GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Silicone Gasket and Sealant TA-30 | WSE-M4G323-A4 |
| Thread Sealant with PTFE TA-24 | WSK-M2G350-A2 |
| Motorcraft SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada) or equivalent | WSS-M2C930-A |
| Gasket Maker TA-16 | WSK-M2G348-A5 |
| Silicone Gasket Remover ZC-30 | |
| Motorcraft Metal Surface Prep ZC-31 | |
| General Specifications | |
| Oil capacity | 4.0 quarts + 1/2 quart with filter change (4.5 quarts total) |
GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Displacement (CID) | 3.0L |
| No. of Cylinders | 6 |
| Bore | 89.00 mm (3.50 in) |
| Stroke | 80.00 mm (3.14 in) |
| Firing Order | 1-4-2-5-3-6 |
| Oil Pressure (Hot 2500 RPM) | 276-414 Kpa (40-60 psi) |
| Oil Capacity | 4.0 quarts + 1/2 quart with filter change (4.5 quarts total) |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| A/C compressor and power steering pump bracket bolts and stud bolts | 47 |
| A/C line bracket nut | 11 |
| Accelerator cable bracket bolts | 10 |
| Accessory drive belt tensioner bolts | 27 |
| Camshaft position sensor bolts | 3 |
| Camshaft sprocket bolt | 63 |
| Camshaft synchronizer retaining bolt | 30 |
| Camshaft thrust plate bolts | 10 |
| Clutch pressure plate | 32 |
| Connecting rod bearing cap nuts | 35 |
| Coolant pump pulley bolts | 25 |
| Crankshaft damper bolts | 145 |
| Crankshaft position sensor bolts | 10 |
| Crankshaft pulley bolts | 63 |
| Cylinder head bolts a | |
| Dual converter Y-pipe-to-exhaust manifold nuts | 40 |
| Engine lifting eye nuts | 20 |
| Engine support insulator bracket-to-engine bolts | 48 |
| Engine support insulator bracket-to-engine support insulator nuts | 109 |
| Engine support insulator-to-frame nuts | 103 |
| Exhaust gas recirculation (EGR) vacuum regulator solenoid stud bolt | 10 |
| EGR valve bolts | 20 |
| Exhaust manifolds bolts and stud bolts a | |
| Exhaust manifold-to-EGR valve tube fittings | 50 |
| Fan shroud bolts | 7 |
| Flexplate bolts | 80 |
| Flywheel bolts | 80 |
| Front axle mounting bolts | 66 |
| Front cover bolts and studs | 25 |
| Front drive shaft strap bolts | 19 |
| Fuel rail bolts | 10 |
| Fuel tube bracket nuts | 30 |
| Generator mounting bracket bolts | 47 |
| Ground cable nut | 10 |
| Hydraulic lash adjuster retainer bolts | 12 |
| Intake manifold bolts a | |
| Knock sensor (KS) bolt | 25 |
| Lower intake manifold bolts | 29 |
| Main bearing caps bolts | 80 |
| Oil level indicator and tube bracket nut | 18 |
| Oil pan baffle nuts | 32 |
| Oil pan bolts | 12 |
| Oil pressure switch | 20 |
| Oil pump bolts | 48 |
| Powertrain control module (PCM) ground strap nut | 10 |
| Rocker arm bolts | 32 |
| Starter motor bolts | 25 |
| Throttle body bolts and stud bolt | 10 |
| Torque converter access plate bolts | 12 |
| Torque converter nuts | 35 |
| Transmission cooler line bracket bolt | 11 |
| Transmission-to-engine bolts | 45 |
| Upper intake manifold support bracket nut | 6 |
| Valve cover studs and bolts | 12 |
| Wiring harness bracket-to-A/C compressor and power steering pump bracket nut | 10 |
| Wiring harness bracket-to-transmission nut | 30 |
TORQUE SPECIFICATIONS
a Refer to the procedure in this article.
The 3.0L engine has
- a V-block with 6 cylinders and splayed crankpins.
- a distributorless ignition system.
- a multi-port, sequential fuel injection (SFI) system.
- overhead valves.
- hydraulic valve tappets for automatic lash adjustment.
- connecting rod parting faces that are unique with an interference fit.
For basic engine mechanical concerns, refer to ENGINE SYSTEM - GENERAL INFORMATION article. For driveability concerns, refer to the INTRODUCTION - GASOLINE ENGINES article.
Scheme 171
| Item | Part Number | Description |
|---|---|---|
| 1 | 9A825 | Speed control cable |
| 2 | 9E894 | Return spring |
| 3 | N800312 | Bolt |
| 4 | 9E766 | Snow shield |
| 5 | 9A758 | Accelerator cable |
Scheme 172
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | Idle air control (IAC) valve electrical connector (part of 12B637) |
| 2 | 14A464 | Throttle position (TP) sensor electrical connector (part of 12B637) |
| 3 | 13A506 | Wiring harness retainer |
| 4 | 9E498 | Vacuum hose |
| 5 | 6C324 | Positive crankcase ventilation (PCV) valve tube |
| 6 | 9C482 | Brake booster vacuum hose |
| 7 | 9D477 | Exhaust manifold-to-exhaust gas recirculation (EGR) valve tube |
| 8 | 9Y476 | Fuel vapor hose |
| 9 | 14A464 | EGR vacuum regulator solenoid electrical connector (part of 12B637) |
Scheme 173
| Item | Part Number | Description |
|---|---|---|
| 10 | N808338 | Upper intake manifold brace upper nut |
| 11 | N804178 | Upper intake manifold brace lower nut |
| 12 | 95444 | Upper intake manifold brace |
| 13 | W708242-S | Upper intake manifold bolt (2 required) |
| 14 | W706375-S | Upper intake manifold bolt |
| 15 | W707272-S | Upper intake manifold stud bolt |
| 16 | 9424 | Upper intake manifold |
| 17 | 9H486 | Upper intake manifold gasket (3 required) |
Scheme 174
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-268774) article.
- Remove the air cleaner outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION AND FILTERING»(ref-268732) article.
- Remove the bolt and the snow shield.
- Disconnect the accelerator cable, speed control cable and the return spring.
- Disconnect the accelerator cable and speed control cable from the accelerator bracket.
- Disconnect the throttle position (TP) sensor and idle air control (IAC) valve electrical connectors. Disconnect the wire retainer.
- Disconnect the engine vacuum harness-to-vacuum reservoir hose connection.
- Disconnect the exhaust manifold-to-exhaust gas recirculation (EGR) valve tube from the EGR valve. To install, tighten to 50 Nm (37 lb-ft).
- Disconnect the fuel vapor hose from the intake manifold.
- Disconnect the EGR vacuum regulator solenoid electrical connector.
- Disconnect the brake booster vacuum hose and the positive crankcase ventilation (PCV) valve tube.
- Remove the oil level indicator tube bracket nut and position the tube and bracket out of the way. To install, tighten to 18 Nm (13 lb-ft).
- Remove the nut and the upper intake manifold brace. To install, tighten to 6 Nm (53 lb-in).
- Remove the bolts, the stud bolt and the upper intake manifold. Remove and discard the gaskets. Clean and inspect all mating surfaces.
- To install, reverse the removal procedure. To install, tighten to 10 Nm (89 lb-in).
