Full Frame and Body Mounting: Specifications Ford Ranger II

Frames, Subframes & Crossmembers 6 illustrations ~151 words

TORQUE SPECIFICATIONS

DescriptionNm
Vertical transmission support bolts99
Horizontal transmission support bolts127
Transmission mount nuts90

TORQUE SPECIFICATIONS

Scheme 14

Scheme 14: Frame and Body Mounting
ItemPart NumberDescription
1No. 1A crossmember (4x4 only)
2No. 1 crossmember
3Transmission crossmember
4Cab support crossmember
5Pickup bed support
6Rear crossmember

The frame consists of 2 steel channel rails, a rear crossmember, a number of additional support crossmember and a front crossmember.

The No. 1A (4WD only) and the No. 1 crossmember are welded to the frame side rails. The remaining frame crossmember are riveted and/or bolted into place.

Scheme 15

Scheme 15
ItemPart NumberDescription
1N621946-S2Nut and washer
2N800788-S2Spacer
31000192Upper insulator assembly
41000193Lower insulator assembly
5N800442-S428Bolt

Scheme 16

Scheme 16
ItemPart NumberDescription
1N808698Bolt and washer
2N802289Spacer
31000192Upper insulator assembly
41000193Lower insulator assembly

Scheme 17

Scheme 17
ItemPart NumberDescription
1W705283-S428Bolt and washer
2N802289-S2Spacer
31000192Upper insulator assembly
41000193Lower insulator assembly

Scheme 18

Scheme 18
ItemPart NumberDescription
1W705283-S428Bolt and washer
2N802289-S2Spacer
31000192Upper insulator assembly
41000193Lower insulator assembly

Scheme 19

Scheme 19: Drilling Precautions
  1. If a hole must be drilled in the frame, make sure the hole meets the following requirements: The hole is at least the specified distance from the edge of the nearest hole. The edge of the drilled hole is at least the specified distance from the edge of the flange. The hole is at least the specified distance above the frame centerline. The drilled hole is at least the specified distance from any other existing bracket or component of the frame.
