TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Accelerator pedal and sensor assembly bolts | 9 |
TORQUE SPECIFICATIONS
The acceleration controls consist of the accelerator pedal and sensor assembly.
The engine management system electronically operates the throttle of the engine in response to throttle pedal movements initiated by the driver. In the event of a system failure, the engine management system provides a "limp home" mode which allows the car to be driven with limited performance.
Refer to the Introduction - Gasoline Engines article.
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | Accelerator pedal sensor electrical connector |
| 2 | W506015 | Fixed accelerator pedal and sensor upper retaining bolts (2 required) |
| 3 | W506104 | Fixed accelerator pedal and sensor lower retaining bolt |
| 4 | W506015 | Adjustable accelerator pedal and sensor retaining bolts (3 required) |
| 5 | 9F836 | Accelerator pedal and sensor assembly (fixed pedal assembly shown, adjustable pedal assembly similar) |
REMOVAL AND INSTALLATION
- Disconnect the accelerator pedal sensor electrical connector.
- Remove the 3 accelerator pedal and sensor retaining bolts. To install, tighten to 9 Nm (80 lb-in).
- Remove the accelerator pedal and sensor assembly.
- To install, reverse the removal procedure.
