Power window system consists of 2 switches, one lock switch, and 2 motor and drive assemblies. Driver's door armrest contains left and right up/down control switches for both driver's door window and passenger's door window.
Power windows are regulated by 2 encased cables. (Scheme 1) The cables connect an electric motor-driven regulator to a slider bracket. When power window switch is operated, cables move slider bracket up and down. Vehicle is equipped with a one-touch (down) feature. This allows driver to fully open driver's or passenger's window by firmly pressing switch and then releasing. When the window is fully open, the switch will release.
Scheme 1
CIRCUIT & TERMINAL IDENTIFICATION
Note. To identify main power window switch circuits, refer to the MAIN POWER WINDOW SWITCH CIRCUITS table. To identify power window switch terminals (Scheme 2)-6.
| Pin | Circuit | Function |
|---|---|---|
| A | WHT/GRN | Door Lock Switch Power |
| B | BLK/RED | Main Switch Power |
| C | RED/BLU | Left Window Feed/Return |
| D | GRN/BLU | Left Window Feed/Return |
| F | BLK | Ground |
| H | GRN/BLK | Door Lock Switch Output |
| I | RED/WHT | Right Window Feed/Return |
| J | GRN/WHT | Right Window Feed/Return |
| K | BLK/YEL | Power Supply |
| L | Not Used | Not Used |
MAIN POWER WINDOW SWITCH CIRCUITS
Scheme 2
Scheme 3
Scheme 4
Scheme 5
