SPECIFICATIONS
| Item | Specification |
|---|---|
| Sealants and Primers | |
| Urethane Glass Prep Essex U-401 | WSB-M2G314-B |
| Urethane Metal Primer Essex U-413 | WSB-M2G234-C |
| Urethane Glass Primer Essex U-402 | WSB-M5B280-C |
| Urethane Adhesive Essex 400-HV | WSB-M2G316-B |
| Foam Core Butyl | WSB-M3G143-B |
GENERAL SPECIFICATIONS
| Description | Nm |
|---|---|
| Back window glass nuts | 2 |
| Door glass center run retainer nuts | 8-10 |
| Door glass top run bolt | 11-13 |
| Fixed quarter window glass nuts | 1-2 |
| Movable quarter window latch screws | 7-11 |
| Window glass motor bolts | 6-9 |
| Window glass rear run channel bolt | 11-13 |
| Window regulator control switch screws | 2-3 |
| Windshield garnish moulding assist handle bolts | 3-4 |
TORQUE SPECIFICATIONS
