - The interior auto-dimming rear view mirror automatically reduces the glare caused by headlamps reflecting in the interior rear view mirror. The interior auto-dimming rear view mirror adjusts the reflectance level of the interior rear view mirror glass to eliminate unwanted glare. The reflectance level of the mirror glass is variable and depends on the amount of rear glare in relation to ambient light conditions in front of the interior mirror. When the forward sensor detects daytime conditions, the rearward sensor is inactive and the interior rear view mirror stays in a high reflectance mode. When the forward sensor detects nighttime conditions, the rearward sensor is active and detects glare from the headlights of vehicles approaching from the rear or other glare-producing light sources. To provide increased visibility when backing up, the interior rear view mirror will automatically return to a high reflectance mode whenever the vehicle is in REVERSE.

On vehicles equipped with navigation or SYNC, the interior rear view mirror will contain an integrated microphone. For microphone information or diagnostics, refer to INFORMATION AND ENTERTAINMENT SYSTEMS article.

On vehicles equipped with a compass, the interior rear view mirror will contain an integrated compass module. For compass information, calibration or diagnostics, refer to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article.

Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool 73III Automotive Meter 105-R0057 or equivalent

Scheme 1

Scheme 1: Rear View Mirrors
Scheme 1: Rear View Mirrors

Principles of Operation

Adjusting the exterior rear view mirror control switch to the LH or RH position determines which power mirror glass will be controlled.

Heated Exterior Rear View Mirror

The heated exterior rear view mirrors only operate when the heated rear window is ON. The heated rear window switch controls the operation of the heated exterior rear view mirrors. The heated rear window switch is an integral part of the HVAC electronic automatic temperature control (EATC) module or the HVAC electronic manual temperature control (EMTC). The heated exterior rear view mirror power is supplied by the heated rear window relay through a separate battery junction box (BJB) fuse that isolates the heated exterior rear view mirrors from the heated rear window system in the event of a concern.

Interior Auto-Dimming Rear View Mirror

The interior auto-dimming rear view mirror automatically reduces the glare caused by headlamps reflecting in the interior rear view mirror. The auto-dimming feature is disabled when the vehicle is in REVERSE. Power is supplied to the auto-dimming interior mirror when the ignition is in the RUN or ACC position.

The interior auto-dimming rear view mirror has 2 photoelectric sensors that detect forward and rearward light conditions. Based on these inputs, the automatic dimming feature adjusts the reflectance level of the interior rear view mirror glass to eliminate unwanted glare. The reflectance level of the mirror glass is variable and depends on the amount of rearward glare in relation to ambient light conditions in front of the interior mirror.

When the forward sensor detects daytime conditions, the rearward sensor is inactive and the interior rear view mirror stays in a high reflectance mode. When the forward sensor detects nighttime conditions, the rearward sensor is active and detects glare from the headlights of vehicles approaching from the rear or other glare-producing light sources. To provide increased visibility when backing up, the interior rear view mirror will automatically return to a high reflectance mode whenever the vehicle is in REVERSE.

If the forward or rearward sensors are blocked, the automatic dimming interior mirror might not work correctly.

Memory Exterior Mirrors

The memory mirror function recalls the preferred positioning of the exterior mirrors. Memory is activated by the door mounted switches or the remote keyless entry (RKE) transmitter. The driver seat module (DSM) constantly tracks the exterior mirror position by using the potentiometers in the exterior mirror assembly. The positions remain in memory as long as the DSM retains power. When a memory position is recalled by the operator, the DSM powers the exterior mirror motors simultaneously and monitors the potentiometer circuits. When the stored memory position is reached, the DSM removes the voltage from the motors. If the exterior mirror control switch is operated during a memory recall, the DSM stops the recall and responds to the exterior mirror control switch command.

For information on the DSM and Memory Position Programming, refer to SEATING article.

Inspection and Verification

  1. Verify the customer concern.
  2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Interior auto-dimming rear view mirror Exterior mirror Exterior mirror control switch Battery junction box (BJB) fuse(s): 49 (15A) Smart junction box (SJB) fuse(s): 12 (7.5A) 31 (10A) 41 (15A) Driver seat module (DSM) HVAC Electronic automatic temperature control (EATC) HVAC Electronic manual temperature control (EMTC) Exterior mirror Exterior mirror control switch Exterior mirror glass Exterior mirror motor Heated rear window relay Interior auto-dimming rear view mirror Loose or corroded connections Wiring harness
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the cause is not visually evident, connect the scan tool to the data link connector (DLC).
  5. If the scan tool does not communicate with the VCM: check the VCM connection to the vehicle. check the scan tool connection to the VCM. refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article, No Power To The Scan Tool, to diagnose no communication with the scan tool.
  6. If the scan tool does not communicate with the vehicle: verify the ignition key is in the ON position. verify the scan tool operation with a known good vehicle. refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article to diagnose no response from the DSM.
  7. Carry out the network test. If the scan tool responds with no communication from one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article. If the network test passes, retrieve and record the continuous memory DTCs.
  8. Clear the continuous DTCs and carry out the self-test diagnostics for the DSM.
  9. If the DTCs retrieved are related to the concern, go to the Driver Seat Module (DSM) DTC Table. For all other DTCs, refer to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) article.
  10. If no DTCs related to the concern are retrieved, go to «Symptom Chart»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) .
DTCDescriptionAction
B1667Mirror Driver Up/Down Motor StalledGo to Pinpoint Test F .
B1668Mirror Driver Right/Left Motor StalledGo to Pinpoint Test F .
B1669Mirror Passenger Up/Down Motor StalledGo to Pinpoint Test F .
B1670Mirror Passenger Right/Left Motor StalledGo to Pinpoint Test F .
B1733Mirror Driver Vertical Switch Circuit FailureGo to Pinpoint Test F .
B1737Mirror Driver Horizontal Switch Circuit FailureGo to Pinpoint Test F .
B1741Mirror Passenger Vertical Switch Circuit FailureGo to Pinpoint Test F .
B1745Mirror Passenger Horizontal Switch Circuit FailureGo to Pinpoint Test F .
B2223Mirror Driver Drive Circuit FailureGo to Pinpoint Test F .
B2224Mirror Passenger Drive Circuit FailureGo to Pinpoint Test F .
B2312Mirror Passenger Horizontal Feedback Potentiometer Circuit FailureGo to Pinpoint Test F .
B2314Mirror Passenger Horizontal Feedback Potentiometer Circuit Short to BatteryGo to Pinpoint Test F .
B2316Mirror Passenger Vertical Feedback Potentiometer Circuit FailureGo to Pinpoint Test F .
B2318Mirror Passenger Vertical Feedback Potentiometer Circuit Short to BatteryGo to Pinpoint Test F .
B2320Mirror Driver Horizontal Feedback Potentiometer Circuit FailureGo to Pinpoint Test F .
B2322Mirror Driver Horizontal Feedback Potentiometer Circuit Short to BatteryGo to Pinpoint Test F .
B2324Mirror Driver Vertical Feedback Potentiometer Circuit FailureGo to Pinpoint Test F .
B2326Mirror Driver Vertical Feedback Potentiometer Circuit Short to BatteryGo to Pinpoint Test F .
All other DTCsREFER to the Master DTC Table in MULTIFUNCTION ELECTRONIC MODULES article.

DRIVER SEAT MODULE (DSM) DTC TABLE

Symptom Chart

ConditionPossible SourcesAction
Mirror vibrates/looseExterior mirror mounting nuts looseTIGHTEN nuts to 9 N.m (80 lb-in).
NOTE: Compare the LH and RH exterior mirror glass to verify that the exterior mirror glass is loose. Mirror glass loosePRESS the center of the exterior mirror glass up, down, left and right to make sure that the exterior mirror glass is seated correctly. If the exterior mirror glass is still loose, REMOVE the exterior mirror glass and INSPECT the exterior mirror backing plate for damage. If the exterior mirror backing plate is damaged, INSTALL a new exterior mirror glass. REFER to Exterior Mirror Glass .
Aftermarket air deflector/stone shieldsIf possible, REMOVE aftermarket air deflector/stone shield, then ROAD TEST the vehicle. If concern is no longer present, ADVISE customer that aftermarket components were causing undesired vibration.
Wind noiseFoam gasket between rear view mirror and door is missing or damagedVERIFY gasket is present and in good condition. REPOSITION gasket or INSTALL a new foam gasket between rear view mirror and door frame if necessary.
Exterior mirror is not correctly fitted to the doorVERIFY that there are no gaps between the exterior mirror and the door. If necessary, LOOSEN the exterior mirror nuts and REPOSITION the exterior mirror.
Exterior mirror coverVERIFY that the exterior mirror cover is not loose or broken. INSTALL a new exterior mirror cover if necessary. REFER to Exterior Mirror Cover .
The mirrors are inoperative - puddle lampsFuse Circuitry Exterior mirrorsREFER to EXTERIOR LIGHTING article.
The mirrors are inoperative - non-memory mirrorsFuse Circuitry Exterior mirror control switchGo to Pinpoint Test A .
A single mirror is inoperative - non-memory mirrorsCircuitry Exterior mirror control switch Exterior mirror motor Exterior mirrorGo to Pinpoint Test B .
A single mirror does not function with switch logic - non-memory mirrorsCircuitry Exterior mirror control switch Exterior mirror motor Exterior mirrorGo to Pinpoint Test C .
The auto-dimming mirror does not operate correctlyObstructed rear-facing sensor Stickers, window decals, tags Non-OEM window tinting Obstructed forward-facing sensor Stickers, window decals, tags Non-OEM window tintingIf possible, REMOVE the obstruction. If the obstruction cannot be removed, go to Pinpoint Test D to TEST the auto-dimming mirror for correct function.
Light source near or inside of vehicleNone. Any light source the rear-facing sensor is exposed to can be considered glare.
Vehicle inside garage or tunnelNone. Ambient light conditions are similar to nighttime.
Fuse Circuitry Interior auto-dimming mirrorGo to Pinpoint Test D .
The heated exterior mirror is inoperativeFuse Circuitry Exterior mirror glass Exterior mirrorGo to Pinpoint Test E .
The memory mirror is inoperativeFuse Circuitry Exterior mirror control switch Exterior mirror Driver seat module (DSM)Go to Pinpoint Test F .
NOTE
Compare the LH and RH exterior mirror glass to verify that the exterior mirror glass is loose.

Symptom Chart

Pinpoint Test A: The Mirrors are Inoperative - Non-Memory Mirrors

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Mirrors for schematic and connector information.

Normal Operation

The exterior mirror control switch receives power through circuit SBP12 (GN/RD) and ground through circuit GD133 (BK). The exterior mirror control switch uses circuit CPM23 (GY) as the common circuit for both exterior mirror up/down and right/left movement.

This pinpoint test is intended to diagnose the following

  1. Fuse
  2. Wiring, terminals or connectors
  3. Exterior mirror control switch

Scheme 2

Scheme 2: PINPOINT TEST A: THE MIRRORS ARE INOPERATIVE - NON-MEMORY MIRRORS
Scheme 2: PINPOINT TEST A: THE MIRRORS ARE INOPERATIVE - NON-MEMORY MIRRORS

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. A1 CHECK FOR POWER TO THE EXTERIOR MIRROR CONTROL SWITCH - CIRCUIT SBP12 (GN/RD) Disconnect: Exterior Mirror Control Switch C527 Measure the voltage between exterior mirror control switch C527-3, circuit SBP12 (GN/RD) harness side and ground. Is the voltage greater than 10 volts? YES : Go to A2 . NO : VERIFY that smart junction box (SJB) fuse 12 (7.5A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation.
  2. A2 CHECK CIRCUIT GD133 (BK) FOR AN OPEN Measure the resistance between exterior mirror control switch C527-1, circuit GD133 (BK) harness side and ground. Is the resistance less than 5 ohms? YES : Go to A3 . NO : REPAIR the circuit. TEST the system for normal operation.
  3. A3 CHECK CIRCUIT CPM23 (GY) FOR A SHORT TO VOLTAGE Key in ON position. Measure the voltage between exterior mirror control switch C527-6, circuit CPM23 (GY) harness side and ground. Is any voltage present? YES : REPAIR the circuit. TEST the system for normal operation. NO : Go to A4 .
  4. A4 CHECK CIRCUIT CPM23 (GY) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between exterior mirror control switch C527-6, circuit CPM23 (GY) harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to A5 . NO : REPAIR the circuit. TEST the system for normal operation.
  5. A5 CHECK CIRCUIT CPM23 (GY) FOR AN OPEN Disconnect: LH Exterior Mirror C516 Measure the resistance between LH exterior mirror C516-2, circuit CPM23 (GY) harness side and exterior mirror control switch C527-6, circuit CPM23 (GY) harness side. Is the resistance less than 5 ohms? YES : INSTALL a new exterior mirror control switch. REFER to «Exterior Mirror Control Switch»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system__exterior-mirror-control-switch) . TEST the system for normal operation. NO : REPAIR the circuit. TEST system for normal operation.

Pinpoint Test B: A Single Mirror is Inoperative - Non-Memory Mirrors

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Mirrors for schematic and connector information.

Under normal operation, the exterior mirror control switch uses circuit CPM23 (GY) as the common circuit for both exterior mirror up/down and right/left movement.

This pinpoint test is intended to diagnose the following

  1. Wiring, terminals or connectors
  2. Exterior mirror control switch
  3. Exterior mirror motor
  4. Exterior mirror
  1. B1 CHECK THE LH AND RH EXTERIOR MIRRORS Operate the exterior mirrors. Does the LH exterior mirror operate? YES : Go to B2 . NO : Go to B4 .
  2. B2 CHECK THE EXTERIOR MIRROR CONTROL SWITCH Disconnect: Exterior Mirror Control Switch C527 Carry out the Exterior Mirror Control Switch Component Test. Refer to appropriate COMPONENT TESTING article article. Did the exterior mirror control switch pass the component test? YES : Go to B3 . NO : INSTALL a new exterior mirror control switch. REFER to «Exterior Mirror Control Switch»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system__exterior-mirror-control-switch) . TEST the system for normal operation.
  3. B3 CHECK CIRCUIT CPM23 (GY) FOR AN OPEN Key in OFF position. Disconnect: RH Exterior Mirror C625 Measure the resistance between exterior mirror control switch C527-6, circuit CPM23 (GY) harness side and RH exterior mirror C625-2, circuit CPM23 (GY) and the harness side. Is the resistance less than 5 ohms? YES : CHECK the RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
  4. B4 CHECK THE EXTERIOR MIRROR CONTROL SWITCH Disconnect: Exterior Mirror Control Switch C527 Carry out the Exterior Mirror Control Switch Component Test. Refer to appropriate COMPONENT TESTING article. Did the exterior mirror control switch pass the component test? YES : Go to B5 . NO : INSTALL a new exterior mirror control switch. REFER to «Exterior Mirror Control Switch»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system__exterior-mirror-control-switch) . TEST the system for normal operation.
  5. B5 CHECK CIRCUIT CPM23 (GY) FOR AN OPEN Key in OFF position. Disconnect: LH Exterior Mirror C516 Measure the resistance between exterior mirror control switch C527-6, circuit CPM23 (GY) harness side and LH exterior mirror C516-2, circuit CPM23 (GY) harness side. Is the resistance less than 5 ohms? YES : CHECK the LH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.

Pinpoint Test C: A Single Mirror Does Not Function with Switch Logic - Non-Memory Mirrors

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Mirrors for schematic and connector information.

Under normal operation, the exterior mirror control switch uses circuits CPM16 (BN/BU), CPM17 (BU/GN), CPM20 (BN/WH), CPM21 (YE/VT) or CPM23 (GY) to control the exterior mirror movement.

  1. When power is received through circuit CPM16 (BN/BU)/CPM20 (BN/WH) and ground through circuit CPM23 (GY), the LH/RH exterior mirror will operate left.
  2. When ground is received through circuit CPM16 (BN/BU)/CPM20 (BN/WH) and power through circuit CPM23 (GY), the LH/RH exterior mirror will operate right.
  3. When power is received through circuit CPM17 (BU/GN)/CPM21 (YE/VT) and ground through circuit CPM23 (GY), the LH/RH exterior mirror will operate down.
  4. When ground is received through circuit CPM17 (BU/GN)/CPM21 (YE/VT) and power through circuit CPM23 (GY), the LH/RH exterior mirror will operate up.

This pinpoint test is intended to diagnose the following

  1. Wiring, terminals or connectors
  2. Exterior mirror control switch
  3. Exterior mirror motor
  4. Exterior mirror

Scheme 7

Scheme 7: PINPOINT TEST C: A SINGLE MIRROR DOES NOT FUNCTION WITH SWITCH LOGIC - NON-MEMORY MIRRORS
Scheme 7: PINPOINT TEST C: A SINGLE MIRROR DOES NOT FUNCTION WITH SWITCH LOGIC - NON-MEMORY MIRRORS

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. C1 CHECK THE MIRROR MOVEMENT (LEFT/RIGHT) Operate the LH and RH exterior mirrors in the left and right direction. Do the exterior mirrors move left and right? YES : Go to C2 . NO : Go to C3 .
  2. C2 CHECK THE MIRROR MOVEMENT (UP/DOWN) Operate the LH and RH exterior mirrors in the up and down direction. Do the exterior mirrors move up and down? YES : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation. NO : Go to C4 .
  3. C3 CHECK THE VOLTAGE TO THE INOPERATIVE MIRROR Key in OFF position. Disconnect: Inoperative Exterior Mirror C516 or C625 NOTE: Position the exterior mirror control switch to the LH or RH mirror position. While operating the exterior mirror control switch in the right position, measure the voltage between ground and exterior mirror: (LH) C516-4, circuit CPM16 (BN/BU) harness side. (RH) C625-4, circuit CPM20 (BN/WH) harness side. Is the voltage greater than 10 volts? YES : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . TEST the system for normal operation. NO : Go to C5 .
  4. C4 CHECK THE VOLTAGE TO THE INOPERATIVE MIRROR Disconnect: Inoperative Exterior Mirror C516 or C625 NOTE: Position the exterior mirror control switch to the LH or RH mirror position. While operating the exterior mirror control switch in the up position, measure the voltage between ground and exterior mirror: (LH) C516-1, circuit CPM17 (BU/GN) harness side. (RH) C625-1, circuit CPM21 (YE/VT) harness side. Is the voltage greater than 10 volts? YES : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . TEST the system for normal operation. NO : Go to C6 .
  5. C5 CHECK CIRCUIT CPM16 (BN/BU) OR CIRCUIT CPM20 (BN/WH) FOR AN OPEN Disconnect: Exterior Mirror Control Switch C527 NOTE: LH mirror only. NOTE: RH mirror only. Measure the resistance between exterior mirror control switch C527-8, circuit CPM16 (BN/BU) harness side and LH exterior mirror C516-4, circuit CPM16 (BN/BU) harness side. Measure the resistance between exterior mirror control switch C527-7, circuit CPM20 (BN/WH) harness side and RH exterior mirror C625-4, circuit CPM20 (BN/WH) harness side. Is the resistance less than 5 ohms? YES : INSTALL a new exterior mirror control switch. REFER to «Exterior Mirror Control Switch»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system__exterior-mirror-control-switch) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
  6. C6 CHECK CIRCUIT CPM17 (BU/GN) OR CIRCUIT CPM21 (YE/VT) FOR AN OPEN Disconnect: Exterior Mirror Control Switch C527 NOTE: LH mirror only. NOTE: RH mirror only. Measure the resistance between exterior mirror control switch C527-5, circuit CPM17 (BU/GN) harness side and LH exterior mirror C516-1, circuit CPM17 (BU/GN) harness side. Measure the resistance between exterior mirror control switch C527-2, circuit CPM21 (YE/VT) harness side and RH exterior mirror C625-1, circuit CPM21 (YE/VT) harness side. Is the resistance less than 5 ohms? YES : INSTALL a new exterior mirror control switch. REFER to «Exterior Mirror Control Switch»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system__exterior-mirror-control-switch) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.

Pinpoint Test D: The Auto-Dimming Mirror Does Not Operate Correctly

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Mirrors for schematic and connector information.

The interior auto-dimming mirror receives power from circuit CBP41 (BU), or if equipped with a microphone, circuit CBP31 (BU/OG), and ground from circuit GD133 (BK). When the vehicle is placed in REVERSE, voltage is sent to circuit CLS10 (GN/BN) and the interior auto-dimming mirror will turn the dimming feature off. There are 2 photoelectric sensors: one in the front of the interior rear view mirror and one mounted on the glass side of the mirror. If the sensors are blocked, the interior auto-dimming mirror might not work correctly. Always verify both sensors are not physically blocked before attempting to diagnose auto-dimming mirror concerns.

This pinpoint test is intended to diagnose the following

  1. Fuse
  2. Wiring, terminals or connectors
  3. Interior auto-dimming mirror

Note. If the transmission range (TR) sensor is malfunctioning and the backup lamps are on all the time or do not turn on, the interior auto-dimming mirror will not darken or return to normal view.

Scheme 11

Scheme 11: PINPOINT TEST D: THE AUTO-DIMMING MIRROR DOES NOT OPERATE CORRECTLY
Scheme 11: PINPOINT TEST D: THE AUTO-DIMMING MIRROR DOES NOT OPERATE CORRECTLY

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. D1 CHECK OPERATION OF THE BACKUP LAMPS Key in ON position. Move the shift control selector through the entire range. Do the backup lamps illuminate only in REVERSE? YES : Go to D2 . NO : REFER to «EXTERIOR LIGHTING»(/ford/taurus-x/i-2007-2009/remont/exterior-lights/#exterior-lighting-system) article to diagnose the backup lamps.
  2. D2 VERIFY THE FORWARD AND REARWARD FACING SENSORS ARE NOT BLOCKED Visually verify the forward and rearward facing sensors are not blocked. Sources of blockage can include: stickers, window decals or tags. fold-down screens for TVs or DVD players. non-OEM window tinting. Were either of the sensors blocked? YES : If possible, REMOVE the blockage. TEST the system for normal operation. If it is not possible to remove the blockage, REVIEW the operation of the interior auto-dimming mirror with the customer. NO : Go to D3 .
  3. D3 CHECK OPERATION OF THE AUTO-DIMMING INTERIOR MIRROR - DAYLIGHT CONDITIONS Key in ON position. Use a bright lamp to illuminate the forward facing sensor and the rearward facing sensor. The mirror should adjust to a high reflectance mode (mirror will be clear). Did the mirror adjust to the high reflectance (clear) mode? YES : Go to D4 . NO : INSTALL a new interior auto-dimming mirror. REFER to «Auto-Dimming Interior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system__auto-dimming-interior-mirror) . TEST the system for normal operation.
  4. D4 CHECK THE OPERATION OF THE AUTO-DIMMING MIRROR - NIGHTTIME CONDITIONS WITHOUT GLARE Key in ON position. NOTE: Covering the sensor with a finger or hand is not adequate. Simulate nighttime conditions without glare: cover the forward sensor with black electrical tape or other dark material. cover the rearward facing sensor. The mirror should adjust to the high reflectance mode. Did the mirror adjust to the high reflectance (clear) mode? YES : Go to D5 . NO : Go to D7 .
  5. D5 CHECK THE OPERATION OF THE AUTO-DIMMING MIRROR - NIGHTTIME CONDITIONS WITH GLARE Key in ON position. NOTE: Covering the sensor with a finger or hand is not adequate. Simulate nighttime conditions with glare: cover the forward sensor with black electrical tape or other dark material. illuminate the rearward facing sensor. The mirror should darken to a lower reflectance mode. Did the mirror darken to a lower reflectance (darker) mode? YES : Go to D6 . NO : Go to D7 .
  6. D6 CHECK THE OPERATION OF THE AUTO-DIMMING MIRROR - NIGHTTIME CONDITIONS WITH THE VEHICLE IN REVERSE Key in ON position. NOTE: Covering the sensor with a finger or hand is not adequate. Simulate nighttime conditions with glare: cover the forward sensor with black electrical tape or other dark material. illuminate the rearward facing sensor. Select REVERSE. Did the mirror adjust to a high reflectance (clear) mode? YES : The system is operating correctly at this time. REVIEW the operation of the interior auto-dimming interior mirror with the customer. NO : Go to D7 .
  7. D7 CHECK THE INTERIOR MIRROR FOR A MICROPHONE Check the interior mirror for a microphone. Is the interior mirror equipped with a microphone? YES : Go to D8 . NO : Go to D11 .
  8. D8 CHECK CIRCUIT CBP41 (BU) FOR VOLTAGE Disconnect: Interior Auto-Dimming Mirror C9012 Measure the voltage between interior auto-dimming mirror C9012-1, circuit CBP41 (BU) harness side and ground. Is the voltage greater than 10 volts? YES : Go to D9 . NO : VERIFY that smart junction box (SJB) fuse 41 (15A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation.
  9. D9 CHECK CIRCUIT GD133 (BK) FOR AN OPEN Key in OFF position. Measure the resistance between interior auto-dimming mirror C9012-10, circuit GD133 (BK) harness side and ground. Is the resistance less than 5 ohms? YES : Go to D10 . NO : REPAIR the circuit. TEST the system for normal operation.
  10. D10 CHECK CIRCUIT CLS10 (GN/BN) FOR VOLTAGE Key in ON position. Select REVERSE. Measure the voltage between interior auto-dimming mirror C9012-3, circuit CLS10 (GN/BN) harness side and ground. Is the voltage greater than 10 volts? YES : INSTALL a new interior auto-dimming mirror. REFER to «Auto-Dimming Interior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system__auto-dimming-interior-mirror) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
  11. D11 CHECK CIRCUIT CBP31 (BU/OG) FOR VOLTAGE Disconnect: Auto-Dimming Interior Mirror C911 Measure the voltage between interior auto-dimming mirror C911-1, circuit CBP31 (BU/OG) harness side and ground. Is the voltage greater than 10 volts? YES : Go to D12 . NO : VERIFY that SJB fuse 31 (15A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation.
  12. D12 CHECK CIRCUIT GD133 (BK) FOR AN OPEN Key in OFF position. Measure the resistance between interior auto-dimming mirror C911-2, circuit GD133 (BK) harness side and ground. Is the resistance less than 5 ohms? YES : Go to D13 . NO : REPAIR the circuit. TEST the system for normal operation.
  13. D13 CHECK CIRCUIT CLS10 (GN/BN) FOR VOLTAGE Key in ON position. Select REVERSE. Measure the voltage between interior auto-dimming mirror C911-3, circuit CLS10 (GN/BN) harness side and ground. Is the voltage greater than 10 volts? YES : INSTALL a new interior auto-dimming mirror. REFER to «Auto-Dimming Interior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system__auto-dimming-interior-mirror) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.

Pinpoint Test E: The Heated Exterior Mirror is Inoperative

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Heated Windows for schematic and connector information.

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Mirrors for schematic and connector information.

When the engine is running and the heated rear window switch is pressed, the HVAC electronic automatic temperature control (EATC) or the HVAC electronic manual temperature control (EMTC) grounds circuit CH122 (WH/OG) and the heated rear window relay closes. When the heated rear window relay is closed, power is supplied to circuit CRD06 (BN/YE) to battery junction box (BJB) fuse 49 (15A). The heated exterior mirrors receive power from circuit CBB49 (VT/GY), through BJB fuse 49 (15A). Ground is supplied to the LH heated exterior mirror through circuit GD133 (BK) and to the RH heated exterior mirror through circuit GD148 (BK/YE).

This pinpoint test is intended to diagnose the following

  1. Fuse
  2. Wiring, terminals or connectors
  3. Exterior mirror glass
  4. Exterior mirror

Scheme 20

Scheme 20: PINPOINT TEST E: THE HEATED EXTERIOR MIRROR IS INOPERATIVE
Scheme 20: PINPOINT TEST E: THE HEATED EXTERIOR MIRROR IS INOPERATIVE

Scheme 21

Scheme 21
Scheme 21
  1. E1 CHECK THE OPERATION OF THE HEATED REAR WINDOW SYSTEM With the engine running, depress the heated rear window switch to the ON position. Place a hand on the heated rear window to verify that the heated rear window heats up. Does the heated rear window system operate? YES : Go to E2 . NO : REFER to «GLASS, FRAMES AND MECHANISMS»(/ford/taurus-x/i-2007-2009/remont/heated-glassdefoggers/#windows-and-glass) article to diagnose the heated rear window system.
  2. E2 CHECK THE OPERATION OF THE LH HEATED EXTERIOR MIRROR With the heated rear window switch in the ON position. Place a hand on the LH heated mirror to verify that the LH heated mirror heats up. Does the LH heated rear view mirror operate? YES : Go to E5 . NO : Go to E3 .
  3. E3 CHECK CIRCUIT CBB49 (VT/GY) FOR VOLTAGE Key in OFF position. Disconnect: LH Exterior Mirror C516 With the engine running, depress the heated rear window switch to ON. Measure the voltage between LH exterior mirror C516-6, circuit CBB49 (VT/GY) harness side and ground. Is the voltage greater than 10 volts? YES : Go to E4 . NO : VERIFY that battery junction box (BJB) fuse 49 (15A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation.
  4. E4 CHECK CIRCUIT GD133 (BK) FOR AN OPEN Key in OFF position. Measure the resistance between LH exterior mirror C516-7, circuit GD133 (BK) harness side and ground. Is the resistance less than 5 ohms? YES : CHECK the LH exterior mirror jumper harness between the vehicle harness and the exterior mirror glass for open circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror glass. REFER to «Exterior Mirror Glass»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
  5. E5 CHECK CIRCUIT CBB49 (VT/GY) FOR VOLTAGE Key in OFF position. Disconnect: RH Exterior Mirror C625 With the engine running, depress the heated rear window switch to ON. Measure the voltage between RH exterior mirror C625-6, circuit CBB49 (VT/GY) harness side and ground. Is the voltage greater than 10 volts? YES : Go to E6 . NO : REPAIR the circuit. TEST the system for normal operation.
  6. E6 CHECK CIRCUIT GD148 (BK/YE) FOR AN OPEN Measure the resistance between RH exterior mirror C625-7, circuit GD148 (BK/YE) harness side and ground. Is the resistance less than 5 ohms? YES : CHECK the RH exterior mirror jumper harness between the vehicle harness and the exterior mirror glass for open circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror glass. REFER to «Exterior Mirror Glass»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.

Pinpoint Test F: The Memory Mirror is Inoperative

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Mirrors for schematic and connector information.

The exterior mirror control switch sends input to the driver seat module (DSM) for the LH exterior mirror by switching power and ground to circuits CPM16 (BN/BU), CPM17 (BU/GN) and CPM23 (GY), and for the RH exterior mirror by switching power and ground to circuits CPM20 (BN/WH), CPM21 (YE/VT) and CPM23 (GY). The DSM will then supply the appropriate power and ground signals for the LH exterior mirror motor up/down circuits CPM26 (WH), CPM29 (GN) and left/right circuits CPM26 (WH), CPM28 (BU/BN), or the RH exterior mirror motor up/down circuits CPM31 (YE/GY), CPM34 (WH/BN) and left/right circuits CPM31 (YE/GY), CPM33 (WH/VT).

The DSM supplies the LH and RH exterior mirror feedback potentiometer reference voltage through circuit LPM30 (GY/VT) and ground through circuit RPM30 (YE). The DSM receives feedback from the LH exterior mirror feedback potentiometer through circuit (up/down) VPM35 (YE/BU) and circuit (left/right) VPM36 (BN/YE). The DSM receives feedback from the RH exterior mirror feedback potentiometer through circuit (up/down) VPM37 (BU/OG) and circuit (left/right) VPM38 (BN/GN).

DTC DescriptionFault Trigger Conditions
B1667 - Mirror Driver Up/Down Motor StalledOpen or incorrect mirror motor position reported to the DSM during On-Demand Self Test.
B1668 - Mirror Driver Right/Left Motor StalledOpen or incorrect mirror motor position reported to the DSM during On-Demand Self Test.
B1669 - Mirror Passenger Up/Down Motor StalledOpen or incorrect mirror motor position reported to the DSM during On-Demand Self Test.
B1670 - Mirror Passenger Right/Left Motor StalledOpen or incorrect mirror motor position reported to the DSM during On-Demand Self Test.
B1733 - Mirror Driver Vertical Switch Circuit FailureMirror switch failure detected by the DSM when switch is activated.
B1737 - Mirror Driver Horizontal Switch Circuit FailureMirror switch failure detected by the DSM when switch is activated.
B1741 - Mirror Passenger Vertical Switch Circuit FailureMirror switch failure detected by the DSM when switch is activated.
B1745 - Mirror Passenger Horizontal Switch Circuit FailureMirror switch failure detected by the DSM when switch is activated.
B2223 - Mirror Driver Drive Circuit FailureShort to ground or battery.
B2224 - Mirror Passenger Drive Circuit FailureShort to ground or battery.
B2312 - Mirror Passenger Horizontal Feedback Potentiometer Circuit FailureOpen or short to ground.
B2314 - Mirror Passenger Horizontal Feedback Potentiometer Circuit Short to BatteryShort to battery.
B2316 - Mirror Passenger Vertical Feedback Potentiometer Circuit FailureOpen or short to ground.
B2318 - Mirror Passenger Vertical Feedback Potentiometer Circuit Short to BatteryShort to battery.
B2320 - Mirror Driver Horizontal Feedback Potentiometer Circuit FailureOpen or short to ground.
B2322 - Mirror Driver Horizontal Feedback Potentiometer Circuit Short to BatteryShort to battery.
B2324 - Mirror Driver Vertical Feedback Potentiometer Circuit FailureOpen or short to ground.
B2326 - Mirror Driver Vertical Feedback Potentiometer Circuit Short to BatteryShort to battery.

This pinpoint test is intended to diagnose the following

  1. Fuse
  2. Wiring, terminals or connectors
  3. Exterior mirror control switch
  4. Exterior mirror
  5. DSM

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37
  1. F1 RETRIEVE THE DTCs FROM THE DRIVER SEAT MODULE (DSM) Use the recorded DSM DTCs from the continuous and on-demand self tests. Are any DTCs retrieved? YES : If DTC B1667 - If other DTCs are present diagnose them first. If no other DTCs are present, INSPECT the exterior mirror motor for foreign material, damage or a binding condition. If no condition is found, go to F11 . If DTC B1668 - If other DTCs are present diagnose them first. If no other DTCs are present, INSPECT the exterior mirror motor for foreign material, damage or a binding condition. If no condition is found, go to F12 . If DTC B1669 - If other DTCs are present diagnose them first. If no other DTCs are present, INSPECT the exterior mirror motor for foreign material, damage or a binding condition. If no condition is found, go to F13 . If DTC B1670 - If other DTCs are present diagnose them first. If no other DTCs are present, INSPECT the exterior mirror motor for foreign material, damage or a binding condition. If no condition is found, go to F14 . If DTC B1733, B1737, B1741 or B1745 - CARRY OUT the Exterior Mirror Control Switch Component Test. Refer to appropriate COMPONENT TESTING article. If the switch tests OK, go to F15 . If DTC B2223 Go to F16 . If DTC B2224 Go to F18 . If DTC B2312, B2316, B2320 or B2324, go to F20 . If DTC B2314, B2318, B2322 or B2326, go to F22 . NO : Go to F2 .
  2. F2 CHECK OPERATION OF THE MIRRORS FROM THE EXTERIOR MIRROR CONTROL SWITCH Operate the mirrors using the exterior mirror control switch. Do the mirrors operate from the exterior mirror control switch? YES : Go to F8 . NO : Go to F3 .
  3. F3 CHECK THE EXTERIOR MIRROR CONTROL SWITCH Key in OFF position. Disconnect: Exterior Mirror Control Switch C527 Carry out the Exterior Mirror Control Switch Component Test. Refer to appropriate COMPONENT TESTING article. Did the exterior mirror control switch pass the component test? YES : Go to F4 . NO : INSTALL a new exterior mirror control switch. REFER to «Exterior Mirror Control Switch»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system__exterior-mirror-control-switch) . TEST the system for normal operation.
  4. F4 CHECK FOR POWER TO THE EXTERIOR MIRROR CONTROL SWITCH - CIRCUIT SBP12 (GN/RD) Disconnect: Exterior Mirror Control Switch C527 Measure the voltage between exterior mirror control switch C527-3, circuit SBP12 (GN/RD) harness side and ground. Is the voltage greater than 10 volts? YES : Go to F5 . NO : VERIFY that smart junction box (SJB) fuse 12 (7.5A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation.
  5. F5 CHECK CIRCUIT GD133 (BK) FOR AN OPEN Measure the resistance between exterior mirror control switch C527-1, circuit GD133 (BK) harness side and ground. Is the resistance less than 5 ohms? YES : Go to F6 . NO : REPAIR the circuit. TEST the system for normal operation.
  6. F6 CHECK CIRCUIT CPM23 (GY) FOR A SHORT TO GROUND Disconnect: DSM C341d Measure the resistance between exterior mirror control switch C527-6, circuit CPM23 (GY) harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to F7 . NO : REPAIR the circuit. TEST the system for normal operation.
  7. F7 CHECK CIRCUIT CPM23 (GY) FOR AN OPEN Measure the resistance between DSM C341d-16, circuit CPM23 (GY) harness side and exterior mirror control switch C527-6, circuit CPM23 (GY) harness side. Is the resistance less than 5 ohms? YES : Go to F23 . NO : REPAIR the circuit. TEST system for normal operation.
  8. F8 CHECK CIRCUIT RPM30 (YE) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: Exterior Mirror C516 and C625 Disconnect: DSM C341d Key in ON position. Measure the voltage between DSM C341d-11, circuit RPM30 (YE) harness side and ground. Is any voltage present? YES : REPAIR the circuit. TEST the system for normal operation. NO : Go to F9 .
  9. F9 CHECK CIRCUIT LPM30 (GY/VT) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between DSM C341d-1, circuit LPM30 (GY/VT) harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to F10 . NO : REPAIR the circuit. TEST the system for normal operation.
  10. F10 CHECK CIRCUIT RPM30 (YE) AND CIRCUIT LPM30 (GY/VT) FOR AN OPEN Measure the resistance between DSM: C341d-11, circuit RPM30 (YE) harness side and LH exterior mirror C516-12, circuit RPM30 (YE) harness side. C341d-11, circuit RPM30 (YE) harness side and RH exterior mirror C625-12, circuit RPM30 (YE) harness side. C341d-1, circuit LPM30 (GY/VT) harness side and LH exterior mirror C516-10, circuit LPM30 (GY/VT) harness side. C341d-1, circuit LPM30 (GY/VT) harness side and RH exterior mirror C625-10, circuit LPM30 (GY/VT) harness side. Are the resistances less than 5 ohms? YES : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . CLEAR the DTCs. TEST the system for normal operation. NO : REPAIR the circuit(s). TEST the system for normal operation.
  11. F11 CHECK CIRCUIT CPM26 (WH) AND CIRCUIT CPM29 (GN) FOR AN OPEN Key in OFF position. Disconnect: LH Exterior Mirror C516 Disconnect: DSM C341d Measure the resistance between DSM: C341d-4, circuit CPM29 (GN) harness side and LH exterior mirror C516-1, circuit CPM29 (GN) harness side. C341d-2, circuit CPM26 (WH) harness side and LH exterior mirror C516-2, circuit CPM26 (WH) harness side. Are the resistances less than 5 ohms? YES : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . CLEAR the DTCs. TEST the system for normal operation. NO : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation.
  12. F12 CHECK CIRCUIT CPM28 (BU/BN) FOR AN OPEN Key in OFF position. Disconnect: LH Exterior Mirror C516 Disconnect: DSM C341d Measure the resistance between DSM C341d-5, circuit CPM28 (BU/BN) harness side and LH exterior mirror C516-4, circuit CPM28 (BU/BN) harness side. Is the resistances less than 5 ohms? YES : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . CLEAR the DTCs. TEST the system for normal operation. NO : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation.
  13. F13 CHECK CIRCUIT CPM31 (YE/GY) AND CIRCUIT CPM34 (WH/BN) FOR AN OPEN Key in OFF position. Disconnect: RH Exterior Mirror C625 Disconnect: DSM C341d Measure the resistance between DSM: C341d-7, circuit CPM34 (WH/BN) harness side and RH exterior mirror C625-1, circuit CPM34 (WH/BN) harness side. C341d-8, circuit CPM31 (YE/GY) harness side and RH exterior mirror C625-2, circuit CPM31 (YE/GY) harness side. Are the resistances less than 5 ohms? YES : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . CLEAR the DTCs. TEST the system for normal operation. NO : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation.
  14. F14 CHECK CIRCUIT CPM33 (WH/VT) FOR AN OPEN Key in OFF position. Disconnect: RH Exterior Mirror C625 Disconnect: DSM C341d Measure the resistance between DSM C341d-6, circuit CPM33 (WH/VT) harness side and RH exterior mirror C625-4, circuit CPM33 (WH/VT) harness side. Is the resistance less than 5 ohms? YES : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . CLEAR the DTCs. TEST the system for normal operation. NO : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation.
  15. F15 CHECK CIRCUITS CPM16 (BN/BU), CPM17 (BU/GN), CPM20 (BN/WH), CPM21 (YE/VT) AND CPM23 (GY) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: Exterior Mirror Control Switch C527 Disconnect: DSM C341d Key in ON position. Measure the voltage between ground and exterior mirror control switch: C527-2, circuit CPM21 (YE/VT) harness side. C527-5, circuit CPM17 (BU/GN) harness side. C527-6, circuit CPM23 (GY) harness side. C527-7, circuit CPM20 (BN/WH) harness side. C527-8, circuit CPM16 (BN/BU) harness side. Is any voltage present? YES : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation. NO : Go to F23 .
  16. F16 CHECK CIRCUITS CPM26 (WH), CPM28 (BU/BN) AND CPM29 (GN) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: LH Exterior Mirror C516 Disconnect: DSM C341d Key in ON position. Measure the voltage between ground and DSM: C341d-2, circuit CPM26 (WH) harness side. C341d-4, circuit CPM29 (GN) harness side. C341d-5, circuit CPM28 (BU/BN) harness side. Is any voltage present? YES : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation. NO : Go to F17 .
  17. F17 CHECK CIRCUITS CPM26 (WH), CPM28 (BU/BN) AND CPM29 (GN) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between ground and DSM: C341d-2, circuit CPM26 (WH) harness side. C341d-4, circuit CPM29 (GN) harness side. C341d-5, circuit CPM28 (BU/BN) harness side. Are the resistances greater than 10,000 ohms? YES : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . CLEAR the DTCs. TEST the system for normal operation. NO : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation.
  18. F18 CHECK CIRCUITS CPM31 (YE/GY), CPM33 (WH/VT) AND CPM34 (WH/BN) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: RH Exterior Mirror C625 Disconnect: DSM C341d Key in ON position. Measure the voltage between ground and DSM: C341d-6, circuit CPM33 (WH/VT) harness side. C341d-7, circuit CPM34 (WH/BN) harness side. C341d-8, circuit CPM31 (YE/GY) harness side. Is any voltage present? YES : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation. NO : Go to F19 .
  19. F19 CHECK CIRCUITS CPM31 (YE/GY), CPM33 (WH/VT) AND CPM34 (WH/BN) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between ground and DSM: C341d-6, circuit CPM33 (WH/VT) harness side. C341d-7, circuit CPM34 (WH/BN) harness side. C341d-8, circuit CPM31 (YE/GY) harness side. Are the resistances greater than 10,000 ohms? YES : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . CLEAR the DTCs. TEST the system for normal operation. NO : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation.
  20. F20 CHECK CIRCUITS VPM35 (YE/BU), VPM36 (BN/YE), VPM37 (BU/OG) AND VPM38 (BN/GN) FOR AN OPEN Key in OFF position. Disconnect: Exterior Mirror C516 or C625 Disconnect: DSM C341d Measure the resistance between DSM: (DTC B2312) C341d-15, circuit VPM37 (BU/OG) harness side and RH exterior mirror C625-11, circuit VPM37 (BU/OG) harness side. (DTC B2316) C341d-14, circuit VPM38 (BN/GN) harness side and RH exterior mirror C625-9, circuit VPM38 (BN/GN) harness side. (DTC B2320) C341d-12, circuit VPM36 (BN/YE) harness side and LH exterior mirror C516-9, circuit VPM36 (BN/YE) harness side. (DTC B2324) C341d-13, circuit VPM35 (YE/BU) harness side and LH exterior mirror C516-11, circuit VPM35 (YE/BU) harness side. Are the resistances less than 5 ohms? YES : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation. NO : Go to F21 .
  21. F21 CHECK CIRCUITS VPM35 (YE/BU), VPM36 (BN/YE), VPM37 (BU/OG) AND VPM38 (BN/GN) FOR A SHORT TO GROUND Measure the resistance between ground and DSM: (DTC B2312) C341d-15, circuit VPM37 (BU/OG) harness side. (DTC B2316) C341d-14, circuit VPM38 (BN/GN) harness side. (DTC B2320) C341d-13, circuit VPM35 (YE/BU) harness side. (DTC B2324) C341d-12, circuit VPM36 (BN/YE) harness side. Are the resistances greater than 10,000 ohms? YES : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation. NO : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . CLEAR the DTCs. TEST the system for normal operation.
  22. F22 CHECK CIRCUITS VPM35 (YE/BU), VPM36 (BN/YE), VPM37 (BU/OG) AND VPM38 (BN/GN) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: Exterior Mirror C516 or C625 Disconnect: DSM C341d Key in ON position. Measure the voltage between ground and DSM: (DTC B2314) C341d-15, circuit VPM37 (BU/OG) harness side. (DTC B2318) C341d-14, circuit VPM38 (BN/GN) harness side. (DTC B2322) C341d-13, circuit VPM35 (YE/BU) harness side. (DTC B2326) C341d-12, circuit VPM36 (BN/YE) harness side. Is any voltage present? YES : REPAIR the circuit(s). CLEAR the DTCs. TEST the system for normal operation. NO : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) . CLEAR the DTCs. TEST the system for normal operation.
  23. F23 CHECK THE DSM FOR CORRECT OPERATION Disconnect all DSM connectors. Check for: corrosion. pushed-out pins. Connect all DSM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) article. CLEAR the DTCs. REPEAT the self-test. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

Exterior Mirrors - Exploded View

Note. Sable and Taurus shown, Taurus X similar.

Note. RH shown, LH similar.

Scheme 38

Scheme 38: Exterior Mirrors - Exploded View
Scheme 38: Exterior Mirrors - Exploded View
ItemPart NumberDescription
1N621906Exterior mirror nut (3 required)
214630 RH/ 14631 LHExterior mirror electrical connector
317K707Exterior mirror glass
4Exterior mirror motor screw (3 required) (part of 17D696)
517D696Exterior mirror motor
617D742 RH/ 17D743 LHExterior mirror cover
717682 RH/ 17683 LHExterior mirror
  1. For additional information, refer to the procedures in this article.

REMOVAL AND INSTALLATION

Note. Do not remove the exterior mirror assembly when repairing an individual part. Individual components can be installed without removing the exterior mirror.

Note. Sable and Taurus shown, Taurus X similar.

  1. Remove the sail panel. Pull outward on the sail panel to release the retaining clips. Disconnect the electrical connector.
  2. Disconnect the exterior mirror electrical connector.
  3. Remove the 3 exterior mirror nuts. To install, tighten to 9 Nm (80 lb-in).
  4. Remove the exterior mirror.
  5. To install, reverse the removal procedure.

REMOVAL

Note. Taurus X shown, Sable and Taurus similar.

  1. Disengage the upper outboard mirror glass retaining tab. Position the exterior mirror glass to the full lower inboard position. Insert a flat-blade screwdriver between the upper outboard retaining tab and the exterior mirror glass backing plate. Twist the flat-blade screwdriver to release the retaining tab from the exterior mirror glass backing plate.
  2. Disengage the lower outboard mirror glass retaining tab. Position the exterior mirror glass to the full upper inboard position. Insert a flat-blade screwdriver between the lower outboard retaining tab and the exterior mirror glass backing plate. Twist the flat-blade screwdriver to release the retaining tab from the exterior mirror glass backing plate.
  3. Remove the exterior mirror glass from the exterior mirror motor. Gently pull the outboard side of the exterior mirror glass outward. If equipped, disconnect the electrical connectors.

INSTALLATION

  1. If equipped, connect the electrical connectors.
  2. Position the exterior mirror glass onto the exterior mirror motor.
  3. Place a hand against the back of the exterior mirror and a hand flat against the exterior mirror glass. Position the exterior mirror glass to the full lower inboard position and press the exterior mirror glass to fully seat the retaining tab onto the exterior mirror motor. Position the exterior mirror glass to the full lower outboard position and press the exterior mirror glass to fully seat the retaining tab onto the exterior mirror motor. Position the exterior mirror glass to the full upper outboard position and press the exterior mirror glass to fully seat the retaining tab onto the exterior mirror motor.

Note. Sable and Taurus shown, Taurus X similar.

  1. Remove the exterior mirror glass. For additional information, refer to «Exterior Mirror Glass»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) .
  2. Remove the 3 exterior mirror motor screws.
  3. Remove the exterior mirror motor. Disconnect the electrical connector.
  4. To install, reverse the removal procedure.

Note. Sable and Taurus shown, Taurus X similar.

  1. Remove the exterior mirror glass. For additional information, refer to «Exterior Mirror Glass»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) .
  2. Release the 4 exterior mirror cover retaining tabs.
  3. Remove the exterior mirror cover. Pull outward on the exterior mirror cover.
  4. To install, reverse the removal procedure.

Exterior Mirror Control Switch

Note. Taurus X shown, Sable and Taurus similar.

Scheme 39

Scheme 39: Exterior Mirror Control Switch
Scheme 39: Exterior Mirror Control Switch
ItemPart NumberDescription
1176709Sail panel
214631Exterior mirror control switch electrical connector
317B676Exterior mirror control switch
  1. Remove the sail panel. Disconnect the electrical connector.
  2. Depress the 2 locking tabs and remove the exterior mirror control switch.
  3. To install, reverse the removal procedure.

Auto-Dimming Interior Mirror

Special Tools Illustration Tool Name Tool Number Mirror Remover 501-D118

Scheme 40

Scheme 40: Auto-Dimming Interior Mirror
Scheme 40: Auto-Dimming Interior Mirror
ItemPart NumberDescription
1Interior auto-dimming mirror electrical connector (part of 14A005)
219A548Compass module
317700Interior auto-dimming mirror
  1. Remove the wire cover.
  2. Disconnect the electrical connector.
  3. Insert the special tool between the mirror mount and windshield bracket from the top.
  4. If equipped, separate the compass module from the mirror assembly by disengaging the compass module locking tabs.
  5. Release the mirror mount from the windshield bracket by pulling the tool and mirror down and away from the windshield.
  1. Slide the mirror mount over the windshield bracket from the top and adjust the mirror to the upward position.
  2. Quickly press the mirror assembly downward along the windshield until a click is felt. The click indicates the base is engaged to the windshield bracket.
  3. Connect the electrical connector and wire cover.
  4. If equipped, install the compass module. Check the compass zone and calibration. For additional information, refer to «INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES»(/ford/taurus-x/i-2007-2009/remont/gauges-instrument-panels/#information-center) article.
