Information System and Entertainment Systems Ford Taurus X I

TORQUE SPECIFICATIONS TABLE

TORQUE SPECIFICATIONS TABLE

Information and Entertainment System

Note. The smart junction box (SJB) is also known as the generic electronic module (GEM).

Audio Line-Up

The following audio systems are available

1. Base AM/FM/single CD 4 speakers
2. Premium AM/FM/6-CD in-dash changer with MP3 4 speakers
3. Audiophile AM/FM/6-CD in-dash changer with MP3 5 speakers (includes a subwoofer)
4. Navigation Navigation audio control module (ACM) with voice recognition Touch-screen navigation screen integral to the ACM Microphone in the inside rear view mirror for voice-activation Available with premium or Audiophile sound system

The following options are also available

1. DVD entertainment system
2. Satellite audio
3. Steering wheel controls
4. SYNC system

All vehicles are equipped with an audio input jack.

Antenna - Sedan

The antenna system consists of

1. Antenna grid (part of the rear window glass)
2. Antenna module
3. 2-piece antenna cable

The antenna receives AM and FM radio waves. The waves are sent to the ACM through the antenna cable.

The antenna uses a 2-piece coaxial cable to connect the ACM to the antenna base. The front antenna lead-in cable is connected to the ACM and has an in-line connector at the RH cowl side. The rear antenna cable is part of the wiring harness and cannot be replaced separate from the harness.

The antenna is located in the inside of the rear window glass and can be repaired, but not replaced separately from the glass. Refer to GLASS, FRAMES AND MECHANISMS article.

The satellite antenna (if equipped) consists of a roof-mounted antenna capable of receiving digital satellite audio signals. A one-piece antenna cable connects the satellite antenna to the satellite digital audio receiver system (SDARS) module.

Antenna - Wagon

The antenna system consists of

1. Antenna mast
2. Antenna base and cable
3. Antenna lead-in cable

The antenna uses a 2-piece coaxial cable to connect the ACM to the antenna base. The front antenna lead-in cable is connected to the ACM and has an in-line connector at the RH cowl side. The rear antenna cable is part of the wiring harness and cannot be replaced separate from the harness.

If the vehicle is equipped with satellite audio, a combination AM/FM/satellite radio antenna is used. It is mounted on the roof.

Speakers

All vehicles are equipped with 4 door-mounted speakers. The optional subwoofer is mounted either on the parcel shelf (Sedan) or in the right rear quarter panel (Wagon).

Navigation System

The navigation system is integral to the ACM. The navigation ACM controls the operation of the navigation system and the audio system. The system uses a GPS antenna, a vehicle speed input, and other sensor information to accurately establish the vehicle position. The navigation ACM provides the visual and audible instructions of the maneuvers required to arrive at the pre-entered destination. An audible switch feedback is provided to confirm if an ACM button or touch screen button is pressed.

The voice recognition system allows the user to interface with the system without using the touch screen. A microphone located in the interior rear view mirror provides a direct input to the ACM.

Satellite Audio

The satellite audio system is comprised of the following

1. Satellite digital audio receiver system (SDARS) module, located behind the RH quarter trim panel (Wagon) or in the LH side of the luggage compartment (Sedan)
2. Satellite radio antenna cable
3. Satellite radio antenna

DVD Entertainment System

The DVD entertainment system includes the following

1. Rear entertainment module (RETM)
2. A/V ports for connecting a gaming system
3. 2 wireless headphones
4. A wireless remote control

SYNC System

The SYNC system is comprised of the following

1. Accessory protocol interface module (APIM), located in the center console
2. SYNC-specific steering wheel controls
3. Microphone located in the rear view mirror
4. Universal serial bus (USB) port, located in the center console
5. Audio input jack, located in the center console

SYNC is a hands-free communications and entertainment system that allow the following interactions

1. Send and receive phone calls via a Bluetooth®-enabled phone
2. Send and receive text messages via a Bluetooth®-enabled phone
3. Connect media devices (such as an iPod® or USB flash device) in order to play audio files
4. Play audio files via a Bluetooth®-enabled audio device

Not all features will be available with every phone.

For audio system operation, including the SYNC system, refer to the Owner's Literature.

Special Tools Illustration Tool Name Tool Number 73III Automotive Meter 105-R0057 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Flex Probe Kit 105-R025C or equivalent Universal Serial Bus (USB) Male-A To Male-A Cable CCMUSB2-AM-AM-10

Scheme 1

Scheme 2

Scheme 3

Principles of Operation

Note. The smart junction box (SJB) is also known as the generic electronic module (GEM).

Audio Control Module (ACM)

The audio system can be operated while the key is in RUN or ACC. The accessory delay feature allows the audio system to be operated for a preset period of time after the key is moved to OFF and a front door has not been opened. The audio control module (ACM) sends AC voltage audio signals to the speakers or to the amplifier, depending on vehicle configuration. The ACM can produce its own DTCs, which can be communicated to the scan tool through the medium speed controller area network (MS-CAN), or can be retrieved through the ACM self-test by simultaneously pressing presets 3 and 6. The ACM communicates via the MS-CAN.

The navigation module is integrated into the ACM and controls the operation and the interface between the user, the vehicle subsystems, and the external components. The navigation module is on the MS-CAN and can be diagnosed with a scan tool.

The vehicle navigation system guides the user to a pre-entered destination. A navigation map DVD stored in the navigation module sends route calculation data to the ACM. The ACM audibly and visually instructs the user of the maneuvers required to arrive at the destination entered.

In order to calculate the initial vehicle position, the global positioning system (GPS) antenna is used to track several available satellites simultaneously. The GPS antenna only receives data and does not communicate with the satellites. A gyroscope, integral to the navigation module, monitors the pitch and yaw of the vehicle created during cornering or turning. Vehicle speed and reverse signals received through the MS-CAN are also used to detect vehicle speed and direction changes.

Noise Suppression Equipment

The radio frequency suppression equipment reduces interference transmitted through the speakers by the engine ignition and electrical systems. When installing any new radio suppression equipment components, make sure that a good contact is made at all connections.

The satellite audio system consists of a satellite digital audio receiver system (SDARS) module, a satellite radio antenna, and an antenna cable. The satellite radio antenna receives digital audio signals and sends them to the SDARS module, where the signals are converted and sent to the ACM, the rear entertainment module (RETM) (if equipped with the DVD entertainment system but not the SYNC system), or the accessory protocol interface module (APIM) (if equipped with the SYNC system). The SDARS module communicates via the MS-CAN.

Antenna - AM/FM

For sedans, the combination AM/FM antenna is located on the rear window glass. An antenna isolator module is used to reduce interference from the rear window defroster. The audio signals are sent to the ACM via a coaxial cable. The AM/FM antenna cannot be replaced separately from the rear window glass.

For wagons, a fixed-mast AM/FM antenna is used, rather than an in-glass antenna.

Antenna - Satellite Radio

The satellite radio antenna is located on the roof of the vehicle. The antenna receives digital audio signals and sends them to the SDARS module through the satellite radio antenna cable. For sedans, a dedicated satellite radio antenna is used. For wagons, a combination AM/FM/satellite radio antenna is used.

Subwoofer

The Audiophile system is equipped with a subwoofer and subwoofer amplifier. The ACM controls the subwoofer amplifier through the enable/clip detection circuit. The enable/clip detection circuit carries out 2 functions: to turn the amplifier on, and to indicate to the ACM when the subwoofer output distortion signal reaches a damaging level. The ACM then clips the audio output signal to prevent damage to the subwoofer.

The DVD entertainment system utilizes a RETM, mounted to the headliner, which provides video playback on a screen when a video DVD is played. The audio signals to the rear speakers are routed from the ACM through the RETM. The wake-up signal for the RETM is sent from the ACM through the MS-CAN.

Single-Play Mode

In single-play mode, any audio input routed through the RETM is broadcast through all of the vehicle speakers. These audio inputs include the RETM, satellite audio, SYNC audio, and peripheral gaming devices plugged into the RETM.

Dual-Play Mode

In dual-play mode, the ACM continues to control the output to the front speakers, while the RETM mutes the audio to the rear speakers. The RETM continues to broadcast the rear audio source to the headphones. When the headphones are set to channel A, all audio sources can be accessed. When the headphones are set to channel B, only the DVD audio and auxiliary audio sources (such as a gaming system) can be sent to the headphones.

The SYNC system allows interaction with several types of customer devices, including mobile phones and media devices. The system is comprised of the APIM, a microphone (located in the interior rear view mirror), the universal serial bus (USB) cable and port, and the audio input jack. The APIM contains an on-board Bluetooth® chipset, which enables certain wireless devices to interact with the system.

The APIM consists of 2 internal modules: the consumer interface processor (CIP) and the vehicle interface processor (VIP). The modules are not replaceable individually, but can be flashed independently, if required.

The CIP interfaces with all of the inputs to the APIM. The CIP contains an analog-to-digital-to-analog converter, as well as the Bluetooth® chipset. Any consumer-available application upgrades that are available are loaded directly to the CIP through the USB port.

The VIP provides an interface between the CIP and the vehicle. The main functions of the VIP are controlling the APIM power management and translating both inbound and outbound signals over the controller are network (CAN).

The APIM can receive inputs from the following audio sources

1. USB port
2. Audio input jack
3. SDARS module
4. Bluetooth®

The USB port can be used for connecting a media device (such as an iPod®) with the device's available cable, or for directly plugging in a portable mass storage device (such as a "thumb drive"). When playing media files stored on a mass storage device, the SYNC system will only play files that do not have digital rights management (DRM) protection. The USB port can also be used for uploading vehicle application upgrades.

The USB port is powered by the APIM, so no external power source is needed to power a device plugged into the USB port if the device supports this feature.

The audio input jack can be used for connecting a media device (such as an iPod®) utilizing a 1/8-inch audio jack. When a device is connected through the audio input jack, only the speaker volume can be controlled by the ACM. All other functions (such as seek, fast forward, pause, etc.) must be carried out on the device itself.

If the vehicle is equipped with satellite audio, the audio signals from the SDARS module are sent to the APIM, rather than directly to the ACM. The APIM then relays the satellite audio signals to the ACM.

The Bluetooth® interface can accommodate both Bluetooth®-enabled mobile phones and Bluetooth®-enabled media devices. Any Bluetooth® device used with the SYNC system must first be paired with the system before it is operational.

Bluetooth® is a secure, short-range radio frequency that allows devices to communicate wirelessly through radio waves. The operating range of a Bluetooth® signal is a maximum of 32 feet.

Only one Bluetooth® phone and one Bluetooth® device can be connected to the system at any one time. If an additional device of either type is paired with the system and made active, the APIM will disconnect any active connection and establish a connection with the new device.

It is important to understand that not all mobile phones will have the same level of features when interacting with the SYNC system.

In addition to audio information, metadata may also be sent to the APIM from a device plugged into the USB port. Metadata consists of such information as artist, album title, song title, and genre. The metadata is used by the APIM to create indexes that can be used to sort for particular music, based on customer preference. Not all USB devices will send metadata to the APIM; also, no metadata is transferred when a device is connected through the audio input jack. When a new media device is connected to the SYNC system, the APIM will automatically index the information. This may take up to several minutes (depending on the amount of data on the device), and is considered normal operation. When a device that was previously connected to the SYNC system is reconnected, the APIM will update the index (rather than creating a new one), which reduces the amount of time needed to create the index.

The APIM receives both stereo and mono sound inputs, and can also transmit both stereo and mono sound. The mono function is used to receive the microphone input, and to send sound to the ACM for voice prompts, the text-to-speech (TTS) feature, ring tones, and any audio received through a connected mobile phone. The TTS feature speaks information so that it does not have to be read from the display.

The APIM communicates via the MS-CAN.

Voice Recognition For Vehicles With Navigation And The SYNC System

When a vehicle is equipped with both the navigation system and the SYNC system, the interaction between the audio system components is unique for voice recognition.

Both the navigation ACM and the APIM utilize voice-recognition, but in order for the modules to determine which one should be acknowledging the voice command, the voice command set is different. This allows the modules to identify the intended source when the VOICE button is pressed. The VOICE (an icon of someone speaking) and PHONE (an icon of a phone and an up-and-down arrow) buttons are wired to the navigation ACM, rather than to the APIM (as they are in non-navigation audio systems).

When the audio system enters voice recognition mode, the ACM sends a CAN message to the APIM to enter voice recognition mode. The microphone is wired directly to the APIM, which relays the microphone input to the ACM through dedicated wiring. Control of the voice functions is given to whichever module is indicated by the first voice command.

Steering Wheel Controls

The steering wheel controls consist of a series of resistors. Each steering wheel control switch function corresponds with a specific resistance value within the switch. When a switch is pressed, the ACM (or the APIM) monitors the change in reference voltage to determine the requested function.

Audio Input Jack - Vehicles Without The SYNC System

The audio input jack allows for a portable MP3 player to be connected to the vehicle audio system. When a portable MP3 player is connected, audio from the MP3 player can be played through the vehicle speakers.

Audio Signals

Audio signal flow varies greatly depending on vehicle content.

Stereo signals contain left and right channel information, and are used for most audio signals.

A mono signal is used for the microphone input to the APIM. The mono signal is also used for the voice prompts, the TTS feature, ring tones, and any audio received through a connected mobile phone. These audio signals are output from the APIM to the ACM. The mono and stereo outputs from the APIM utilize separate circuits.

A digital signal is used to transmit data from a media device connected through the USB port to the APIM. The APIM then converts the signal to analog and relays the signal to the ACM.

A wireless signal is used to broadcast audio signals from a Bluetooth® device to the APIM. As with a digital signal sent through the USB port, the APIM converts the wireless audio signal to analog and relays it to the ACM.

Network Communication

The following audio system components communicate via the medium speed controller area network (MS-CAN)

1. Audio control module (ACM)
2. Navigation ACM
3. Satellite digital audio receiver system (SDARS) module
4. Rear entertainment module (RETM)
5. Accessory protocol interface module (APIM)

The following messages are utilized by the audio system

AUDIO SYSTEM

Inspection and Verification

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Audio control module (ACM) Antenna Audio input jack Speaker(s) Steering wheel controls Universal serial bus (USB) port Navigation map DVD Noise suppression equipment Smart junction box (SJB) fuse(s): 3 (15A) (satellite digital audio receiver system [SDARS] module, rear entertainment module [RETM], and accessory protocol interface module [APIM] hot at all times) 28 (5A) (ACM hot in START) 38 (20A) (subwoofer amplifier hot at all times) 39 (20A) (ACM hot at all times) 41 (15A) (accessory delay feed) Wiring, terminals or connectors
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the cause is not visually evident, connect the scan tool to the data link connector (DLC).
5. If the scan tool does not communicate with the VCM: Check the VCM connection to the vehicle. Check the scan tool connection to the VCM. Refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article, No Power To The Scan Tool, to diagnose no communication with the scan tool.
6. If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article to diagnose no response from the PCM.
7. Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article. If the network test passes, retrieve and record the continuous memory DTCs.
8. Clear the continuous DTCs and carry out the self-test diagnostics for the ACM.
9. If the DTCs retrieved are related to the concern, go to «DTC Tables»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__dtc-tables) .
10. If no DTCs related to the concern are retrieved, go to the Speaker Walk-Around Test (All Audio Systems Except Navigation), the Audio Control Module (ACM) Self-Diagnostic Mode (All Audio Systems Except Navigation), the Audio Control Module (ACM) Self-Diagnostic Mode - Navigation, or the Satellite Audio Bezel Diagnostic Test.

Speaker Walk-Around Test (All Audio Systems Except Navigation)

Note. To enter the speaker walk-around test or ACM self-diagnostic mode, the ACM must be on and in radio tuner (AM/FM) mode.

1. To enter the speaker walk-around test, simultaneously press the ACM preset buttons 3 and 6.
2. The speaker walk-around test stops at each speaker and applies sound to each speaker for about 1-2 seconds. Each speaker is tested and displayed on the ACM in the following sequence: RF, LF, LR, RR, and SUBWOOFER.
3. To exit the speaker walk-around test, turn the key to OFF, turn the ACM off, or press preset button 1 for diagnostics (DIA).

Audio Control Module (ACM) Self-Diagnostic Mode - All ACMs Without Navigation

Note. To enter the ACM self-diagnostic mode, the ACM must be turned on and in radio tuner (AM/FM) mode.

1. To enter the following tests, press the desired preset button while in the speaker walk-around test or while in the ACM self-diagnostic mode.
2. The self-diagnostic mode has the following functions available: Preset button 1 = On-Demand Self-Test. This button runs the on-demand self-test. Pressing the MENU DOWN button allows scrolling of any DTCs found during the test while in this menu. Preset button 2 = Display Continuous DTCs. This button enables viewing of any continuous DTCs that have been logged. Pressing the MENU UP button allows scrolling of any DTCs while in this menu. While continuous DTCs are being displayed, pressing the EJECT button will clear all present DTCs. The key must be cycled OFF, then ON, to permanently clear DTCs. For steering wheel control switch DTCs, any steering wheel control switch must be pressed prior to pressing EJECT. Preset button 3 = Signal Strength Test. This button displays the signal strength. Preset button 4 = Software Version Display. This button displays the ACM software version. Pressing the MENU UP button allows scrolling of all audio subsystem software versions while in this menu. Preset button 5 = Display Test. This test illuminates all the display segments for 5 seconds, then either turns all segments off or indicates DISPLAY TEST on the screen. Preset button 6 = Configuration Status. This button enables ACM configuration status. Pressing the MENU button displays the ACM part number while in this menu.
3. To exit the self-diagnostic mode, turn the ACM off or turn the key to OFF.
4. If the concern remains and the fault is not detected, go to «Symptom Chart»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) to continue diagnostics.

Audio Control Module (ACM) Self-Diagnostic Mode - Navigation ACM

The navigation system provides internal self-diagnostics to assist with diagnosing vehicle concerns.

Press and hold preset buttons 3 and 6 simultaneously for 3 seconds.

Press the End Test button on the screen to exit the speaker walk test.

Scheme 4

The following diagnostics are available using the on-screen buttons as follows

Scheme 5

1. On Demand Self Test: provides internal self-test diagnostics and displays all the DTCs resulting from the self-test.
2. View DTC's: provides a list of all the DTCs currently stored in memory.
3. Configuration Status: displays the current ACM configuration.
4. System Info: displays the navigation ACM part number and software information.
5. GPS Info: provides satellite and current vehicle information.
6. Speaker Walk Test: carries out a speaker walk-around test.
7. Multi-disc Test: checks the status of the CD player mechanism.
8. Display Test: allows the screen colors to be checked, and allows testing of individual display screen touch sectors.
9. Hardkey Test: provides the status (active/not active) of the ACM buttons and touch screen.
10. Radio Signal Strength: carries out a test of the antenna signal.
11. Exit Diagnostics: exits diagnostics and returns to the main navigation screen.

1. If the concern remains and the fault is not detected, go to «Symptom Chart - Navigation»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) to continue diagnostics.

Satellite Audio Bezel Diagnostic Test

Note. To enter the satellite audio bezel diagnostic test, the audio system must be on and in SAT mode.

1. To enter the satellite audio bezel diagnostic test, simultaneously press and hold the AUX button and preset button 2 (except navigation), or SOUND and preset button 1 (navigation).
2. Upon entering the self-test, the audio system produces 2 continuously alternating tones of different pitch, one for the right channel, then one for the left.
3. The test continues by displaying any DTCs currently present. If no DTCs are present, NO DTCS will be displayed. If there are DTCs present, the ACM will auto-scroll through the list of active DTCs.
4. Historical DTCs can be viewed by pressing the AUX button and preset button 2 (except navigation), or SOUND and preset button 1 (navigation) simultaneously while in the active DTC mode. If any DTCs are present, simultaneously pressing the AUX button and preset button 2 (except navigation), or SOUND and preset button 1 (navigation) will prompt CLEAR DTCS? on the display. To clear historical DTCs, press preset buttons 1, 2, and 3 consecutively within 4 seconds. To exit historical DTCs (with or without clearing DTCs), press the AUX button and preset button 2 (except navigation), or SOUND and preset button 1 (navigation) simultaneously.
5. If no historical DTCs are present, pressing the AUX button and preset button 2 (except navigation), or SOUND and preset button 1 (navigation) simultaneously while in active DTC mode will display the DLP software version.
6. To exit the satellite audio bezel diagnostic test, press the AUX button and preset button 2 (except navigation), or SOUND and preset button 1 (navigation) simultaneously while the DLP (SDARS module) software version is displayed, or turn the ACM off.
7. If the concern remains and the fault is not detected, go to «Symptom Chart - Audio System»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) .

DTC Tables

Note. For all U-codes listed in this chart, if no related symptoms are observed, disregard the DTC.

Note. For all U-codes listed in this chart, if DTC B1318 is present, diagnose it before diagnosing the U-code DTC.

AUDIO CONTROL MODULE (ACM) DTC TABLE

Note. For all U-codes listed in this chart, if no related symptoms are observed, disregard the DTC.

Note. For all U-codes listed in this chart, if DTC B1318 is present, diagnose it before diagnosing the U-code DTC.

SATELLITE DIGITAL AUDIO RECEIVER SYSTEM (SDARS) MODULE DTC TABLE

Note. For all U-codes listed in this chart, if no related symptoms are observed, disregard the DTC.

Note. For all U-codes listed in this chart, if DTC B1318 is present, diagnose it before diagnosing the U-code DTC.

REAR ENTERTAINMENT MODULE (RETM) DTC TABLE

Note. For all U-codes listed in this chart, if no related symptoms are observed, disregard the DTC.

Note. For all U-codes listed in this chart, if DTC B1318 is present, diagnose it before diagnosing the U-code DTC.

ACCESSORY PROTOCOL INTERFACE MODULE (APIM) DTC TABLE

Symptom Chart

Symptom Chart - Audio System

Symptom Chart - Navigation

Symptom Chart - SYNC System

Pinpoint Test A: Poor Reception - AM/FM

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

Normal Operation

For the sedan, the radio antenna, integral to the rear window glass, receives AM and FM radio waves. The antenna module, which receives voltage from the audio control module (ACM) through circuit CME44 (YE/GN), sends the radio waves to the ACM through the antenna cable.

For the wagon, the fixed radio antenna receives AM and FM radio waves and sends them to the ACM.

The noise suppression equipment reduces engine ignition and electrical systems interference transmitted through the speakers.

1. DTC B2103 (Antenna Not Connected) - sets during the antenna connected test (part of the ACM self-test) when the signal strength is less than the pre-configured threshold value. In order for this DTC to set, the ACM must be tuned to AM, and the self-test must be run with the scan tool.

This pinpoint test is intended to diagnose the following

1. RDS/PTY function setting
2. Wiring, terminals or connectors (sedan only)
3. Antenna
4. Antenna cable
5. Antenna module (sedan only)
6. Charging system
7. Ignition system
8. Noise suppression equipment
9. ACM

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 6

Scheme 7

1. A1 VERIFY THE RDS/PTY SETTING Verify the RDS/PTY function is set to ALL. For non-navigation audio systems, press MENU repeatedly until RBDS (ON/OFF) appears on the display, then press the TUNE UP or TUNE DOWN button until ALL is displayed. For navigation audio systems, while in FM mode, press SHOW OPTIONS, make sure RDS is active, then press SET PTY and select ALL. Press the SEEK DOWN or SEEK UP button to scan for a good channel. Is a good channel found? YES : The system is operating correctly at this time. The cause of the concern was that no channel in the selected category was found. NO : Go to A2 .
2. A2 CHECK THE AUDIO SYSTEM RECEPTION Check the ACM signal reception with the engine running, and with the engine off. Does the poor reception only occur with the engine running? YES : Go to A3 . NO : Go to A6 .
3. A3 CHECK THE NOISE SUPPRESSION EQUIPMENT Key in OFF position. Check all required noise suppression equipment and the radio frequency interference suppression bond for security, cleanliness, and metal-to-metal contact. Are the connections clean, secure, and in metal-to-metal contact? YES : Go to A4 . NO : CLEAN and SECURE the connections, or INSTALL new suppression equipment as necessary. TEST the system for normal operation.
4. A4 CHECK THE GENERATOR Key in OFF position. Check the generator by disconnecting the wiring harness from the voltage regulator. Start the vehicle. Operate the audio system in radio tuner (AM/FM) mode. Is the reception OK? YES : INSTALL a new generator. REFER to «GENERATOR AND REGULATOR»(/ford/taurus-x/i-2007-2009/remont/charging-system/#charging-system-generators-regulators) article. TEST the system for normal operation. NO : Go to A5 .
5. A5 CHECK THE IGNITION CIRCUITS Key in OFF position. Connect the wiring harness to the voltage regulator. Check the ignition circuits for correct routing, grounding, and integrity of the connections. Check the spark plugs and ignition coils. Are the ignition components OK? YES : USE a jumper cable to ground various parts of the vehicle to the frame (for example: engine, fenders, quarter panels, stone deflectors, air cleaner, body sheet metal). When the noise is eliminated, PROVIDE a permanent ground where necessary. TEST the system for normal operation. NO : REPAIR the ignition system as necessary. TEST the system for normal operation.
6. A6 CHECK THE ANTENNA COAXIAL CABLE Key in OFF position. Disconnect: Antenna Coaxial Cable (At Antenna or Antenna Module) Disconnect: Antenna Coaxial Cable (At ACM) Measure the resistance of the antenna coaxial cable between the antenna and the ACM Is the resistance less than 2 ohms? YES : For the sedan, go to A7 . For the wagon, go to A11 . NO : INSTALL a new antenna cable. REFER to «Antenna Cable - Satellite Radio»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__antenna-cable-satellite-radio) . CLEAR the DTCs. REPEAT the self-test.
7. A7 CHECK CIRCUIT CME44 (YE/GN) FOR VOLTAGE Disconnect: Antenna Module C9021 Operate the audio system in radio tuner (AM/FM) mode. Measure the voltage between the antenna module C9021-1, circuit CME44 (YE/GN), harness side and ground. Is the voltage greater than 10 volts? YES : Go to A9 . NO : Go to A8 .
8. A8 CHECK CIRCUIT CME44 (YE/GN) FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Disconnect: ACM C240a Measure the resistance between the ACM, C240a-5, circuit CME44 (YE/GN), harness side and the antenna module C9021-1, circuit CME44 (YE/GN), harness side; and between the ACM C240a-5, circuit CME44 (YE/GN), harness side and ground. Is the resistance less than 5 ohms between the ACM and the antenna module, and greater than 10,000 ohms between the ACM and ground? YES : Go to A9 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
9. A9 CHECK THE ANTENNA GRID Disconnect: Antenna Module C9021 Inspect the antenna grid closely for signs of damage. Is the antenna grid OK? YES : Go to A10 . NO : REPAIR the antenna grid as necessary. REFER to «GLASS, FRAMES AND MECHANISMS»(/ford/taurus-x/i-2007-2009/remont/heated-glassdefoggers/#windows-and-glass) article. TEST the system for normal operation.
10. A10 ISOLATE THE ANTENNA MODULE Key in OFF position. Substitute the antenna module for a known good antenna module. Operate the audio system in radio tuner (AM/FM) mode. Is the reception OK? YES : INSTALL a new antenna module. CLEAR the DTCs. REPEAT the self-test. NO : INSTALL the original antenna module. Go to A12 .
11. A11 ISOLATE THE ANTENNA Connect: Antenna Coaxial Cable (At ACM) Substitute the antenna for a known good antenna. Operate the audio system in radio tuner (AM/FM) mode. Is the reception OK? YES : INSTALL a new antenna. REFER to «Antenna»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__antenna) . CLEAR the DTCs. REPEAT the self-test. NO : INSTALL the original antenna. Go to A12 .
12. A12 SUBSTITUTE THE ANTENNA CABLE Key in OFF position. Substitute a known good antenna cable. Operate the audio system in radio tuner (AM/FM) mode. Is the reception OK? YES : INSTALL a new antenna cable. REFER to «Antenna Cable - Satellite Radio»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__antenna-cable-satellite-radio) . CLEAR the DTCs. REPEAT the self-test after the repair. NO : INSTALL the original antenna cable. Go to A13 .
13. A13 CHECK FOR CORRECT ACM OPERATION Key in OFF position. Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect the ACM connectors and make sure they seat correctly. Operate the system and determine if the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

Pinpoint Test B: Poor Quality/Distorted/No Sound from One or More Speakers (Not All Speakers)

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

The audio control module (ACM) directs audio signals to the speakers and to the rear entertainment module (RETM) (if equipped) in the form of a fluctuating AC voltage. The rear door speakers receive audio signals through the RETM (if equipped) or directly from the ACM.

If the vehicle is equipped with the DVD entertainment system, the RETM mutes the speaker output to the rear speakers when the audio system is in dual-play mode. Make sure the audio system is in single-play mode before diagnosing a symptom of no sound to the rear speakers.

For the navigation system, if the voice guidance setting is set to zero rather than to off, it may appear that the front speakers intermittently produce no sound. Make sure the voice guidance setting is not set to zero before addressing a concern with the front speakers.

1. DTC B2965 (Audio System Speaker Circuit Fault) - sets when an open, a short to ground, or a short to voltage is detected on the front door or rear door speaker circuits. The ACM checks for faults once every 500ms during normal operation. The following should also be noted: The Audiophile ACM does not check for opens in the front door speakers. The navigation ACM does not check for opens.

For some audio systems, a short to ground or short to voltage in the circuitry to one of the speakers will cause all speakers to lose sound due to the built-in overload protection feature of the ACM. In this case, DTC B2965 will set in the ACM, and this pinpoint test should be followed to isolate the damaged circuit.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Speaker
3. RETM (if equipped)
4. ACM

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Make sure the audio system is in single-play mode before beginning this pinpoint test, or the results will not be accurate.

1. B1 CHECK THE SPEAKER CIRCUITS FOR VOLTAGE Key in OFF position. Disconnect: Suspect Speaker Operate the audio system in radio tuner (AM/FM) mode. Measure the AC voltage between the suspect speaker pin 1 and pin 2, harness side as follows: Suspect Speaker Connector-Pin, Circuit Connector-Pin, Circuit LH front C523-1 VME07 (WH) C523-2 RME07 (WH/BN) RH front C612-1 VME10 (WH/VT) C612-2 RME10 (WH/OG) LH rear C702-1 VME09 (WH/GN) C702-2 RME09 (BN/YE) RH rear C802-1 VME12 (BN/WH) C802-2 RME12 (BN/BU) Is a fluctuating AC voltage present? YES : INSTALL a new speaker for the suspect speaker. REFER to «Door Speaker»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__door-speaker) or «Parcel Shelf Speaker»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__parcel-shelf-speaker) . CLEAR any DTCs present. TEST the system for normal operation. NO : For a front speaker concern, go to B10 . For a rear speaker concern, go to B2 .
2. B2 VERIFY THE PRESENCE OF A DVD ENTERTAINMENT SYSTEM Key in OFF position. Check for the presence of a DVD entertainment system. Is the vehicle equipped with a DVD entertainment system? YES : Go to B5 . NO : Go to B3 .
3. B3 CHECK THE REAR SPEAKER CIRCUITS FOR A SHORT TO VOLTAGE Disconnect: ACM C240a Key in ON position. Measure the voltage between the suspect speaker pins, harness side and ground as follows: Suspect Speaker Connector-Pin Circuit LH rear C702-1 VME09 (WH/GN) C702-2 RME09 (BN/YE) RH rear C802-1 VME12 (BN/WH) C802-2 RME12 (BN/BU) Is any voltage present? YES : REPAIR the circuit in question. CLEAR any DTCs present. TEST the system for normal operation. NO : Go to B4 .
4. B4 CHECK THE REAR SPEAKER CIRCUITS FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the suspect speaker, harness side and the ACM, harness side; and between the suspect speaker, harness side and ground as follows: Suspect Speaker Speaker Connector- Pin ACM Connector- Pin Circuit LH rear C702-1 C240a-9 VME09 (WH/GN) C702-2 C240a-22 RME09 (BN/YE) RH rear C802-1 C240a-10 VME12 (BN/WH) C802-2 C240a-23 RME12 (BN/BU) Is the resistance less than 5 ohms between the suspect speaker and the ACM, and greater than 10,000 ohms between the suspect speaker and ground? YES : Go to B12 . NO : REPAIR the circuit in question. CLEAR any DTCs present. TEST the system for normal operation.
5. B5 CHECK THE ACM OUTPUT SIGNALS Disconnect: RETM C9029 Operate the audio system in radio tuner (AM/FM) mode. Measure the AC voltage between the RETM pins, harness side as follows: Suspect Speaker Connector-Pin/ Circuit Connector-Pin/ Circuit LH rear C9029-27 VME09 (WH/GN) C9029-28 RME09 (BN/YE) RH rear C9029-11 VME12 (BN/WH) C9029-12 RME12 (BN/BU) Is a fluctuating AC voltage present? YES : Go to B8 . NO : Go to B6 .
6. B6 CHECK THE ACM OUTPUT CIRCUITS FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: ACM C240a Key in ON position. Measure the voltage between the RETM, harness side and ground as follows: Suspect Speaker Connector-Pin Circuit LH rear C9029-27 VME09 (WH/GN) C9029-28 RME09 (BN/YE) RH rear C9029-11 VME12 (BN/WH) C9029-12 RME12 (BN/BU) Is any voltage present? YES : REPAIR the circuit in question. CLEAR any DTCs present. TEST the system for normal operation. NO : Go to B7 .
7. B7 CHECK THE ACM OUTPUT CIRCUITS FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the ACM, harness side and the RETM, harness side; and between the ACM, harness side and ground as follows: Suspect Speaker ACM Connector- Pin RETM Connector- Pin Circuit LH rear C240a-9 C9029-27 VME09 (WH/GN) C240a-22 C9029-28 RME09 (BN/YE) RH rear C240a-10 C9029-11 VME12 (BN/WH) C240a-23 C9029-12 RME12 (BN/BU) Is the resistance less than 5 ohms between the ACM and the RETM, and greater than 10,000 ohms between the ACM and ground? YES : Go to B12 . NO : REPAIR the circuit in question. CLEAR any DTCs present. TEST the system for normal operation.
8. B8 CHECK THE RETM OUTPUT CIRCUITS FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: Suspect Speaker Key in ON position. Measure the voltage between the suspect speaker pins, harness side and ground as follows: Suspect Speaker Connector-Pin Circuit LH rear C702-1 VME09 (WH/GN) C702-2 RME09 (BN/YE) RH rear C802-1 VME12 (BN/WH) C802-2 RME12 (BN/BU) Is any voltage present? YES : REPAIR the circuit in question. CLEAR any DTCs present. TEST the system for normal operation. NO : Go to B9 .
9. B9 CHECK THE RETM OUTPUT CIRCUITS FOR AN OPEN OR SHORT TO GROUND Measure the resistance between the suspect speaker, harness side and the RETM, harness side; and between the suspect speaker, harness side and ground as follows: Suspect Speaker Speaker Connector- Pin RETM Connector- Pin Circuit LH rear C702-1 C949-30 VME09 (WH/GN) C702-2 C949-29 RME09 (BN/YE) RH rear C802-1 C949-14 VME12 (BN/WH) C802-2 C949-13 RME12 (BN/BU) Is the resistance less than 5 ohms between the suspect speaker and the RETM, and greater than 10,000 ohms between the suspect speaker and ground? YES : Go to B13 . NO : REPAIR the circuit in question. CLEAR any DTCs present. TEST the system for normal operation.
10. B10 CHECK THE FRONT SPEAKER CIRCUITS FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: ACM C240a Key in ON position. Measure the voltage between the suspect speaker, harness side and ground as follows: Suspect Speaker Connector-Pin Circuit LH front C523-1 VME07 (WH) C523-2 RME07 (WH/BN) RH front C612-1 VME10 (WH/VT) C612-2 RME10 (WH/OG) Is any voltage present? YES : REPAIR the circuit in question. CLEAR any DTCs present. TEST the system for normal operation. NO : Go to B11 .
11. B11 CHECK THE FRONT SPEAKER CIRCUITS FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the ACM, harness side and the suspect speaker, harness side; and between the ACM, harness side and ground as follows: Suspect Speaker ACM Connector- Pin Speaker Connector- Pin Circuit LH front C240a-8 C523-1 VME07 (WH) C240a-21 C523-2 RME07 (WH/BN) RH front C240a-11 C612-1 VME10 (WH/VT) C240a-12 C612-2 RME10 (WH/OG) Is the resistance less than 5 ohms between the ACM and the suspect speaker, and greater than 10,000 ohms between the ACM and ground YES : Go to B12 . NO : REPAIR the circuit in question. CLEAR any DTC present. TEST the system for normal operation.
12. B12 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and determine if the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
13. B13 CHECK FOR CORRECT RETM OPERATION Connect: All Disconnected Connectors Disconnect the RETM connector. Check for: corrosion damaged pins pushed-out pins Connect the RETM connector and make sure it seats correctly. Operate the system and determine if the concern is still present. Is the concern still present? YES : INSTALL a new RETM. REFER to «Rear Entertainment Module (RETM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

Pinpoint Test C: The Subwoofer is Inoperative/Does Not Operate Correctly - Audiophile

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

The subwoofer speaker is powered by a separate subwoofer amplifier. For wagons, the subwoofer speaker is integral to the subwoofer enclosure. For sedans, there are 2 subwoofer speakers connected to the subwoofer amplifier through circuits VME01 (GN/VT), RME01 (GY), VME02 (VT), and RME02 (YE). The subwoofer receives audio signals from the ACM through circuits VME22 (VT/GN) and RME22 (GN/WH). The subwoofer amplifier receives voltage (at all times) through circuit SBP38 (BN/RD), and ground through circuit GD148 (BK/YE).

To enable the subwoofer amplifier, the ACM sends voltage through the enable/clip circuit SME23 (VT/RD). The circuit acts as both an output (to enable the amplifier) and an input (to detect an amplifier overload condition). A variable resistor in the subwoofer amplifier modifies the voltage signal from the ACM. In the event of an overload, the ACM clips the audio output signal to the amplifier (heard as distortion), in order to prevent damage to the amplifier and speakers.

The clip/enable status is based on the following voltages, as detected by the ACM

1. Less than 0.4 volts: amplifier disabled
2. Between 3.8 and 6.7 volts: amplifier enabled
3. Greater than 8.5 volts: amplifier clipped

An open in circuit SME23 (VT/RD) will cause the subwoofer to produce no sound, because the enable signal will not reach the subwoofer amplifier. A short to ground or short to voltage can cause severe distortion to be heard from the subwoofer.

1. DTC B1154 (Subwoofer #1 Short to Ground) - sets when a short to ground is detected on circuit RME22 (GN/WH) or VME22 (VT/GN). This DTC only sets during the on-demand self-test.
2. DTC B1155 (Subwoofer #1 Short to Battery) - sets when a short to voltage is detected on circuit RME22 (GN/WH) or VME22 (VT/GN). This DTC only sets during the on-demand self-test.
3. DTC B2913 (Audio Subwoofer Not Connected) - sets when the ACM does not detect the subwoofer through circuit SME23 (VT/RD) during the subwoofer connection test (part of the ACM self-test).

This pinpoint test is intended to diagnose the following

1. Fuse
2. Wiring, terminals or connectors
3. Subwoofer amplifier
4. Subwoofer speaker
5. ACM

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. C1 DETERMINE THE VEHICLE TYPE Determine the vehicle type. Is the vehicle a wagon? YES : Go to C3 . NO : Go to C2 .
2. C2 DETERMINE THE INOPERATIVE SUBWOOFER Operate the audio system in radio tuner (AM/FM) mode and observe the subwoofer operation. Are both subwoofer speakers inoperative? YES : Go to C3 . NO : Go to C11 .
3. C3 CHECK CIRCUIT SBP38 (BN/RD) FOR VOLTAGE Key in OFF position. Disconnect: Subwoofer Amplifier C3041 or C466a Measure the voltage between the subwoofer amplifier C3041-5 or C466a-5, circuit SBP38 (BN/RD), harness side and ground. Is the voltage greater than 10 volts? YES : Go to C4 . NO : VERIFY the smart junction box (SJB) fuse 38 (20A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation.
4. C4 CHECK CIRCUIT GD148 (BK/YE) FOR AN OPEN Measure the resistance between the subwoofer amplifier C3041-2 or C466a-2, circuit GD148 (BK/YE), harness side and ground. Is the resistance less than 5 ohms? YES : Go to C5 . NO : REPAIR the circuit. TEST the system for normal operation.
5. C5 CHECK CIRCUIT SME23 (VT/RD) FOR VOLTAGE Operate the audio system in radio tuner (AM/FM) mode. Measure the voltage between the subwoofer amplifier C3041-1 or C466a-1, circuit SME23 (VT/RD), harness side and ground. Is the voltage between 3.8 and 6.7 volts? YES : Go to C8 . NO : Go to C6 .
6. C6 CHECK CIRCUIT SME23 (VT/RD) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: ACM C240b Measure the voltage between the subwoofer amplifier C3041-1 or C466a-1, circuit SME23 (VT/RD), harness side and ground. Is any voltage present? YES : REPAIR the circuit. TEST the system for normal operation. NO : Go to C7 .
7. C7 CHECK CIRCUIT SME23 (VT/RD) FOR AN OPEN OR SHORT TO GROUND Measure the resistance between the subwoofer amplifier C3041-1 or C466a-1, circuit SME23 (VT/RD), harness side and the ACM C240b-4, circuit SME23 (VT/RD), harness side; and between the subwoofer amplifier C3041-1 or C466a-1, circuit SME23 (VT/RD), harness side and ground. Is the resistance less than 5 ohms between the subwoofer amplifier and the ACM, and greater than 10,00 ohms between the subwoofer amplifier and ground? YES : Go to C14 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
8. C8 CHECK THE AUDIO SIGNAL TO THE SUBWOOFER AMPLIFIER Key in OFF position. Connect: ACM C240b Operate the audio system in radio tuner (AM/FM) mode. Measure the AC voltage between the subwoofer amplifier C3041-7 or C466a-7, circuit VME22 (VT/GN), harness side and the subwoofer amplifier C3041-8 or C466a-8, circuit RME22 (GN/WH), harness side. Is a fluctuating AC voltage present? YES : INSTALL a new subwoofer amplifier. REFER to «Subwoofer Amplifier»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : Go to C9 .
9. C9 CHECK THE AUDIO CIRCUITS FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: ACM C240b Key in ON position. Measure the voltage between the subwoofer amplifier C3041-7 or C466a-7, circuit VME22 (VT/GN), harness side and ground; and between the subwoofer amplifier C3041-8, circuit RME22 (GN/WH), harness side and ground. Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to C10 .
10. C10 CHECK THE AUDIO CIRCUITS FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the subwoofer amplifier, harness side and the ACM, harness side; and between the subwoofer amplifier, harness side and ground as follows: Subwoofer Amplifier Connector-Pin ACM Connector-Pin Circuit C466a-7 or C3041-7 C240b-1 VME22 (VT/GN) C466a-8 or C3041-8 C240b-2 RME22 (GN/WH) Is the resistance less than 5 ohms between the subwoofer amplifier and the ACM, and greater than 10,000 ohms between the subwoofer amplifier and ground? YES : Go to C14 . NO : REPAIR the circuit in question. TEST the system for normal operation.
11. C11 CHECK THE AUDIO CIRCUITS TO THE SUSPECT SUBWOOFER SPEAKER FOR VOLTAGE Key in OFF position. Disconnect: Suspect Subwoofer Speaker Operate the audio system in radio tuner (AM/FM) mode. Measure the AC voltage between the LH subwoofer speaker C3120-1, circuit VME02 (VT), harness side and the LH subwoofer speaker C3120-2, circuit RME02 (YE), harness side; or between the RH subwoofer speaker C3121-1, circuit VME01 (GN/VT), harness side and the RH subwoofer speaker C3121-2, circuit RME01 (GY), harness side. Is a fluctuating AC voltage present? YES : INSTALL a new subwoofer speaker. REFER to «Subwoofer Speaker»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : Go to C12 .
12. C12 CHECK THE AUDIO CIRCUITS TO THE SUSPECT SUBWOOFER SPEAKER FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: Subwoofer Amplifier C466b Key in ON position. Measure the voltage between the subwoofer amplifier, harness side and ground as follows: Subwoofer Amplifier Connector-Pin Circuit C466b-3 VME02 (VT) C466b-4 RME02 (YE) C466b-1 VME01 (GN/VT) C466b-2 RME01 (GY) Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to C13 .
13. C13 CHECK THE AUDIO CIRCUITS TO THE SUSPECT SUBWOOFER SPEAKER FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the suspect subwoofer speaker, harness side and the subwoofer amplifier, harness side; and between the suspect subwoofer speaker, harness side and ground as follows: Subwoofer Speaker Connector-Pin Subwoofer Amplifier Connector-Pin Circuit C3120-1 C466b-3 VME02 (VT) C3120-2 C466b-4 RME02 (YE) C3121-1 C466b-1 VME01 (GN/VT) C3121-2 C466b-2 RME01 (GY) Is the resistance less than 5 ohms between the suspect subwoofer speaker and the subwoofer amplifier, and greater than 10,000 ohms between the suspect subwoofer speaker and ground? YES : INSTALL a new subwoofer amplifier. REFER to «Subwoofer Amplifier»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : REPAIR the circuit in question. TEST the system for normal operation.
14. C14 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and determine if the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

Pinpoint Test D: The Audio Does Not Reduce When The Parking Aid Tone Sounds

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

When the parking aid module (PAM) detects an object in range, it sounds an alarm and grounds circuit CME05 (GN/BU) to the ACM. When the ACM detects the circuit grounded, it reduces the audio output until the parking aid module signal is no longer detected.

1. DTC B2384 (Audio Reverse Park Aid Mute Ckt Failure) - sets during the on-demand test if the mute circuit is detected as active. This could be because the vehicle is in reverse (R) and an object is within range of the parking aid system. Put the vehicle in park (P) while running the on-demand self-test to eliminate this as a possible cause of the DTC.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Parking aid system concern

1. D1 CHECK THE ACM DTCs Put the vehicle in park (P). Carry out the ACM on-demand self-test. Is DTC B2384 present? YES : Go to D2 . NO : REFER to «PARKING AID»(/ford/taurus-x/i-2007-2009/remont/collisionavoidance/#parking-aid-system) article to continue diagnosis of the parking aid system.
2. D2 CHECK THE PARKING AID MODULE OUTPUT Key in OFF position. Disconnect: PAM C3267 Carry out the ACM on-demand self-test. Is DTC B2384 present? YES : REPAIR circuit CME05 (GN/BU) for a short to ground. CLEAR the DTCs. REPEAT the self-test. NO : REFER to «PARKING AID»(/ford/taurus-x/i-2007-2009/remont/collisionavoidance/#parking-aid-system) article to continue diagnosis of the parking aid system.

Pinpoint Test E: The Steering Wheel Controls Are Inoperative/Do Not Operate Correctly

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

There are 3 different steering wheel controls configurations

1. Non-navigation, without the SYNC system VOL-, VOL+, SEEK-, SEEK+, MEDIA, MUTE
2. Non-navigation, with the SYNC system MENU-, MENU+, VOICE, OK, PHONE
3. Navigation, with or without the SYNC system VOL-, VOL+, SEEK-, SEEK+, MEDIA, VOICE

For vehicles without both navigation and the SYNC system, all the steering wheel controls are wired to the audio control module (ACM). Voltage is sent from the ACM to the steering wheel controls through circuit VME14 (GY/YE), and the ACM ground the reference voltage through circuit RMC27 (WH/BN).

For vehicles with the SYNC system but not navigation, all the steering wheel controls are wired to the accessory protocol interface module (APIM). Voltage is sent from the APIM to the steering wheel controls through circuit CMM15 (GY/BU), and the APIM grounds the reference voltage through circuit CMM14 (WH).

For vehicles equipped with navigation, all the steering wheel controls are wired to the ACM, regardless of whether the vehicle is equipped with the SYNC system or not.

For all configurations, when a switch is pressed, the voltage is routed through a specific resistor value for each function. The ACM (or APIM) then uses the reference voltage to determine which control input function has been selected.

1. DTC B1117 (Audio Steering Wheel Button Stuck) - set by the ACM or the APIM (depending on vehicle configuration) when a steering wheel control switch is detected as active for more than 120 seconds during normal operation, or for any duration during the self-test. A short to ground on VME14 (GY/YE) should not set this DTC, as the reference voltage would fall out-of-range, resulting in DTC B1136 or B2404 being set.
2. DTC B1136 (Audio Steering Wheel Switch #2 Circuit Failure) - set by the APIM when the reference voltage to the steering wheel controls is out-of-range. This can be caused by a number of different failures on the steering wheel controls circuit except for a stuck button or a short to ground in circuit CMM14 (WH).
3. DTC B2404 (Audio Steering Wheel Switch Circuit Fault) - set by the ACM when the reference voltage to the steering wheel controls is out-of-range. This can be caused by a number of different failures on the steering wheel controls circuit except for a stuck button a short to ground in circuit RMC27 (WH/BN).

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Clockspring
3. Steering wheel controls
4. ACM
5. APIM (if equipped)

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 15

Scheme 16

1. E1 DETERMINE THE INOPERATIVE STEERING WHEEL CONTROLS Determine which steering wheel controls are inoperative by pressing each steering wheel control button individually while operating the audio system in various modes (AM/FM, SYNC, etc.). Is the concern with the VOL-, VOL+, SEEK-, SEEK+, MEDIA, or MUTE button? YES : Go to E2 . NO : Go to E3 .
2. E2 MONITOR THE STEERING WHEEL CONTROL PIDs (ACM CONTROLLED SWITCHES) Enter the following diagnostic mode on the diagnostic tool: ACM DataLogger Monitor the steering wheel controls PIDs while pressing each steering wheel controls button as follows: Steering Wheel Controls Button PID VOL- VOL_DN VOL+ VOL_UP SEEK- SEEK_DN SEEK+ SEEK_UP MEDIA MODE_SW MUTE MUTE_SW Do the PID values agree with the switch positions? YES : Go to E8 . NO : If only one PID value is incorrect or the PID value always reads one particular switch position, INSTALL new steering wheel controls. REFER to «Steering Wheel Controls»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . CLEAR any DTCs present. TEST the system for normal operation. Otherwise, go to E4 .
3. E3 MONITOR THE STEERING WHEEL CONTROL PIDs (APIM CONTROLLED SWITCHES) Enter the following diagnostic mode on the diagnostic tool: APIM DataLogger Monitor the steering wheel controls PIDs while pressing each steering wheel controls button as follows: Steering Wheel Controls Button PID MENU- MENUM_SW MENU+ MENUP_SW VOICE VOICE_SW OK OK_SW PHONE PHONE_SW Do the PID values agree with the switch positions? YES : Go to E9 . NO : If only one PID value is incorrect or the PID value always reads one particular switch position, INSTALL new steering wheel controls. REFER to «Steering Wheel Controls»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . CLEAR any DTCs present. TEST the system for normal operation. Otherwise, go to E4 .
4. E4 CHECK THE REFERENCE VOLTAGE CIRCUIT TO THE CLOCKSPRING FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: Clockspring C218a Disconnect: ACM C240a or APIM C3342 Key in ON position. For a concern with an ACM-controlled button, measure the voltage between the clockspring C218a-13, circuit VME14 (GY/YE), harness side and ground. For a concern with an APIM-controlled button, measure the voltage between the clockspring C218a-6, circuit CMM15 (GY/BU), harness side and ground. Is any voltage present? YES : REPAIR the circuit in question. CLEAR any DTCs present. TEST the system for normal operation. NO : Go to E5 .
5. E5 CHECK THE CIRCUITS TO THE CLOCKSPRING FOR AN OPEN OR SHORT TO GROUND NOTE: Circuit RMC27 (WH/BN) does not need to be checked for a short to ground. Key in OFF position. For a concern with an ACM-controlled button, measure the resistance between the ACM, harness side and the clockspring, harness side; and between the ACM, harness side and ground as follows: ACM Connector-Pin Clockspring Connector-Pin Circuit C240a-18 C218a-13 VME14 (GY/YE) C240a-19 C218a-19 RMC27 (WH/BN) For a concern with an APIM-controlled button, measure the voltage between the APIM, harness side and the clockspring, harness side; and between the APIM, harness side and ground as follows: APIM Connector-Pin Clockspring Connector-Pin Circuit C3342-14 C218a-6 CMM15 (GY/BU) C3342-15 C218a-4 CMM14 (WH) Is the resistance less than 5 ohms between the ACM (or APIM) and the clockspring, and greater than 10,000 ohms between the ACM (or APIM) and ground? YES : Go to E6 . NO : REPAIR the circuit in question. CLEAR any DTCs present. TEST the system for normal operation.
6. E6 CHECK THE CLOCKSPRING FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: Clockspring C218b Key in ON position. For a concern with an ACM-controlled button, measure the voltage between the clockspring C218b-10, circuit VME14 (GY/YE), component side and ground. For a concern with an APIM-controlled button, measure the voltage between the clockspring C218b-3, circuit CMM15 (GY/BU), component side and ground. Is any voltage present? YES : INSTALL a new clockspring. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/taurus-x/i-2007-2009/remont/airbag/#supplemental-inflatable-restraint-system) article. CLEAR any DTCs present. TEST the system for normal operation. NO : Go to E7 .
7. E7 CHECK THE CLOCKSPRING FOR AN OPEN OR SHORT TO GROUND NOTE: Circuits RMC27 (WH/BN) and CMM14 (WH) do not need to be checked for a short to ground. Key in OFF position. For a concern with an ACM-controlled button, measure the resistance between the clockspring C218a, component side and the clockspring C218b, component side; and between the clockspring C218a, harness side and ground as follows: Clockspring Connector-Pin Clockspring Connector-Pin Circuit C218a-13 C218b-10 VME14 (GY/YE) C218a-12 C218b-11 RMC27 (WH/BN) For a concern with an APIM-controlled button, measure the voltage between clockspring, harness side and the steering wheel controls, harness side; and between the clockspring, harness side and ground as follows: Clockspring Connector-Pin Clockspring Connector-Pin Circuit C218a-6 C218b-3 CMM15 (GY/BU C218a-4 C218b-5 CMM14 (WH) Is the resistance less than 5 ohms between the clockspring C218a and the clockspring C218b, and greater than 10,000 ohms between the clockspring C218a and ground? YES : INSTALL new steering wheel controls. REFER to «Steering Wheel Controls»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . CLEAR any DTCs present. NO : INSTALL a new clockspring. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/taurus-x/i-2007-2009/remont/airbag/#supplemental-inflatable-restraint-system) article. CLEAR any DTCs present. TEST the system for normal operation.
8. E8 CHECK FOR CORRECT ACM OPERATION Key in OFF position. Connect: Any Disconnected Connectors Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR any DTCs present. REPEAT the self-test.
9. E9 CHECK FOR CORRECT APIM OPERATION Connect: All Disconnected Connectors Disconnect the APIM connector. Check for: corrosion damaged pins pushed-out pins Connect the APIM connector and make sure it seats correctly. Wait 2 minutes for the APIM to re-initalize. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new APIM. REFER to «Accessory Protocol Interface Module (APIM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__accessory-protocol-interface-module-apim) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR any DTCs present. REPEAT the self-test.

Pinpoint Test F: The Speed Sensitive Volume Does Not Operate Correctly

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

The speed sensitive volume function adjusts the volume based on the vehicle speed sensor (VSS) signal from the instrument cluster (IC). The IC does not generate the VSS signal; it gateways the signal from the PCM.

1. DTC U0155 (Lost Communication With Instrument Panel Cluster Control [IC] Module) - sets when the VSS signal is lost for greater than 5 seconds. When the signal is lost, the ACM turns the speed sensitive volume feature off. The smart junction box (SJB) and heating ventilation air conditioning (HVAC) module-electronic automatic temperature control (EATC) also receive this signal, and should demonstrate symptoms if the VSS signal is lost. If no symptoms are present, this DTC can be ignored, as it may have been set by a low battery voltage condition.

This pinpoint test is intended to diagnose the following

1. Speed sensitive volume setting
2. VSS signal concern
3. ACM

1. F1 CHECK THE SPEEDOMETER OPERATION Drive the vehicle and observe the speedometer. Does the speedometer operate correctly? YES : Go to F2 . NO : REFER to «INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES»(/ford/taurus-x/i-2007-2009/remont/gauges-instrument-panels/#information-center) article to diagnose the inoperative speedometer.
2. F2 CHECK THE SPEED SENSITIVE VOLUME SETTING Turn the speed sensitive volume off. For vehicles without navigation, press MENU until the speed sensitive volume prompt is reached, then press TUNE DOWN until the feature is turned off. For vehicles with navigation, press SOUND, select the SCV tab, and turn the feature off. Operate the audio system in radio tuner (AM/FM) mode. Drive the vehicle at various speeds and observe the speaker volume. Set the speed sensitive volume to maximum compensation. For vehicles without navigation, press MENU until the speed sensitive volume prompt is reached, then press TUNE UP until the feature is set to setting "7". For vehicles with navigation, press SOUND, select the SCV tab, then press "7". Operate the audio system in radio tuner (AM/FM) mode. Drive the vehicle at various speeds and observe the speaker volume. Does the volume remain constant with the speed sensitive volume turned off, and increase and decrease with vehicle speed with the speed sensitive volume set to maximum? YES : The system is operating correctly at this time. INFORM the customer of proper operation. NO : Go to F3 .
3. F3 CHECK FOR DTC U0155 Key in ON position. Using the scan tool, clear any ACM continuous DTCs. Key in OFF position. Key in ON position. Wait at least 10 seconds. Retrieve the ACM continuous DTCs. Is DTC U0155 present? YES : Go to F4 . NO : Go to F5 .
4. F4 CHECK FOR COMMUNICATION WITH THE IC Carry out the network test using the scan tool. Does the scan tool communicate with the IC? YES : Go to F5 . NO : REFER to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article.
5. F5 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and determine if the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

Pinpoint Test G: The Video System Does Not Operate Correctly

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

The rear entertainment module (RETM) routes audio signals to the audio control module (ACM). In single-play mode, the ACM plays the DVD audio on all speakers. In dual-play mode, the audio to the rear speakers is muted and the RETM continues to control the rear audio source to the headphones.

If the vehicle is equipped with satellite audio and/or the SYNC system, the audio signals from these sources are routed through the RETM to the ACM. This allows for single-play and dual-play to include these audio sources.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. RETM
3. ACM

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Before diagnosing the RETM, make sure a known good DVD is installed.

1. G1 IDENTIFY THE SYMPTOM Operate the audio system in DVD single-play mode and observe the DVD video. Does the DVD video operate correctly? YES : If the vehicle is equipped with satellite audio or the SYNC system, go to G3 . Go to G4 . NO : Go to G2 .
2. G2 CHECK THE OPERATION OF THE DVD VIDEO With the RETM still on, press the VIDEO button once or twice while observing the DVD video. Does the DVD video display? YES : The system is operating correctly at this time. The concern was caused by an incorrect system setting. INFORM the customer that pressing the power button or the VIDEO button while a DVD is playing can cause the display to go blank. NO : Go to G6 .
3. G3 CHECK THE RETM AUDIO PASS-THROUGH Operate the audio system in satellite audio or SYNC mode. Does the satellite audio (or SYNC) audio operate correctly? YES : Go to G6 . NO : Go to G4 .
4. G4 CHECK THE AUDIO CIRCUITS TO THE ACM FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: ACM C240c Disconnect: RETM C9029 Key in ON position. Measure the voltage between the ACM, harness side and ground as follows: ACM Connector-Pin Circuit C240c-1 VME41 (GN/OG) C240c-2 RME41 (BU/BN) C240c-9 VME42 (VT/BN) C240c-10 RME42 (YE/BU) Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to G5 .
5. G5 CHECK THE AUDIO CIRCUITS TO THE ACM FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the ACM, harness side and the RETM, harness side; and between the ACM, harness side and ground as follows: ACM Connector-Pin RETM Connector-Pin Circuit C240c-1 C9029-10 VME41 (GN/OG) C240c-2 C9029-9 RME41 (BU/BN) C240c-9 C9029-26 VME42 (VT/BN) C240c-10 C9029-25 RME42 (YE/BU) Are the resistances less than 5 ohms between the ACM and the RETM, and greater than 10,000 ohms between the ACM and ground? YES : Go to G6 . NO : REPAIR the circuit in question. TEST the system for normal operation.
6. G6 CHECK FOR CORRECT RETM OPERATION Connect: All Disconnected Connectors Disconnect the RETM connector. Check for: corrosion damaged pins pushed-out pins Connect the RETM connector and make sure it seats correctly. Operate the system and determine if the concern is still present. Is the concern still present? YES : INSTALL a new RETM. REFER to «Rear Entertainment Module (RETM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. If the concern is still present, go to G7 . NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
7. G7 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and determine if the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Digital signals are received by the satellite antenna and sent to the satellite digital audio receiver system (SDARS) module, which then converts the signals and provides audio signals to the audio control module (ACM), the accessory protocol interface module (APIM), or to the rear entertainment module (RETM), depending on vehicle configuration.

A short to ground typically has no effect on the antenna signal. However, an open in the antenna circuit will result in no sound from the satellite radio system. A short to voltage in the antenna circuit can have varying effects on the system.

1. DTC B1031 (SDARS Satellite Antenna Open) - sets when an open or high resistance is detected in the satellite antenna circuit. This DTC can be either continuous or on-demand.
2. DTC B1032 (SDARS Satellite Antenna Short) - sets when a short to ground is detected in the satellite antenna circuit. This DTC can be either continuous or on-demand.

This pinpoint test is intended to diagnose the following

1. Obstructions to the line of sight
2. Satellite radio antenna cable
3. Satellite radio antenna
4. SDARS module

PINPOINT TEST H: POOR RECEPTION/NO SOUND - SATELLITE AUDIO

1. H1 CHECK THE OPERATION OF THE SATELLITE AUDIO Drive the vehicle to an open location, free of obstacles. Operate the audio system in satellite audio mode. Is the reception OK? YES : The system is OK at this time. ADVISE the customer that the satellite signal can be affected by obstructions to the satellite antenna line of sight. NO : Go to H2 .
2. H2 CHECK FOR A SATELLITE ANTENNA FAULT MESSAGE Operate the audio system in satellite audio mode and observe the ACM display. Does the ACM display indicate a satellite radio antenna fault? YES : Go to H3 . NO : For vehicles without a DVD entertainment systemGo to «Pinpoint Test I»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-i-the-satellite-audio) . For vehicles with a DVD entertainment systemGo to «Pinpoint Test J»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-j-the-satellite-audio) .
3. H3 CHECK THE SATELLITE RADIO ANTENNA CABLE Key in OFF position. Disconnect: Satellite Radio Antenna Connection (At Satellite Radio Antenna) Disconnect: Satellite Radio Antenna Connection (at SDARS module) Measure the resistance of the satellite radio antenna cable between the SDARS module and the satellite radio antenna connection. Is the resistance less than 1 ohm? YES : Go to H4 . NO : INSTALL a new satellite radio antenna cable. REFER to «Antenna Cable - Satellite Radio»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__antenna-cable-satellite-radio) . CLEAR any DTCs present. TEST the system for normal operation.
4. H4 SUBSTITUTE THE SATELLITE RADIO ANTENNA Install a known good satellite radio antenna. Operate the audio system in satellite audio mode. Is the reception OK? YES : INSTALL a new satellite radio antenna. REFER to «Antenna»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__antenna) . CLEAR any DTCs present. TEST the system for normal operation. NO : Go to H5 .
5. H5 CHECK FOR CORRECT SDARS MODULE OPERATION Key in OFF position. Disconnect the SDARS module connector. Check for: corrosion damaged pins pushed-out pins Connect the SDARS module connector and make sure it seats correctly. Operate the system and determine if the concern is still present. Is the concern still present? YES : INSTALL a new SDARS module. REFER to «Satellite Digital Audio Receiver System (SDARS) Module»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test I: The Satellite Audio Is Inoperative/Does Not Operate Correctly - Vehicles Without DVD Entertainment System

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

The satellite digital audio receiver system (SDARS) module receives voltage through circuit SBP03 (BU/RD), and ground through circuit GD103 (BK/BU). Digital signals are received by the satellite radio antenna and sent to the SDARS module, which converts the signals to analog and sends them to either the audio control module (ACM) or to the accessory protocol interface module (APIM) (if equipped).

If there is an open in the satellite antenna circuit, there will be no satellite audio. The ACM display will indicate a satellite antenna concern (the method varies according to the type of ACM) when the audio system is operated in satellite radio mode. To diagnose an open in the satellite antenna circuit, go to Pinpoint Test H .

The SDARS module transmits left and right channel audio signals. When there is a fault in any of the audio signal circuits, the audio quality is reduced. If the circuits for a specific channel are shorted together, loss of audio on the entire channel will occur. This can be detected by using the SDARS module tones test.

1. DTC U0184 (Lost Communication With Radio [ACM]) - set by the SDARS module when certain medium speed controller area network (MS-CAN) messages are missing from the ACM for greater than 5 seconds. This results in loss of satellite radio functionality.
2. DTC U0193 (Lost Communication With Digital Audio Control Module [SDARS]) - set by the ACM when certain MS-CAN messages are missing from the SDARS module for greater than 5 seconds. This results in loss of satellite radio functionality.
3. DTC U0197 (Lost Communication With Telephone Control Module) - set by the SDARS module when certain MS-CAN messages are missing from the APIM for greater than 5 seconds.

This pinpoint test is intended to diagnose the following

1. Subscription status
2. Wiring, terminals or connectors
3. SDARS module
4. APIM (if equipped)
5. ACM

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

1. I1 VERIFY AN ACTIVE SUBSCRIPTION Enter satellite mode on the ACM and observe the display. Does the display read CALL SIRIUS? YES : The subscription has expired. INFORM the customer to contact Sirius to re-activate the subscription. NO : If the display indicates a satellite antenna fault, go to «Pinpoint Test H»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-h-poor-receptionno-sound) . Otherwise, go to I2 .
2. I2 CHECK FOR NON-NETWORK DTCs Carry out the SDARS module self-test using the scan tool. Are any non-network DTCs present? YES : For DTC B1031 or DTC B1032, go to «Pinpoint Test H»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-h-poor-receptionno-sound) . For all other DTCs, REFER to «DTC Tables»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__dtc-tables) . NO : Go to I3 .
3. I3 CHECK FOR COMMUNICATION WITH THE ACM AND APIM Carry out the network test using the scan tool. Does the scan tool communicate with the ACM and the APIM (if equipped)? YES : Go to I4 . NO : REFER to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article to diagnose no communication with the ACM or APIM.
4. I4 CHECK FOR LOST COMMUNICATION DTCs Key in ON position. Using the scan tool, clear any ACM and SDARS module continuous DTCs. Key in OFF position. Key in ON position. Wait at least 10 seconds. Retrieve the ACM and SDARS module continuous DTCs. Is DTC U0184 (SDARS module), U0193 (ACM), or U0197 (SDARS module, if equipped with the SYNC system) present? YES : For DTC U0184, go to I13 . For DTC U0193, go to I11 . For DTC U0197, go to I12 . NO : Go to I5 .
5. I5 CHECK THE SATELLITE AUDIO OUTPUT Enter the following diagnostic mode on the diagnostic tool: Electrical -> Audio -> Tones Test -> Satellite Digital Audio Receiver System Carry out the SDARS module tones test using the scan tool. Are alternating LH/RH tones audible? YES : Go to I11 . NO : If the vehicle is equipped with the SYNC system, go to I6 . Otherwise, go to I9 .
6. I6 CHECK THE OPERATION OF THE SYNC SYSTEM AUDIO Operate the audio system in radio tuner (AM/FM) mode. Connect: Known Good MP3 Device (To Audio Input Jack) Using the ACM buttons, press AUX until "SYNC LINE IN" appears on the display (except navigation), or press MEDIA, select "USER DEVICE", and press "SOURCE" repeatedly until "LINE IN" appears (navigation). Using the known good MP3 device, attempt to play a file through the audio input jack. Does the SYNC system audio operate correctly? YES : Go to I7 . NO : Go to «Pinpoint Test U»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-u-poor-qualitydistortedno-sound) .
7. I7 CHECK THE AUDIO CIRCUITS TO THE APIM FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: APIM C3342 Disconnect: SDARS Module C4344 Key in ON position. Measure the voltage between the SDARS module, harness side and ground as follows: Connector-Pin Circuit C4344-5 VME41 (GN/OG) C4344-6 VME42 (VT/BN) C4344-11 RME41 (BU/BN) C4344-12 RME42 (YE/BU) Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to I8 .
8. I8 CHECK THE AUDIO CIRCUITS TO THE APIM FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the APIM, harness side and the SDARS module, harness side; and between the APIM, harness side and ground as follows: APIM Connector-Pin SDARS Module Connector-Pin Circuit C3342-10 C4344-5 VME41 (GN/OG) C3342-7 C4344-6 VME42 (VT/BN) C3342-11 C4344-11 RME41 (BU/BN) C3342-8 C4344-12 RME42 (YE/BU) Is the resistance less than 5 ohms between the APIM and the SDARS module, and greater than 10,000 ohms between the APIM and ground? YES : Go to I11 . NO : REPAIR the circuit in question. TEST the system for normal operation.
9. I9 CHECK THE AUDIO CIRCUITS TO THE ACM FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: ACM C240c Disconnect: SDARS Module C4344 Key in ON position. Measure the voltage between the SDARS module, harness side and ground as follows: Connector-Pin Circuit C4344-5 VME41 (GN/OG) C4344-6 VME42 (VT/BN) C4344-11 RME41 (BU/BN) C4344-12 RME42 (YE/BU) Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to I10 .
10. I10 CHECK THE AUDIO CIRCUITS FROM THE SDARS MODULE FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the SDARS module, harness side and the ACM, harness side; and between the SDARS module, harness side and ground as follows: SDARS Module Connector-Pin ACM Connector-Pin Circuit C4344-5 C240c-1 VME41 (GN/OG) C4344-6 C240c-9 VME42 (VT/BN) C4344-11 C240c-2 RME41 (BU/BN) C4344-12 C240c-10 RME42 (YE/BU) Is the resistance less than 5 ohms between the SDARS module and the ACM, and greater than 10,000 ohms between the SDARS module and ground? YES : Go to I11 . NO : REPAIR the circuit in question. TEST the system for normal operation.
11. I11 ISOLATE THE SDARS MODULE Key in OFF position. Connect: ACM C240c Connect: APIM C3342 (If Equipped) Install a new SDARS module. Refer to «Satellite Digital Audio Receiver System (SDARS) Module»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . Operate the audio system in satellite radio mode. Does the system operate correctly? YES : The concern was caused by an inoperative SDARS module. The system is operating correctly at this time. NO : If equipped with the SYNC system, go to I12 . Otherwise, go to I13 .
12. I12 CHECK FOR CORRECT APIM OPERATION Connect: All Disconnected Connectors Disconnect the APIM connector. Check for: corrosion damaged pins pushed-out pins Connect the APIM connector and make sure it seats correctly. Wait 2 minutes for the APIM to re-initalize. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new APIM. REFER to «Accessory Protocol Interface Module (APIM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__accessory-protocol-interface-module-apim) . TEST the system for normal operation. If the concern is still present, go to I13 . NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
13. I13 CHECK FOR CORRECT ACM OPERATION Key in OFF position. Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and determine if the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test J: The Satellite Audio Is Inoperative/Does Not Operate Correctly - Vehicles With DVD Entertainment System

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

The satellite digital audio receiver system (SDARS) module receives voltage through circuit SBP03 (BU/RD) and ground through circuit GD103 (BK/BU). Digital signals are received by the satellite radio antenna and sent to the SDARS module, which converts the signals to analog and sends them to either the rear entertainment module (RETM), or the accessory protocol interface module (APIM) (if equipped).

The satellite audio signals utilize separate circuitry from the remaining audio signals. This allows the audio control module (ACM) to distinguish between satellite and SYNC or DVD audio, in order to provide for more dual-play options.

If there is an open in the satellite radio antenna circuit, there will be no satellite audio. The ACM display will indicate a satellite antenna concern (the method varies according to the type of ACM) when the audio system is operated in satellite radio mode. To diagnose an open in the satellite radio antenna circuit, go to Pinpoint Test H .

This pinpoint test is intended to diagnose the following

1. Subscription status
2. Wiring, terminals or connectors
3. SDARS module
4. RETM
5. APIM (if equipped)
6. ACM

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

1. J1 VERIFY AN ACTIVE SUBSCRIPTION Enter satellite mode on the ACM and observe the display. Does the display read CALL SIRIUS? YES : The subscription has expired. INFORM the customer to contact Sirius to re-activate the subscription. NO : If the display indicates a satellite antenna fault, go to «Pinpoint Test H»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-h-poor-receptionno-sound) . Otherwise, go to J2 .
2. J2 CHECK FOR NON-NETWORK DTCs Carry out the SDARS module self-test using the scan tool. Are any non-network DTCs present? YES : For DTC B1031 or DTC B1032, go to «Pinpoint Test H»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-h-poor-receptionno-sound) . For all other DTCs, REFER to «DTC Tables»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__dtc-tables) . NO : Go to J3 .
3. J3 CHECK FOR COMMUNICATION WITH THE ACM AND APIM Carry out the network test using the scan tool. Does the scan tool communicate with the ACM and the APIM (if equipped)? YES : Go to J4 . NO : REFER to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article to diagnose no communication with the ACM or APIM.
4. J4 CHECK FOR LOST COMMUNICATION DTCs Key in ON position. Using the scan tool, clear any ACM and SDARS module continuous DTCs. Key in OFF position. Key in ON position. Wait at least 10 seconds. Retrieve the ACM and SDARS module continuous DTCs. Is DTC U0184 (SDARS module), U0193 (ACM), or U0197 (SDARS module, if equipped with the SYNC system) present? YES : For DTC U0184, go to J15 . For DTC U0193, go to J13 . For DTC U0197, go to J14 . NO : Go to J5 .
5. J5 CHECK THE SATELLITE AUDIO OUTPUT Enter the following diagnostic mode on the diagnostic tool: Electrical -> Audio -> Tones Test -> Satellite Digital Audio Receiver System Carry out the SDARS module tones test using the scan tool. Are alternating LH/RH tones audible? YES : Go to J13 . NO : Go to J6 .
6. J6 CHECK THE OPERATION OF THE DVD AUDIO Insert a known good DVD, and operate the audio system in DVD single-play mode. Observe the audio output from the DVD. Does the DVD audio operate correctly? YES : If the vehicle is equipped with the SYNC system, go to J7 . Otherwise, go to J11 . NO : Go to «Pinpoint Test G»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-g-the-video-system) .
7. J7 CHECK THE AUDIO CIRCUITS TO THE APIM FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: APIM C3342 Disconnect: SDARS Module C4344 Key in ON position. Measure the voltage between the SDARS module, harness side and ground as follows: Connector-Pin Circuit C4344-5 VME41 (GN/OG) C4344-6 VME42 (VT/BN) C4344-11 RME41 (GN/OG) C4344-12 RME42 (YE/BU) Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to J8 .
8. J8 CHECK THE AUDIO CIRCUITS TO THE APIM FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Key in ON position. Measure the resistance between the SDARS module, harness side and the APIM, harness side; and between the SDARS module, harness side and ground as follows: SDARS Module Connector-Pin APIM Connector-Pin Circuit C4344-5 C3342-10 VME41 (GN/OG) C4344-6 C3342-7 VME42 (VT/BN) C4344-11 C3342-11 RME41 (GN/OG) C4344-12 C3342-8 RME42 (YE/BU) Is the resistance less than 5 ohms between the SDARS module and the APIM, and greater than 10,000 ohms between the SDARS module and ground? YES : Go to J9 . NO : REPAIR the circuit in question. TEST the system for normal operation.
9. J9 CHECK THE AUDIO CIRCUITS FROM THE APIM TO THE RETM FOR A SHORT TO VOLTAGE Disconnect: RETM C9029 Key in ON position. Measure the voltage between the RETM, harness side and ground as follows: Connector-Pin Circuit C9029-5 VME58 (YE/VT) C9029-6 RME58 (BN/BU) C9029-21 VME59 (YE/OG) C9029-22 RME59 (WH/GN) Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to J10 .
10. J10 CHECK THE AUDIO CIRCUITS FROM THE APIM TO THE RETM FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the APIM, harness side and the RETM, harness side; and between the APIM, harness side and ground as follows: APIM Connector-Pin RETM Connector-Pin Circuit C3342-40 C9029-5 VME58 (YE/VT) C3342-41 C9029-21 VME59 (YE/OG) C3342-42 C9029-6 RME58 (BN/BU) C3342-43 C9029-22 RME59 (WH/GN) Is the resistance less than 5 ohms between the APIM and the RETM, and greater than 10,000 ohms between the APIM and ground? YES : Go to J13 . NO : REPAIR the circuit in question. TEST the system for normal operation.
11. J11 CHECK THE AUDIO CIRCUITS TO FROM THE SDARS MODULE FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: SDARS Module C4344 Disconnect: RETM C9029 Measure the voltage between the SDARS module, harness side and ground as follows: Connector-Pin Circuit C4344-5 VME41 (GN/OG) C4344-6 VME42 (VT/BN) C4344-11 RME41 (GN/OG) C4344-12 RME42 (YE/BU) Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to J12 .
12. J12 CHECK THE AUDIO CIRCUITS TO FROM THE SDARS MODULE FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the SDARS module, harness side and the RETM, harness side; and between the SDARS module, harness side and ground as follows: SDARS Module Connector-Pin RETM Connector-Pin Circuit C4344-5 C9029-4 VME41 (GN/OG) C4344-6 C9029-3 RME41 (GN/OG) C4344-11 C9029-20 VME42 (VT/BN) C4344-12 C9029-19 RME42 (YE/BU) Is the resistance less than 5 ohms between the SDARS module and the RETM, and greater than 10,000 ohms between the SDARS module and ground? YES : Go to J13 . NO : REPAIR the circuit in question. TEST the system for normal operation.
13. J13 ISOLATE THE SDARS MODULE Key in OFF position. Connect: RETM C9029 Connect: APIM C3342 (If Equipped) Install a new SDARS module. Refer to «Satellite Digital Audio Receiver System (SDARS) Module»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . Operate the audio system in satellite radio mode. Does the system operate correctly? YES : The concern was caused by an inoperative SDARS module. The system is operating correctly at this time. NO : If equipped with the SYNC system, go to J14 . Otherwise, go to J15 .
14. J14 CHECK FOR CORRECT APIM OPERATION Connect: All Disconnected Connectors Disconnect the APIM connector. Check for: corrosion damaged pins pushed-out pins Connect the APIM connector and make sure it seats correctly. Wait 2 minutes for the APIM to re-initalize. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new APIM. REFER to «Accessory Protocol Interface Module (APIM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__accessory-protocol-interface-module-apim) . TEST the system for normal operation. If the concern is still present, go to J15 . NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
15. J15 CHECK FOR CORRECT ACM OPERATION Connect: All Disconnected Connectors Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and determine if the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test K: The Audio Input Jack Is Inoperative/Does Not Operate Correctly

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

Normal Operation - Vehicles Without the SYNC System

Audio signals are sent from the audio input jack to the audio control module (ACM). There are no external power or ground circuits to the audio input jack.

Vehicles With the SYNC System

Audio signals are sent from the audio input jack to the accessory protocol interface module (APIM). The signals are then sent to the ACM. There are no external power or ground circuits to the audio input jack.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Audio input jack
3. ACM
4. APIM (if equipped)

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Before carrying out this pinpoint test, make sure the MP3 device is operating correctly.

1. K1 CHECK THE AUDIO INPUT JACK AUDIO Connect: Known Good MP3 Device (to Audio Input Jack) Using the known good MP3 device, attempt to play a file using the audio input jack. Does the file play correctly? YES : The system is operating correctly at this time. The concern may be with the customer device. NO : Go to K2 .
2. K2 DETERMINE THE VEHICLE CONTENT Disconnect: Known Good MP3 Device (From Audio Input Jack) Determine if the vehicle is equipped with the SYNC system. Is the vehicle equipped with the SYNC system? YES : Go to K3 . NO : Go to K4 .
3. K3 CHECK THE APIM AUDIO OUTPUT Attempt to play an audio file using either the universal serial bus (USB) port or a Bluetooth® device. Is the audio output OK for devices connected through the USB port or Bluetooth®? YES : Go to K4 . NO : Go to «Pinpoint Test R»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-r-unable-to-pair) .
4. K4 CHECK THE AUDIO INPUT JACK CIRCUITS FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: Audio Input Jack C3312 Disconnect: ACM C240c or APIM C3342 (If Equipped) Key in ON position. Measure the voltage between the audio input jack, harness side and ground as follows: Connector-Pin Circuit C3312-1 VME46 (BU/GN) C3312-2 RME46 (WH/GN) C3312-3 RME45 (YE/GN) C3312-4 VME45 (BU) Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to K5 .
5. K5 CHECK THE AUDIO INPUT JACK CIRCUITS FOR AN OPEN OR SHORT TO GROUND Key in OFF position. For vehicles without the SYNC system, measure the resistance between the audio input jack, harness side and the ACM, harness side; and between the audio input jack, harness side and ground as follows: Audio Input Jack Connector-Pin ACM Connector-Pin Circuit C3312-1 C240c-6 VME46 (BU/GN) C3312-2 C240c-14 RME46 (WH/GN) C3312-3 C240c-8 RME45 (YE/GN) C3312-4 C240c-7 VME45 (BU) For vehicles with the SYNC system, measure the resistance between the audio input jack, harness side and the APIM, harness side; and between the audio input jack, harness side and ground as follows: Audio Input Jack Connector-Pin APIM Connector-Pin Circuit C3312-1 C3342-47 VME46 (BU/GN) C3312-2 C3342-48 RME46 (WH/GN) C3312-3 C3342-46 RME45 (YE/GN) C3312-4 C3342-45 VME45 (BU) Is the resistance less than 5 ohms between the audio input jack and the ACM (or APIM), and greater than 10,000 ohms between the audio input jack and ground? YES : Go to K6 . NO : REPAIR the circuit in question. TEST the system for normal operation.
6. K6 SUBSTITUTE THE AUDIO INPUT JACK Connect: ACM C240c or APIM C3342 (If Equipped) Install a known good audio input jack. Operate the audio system using a device plugged into the audio input jack. Does the system operate correctly? YES : INSTALL a new audio input jack. REFER to «Audio Input Jack»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__audio-input-jack) . TEST the system for normal operation. NO : INSTALL the original audio input jack. For vehicles without the SYNC system, go to K7 . For vehicles with the SYNC system, go to K8 .
7. K7 CHECK FOR CORRECT ACM OPERATION Key in OFF position. Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and determine if the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
8. K8 CHECK FOR CORRECT APIM OPERATION Connect: All Disconnected Connectors Disconnect the APIM connector. Check for: corrosion damaged pins pushed-out pins Connect the APIM connector and make sure it seats correctly. Wait 2 minutes for the APIM to re-initalize. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new APIM. REFER to «Accessory Protocol Interface Module (APIM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__accessory-protocol-interface-module-apim) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

The global positioning system (GPS) antenna provides information from the GPS satellite system to the GPS receiver in the navigation audio control module (ACM). This information is used to calculate vehicle position and direction of travel.

1. DTC 2204 (GPS Antenna Connection Open or Short) - sets when an open, short to ground, or short to voltage is detected in the GPS antenna circuit.

This pinpoint test is intended to diagnose the following

1. GPS antenna
2. Audio control module (ACM)

Scheme 17

1. L1 CHECK THE OPERATION OF THE GPS ICON Move the vehicle outside of any enclosed structure to an area that is unobstructed by trees, tall buildings, and bridges. Operate the audio system in navigation mode. Does the GPS icon appear, then disappear? YES : The system is operating correctly at this time. NOTIFY the customer that obstructions to the line of sight may affect the GPS antenna. NO : Go to L2 .
2. L2 CHECK THE ACM RECORDED DTCs Check the recorded DTCs from the ACM self-test. Is DTC B2204 recorded? YES : Go to L4 . NO : Go to L3 .
3. L3 CHECK THE GPS ANTENNA MOUNTING Verify the GPS antenna is installed correctly and no aftermarket equipment is obstructing the antenna. Is the GPS antenna mounted correctly? YES : Go to L4 . NO : Correctly INSTALL the GPS antenna. REFER to «Global Positioning System (GPS) Antenna»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__global-positioning-system-gps-antenna) . TEST the system for normal operation.
4. L4 SUBSTITUTE THE GPS ANTENNA Install a known good GPS antenna. Move the vehicle outside of any enclosed structure to an area that is unobstructed by trees, tall buildings, and bridges. Operate the audio system in navigation mode. Does the GPS icon appear, then disappear? YES : INSTALL a new GPS antenna. REFER to «Global Positioning System (GPS) Antenna»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__global-positioning-system-gps-antenna) . CLEAR the DTCs. REPEAT the self-test. NO : INSTALL the original GPS antenna. Go to L5 .
5. L5 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

The audible switch feedback settings are controlled by the audio control module (ACM). The audible switch feedback can be set to ALL, TOUCH SCREEN, or NONE, depending on user preference.

This pinpoint test is intended to diagnose the following

1. Audible switch feedback setting
2. ACM

Scheme 18

1. M1 CHECK THE SWITCH DISPLAY Key in ON position. Turn the ACM on. Press the MENU button. Select the FEEDBACK tab. Is NONE highlighted on the audible feedback settings? YES : SELECT "ALL BUTTONS". TEST the system for normal operation. NO : Go to M2 .
2. M2 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

The voice guidance settings are controlled by the audio control module (ACM). The voice guidance volume can be adjusted or turned off depending on user preference.

This pinpoint test is intended to diagnose the following

1. Incorrect system setting
2. ACM

PINPOINT TEST N: THE VOICE GUIDANCE IS INOPERATIVE/DOES NOT OPERATE CORRECTLY

1. N1 CHECK THE VOICE GUIDANCE SETTINGS Key in ON position. Turn the ACM on. Press the MENU button. Select the FEEDBACK tab. Select DEFAULT SETTING. Verify the voice guidance operation. Does the voice guidance operate correctly? YES : The system is operating correctly at this time. The concern was caused by a customer-selected setting. NO : Go to N2 .
2. N2 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

The primary source of vehicle location for the navigation system is the audio control module (ACM) receiving the position signal through the global positioning system (GPS) antenna.

In addition, the ACM receives the wheel pulse signal from the instrument cluster (IC) (which gateways the signal from the ABS module). This secondary signal is used to calculate vehicle position when the GPS signal is lost. It also supports the adaptive learning function of the ACM, whereby the ACM can compensate for long-term differences between the GPS signal location, and the actual distance traveled by the vehicle.

1. DTC B2204 (GPS Antenna Connection Open or Short) - sets when an open, short to ground, or short to voltage is detected in the GPS antenna circuit. If DTC B2204 is present, go to «Pinpoint Test L»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) .
2. DTC U0155 (Lost Communication With Instrument Panel Cluster [IC] Control Module) - sets when the ACM is missing messages from the instrument cluster for greater than 5 seconds.
3. DTC U2473 (Unexpected Vehicle Speed [VSS]) - sets when the calculated vehicle distance traveled based on the wheel pulse signal does not agree with the GPS antenna location. To do this, the ACM compares the wheel pulse signal during a 4-second range, and compares it with the change in GPS antenna location. If the ACM finds that the variation is greater than 0.5% after performing this check 4 times, it sets DTC U2473. When DTC U2473 is set, the adaptive learn function is disabled. This DTC is also set when the navigation rolling wheel count signal is missing for greater than 2 seconds with the key in RUN.

This pinpoint test is intended to diagnose the following

1. GPS antenna
2. VSS signal concern
3. ACM

PINPOINT TEST O: THE POSITION CURSOR IS INACCURATE

1. O1 CHECK THE OPERATION OF THE NAVIGATION SYSTEM Move the vehicle outside of any enclosed structure to an area that is unobstructed by trees, tall buildings, and bridges. Operate the audio system in navigation mode. Does the GPS icon appear, then disappear? YES : Go to O2 . NO : Go to «Pinpoint Test L»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) .
2. O2 CHECK THE ACM DTCs Review the DTCs from the ACM self-test. Is DTC U2473 present? YES : Go to O3 . NO : Go to «Pinpoint Test L»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) .
3. O3 CHECK FOR COMMUNICATION WITH THE IC Carry out the network test using the scan tool. Does the scan tool communicate with the IC? YES : Go to O4 . NO : REFER to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article.
4. O4 CHECK THE IC AND ABS MODULE DTCs Carry out the self-test for the IC and the ABS module. Are any DTCs recorded? YES : REFER to «INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES»(/ford/taurus-x/i-2007-2009/remont/gauges-instrument-panels/#information-center) article (IC) or «VEHICLE DYNAMIC SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/anti-locktraction-control/#anti-lock-brake-system) article (ABS module) to diagnose a fault in the wheel pulse signal. NO : Go to O5 .
5. O5 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test P: Voice Recognition Is Inoperative/Does Not Operate Correctly - Vehicles Without The SYNC System

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

When the VOICE button (an icon of someone speaking) is pressed, the audio control module (ACM) detects the change in reference voltage on circuit VME14 (GY/YE) and enters voice recognition mode. A microphone located in the interior rear view mirror receives the voice command and sends a signal to the ACM through circuits VMN02 (WH/BN) and RMN02 (VT/BN). Power to the interior rear view mirror is provided through circuit CBP41 (BU), and ground through circuit GD133 (BK).

The microphone test is available through the integrated diagnostic system (IDS). Running this test causes the ACM to produce a test tone. If the system is operating correctly, the microphone detects the tone and produces a signal to the ACM indicating the tone was heard.

1. DTC B2633 (Driver-Front Microphone Circuit Failure) - set by the ACM during the microphone test when the ACM does not receive an adequate signal from the microphone when the test tone is sounded.

This pinpoint test is intended to diagnose the following

1. Fuse
2. Wiring, terminals or connectors
3. Steering wheel controls
4. Microphone (part of the interior rear view mirror)
5. ACM

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 19

Scheme 20

Scheme 21

1. P1 CHECK THE OPERATION OF THE STEERING WHEEL CONTROL SWITCHES Operate the audio system in radio tuner (AM/FM) mode. Press the VOICE button on the steering wheel controls. Does the audio system enter voice recognition mode? YES : Go to P2 . NO : Go to «Pinpoint Test E»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-e-the-steering-wheel) to diagnose the steering wheel controls system.
2. P2 CHECK CIRCUIT CBP41 (BU) FOR VOLTAGE Key in OFF position. Disconnect: Interior Rear View Mirror C9012 Key in ON position. Measure the voltage between the interior rear view mirror C9012-1, circuit CBP41 (BU), harness side and ground. Is the voltage greater than 10 volts? YES : Go to P3 . NO : VERIFY the smart junction box (SJB) fuse 41 (10A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation. If not OK, REFER to the Wiring Diagrams Manual to identify the possible sources of the circuit short.
3. P3 CHECK CIRCUIT GD133 (BK) FOR AN OPEN Key in OFF position. Measure the resistance between the interior rear view mirror C9012-10, circuit GD133 (BK), harness side and ground. Is the resistance less than 5 ohms? YES : Go to P4 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
4. P4 CHECK THE MICROPHONE CIRCUITS FOR A SHORT TO VOLTAGE Disconnect: ACM C240c Key in ON position. Measure the voltage between the interior rear view mirror C9012-4, circuit VMN02 (WH/BN), harness side and ground; and between the interior rear view mirror C9012-5, circuit RMN02 (VT/BN), harness side and ground. Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to P5 .
5. P5 CHECK THE MICROPHONE CIRCUITS FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the inside rear view mirror, harness side and the ACM, harness side; and between the rear view mirror, harness side and ground as follows: Interior Rear View Mirror Connector-Pin ACM Connector-Pin Circuit C9012-4 C240c-11 VMN02 (WH/BN) C9012-5 C240c-12 RMN02 (VT/BN) Is the resistance less than 5 ohms between the interior rear view mirror and the ACM, and greater than 10,000 ohms between the interior rear view mirror and ground? YES : Go to P6 . NO : REPAIR the circuit in question. CLEAR the DTCs. REPEAT the self-test.
6. P6 ISOLATE THE INTERIOR REAR VIEW MIRROR Connect: ACM C240c Install a new interior rear view mirror. Refer to «REAR VIEW MIRRORS»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) article. Operate the audio system in radio tuner (AM/FM) mode. Press the VOICE button on the steering wheel controls and attempt several voice commands. For additional information, refer to the Owner's Literature. Does the voice recognition operate correctly? YES : The concern was caused by an inoperative interior rear view mirror. The system is now operating correctly. NO : Go to P7 .
7. P7 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat correctly. Connect any disconnected connectors. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

The accessory protocol interface module (APIM) receives voltage at all times from circuit SBP03 (BU/RD), and ground through circuit GD103 (BK/BU). The wake-up signal is sent to the APIM by the audio control module (ACM) via the medium speed controller area network (MS-CAN).

1. DTC U0184 (Lost Communication With Radio [ACM]) - set by the APIM when it is missing messages from the ACM over the MS-CAN for greater than 5 seconds.
2. DTC U0196 (Lost Communication With Entertainment Control Module - Rear [AUX]) - set by the APIM when it is missing messages from the RETM over the MS-CAN for greater than 5 seconds.
3. DTC U0197 (Lost Communication With Telephone Control Module) - set by the ACM when it is missing messages from the APIM over the MS-CAN for greater than 5 seconds.

This pinpoint test is intended to diagnose the following

1. Audio system concern
2. Communication network concern
3. Customer error
4. Customer device
5. APIM
6. ACM

PINPOINT TEST Q: THE SYNC SYSTEM IS COMPLETELY INOPERATIVE

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

1. Q1 CHECK THE AUDIO SYSTEM OPERATION Press the AUX button repeatedly until "SYNC LINE IN" appears on the display (except navigation), or look for the presence of the "USER DEVICE" tab (navigation). Is "SYNC LINE IN" available when pressing the AUX button (except navigation), or is the "USER DEVICE" tab present (navigation)? YES : Go to Q2 . NO : Go to Q3 .
2. Q2 CHECK THE SYNC SYSTEM OPERATION NOTE: Carrying out a Master Reset will return all preference settings to the factory defaults, erase all the phone book and call histories and delete any devices paired with the SYNC system. Connect: Known Good MP3 Device (To Audio Input Jack) NOTE: Make sure no universal serial bus (USB) device is plugged-in, and no Bluetooth® device is active for this step. Using the ACM buttons, press AUX until "SYNC LINE IN" appears on the display (except navigation), or press MEDIA, select "USER DEVICE", and press "SOURCE" repeatedly until "LINE IN" appears (navigation). Using the known good MP3 device, attempt to play a file using the audio input jack. Disconnect: Known Good MP3 Device (From Audio Input Jack) Connect: Known Good USB Device (To USB Port) Using the ACM buttons, press AUX until "SYNC USB" appears on the display (except navigation), or press MEDIA, select "USER DEVICE", and press "SOURCE" repeatedly until "USB" appears (navigation). NOTE: If a USB mass storage device is used to play the audio file, the SYNC system will only play audio files that do not have digital rights management (DRM) protection. Using a known good MP3 device or mass storage device, attempt to play a file using the USB port. Disconnect: Known Good USB Device (From USB Port) Using a known good Bluetooth® device, attempt to pair to the APIM using Bluetooth®, and attempt to play an audio file using the Bluetooth® connection. Refer to the Owner's Literature. Do all of the SYNC inputs function correctly? YES : The SYNC system is operating correctly at this time. CARRY OUT a SYNC system Master Reset. For vehicles without navigation, PRESS the "PHONE" button on the steering wheel controls, SCROLL until "SYSTEM SETTINGS" displays on the screen, PRESS "OK", SCROLL until "ADVANCED" displays on the screen, PRESS "OK", SCROLL until "MASTER RESET" displays on the screen, and PRESS "OK" twice. For vehicles with navigation, PRESS "PHONE" on the ACM display, SELECT the "SETTINGS" tab, PRESS "ADVANCED", SELECT "Master Reset", and PRESS "YES". REVIEW the pairing process with the customer. If the customer device still does not pair, the fault is with the customer device. NO : If only some of the inputs are inoperative, go to «Symptom Chart - SYNC System»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) to diagnose the observed symptom. If all inputs are inoperative, go to «Pinpoint Test U»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-u-poor-qualitydistortedno-sound) .
3. Q3 CHECK FOR SCAN TOOL COMMUNICATION Carry out the network test using the scan tool. Does the APIM pass the network test? YES : Go to Q4 . NO : REFER to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article.
4. Q4 CHECK FOR CORRECT APIM OPERATION Connect: All Disconnected Connectors Disconnect the APIM connector. Check for: corrosion damaged pins pushed-out pins Connect the APIM connector and make sure it seats correctly. Wait 2 minutes for the APIM to re-initalize. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new APIM. REFER to «Accessory Protocol Interface Module (APIM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__accessory-protocol-interface-module-apim) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

When a new Bluetooth® device is added, the accessory protocol interface module (APIM) and the Bluetooth® device must be paired together. Most Bluetooth® devices will pair with the SYNC system, although functionality will vary. To determine if a Bluetooth® device is supported, retrieve the consumer interface processor (CIP) software level using the Accessory Protocol Interface Module (APIM) Software Level Check , and verify the customer device is on the compatibility list for the current CIP software level.

Pairing a Bluetooth® device is accomplished through the "Add Device" selection of the phone menu. When pairing a device, the SYNC system generates a unique personal identification number (PIN) that must be entered on the Bluetooth® device in order for the pairing process to be successful. There are also some device-specific actions that must take place. For additional information on the pairing process, refer to the Owner's Literature.

This pinpoint test is intended to diagnose the following

1. Incompatible Bluetooth® device
2. Customer error
3. Customer Bluetooth® device
4. APIM

PINPOINT TEST R: UNABLE TO PAIR BLUETOOTH® DEVICE

1. R1 CHECK THE BLUETOOTH® CONNECTION NOTE: Carrying out a Master Reset will return all preference settings to the factory defaults, erase all the phone book and call histories and delete any devices paired with the SYNC system. Using a known good Bluetooth® device, attempt to pair to the SYNC system using Bluetooth®. Refer to the Owner's Literature. Enter the following diagnostic mode on the diagnostic tool: APIM DataLogger Monitor the BT_PAIR (Bluetooth® device paired) and BT_CONN (Bluetooth® device connected) PIDs. Do the BT_PAIR and BT_CONN PIDs both read "Yes"? YES : The SYNC system is operating correctly at this time. CARRY OUT a SYNC system Master Reset. For vehicles without navigation, PRESS the "PHONE" button on the steering wheel controls, SCROLL until "SYSTEM SETTINGS" displays on the screen, PRESS "OK", SCROLL until "ADVANCED" displays on the screen, PRESS "OK", SCROLL until "MASTER RESET" displays on the screen, and PRESS "OK" twice. For vehicles with navigation, PRESS "PHONE" on the ACM display, SELECT the "SETTINGS" tab, PRESS "ADVANCED", SELECT "Master Reset", and PRESS "YES". REVIEW the pairing process with the customer. If the customer device still does not pair, the fault is with the customer device. NO : Go to R2 .
2. R2 CHECK FOR CORRECT APIM OPERATION Connect: All Disconnected Connectors Disconnect the APIM connector. Check for: corrosion damaged pins pushed-out pins Connect the APIM connector and make sure it seats correctly. Wait 2 minutes for the APIM to re-initalize. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new APIM. REFER to «Accessory Protocol Interface Module (APIM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__accessory-protocol-interface-module-apim) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

The universal serial bus (USB) port is connected to the accessory protocol interface module (APIM) through the USB cable. The USB port can be used to play audio files or upload software from mass storage devices, or for connecting a media device.

If supported by the user device, the USB can provide charging. Because of this feature, when a USB device is plugged into the USB port, the SYNC system does not automatically switch to the device.

The USB cable and port are not serviceable separately.

1. DTC U261C (USB #1 Device Error) - sets when the APIM detect an over-current or over-temperature condition in the USB circuit. This can be caused by a fault in the USB cable or port, or by the customer USB device.

This pinpoint test is intended to diagnose the following

1. Customer USB device
2. USB cable and port
3. APIM

PINPOINT TEST S: THE UNIVERSAL SERIAL BUS (USB) PORT IS INOPERATIVE/DOES NOT OPERATE CORRECTLY

1. S1 CHECK THE USB CONNECTION Connect: Known Good USB Device (To USB Port) Using the ACM buttons, press AUX until "SYNC USB" appears on the display (except navigation), or press MEDIA, select "USER DEVICE", and press "SOURCE" repeatedly until "USB" appears (navigation). NOTE: If a USB mass storage device is used to play the audio file, SYNC will only play audio files that do not have digital rights management (DRM) protection. Using a known good MP3 or mass storage device, attempt to play an audio file using the USB port. Does the known good device successfully play an audio file using the USB connection? YES : The SYNC system is operating correctly. REVIEW the operation of the USB port with the customer. If the customer device still does not operate correctly, the fault is with the customer device. NO : Go to S2 .
2. S2 INSPECT THE USB CABLE Key in OFF position. Disconnect: USB Cable (At APIM) Inspect the USB cable for damage. Connect: USB Cable (AT APIM) Key in ON position. Using the ACM buttons, press AUX until "SYNC USB" appears on the display (except navigation), or press MEDIA, select "USER DEVICE", and press "SOURCE" repeatedly until "USB" appears (navigation). Using a known good MP3 or mass storage device, attempt to play an audio file using the USB port. Does the known good device successfully play the audio file using the USB connection? YES : The concern was caused by the USB connection not being seated correctly. The system is now operating correctly. NO : Go to S3 .
3. S3 ISOLATE THE USB CABLE AND PORT Disconnect: Known Good USB Device (From USB Port) Install a new USB cable and port. Refer to «Universal Serial Bus (USB) Cable and Port»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__universal-serial-bus-usb-cable-and) . Connect: Known Good USB Device (To USB Port) Using the ACM buttons, press AUX until "SYNC USB" appears on the display (except navigation), or press MEDIA, select "USER DEVICE", and press "SOURCE" repeatedly until "USB" appears (navigation). Using a known good MP3 or mass storage device, attempt to play an audio file using the USB port. Does the known good device successfully play an audio file using the USB connection? YES : The concern was caused by an inoperative USB cable. The system is now operating correctly. NO : Go to S4 .
4. S4 CHECK FOR CORRECT APIM OPERATION Connect: All Disconnected Connectors Disconnect the APIM connector. Check for: corrosion damaged pins pushed-out pins Connect the APIM connector and make sure it seats correctly. Wait 2 minutes for the APIM to re-initalize. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new APIM. REFER to «Accessory Protocol Interface Module (APIM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__accessory-protocol-interface-module-apim) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test T: The SYNC System Audible Prompts Are Inoperative/Do Not Operate Correctly

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

The text-to-speech (TTS) and voice prompt features speak certain text information and interaction requests in order to minimize driver distraction by having to look at the audio control module (ACM) while driving. The ring tone alerts the driver to an incoming call.

Audible prompts can range from a simple tone to more elaborate spoken text, based on the customer setting. When interaction mode is set to standard, detailed guidance is provided. When interaction mode is set to advanced, most prompts are tones only and minimal audible guidance is provided. Refer to the Owner's Literature for further information on voice interaction.

The audio signals for the TTS and voice prompt features, the ring tones, and audio from the outside device during a phone call, are sent from the accessory protocol interface module (APIM) to the ACM through circuits VMN14 (WH/VT) and RMN14 (GY/BN).

This pinpoint test is intended to diagnose the following

1. Customer setting
2. Wiring, terminals or connectors
3. ACM
4. APIM

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 22

1. T1 CHECK THE AUDIBLE PROMPT SETTING Operate the audio system in SYNC mode. Verify the audible prompts are enabled. Refer to "SYNC Voice Recognition Feature" in the Owner's Literature. Press the VOICE button on the steering wheel controls and observe the SYNC audible prompt. Does the SYNC system produce an audible prompt correctly? YES : The concern was caused by a customer setting. ADVISE the customer on the operation of the audible prompt feature. NO : Go to T2 .
2. T2 CHECK THE AUDIBLE PROMPT CIRCUITS FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: ACM C240c Disconnect: APIM C3342 Key in ON position. Measure the voltage between the APIM C3342-3, circuit VMN14 (WH/VT), harness side and ground; and between the APIM C3342-4, circuit RMN14 (GY/BN), harness side and ground. Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to T3 .
3. T3 CHECK THE AUDIBLE PROMPT CIRCUITS FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the APIM, harness side and the ACM, harness side; and between the APIM, harness side and ground as follows: APIM Connector-Pin ACM Connector-Pin Circuit C3342-3 C240c-4 VMN14 (WH/VT) C3342-4 C240c-5 RMN14 (GY/BN) Is the resistance less than 5 ohms between the APIM and the ACM, and greater than 10,000 ohms between the APIM and ground? YES : Go to T4 . NO : REPAIR the circuit in question. TEST the system for normal operation.
4. T4 CHECK FOR A VOLTAGE SIGNAL FROM THE APIM Connect: ACM C240c Connect: APIM C3342 Wait 2 minutes for the APIM to re-initialize. Operate the audio system in SYNC mode, and verify the audible prompts are enabled. Refer to "SYNC Voice Recognition Feature" in the Owner's Literature. While pressing the VOICE button repeatedly, measure the AC voltage by backprobing between the ACM C240c-4, circuit VMN14 (WH/VT), harness side and the ACM C240c-5, circuit RMN14 (GY/BN), harness side. Is an AC voltage produced each time the VOICE button is pressed? YES : Go to T5 . NO : Go to T6 .
5. T5 CHECK FOR CORRECT ACM OPERATION Key in OFF position. Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat properly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
6. T6 CHECK FOR CORRECT APIM OPERATION Connect: All Disconnected Connectors Disconnect the APIM connector. Check for: corrosion damaged pins pushed-out pins Connect the APIM connector and make sure it seats correctly. Wait 2 minutes for the APIM to re-initalize. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new APIM. REFER to «Accessory Protocol Interface Module (APIM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__accessory-protocol-interface-module-apim) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test U: Poor Quality/Distorted/No Sound While In SYNC Mode

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

The accessory protocol interface module (APIM) sends left and right channel analog audio signals through circuits VME41 (GN/OG), RME41 (BU/BN), VME42 (VT/BN), and RME42 (YE/BU). If the vehicle is equipped with a DVD entertainment system, these audio signals are sent to the rear entertainment module (RETM), then to the audio control module (ACM). In vehicles without a DVD entertainment system, the audio signals are sent directly to the ACM.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. RETM (if equipped)
3. ACM
4. APIM

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

1. U1 VERIFY THE OPERATION OF THE SYNC SYSTEM AUDIO SOURCES Connect: Known Good MP3 Device (To Audio Input Jack) NOTE: Make sure no universal serial bus (USB) device is plugged-in, and no Bluetooth®device is active for this step. Using the ACM buttons, press AUX until "SYNC LINE IN" appears on the display (except navigation), or press MEDIA, select "USER DEVICE", and press "SOURCE" repeatedly until "LINE IN" appears (navigation). Using the known good MP3 device, attempt to play an audio file using the audio input jack, and listen to the audio output. Disconnect: Known Good MP3 Device (From Audio Input Jack) Connect: Known Good USB Device (To USB Port) Using the ACM buttons, press AUX until "SYNC USB" appears on the display (except navigation), or press MEDIA, select "USER DEVICE", and press "SOURCE" repeatedly until "USB" appears (navigation). NOTE: If a USB mass storage device is used to play the audio file, the SYNC system will only play audio files that do not have digital rights management (DRM) protection. Using a known good MP3 device or a mass storage device, attempt to play a file using the USB port, and listen to the audio output. Disconnect: Known Good USB Device (From USB Port) Using a known good Bluetooth® device, attempt to pair to the APIM using Bluetooth®, and attempt to play an audio file using the Bluetooth® connection while listening to the audio output. Refer to the Owner's Literature. Is there poor quality/distorted sound from each SYNC audio source? YES : If the vehicle is equipped with a DVD entertainment system, go to U2 . Otherwise, go to U3 . NO : If the concern is only with some (but not all) of the audio sources, go to «Symptom Chart - SYNC System»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) to diagnose the observed symptom. If all audio sources operate correctly, the concern is with the customer device.
2. U2 CHECK THE OPERATION OF THE DVD AUDIO NOTE: Make sure a known good DVD is inserted in the RETM before carrying out this step. Operate the audio system in single-play DVD mode. Observe the audio output. Is there poor quality/distorted sound while in DVD mode? YES : Go to «Pinpoint Test G»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-g-the-video-system) . NO : Go to U3 .
3. U3 CHECK THE CIRCUITS FROM THE APIM FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: ACM C240c (Without DVD Entertainment) Disconnect: RETM C9029 (With DVD Entertainment) Disconnect: APIM C3342 Measure the voltage between the APIM, harness side and ground as follows: Connector-Pin Circuit C3342-23 VME42 (VT/BN) C3342-24 RME42 (YE/BU) C3342-25 VME41 (GN/OG) C3342-26 RME41 (BU/BN) Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to U4 .
4. U4 CHECK THE CIRCUITS FROM THE APIM FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the APIM, harness side, and the ACM or RETM (if equipped with DVD entertainment), harness side; and between the APIM, harness side and ground as follows: APIM Connector-Pin ACM or RETM Connector-Pin Circuit C3342-23 C240c-9 or C9029-20 VME42 (VT/BN) C3342-24 C240c-10 or C9029-19 RME42 (YE/BU) C3342-25 C240c-1 or C9029-4 VME41 (GN/OG) C3342-26 C240c-2 or C9029-3 RME41 (BU/BN) Is the resistance less than 5 ohms between the APIM and the ACM (or RETM), and greater than 10,000 ohms between the APIM and ground? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to U5 .
5. U5 CHECK FOR CORRECT APIM OPERATION Connect: All Disconnected Connectors Disconnect the APIM connector. Check for: corrosion damaged pins pushed-out pins Connect the APIM connector and make sure it seats correctly. Wait 2 minutes for the APIM to re-initalize. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new APIM. REFER to «Accessory Protocol Interface Module (APIM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__accessory-protocol-interface-module-apim) . TEST the system for normal operation. If the concern is still present and the vehicle is equipped with a DVD entertainment system, go to U6 . If the concern is still present and the vehicle is not equipped with a DVD entertainment system, go to U7 . NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
6. U6 CHECK FOR CORRECT RETM OPERATION Disconnect the RETM connector. Check for: corrosion damaged pins pushed-out pins Connect the RETM connector and make sure it seats correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new RETM. REFER to «Rear Entertainment Module (RETM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. If the concern is still present, go to U7 . NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
7. U7 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat properly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test V: Voice Recognition Is Inoperative/Does Not Operate Correctly - Vehicles With The SYNC System

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Audio System/Navigation for schematic and connector information.

When the VOICE button (represented by an icon of someone speaking) is pressed, it changes the reference voltage on circuit VME54 (BU/OG), and the audio system enters voice recognition mode. If the vehicle is equipped with navigation, the VOICE switch is wired to the audio control module (ACM). If the vehicle is not equipped with navigation, the VOICE switch is wired to the accessory protocol interface module (APIM). A microphone located in the interior rear view mirror receives the voice command and sends a signal to the APIM through circuits VMN02 (WH/BN) and RMN02 (VT/BN). The microphone is also used to detect outgoing audio during a phone call.

If the vehicle is equipped with navigation, the APIM receives the microphone input, and also broadcasts it to the ACM through circuits VMN02 (WH/BN) and RMN02 (VT/BN). This is to allow voice commands specific to the navigation system to be handled directly by the ACM. The first voice commands spoken determine which system handles the voice commands.

1. DTC B1038 (Microphone Input Circuit Failure) - set by the APIM during the on-demand self-test if the APIM does not detect the microphone.
2. DTC B2633 (Driver-Front Microphone Circuit Failure) - set by the ACM during the microphone test when the ACM does not receive an adequate signal from the microphone when the test tone is sounded.

This pinpoint test is intended to diagnose the following

1. Fuse
2. Wiring, terminals or connectors
3. Steering wheel controls
4. Microphone (part of the interior rear view mirror)
5. ACM (if equipped with navigation)
6. APIM

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 23

Scheme 24

1. V1 CHECK THE OPERATION OF THE STEERING WHEEL CONTROLS Operate the audio system in radio tuner (AM/FM) mode. Press the VOICE button on the steering wheel controls. Does the audio system enter voice recognition mode? YES : Go to V2 . NO : Go to «Pinpoint Test E»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__pinpoint-test-e-the-steering-wheel) to diagnose the steering wheel controls system.
2. V2 CHECK THE OPERATION OF THE VOICE RECOGNITION Press the VOICE button on the steering wheel controls. Wait for the SYNC system to acknowledge the VOICE button being pressed. While still in voice recognition mode, speak the command "PHONE", and observe the audio system. Does the SYNC system acknowledge the command "PHONE"? YES : If the vehicle is equipped with navigation, go to V3 . Otherwise, the system is operating correctly at this time. ADVISE the customer on the correct operation of the voice recognition system. NO : Go to V6 .
3. V3 CHECK THE MICROPHONE SIGNAL TO THE ACM Key in OFF position. Disconnect: ACM C240c NOTE: ACM C240a must remain connected for this step to produce accurate results. Operate the audio system in radio tuner (AM/FM) mode. Press the VOICE button on the steering wheel controls. While speaking a command, measure the AC voltage between the ACM C240c-11, circuit VMN02 (WH/BN), harness side and the ACM C240c-12, circuit RMN02 (VT/BN), harness side. Is a fluctuating AC voltage present? YES : Go to V12 . NO : Go to V4 .
4. V4 CHECK THE MICROPHONE CIRCUITS TO THE ACM FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: APIM C3342 Key in ON position. Measure the voltage between the ACM C240c-11, circuit VMN02 (WH/BN), harness side and ground; and between the ACM C240c-12, circuit RMN02 (VT/BN), harness side and ground. Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to V5 .
5. V5 CHECK THE MICROPHONE CIRCUITS TO THE ACM FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the ACM, harness side and the APIM, harness side; and between the ACM, harness side and ground as follows: ACM Connector-Pin APIM Connector-Pin Circuit C240c-11 C3342-12 VMN02 (WH/BN) C240c-12 C3342-13 RMN02 (VT/BN) Is the resistance less than 5 ohms between the ACM and the APIM, and greater than 10,000 ohms between the ACM and ground? YES : Go to V11 . NO : REPAIR the circuit in question. TEST the system for normal operation.
6. V6 CHECK CIRCUIT CBP41 (BU) FOR VOLTAGE Key in OFF position. Disconnect: Interior Rear View Mirror C9012 Key in ON position. Measure the voltage between the interior rear view mirror C9012-1, circuit CBP41 (BU), harness side and ground. Is the voltage greater than 10 volts? YES : Go to V7 . NO : VERIFY the smart junction box (SJB) fuse 41 (10A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation. If not OK, REFER to the Wiring Diagrams Manual to identify the possible sources of the circuit short.
7. V7 CHECK CIRCUIT GD133 (BK) FOR AN OPEN Key in OFF position. Measure the resistance between the interior rear view mirror C9012-10, circuit GD133 (BK), harness side and ground. Is the resistance less than 5 ohms? YES : Go to V8 . NO : REPAIR the circuit. TEST the system for normal operation.
8. V8 CHECK THE MICROPHONE CIRCUITS FOR A SHORT TO VOLTAGE Disconnect: APIM C3342 Key in ON position. Measure the voltage between the interior rear view mirror C9012-4, circuit VMN02 (WH/BN), harness side and ground; and between the interior rear view mirror C9012-5, circuit RMN02 (VT/BN), harness side and ground. Is any voltage present? YES : REPAIR the circuit in question. TEST the system for normal operation. NO : Go to V9 .
9. V9 CHECK THE MICROPHONE CIRCUITS FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Measure the resistance between the inside rear view mirror, harness side and the APIM, harness side; and between the interior rear view mirror, harness side and ground as follows: Interior Rear View Mirror Connector-Pin APIM Connector-Pin Circuit C9012-4 C3342-5 VMN02 (WH/BN) C9012-5 C3342-6 RMN02 (VT/BN) Is the resistance less than 5 ohms between the interior rear view mirror and the APIM, and greater than 10,000 ohms between the interior rear view mirror and ground? YES : Go to V10 . NO : REPAIR the circuit in question. TEST the system for normal operation.
10. V10 ISOLATE THE INTERIOR REAR VIEW MIRROR Connect: APIM C3342 Install a new interior rear view mirror. Refer to «REAR VIEW MIRRORS»(/ford/taurus-x/i-2007-2009/remont/mirrors/#rear-view-mirror-system) article. Operate the audio system in radio tuner (AM/FM) mode. Press the VOICE button on the steering wheel controls, and attempt several voice commands. Does the voice recognition operate correctly? YES : The fault was caused by an inoperative interior rear view mirror. The system is now operating correctly. NO : Go to V11 .
11. V11 CHECK FOR CORRECT APIM OPERATION Connect: All Disconnected Connectors Disconnect the APIM connector. Check for: corrosion damaged pins pushed-out pins Connect the APIM connector and make sure it seats correctly. Wait 2 minutes for the APIM to re-initalize. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new APIM. REFER to «Accessory Protocol Interface Module (APIM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems__accessory-protocol-interface-module-apim) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
12. V12 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the ACM connectors and make sure they seat properly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new ACM. REFER to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Audio Systems Without Navigation

Note. The terms "Audio Control Module (ACM)" and "audio unit" refer to the same component.

1. Turn the ACM on.
2. Press and hold preset buttons 3 and 6 for 3 seconds. The speaker walk-around test will begin.
3. Before the speaker walk-around test is complete, press preset button 6.
4. Press the TUNE UP button.
5. Record the ACM part number.
6. Turn the ACM off.

Navigation Audio System

1. Turn the ACM on.
2. Press and hold preset buttons 3 and 6 for 3 seconds. The speaker walk-around test will begin.
3. Before the speaker walk-around test is complete, press END TEST on the display screen.
4. Select SYSTEM INFO from the menu.
5. Record the ACM part number.
6. Turn the ACM off.

1. Operate the audio system in satellite radio mode.
2. Press and hold the AUX button and preset button 1, simultaneously. The satellite radio receiver Electronic Serial Number (ESN) will be displayed on the screen.
3. Record the satellite radio receiver ESN.
4. Turn the audio system off.

Audio Systems With Navigation

1. Turn the audio system on.
2. Press the MENU button.
3. Select the SYSTEM INFO tab.
4. Record the satellite radio receiver ESN.
5. Turn the audio system off.

Accessory Protocol Interface Module (APIM) Software Level Check

Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Universal Serial Bus (USB) Male-A to Male-A Cable CCMUSB2-AM-AM-10 or equivalent

1. Turn the Audio Control Module (ACM) on.
2. Connect the scan tool to the Data Link Connector (DLC).
3. Connect one end of the Universal Serial Bus (USB) male-A to male-A cable to the scan tool.
4. Connect the other end of the USB male-A to male-A cable to the vehicle USB port.
5. From the technician service publication website, run On-Line Automotive Service Information System (OASIS) using Quick Start or by manually entering the Vehicle Identification Number (VIN).
6. From the OASIS tab, select the "Sync/APIM" bullet.
7. Select the "Read APIM" button to verify the current Accessory Protocol Interface Module (APIM) software level. The display shows both the Vehicle Interface Processor (VIP) and Consumer Interface Processor (CIP) software levels.
8. The scan tool displays the following information: Last Recorded State - Hardware VIN: vehicle identification number associated with the current APIM Installed date: date the APIM was installed Radio: currently identified ACM in the vehicle HW Part No.: APIM hardware part number Un-installed date: date (if any) the APIM was uninstalled S/N: APIM serial number Last Recorded State - Software Date/Time: date and time of last recorded software installation VIP: VIP software that was installed at that time CIP: CIP software that was installed at that time Description: a description of the content of the software revision History - Software Date/Time: date and time of any recorded software installation VIP: VIP software that was installed at that time CIP: CIP software that was installed at that time Description: a description of the content of the software revision Available Software for Programming Select: allows the software package to be selected Lineage: the original software release, if the software available is a revision VIP: VIP software level that is available with the selection CIP: CIP software level that is available with the selection Description: a description of the content of the software revision
9. Click a CIP software level to view the device compatibility list associated with the CIP software level, if desired.
10. To exit the APIM software level check, disconnect the scan tool from the DLC and the USB port, or exit the OASIS screen.

Antenna

Note. This procedure applies to all antennas except the sedan AM/FM antenna, which is part of the rear window glass.

Scheme 25

REMOVAL AND INSTALLATION

1. Remove the LH and RH D-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Remove the LH and RH C-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
3. Carefully lower the rear of the headliner to gain access to the antenna.
4. Loosen the antenna cable bolt and disconnect the cable from the antenna. To install, tighten to 7 Nm (62 lb-in).
5. Remove the antenna.
6. To install, reverse the removal procedure.

Antenna Cable - Satellite Radio

Note. Headliner shown removed for clarity.

Scheme 26

Note. Headliner and rear seat shown removed for clarity.

Scheme 27

Wagon

1. Remove the RH quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Remove the LH luggage compartment trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
3. Remove both C-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
4. Remove both D-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
5. Disconnect the satellite radio antenna cable-to-Satellite Digital Audio Receiver System (SDARS) module electrical connector.
6. Carefully lower the rear of the headliner to gain access to the satellite antenna.
7. Loosen the satellite radio antenna cable bolt and remove the satellite radio antenna cable. To install, tighten to 7 Nm (62 lb-in).
8. To install, reverse the removal procedure.

1. Remove the audio control module (ACM). For additional information, refer to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) .
2. Remove the A-pillar lower trim panel.
3. Lower the glove compartment door.
4. Disconnect the pin-type retainers for the lead-in cable.
5. Disconnect the antenna cable connection and remove the antenna lead-in cable.
6. To install, reverse the removal procedure.

Audio Input Jack

Note. Vehicle with the SYNC system shown, others similar.

Scheme 28

Scheme 29

1. Remove the floor shifter trim ring by pulling straight up to disengage the clips.
2. Remove the front floor console center finish panel by pulling straight up to disengage the clips.
3. Release the tabs and remove the audio input jack. Disconnect the electrical connector.
4. To install, reverse the removal procedure.

Scheme 30

Note. If installing a new navigation Audio Control Module (ACM), remove the navigation map DVD, if possible, before sending the ACM to an authorized audio system repair facility.

1. Upload the ACM configuration information to the scan tool. For additional information, refer to «MODULE CONFIGURATION»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-configuration-system) article.
2. Remove the instrument panel center finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(/ford/taurus-x/i-2007-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) article.
3. Remove the 4 screws and the ACM. Disconnect the electrical connectors and the antenna lead-in cable.
4. To install, reverse the removal procedure. Download the configuration information to the ACM. For additional information, refer to «MODULE CONFIGURATION»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-configuration-system) article.

Scheme 31

REMOVAL

Note. Programmable Module Installation (PMI) only needs to be carried out if the Rear Entertainment Module (RETM) is being replaced.

1. Upload the RETM configuration to the scan tool. For additional information, refer to «MODULE CONFIGURATION»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-configuration-system) article.
2. Remove the 4 screws.
3. Remove the RETM. Pull down on the sides of the RETM to disengage the clips from the bracket. Using a suitable tool, push the rear most U-hook forward and release the U-hooks. Hang the RETM on the J-hooks and disconnect the electrical connector. Remove the RETM from the J-hooks.

INSTALLATION

1. Hang the RETM on the J-hooks.
2. Connect the electrical connector.
3. Remove the RETM from the J-hooks.
4. Align the left side guide pin with the left side locating hole.
5. Lift up the right side of the RETM and engage the U-hooks.
6. Install the 4 screws.
7. Push on the left and right sides of the RETM to engage the clips.
8. Download the RETM configuration from the scan tool. For additional information, refer to «MODULE CONFIGURATION»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-configuration-system) article.

Door Speaker

Note. Premium speaker shown, others similar.

Scheme 32

1. Remove the door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Remove the 4 screws and the door speaker. Disconnect the electrical connector.
3. To install, reverse the removal procedure.

Global Positioning System (GPS) Antenna

Note. The passenger air bag module has been removed for clarity.

Scheme 33

1. Remove the Audio Control Module (ACM). For additional information, refer to «Audio Control Module (ACM)»(/ford/taurus-x/i-2007-2009/remont/entertainment-systems/#information-system-and-entertainment-systems) .
2. Open and lower the glove compartment door.
3. Release the 2 clips and remove the Global Positioning System (GPS) antenna.
4. To install, reverse the removal procedure.

Parcel Shelf Speaker

Note. Premium speaker shown, others similar.

Scheme 34

1. Remove the parcel shelf. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Remove the 4 screws and the parcel shelf speaker. Disconnect the electrical connector.
3. To install, reverse the removal procedure.

Scheme 35

Scheme 36

Wagon

1. Remove the RH quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Remove the LH luggage compartment trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
3. Remove the 4 bolts or 3 nuts and remove the Satellite Digital Audio Receiver System (SDARS) module. Disconnect the satellite radio antenna cable electrical connector. Disconnect the SDARS module jumper harness. To install, tighten to 7 Nm (62 lb-in) (sedan only).
4. To install, reverse the removal procedure.

Scheme 37

1. Remove the RH rear quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Remove the 4 nuts and the speaker enclosure. Disconnect the electrical connector.
3. To install, reverse the removal procedure.

Scheme 38

1. Remove the driver air bag module. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/taurus-x/i-2007-2009/remont/airbag/#supplemental-inflatable-restraint-system) article.
2. Remove the 2 screws and the steering wheel controls. Disconnect the electrical connector.
3. To install, reverse the removal procedure.

Scheme 39

Scheme 40

Sedan

1. Remove the LH rear trunk trim.
2. Remove the 3 nuts and the subwoofer amplifier. Disconnect the electrical connectors.
3. Remove the RH rear quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
4. Remove the 4 screws and the subwoofer amplifier. Disconnect the electrical connectors.
5. To install, reverse the removal procedure.

Scheme 41

1. Remove the RH rear quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Remove the speaker cushion.
3. Remove the 4 screws and the subwoofer speaker. Disconnect the electrical connector.
4. To install, reverse the removal procedure.

Accessory Protocol Interface Module (APIM)

Scheme 42

Scheme 43

Note. Accessory Protocol Interface Module (APIM) reprogramming is only necessary if a new module is being installed.

1. Verify the current APIM software and hardware level. For additional information, refer to APIM reprogramming in «MODULE CONFIGURATION»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-configuration-system) article.
2. Remove the 4 screws and the front floor console storage bin door.
3. Remove the floor shifter trim ring by pulling straight up to disengage the clips.
4. Remove the front floor console center finish panel by pulling straight up to disengage the clips.
5. Remove the 8 screws and the front floor console storage bin. Disconnect the electrical connectors.
6. Remove the 4 screws and the APIM. Disconnect the APIM electrical connector. Disconnect the Universal Serial Bus (USB) cable.
7. To install, reverse the removal procedure. Reprogram the APIM. For additional information, refer to «MODULE CONFIGURATION»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-configuration-system) article.

Universal Serial Bus (USB) Cable and Port

Scheme 44

1. Remove the floor shifter trim ring by pulling straight up to disengage the clips.
2. Remove the front floor console center finish panel by pulling straight up to disengage the clips.
3. Remove the Universal Serial Bus (USB) cable and port. Disconnect the USB cable and port-to-Accessory Protocol Interface Module (APIM) electrical connector. Disconnect the USB cable and port-to-bezel connector.
4. To install, reverse the removal procedure.

See also:
• GLASS, FRAMES AND MECHANISMS
• MODULE COMMUNICATIONS NETWORK
• CHARGING SYSTEM - GENERAL INFORMATION
• MODULE CONFIGURATION
• INSTRUMENT CLUSTER AND PANEL ILLUMINATION
• WIPERS AND WASHERS
• GENERATOR AND REGULATOR
• PARKING AID
• SUPPLEMENTAL RESTRAINT SYSTEM
• INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES
• VEHICLE DYNAMIC SYSTEMS
• REAR VIEW MIRRORS
• INTERIOR TRIM AND ORNAMENTATION
• INSTRUMENT PANEL AND CONSOLE
• DTC Tables
• Symptom Chart
• Pinpoint Test E
• Pinpoint Test C
• Pinpoint Test A
• Pinpoint Test D
• Pinpoint Test P
• Pinpoint Test B
• Pinpoint Test F
• Pinpoint Test O
• Pinpoint Test I
• Pinpoint Test J
• Pinpoint Test Q
• Pinpoint Test H
• Pinpoint Test V
• Accessory Protocol Interface Module (APIM)
• Pinpoint Test S
• Pinpoint Test U
• Pinpoint Test G
• Pinpoint Test K
• Pinpoint Test N
• Pinpoint Test R
• Pinpoint Test T
• Antenna Cable - Satellite Radio
• Antenna
• Door Speaker
• Parcel Shelf Speaker
• Audio Input Jack
• Global Positioning System (GPS) Antenna
• Accessory Protocol Interface Module (APIM) Software Level Check
• Universal Serial Bus (USB) Cable and Port
