Automatic Transmission - Automatic Transaxle/transmission - External Controls: Removal & Installation Ford Ranger II рестайлинг

Automatic Trans 9 illustrations ~693 words

Removal and Installation

Pinpoint Test C

C3 BSIA
  1. NOTE: The BSIA clip is an assembly aid for the assembly plant and does not need to be replaced.
  2. Remove the insert plate from the BSIA .

Scheme 6

Scheme 6: Removal and Installation

Scheme 7

Scheme 7: Selector Lever Cable And Bracket Exploded View - With Torque Specifications
ItemPart NumberDescription
1Selector lever cable eyelet (part of 7E395)
2Selector lever cable retaining clip (part of 7E395)
3Selector lever cable grommet (part of 7E395)
4Selector lever cable locating clip (part of 7E395)
57H181Selector lever cable retention clip
6Selector lever cable end fitting (part of 7E395)
7Selector lever cable eyelet end adjuster (part of 7E395)
8N605819-HB1Selector lever cable bracket bolts
97B229Selector lever cable bracket
107E395Selector lever cable

PART NUMBER REFERENCE

Scheme 8

Scheme 8: Removal

Scheme 9

Scheme 9
  1. Disconnect the selector lever cable from the steering column. Disconnect the selector lever cable eyelet from the steering column shift selector tube. Disconnect the selector lever cable from the steering column bracket.
  2. Push the rubber grommet and selector lever cable through the bulkhead.
  3. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-365369) .
  4. Disconnect the selector lever cable from the locating clip.
  5. NOTE: To prevent selector lever cable damage, do not apply force to the selector lever cable between the manual control lever and the selector lever cable bracket. Remove the selector lever cable eyelet end from the manual control lever.
  6. Remove the selector lever cable clip and remove the selector lever cable from the bracket.
  7. Remove the selector lever cable bracket from the transmission.

Scheme 10

Scheme 10
  1. Install the selector lever cable bracket. Tighten to 40 Nm (30 lb-ft).
  2. NOTE: To prevent selector lever cable damage, do not apply force to the selector lever cable between the manual control lever and the selector lever cable bracket. NOTE: When installing the selector lever cable, make sure that the selector lever cable locking tabs are locked in place. Press the selector lever cable into the selector lever cable bracket and listen for the selector lever cable retainer to click into place. Pull back on the selector lever cable to make sure that the selector lever is locked into the selector lever cable bracket. Install the selector lever cable into the selector lever cable bracket.
  3. NOTE: To prevent selector lever cable damage, do not apply force to the selector lever cable between the manual control lever and the selector lever cable bracket. NOTE: When installing the selector lever cable end, make sure that the selector lever cable end is correctly installed onto the manual control lever ball stud. Pull back on the selector lever cable to make sure that the selector cable end is correctly installed onto the manual control lever ball stud. Install the selector lever cable end onto the manual control lever ball stud.
  4. Connect the selector lever cable into the locating clip.
  5. Push the rubber grommet and selector lever cable through the bulkhead back into the vehicle.
  6. NOTE: When installing the selector lever cable, make sure that the selector lever cable locking tabs are locked in place and the cable end is snapped onto the ball stud. Press the selector lever cable into the bracket and listen for the cable to click into place. Pull back on the selector lever cable to make sure that it is locked into the bracket. Also, make sure that the selector lever cable end is correctly installed onto the ball stud. Pull back on the selector lever cable to make sure that the cable end is correctly installed. Connect the selector lever cable to the steering column. Connect the selector lever cable to the steering column bracket. Connect the selector lever cable eyelet to the steering column shift selector tube.
  7. Adjust the selector lever cable. For additional information, refer to «SELECTOR LEVER CABLE ADJUSTMENT»(ref-365396-S17272238522010070700000) .

Scheme 11

Scheme 11: Selector Lever Exploded View
ItemPart NumberDescription
1391727-SSteering column shroud screws
23530-ASteering column upper shroud
37G550Transmission Control Switch (TCS) electrical connector
47G357Selector lever pin
57210Selector lever

PART NUMBER REFERENCE

Scheme 12

Scheme 12: Removal and Installation

Scheme 13

Scheme 13
  1. Remove the ignition switch lock cylinder. For additional information, refer to Ignition Switch Lock Cylinder - Functional Lock Cylinder in «STEERING COLUMN»(ref-365411) .
  2. Remove the upper steering column shroud and the rubber shift lever cover.
  3. Remove the selector lever. Disconnect the selector lever harness connector. Remove and discard the selector lever pin. Remove the selector lever.
  4. NOTE: A new selector lever pin must be installed when the old pin is removed. To install, reverse the removal procedure.

Scheme 14

Scheme 14: Transmission Control Switch Exploded View
ItemPart NumberDescription
17210Transmission selector lever
27G550Transmission Control Switch (TCS)
37A214TCS cover

PART NUMBER REFERENCE

Pinpoint Test C

C1 TCS
  1. Remove the TCS cover.
  2. Remove the TCS .
