GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Measurements for the box-to-cab | |
| Pickup box leading edge to cab distance | 25 mm (0.98 in) |
| Ream size, rear bumper bracket bolt holes | 17 mm (0.67 in) |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Fender upper moulding screws | 12 |
| Pickup bed bolts | 63 |
| Pickup bed-to-fender bolts | 12 |
| Rear fender screws | 12 |
| Rear fender lower screws | 12 |
| Rear lamp opening bolts | 12 |
| Step screws | 12 |
| U-bolt nuts | 103 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
- Loosen the 6 pickup bed bolts.
- Center the pickup bed on the rear of the pickup cab.
- Set the gap between leading edge of the pickup bed and the back of the cab.
- Tighten the 6 pickup bed bolts. To install, tighten to 63 N.m (46 lb-ft).
