Accelerator Pedal
Note. 4.0L shown, 2.3L similar.
Scheme 47
| Item | Part Number | Description |
|---|---|---|
| 1 | 9A758 | Accelerator cable |
| 2 | 9275 | Accelerator pedal |
| 3 | N804397 | Accelerator pedal pivot bolt |
ITEM DESCRIPTION
Scheme 48
- Disconnect the accelerator cable from the accelerator pedal.
- Remove the accelerator pedal pivot bolt and the accelerator pedal. To install, tighten to 9 Nm (80 lb-in).
- To install, reverse the removal procedure.
Scheme 49
| Item | Part Number | Description |
|---|---|---|
| 1 | W704704 | Accelerator control splash shield bolts (2 required) |
| 2 | 9E766 | Accelerator control splash shield |
| 3 | Accelerator cable-to-throttle lever (part of 9A758) | |
| 4 | 9A758 | Accelerator cable |
| 5 | Accelerator cable-to-accelerator pedal (part of 9A758) | |
| 6 | 9725 | Accelerator pedal |
ITEM DESCRIPTION
Scheme 50
Scheme 51
Scheme 52
Scheme 53
- Remove the 2 bolts and the accelerator control splash shield. To install, tighten to 3 Nm (27 lb-in).
- Disconnect the accelerator cable from the throttle lever.
- Depress the tabs and remove the accelerator cable from the intake manifold.
- Disconnect the accelerator cable from the accelerator pedal.
- Depress the tabs and remove the accelerator cable from the vehicle.
- To install, reverse the removal procedure.
Scheme 54
| Item | Part Number | Description |
|---|---|---|
| 1 | W704704 | Accelerator control splash shield bolts (3 required) |
| 2 | 9E766 | Accelerator control splash shield |
| 3 | Accelerator cable-to-throttle lever (part of 9A758) | |
| 4 | 9A758 | Accelerator cable |
| 5 | Accelerator cable-to-accelerator pedal (part of 9A758) | |
| 6 | 9725 | Accelerator pedal |
ITEM DESCRIPTION
Scheme 55
Scheme 56
Scheme 57
- Remove the 3 bolts and remove the accelerator control splash shield. To install, tighten to 3 Nm (27 lb-in).
- Disconnect the accelerator cable from the throttle lever.
- Depress the tabs and remove the accelerator cable from the accelerator cable bracket.
- Disconnect the accelerator cable from the accelerator pedal.
- Depress the clips and remove the accelerator cable from the vehicle.
- To install, reverse the removal procedure.
