GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Lubricants | |
| Rust Penetrant & Inhibitor F2AZ-19A501-A | ESR-M99C56-A |
| Steering Gear Grease C3AZ-19578-A | ESW-M1C87-A |
| Ignition Lock Grease FOAZ-19584-A | ESA-M1C232-A |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Brake Shift Interlock Solenoid Bolts | 9 |
| Ignition Switch Bolts | 6 |
| Ignition Switch Electrical Connector Bolt | 1 |
| Transmission Range Indicator Bolt | 3 |
| Lock Cylinder Housing Screws | 22 |
| Shift Tube Bolts | 9 |
| Shock Absorber Electronic Steering Sensor Bolts | 1 |
| Steering Column Lower Bearing Retainer Bolts | 9 |
| Steering Column Support Nuts | 15 |
| Steering Wheel Bolt | 40 |
| Transmission Selector Lever Arm And Support Bolts | 15 |
| Upper Intermediate Shaft To Lower Intermediate Shaft Bolt | 48 |
| Upper Intermediate Shaft To Steering Column Shaft Bolt | 30 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
Note. All fasteners are important because they can affect the performance of vital parts and systems. Incorrect installation of the fasteners can result in major repair expenses. New fasteners with the same part number must be installed if replacement becomes necessary. Do not use a new part of lesser quality or substitute a design. Torque values must be used as specified during assembly to make sure these parts function correctly.
The body of the steering column is made of magnesium die castings. The steering column is attached to a support that is an integral part of the instrument panel. The lower attachments of the steering column are through a bracket that bends during collapse. The upper attachments are through plastic shear modules that separate from the main casting during collapse. A clip and washer are attached to the shear modules to reduce steering column shake and to assist in installation of the steering column.
Refer to STEERING SYSTEM-GENERAL INFORMATION .
Scheme 4
Scheme 5
- Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-204997) .
- Remove the ignition switch lock cylinder (11582). Insert the ignition key and turn to the RUN position. Press the ignition switch lock cylinder release pin while pulling out the ignition switch lock cylinder.
- To install, reverse the removal procedure. Verify ignition switch lock cylinder operation.
Scheme 6
Scheme 7
Scheme 8
Scheme 9
- Remove the steering wheel assembly. For additional information, refer to «WHEEL»(ref-204973-S02999348082005111600000) .
- Twist off the cap from the ignition switch cylinder.
- Remove the ignition switch lock cylinder. Use a 1/8-inch diameter drill bit to drill out the lock cylinder retaining pin. Use a 3/8-inch drill bit to drill down the middle of the ignition lock key slot until the ignition switch lock cylinder breaks loose. Remove and discard the ignition switch lock cylinder and clean the drill shavings from the steering column.
- Remove the bearing retainer.
- Remove the bearing and gear. Thoroughly clean all drill shavings from the steering column and inspect it for damage.
- To install, reverse the removal procedure. Install a new ignition switch lock cylinder. Verify ignition switch lock cylinder operation.
Scheme 10
Scheme 11
- Turn the steering wheel to the straight-ahead position and turn the ignition switch to the OFF position.
- Remove the driver air bag module. For additional information, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-150629) .
- Loosen the steering wheel bolt.
- Using the special tool, remove the steering wheel.
- Remove and discard the original steering wheel bolt.
- Remove the steering wheel while routing the wires from the clockspring through the steering wheel.
- To install, reverse the removal procedure.
