IDENTIFICATION
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
AUXILIARY RELAY BOXES (TAURUS X)
Note. For component location, see ELECTRICAL COMPONENT LOCATOR article.
Scheme 336
Scheme 337
Scheme 338
BATTERY JUNCTION BOX (BJB)
Note. For component location, see ELECTRICAL COMPONENT LOCATOR article.
Scheme 339
| Fuse | Amps | Circuits protected |
|---|---|---|
| F1 | 80 | Smart Junction Box (SJB) |
| F2 | 80 | Smart Junction Box (SJB) |
| F3 | 30 | Wiper run/park relay |
| F4 | Not used | |
| F5 | 20 | Heated seat module, rear |
| F6 | Not used | |
| F7 | 50 | Engine cooling fan motor |
| F8 | Not use | |
| F9 | 40 | Anti-lock Brake System (ABS) module |
| F10 | 30 | Starter relay |
| F11 | 50 | PCM power relay |
| F12 | 20 | Anti-lock Brake System (ABS) module |
| F13 | 20 | Power point, instrument panel |
| F14 | 20 | Power point, console, rear |
| F15 | 20 | Power point, rear |
| F16 | 20 | Power point, console |
| F17 | 10 | Generator |
| F18 | Not used | |
| F19 | Rear defrost relay | |
| F20 | 40 | Rear defrost relay |
| F21 | 30 | Seat control switch, passenger side front |
| F22 | 20 | Heated seat module, front |
| F23 | 10 | EVAP canister vent control solenoid, Powertrain Control Module (PCM) |
| F24 | 10 | A/C clutch relay |
| F25 | 25 | Rear wiper relay |
| F26 | 20 | Reversing lamps relay |
| F27 | 15 | Fuel pump relay |
| F28 | Not used | |
| F29 | 30 | Liftgate/Trunk Module (LTM) |
| F30 | Not used | |
| F31 | 30 | Auxiliary relay box 1 |
| F32 | 30 | Driver Seat Module (DSM) - with memory, Seat control switch, driver side front - without memory |
| F33 | 20 | Ignition switch |
| F34 | Not used | |
| F35 | 40 | Blower motor relay |
| F38 | 10 | Anti-lock Brake System (ABS) module, Steering Angle Sensor Module (SASM), Stability control sensor cluster |
| F39 | 10 | Powertrain Control Module (PCM), Fuel pump motor diode, Fuel pump relay |
| F40 | 10 | Auxiliary coolant pump motor (early production) |
| F45 | 10 | Speed control deactivation switch, Mass Air Flow / Intake Air Temperature (MAF/IAT) sensor, EVAP canister purge valve, Variable Camshaft Timing (VCT) valves, Heated oxygen sensors |
| F46 | 10 | A/C clutch relay, Heated Positive Crankcase Ventilation (PCV) valve, Positive Crankcase Ventilation (PCV) heated fitting |
| F47 | 15 | Powertrain Control Module (PCM) |
| F48 | 15 | Coil on Plugs |
| F49 | 15 | Exterior rear view mirrors |
BATTERY JUNCTION BOX COMPONENTS LEGEND
FUSELINKS
Note. For component location, see ELECTRICAL COMPONENT LOCATOR article.
SMART JUNCTION BOX (SJB)
Note. For component location, see ELECTRICAL COMPONENT LOCATOR article.
Scheme 340
| Fuse | Amps | Circuits protected |
|---|---|---|
| F1 | 30 | Power window motor, driver side front |
| F2 | 15 | Brake Pedal Position (BPP) switch |
| F3 | 15 | Satellite Digital Audio Receiver System (SDARS) module, Rear Entertainment Module (RETM), Accessory Protocol Interface Module (APIM) |
| F4 | 30 | Not used |
| F5 | 10 | Keypad switch assembly, Floor shifter, Field Effect Transistor (FET) |
| F6 | 20 | Front park/turn lamps, Rear lamp assemblies |
| F7 | 10 | Left low beam lamp |
| F8 | 10 | Right low beam lamp |
| F9 | 15 | Overhead console, Second row seat interior / map lamp assembly, Third row seat interior / map lamp assembly - Taurus X |
| F10 | 15 | Exterior rear view mirrors, Backlighting |
| F11 | 10 | All Wheel Drive (AWD) module |
| F12 | 7.5 | Exterior rear view mirror switch, Driver Seat Module (DSM) - with memory, Seat control switch, driver side front - with memory |
| F13 | 5 | Power Steering Control Module (PSCM) |
| F14 | 10 | Liftgate/Trunk Module (LTM), Clock |
| F15 | 10 | HVAC module, EMTC - with manual a/c HVAC module, DATC - with automatic a/c |
| F16 | 15 | Not used |
| F17 | 20 | Door lock actuators, Decklid latch assembly, Liftgate lock actuator, Liftgate/Trunk Module (LTM) |
| F18 | 20 | Second row power fold seat motors |
| F19 | 25 | Roof opening panel module |
| F20 | 15 | Data Link Connector (DLC |
| F21 | 15 | Headlamp switch, Fog lamps |
| F22 | 15 | Front park/turn lamps, Front side lamps, Rear lamp assemblies, License plate lamps |
| F23 | 15 | High beam lamps |
| F24 | 20 | Horn |
| F25 | 10 | Luggage compartment lamp, Second row seat control switches, Vanity mirrors, Overhead console, Second row seat interior / map lamp assembly, Third row seat interior / map lamp assembly - Taurus X |
| F26 | 10 | Instrument Cluster (IC) |
| F27 | 20 | Adjustable pedal switch |
| F28 | 5 | Audio Control Module (ACM) |
| F29 | 5 | Instrument Cluster (IC) |
| F30 | 5 | Floor shifter |
| F31 | 10 | Auto-dimming interior mirror unit, Electronic compass |
| F32 | 10 | Restraints Control Module (RCM) |
| F33 | 10 | Not used |
| F34 | 5 | All Wheel Drive (AWD) module |
| F35 | 10 | Power Steering Control Module (PSCM), Parking Aid Module (PAM), Heated seat modules |
| F36 | 5 | Passive anti-theft transceiver |
| F37 | 10 | HVAC module, EMTC - with manual a/c. HVAC module, DATC - with automatic a/c |
| F38 | 20 | Subwoofer amplifier |
| F39 | 20 | Audio Control Module (ACM) |
| F40 | 20 | Not used |
| F41 | 15 | Audio Control Module (ACM), Door lock switches, Auto-dimming interior mirror unit, Roof opening panel module, Overhead console, Driver side front power window motor |
| F42 | 10 | Not used - Early production |
| F43 | 10 | Not used |
| F44 | 10 | Not used - Early production |
| F45 | 5 | Wiper run/park relay, Rear wiper relay, Rear window defrost relay, Blower motor relay, Auxiliary relay boxes |
| F46 | 7.5 | Passenger air bag deactivation (PAD) indicator, Occupant Classification System Module (OCSM) |
| F47 | 30 cb. | Master window adjust switch |
SMART JUNCTION BOX COMPONENTS LEGEND
