Identification Codes: Other Ford Ranger II

Vehicle Certification (VC) Label

The upper portion of the vehicle certification (VC) label contains the manufacturer name, the month and year of manufacture, the certification statement and the VIN. It also includes gross vehicle weight ratings (GVWR).

Scheme 11

Scheme 12

Exterior paint codes may be listed as a 2-part code. The first set of letters/numbers identify the vehicle primary body color. The second set of letters/number (if applicable) identify a 2-tone or accent body color. All colors are base coat/clear coat.

Scheme 13

Primary Body Color

1. CX - Dark Shadow Gray
2. D3 - Torch Red
3. D6 - Screaming Yellow
4. G2 - Red Fire
5. G3 - Pueblo Gold
6. G9 - Vista Blue
7. UA - Ebony
8. YN - Silver Metallic #2
9. YZ - Oxford White

Accent Body Color

1. CX - Dark Shadow Gray
2. UA - Ebony

Scheme 14

1. 112 - 112 inch (2,845 mm) wheelbase
2. 118 - 118 inch (2,997 mm) wheelbase
3. 126 - 126 inch (3,200 mm) wheelbase

Interior trim codes are listed as a 2-part code. The first code listed identifies the trim level. The second code listed identifies the interior trim color.

Scheme 15

Interior Trim Type

1. L - Stockton cloth bucket seats
2. M - Stockton 2 cloth bucket seats
3. Q - Scenery grain vinyl 60/40 split bench seat
4. R - Mortar cloth 60/40 split bench seat
5. S - Mortar cloth bucket seats
6. T - Imola leather 60/40 split bench seat
7. U - Imola leather bucket seats
8. V - Link weave cloth bucket seats

Interior Trim Color

1. B - Ebony
2. F - Medium/Dark Flint
3. P - Medium Pebble

Tape and paint stripe codes do not apply.

Scheme 16

Scheme 17

1. 7 - Electronic AM/FM stereo with clock
2. B - Premium electronic AM/FM stereo with 6-disc compact disc (CD) changer and MP3 capability
3. E - Electronic AM/FM stereo with 6-disc CD changer and MP3 capability (audiophile sound system)
4. W - Premium electronic AM/FM stereo with cassette, CD player and clock
5. Z - AM/FM stereo with CD player and clock

The following lists the gear ratios on axles.

Scheme 18

1. 86 - 3.73 non-limited slip (7.5 inch)
2. 87 - 4.10 non-limited slip (7.5 inch)
3. 95 - 3.55 non-limited slip (8.8 inch)
4. 96 - 3.73 non-limited slip (8.8 inch)
5. 97 - 4.10 non-limited slip (8.8 inch)
6. F6 - 3.73 limited slip (7.5 inch)
7. R5 - 3.55 limited slip (8.8 inch)
8. R6 - 3.73 limited slip (8.8 inch)
9. R7 - 4.10 limited slip (8.8 inch)

Scheme 19

1. D - 5-speed automatic (5R44E/5R55E)
2. J - 5-speed manual (R1HD)
3. R - 5-speed manual (M5R1)

Spring codes are listed as a 2-part code. The first character identifies the front spring/torsion bar code. The second character identifies the rear spring code.

Scheme 20

Front Spring Codes

1. 22 - 5L54-5310-BA (coil)
2. 33 - 5L54-5310-LA (coil)
3. 55 - 5L54-5310-KA (coil)
4. AA - 5L54-5310-AA (coil)
5. CC - 5L54-5310-MA (coil)
6. DD - 5L54-5310-DA (coil)
7. EE - 5L54-5310-EA (coil)

Front Torsion Bar Codes

1. 1 - F67A-5B326-FA (RH)
2. 1 - F67A-5B327-FA (LH)
3. B - F57A-5B326-BC (RH)
4. B - F57A-5B327-BC (LH)
5. F - F57A-5B326-FC (RH)
6. F - F57A-5B327-FC (LH)

Rear Spring Codes

1. 33 - 4L54-5560-DA (leaf)
2. CC - 3L54-5560-GA (leaf)
3. KK - 4L54-5560-EA (leaf)

Scheme 21

Note. Powertrain calibration information is limited to a maximum of 5 characters per line on the vehicle certification label. Because of this, calibration identification consisting of more than 5 characters will wrap to the second line on the vehicle certification (VC) label.

Powertrain calibration information is printed in the lower right corner of the vehicle certification label. Only the base calibration information is printed. Revision levels will not appear, however, this information can be found in On Line Automotive Service Information System (OASIS). For the current model year, Ford Motor Company is using 3 different protocols which describe powertrain base calibration. These protocols are designed to provide worldwide standardization for vehicle calibration. If the electronic calibration strategy has been used since 1998 and carried into the current model year, Protocol 1 will be used. Refer to Protocol 1 below. If the electronic calibration strategy has been used since 1999 and is carried into the current model year, Protocol 2 will be used. Refer to Protocol 2 below. Electronic calibration strategies introduced in the 2000 or later model years will use Protocol 3. Refer to Protocol 3 below.

Scheme 22

Scheme 23

Scheme 24

Protocol 3 - The following offers a more detailed explanation of the coding strategy for Protocol 3.

Model Year

1. 0 - 2000
2. 1 - 2001
3. 2 - 2002
4. 3 - 2003
5. 4 - 2004
6. 5 - 2005
7. 6 - 2006
8. 7 - 2007

Vehicle Line

1. R3 - Ranger

Transmission

1. 1 - Automatic transmission
2. 2 - Manual transmission

Unique Calibration - The Emissions/CAFE/CO2 Compliance Department is responsible for assigning these calibration numbers. Unique calibration identifications are assigned to cover similar vehicles to differentiate tires, drive configurations, final drive ratios and other certification-significant factors.

These 2 characters are selected by the analyst to identify information unique to each calibration. For example, using the number 2 to denote a 2-valve engine versus using the number 4 to denote a 4-valve engine offers an easily identifiable difference.

Fleet Code

1. 0 - Certification (U.S. 4K, final sale in an export market)
2. 1 - HDGE/Dyno
3. 2 - Fast AMA U.S.
4. 3 - ADP U.S.
5. 4 - Not assigned
6. 5 - Not assigned
7. 6 - Evaporative emissions
8. 7 - MACAA
9. 8 - On-board diagnostics (OBD)
10. 9 - Not assigned

Certification Region

1. Lead region where multiple regions are included in one calibration
2. 5 - U.S. 50 states
3. A - U.S. Federal (including altitude, may include Canada or Mexico)
4. B - U.S. California standard (includes U.S. green states)
5. C - Canada
6. D - China
7. E - European Community (Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Luxembourg, Netherlands, Portugal, Spain, Sweden and United Kingdom)
8. F - European Extended Community (E plus Croatia, Czech Republic, Estonia, Hungary, Norway, Poland, Romania, Russian Federation, Slovakia, Slovenia, Switzerland and Yugoslavia)
9. G - Gulf Cooperative Council
10. H - Hong Kong
11. J - Japan
12. K - Korea
13. L - Malaysia
14. M - Mexico
15. N - New Zealand
16. P - Australia
17. Q - South America (Brazil)
18. S - Singapore
19. T - Taiwan
20. U - South America (unleaded fuel)
21. V - Vietnam
22. X - Rest of World (ROW)
23. Y - Military
24. Z - Israel

Revision Level - Revision levels will advance as revisions occur (not printed on label).

1. 91-99 - Hardware and certification levels
2. 01-04 - Preliminary levels
3. 00 - Job 1 production (initial certification)
4. 05-09 - Pre-job 1 revisions to calibrations
5. 10-89 - Post-job 1 revisions to calibrations
6. 0B - Durability test level
7. BD - On-board diagnostics (OBD) intermediate level (pre-05)
