Charging System - Generators & Regulators Ford Taurus X I

Charging System 1 illustration ~251 words

GENERAL SPECIFICATIONS

ItemSpecification
Generator
Generator pulley ratio2.66:1
Rating90/154 amp (max) @ 600-2,500 engine RPM
Second rating for Taurus X102/170 amp (max) @ 670-2,300 engine RPM
Voltage regulator typeElectronic internal with generator

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

DescriptionNm
Generator B+ nut12
Generator nut/bolts47
Generator stud8

TORQUE SPECIFICATIONS

The generator (including an internal voltage regulator) is belt-driven by the engine accessory drive system. When the engine is started, the generator begins to generate AC which is internally converted to DC. This current is then supplied to the vehicle electrical system through the output (B+) terminal of the generator.

A new voltage regulator and generator must be installed as an assembly. The B+ red radial adapter can be replaced as a separate component.

Scheme 11

Scheme 11: Generator
ItemPart NumberDescription
110346Generator
2Generator electrical connector (part of 14B060)
3Generator B+ terminal (part of 14B060)
4W705790Generator B+ nut
5W709986Generator bolt (lower)
6W709985Generator stud (replacement bolts, W709986-S437)
7W520414Generator stud nut
88620Front end accessory drive belt

REMOVAL AND INSTALLATION

  1. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/taurus-x/i-2007-2009/remont/body-electrical/#battery-mounting-and-cables) article.
  2. Remove the generator B+ nut and terminal. To install, tighten to 12 Nm (9 lb-ft).
  3. Disconnect the generator electrical connector and position the engine wiring harness aside.
  4. Position the upper radiator hose aside and remove the upper radiator hose cradle.
  5. Remove the 5 pin-type retainers from the wire harness across the top of the radiator and position the harness aside.
  6. Rotate the accessory drive belt tensioner and position the accessory drive belt aside.
  7. Remove the upper generator nut and stud. To install, tighten the generator stud to 8 Nm (71 lb-in). To install, tighten the generator nut to 47 Nm (35 lb-ft).
  8. Loosen the lower generator bolt. To install, tighten to 47 Nm (35 lb-ft).
  9. Remove the generator.
  10. To install, reverse the removal procedure.
