VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 2

Scheme 2: VIN Code ID Explanation
Scheme 2: VIN Code ID Explanation

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Severe Service

  1. Short Trips (About 10 Miles) In Freezing Temperatures
  2. Towing Or Heavily Loaded
  3. Severe Dust Conditions
  4. Hot Weather, Stop-And-Go Driving
  5. Extensive Idling Conditions

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Severe Service Operating Conditions

CAMSHAFT TIMING BELT

CAUTIONFailure to replace a faulty camshaft timing belt may result in serious engine damage.

The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".

Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.

Belts or components should be inspected and replaced if any of the following conditions exist

  1. Cracks Or Tears In Belt Surface
  2. Missing, Damaged, Cracked Or Rounded Teeth
  3. Oil Contamination
  4. Damaged Or Faulty Tensioners
  5. Incorrect Tension Adjustment

Replace camshaft timing belt every 60,000 miles (Except California). On 1993 2.0L (California) and 1994-96 2.0L & 2.5L (California) engines replace camshaft timing belt every 105,000 miles.

Scheme 3

Scheme 3: SERVICE POINT LOCATIONS
Scheme 3: SERVICE POINT LOCATIONS

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

SERVICE LABOR TIMES

Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

TIRE INFLATION

Inflation pressure can be found on decal attached to rear face of right door or on the door pillar.

Note. On vehicles equipped with aluminum wheels, there is one locking lug nut on each wheel. The key for this nut is attached to the lug wrench in spare tire compartment.

WHEEL TIGHTENING

Tighten all wheel lug nuts to 65-87 ft. lbs. (88-118 N.m). If wheels are equipped with locking type lug nuts ALWAYS position "Keyed" nut opposite valve stem.

CAUTIONLug nut key should be held square to the lug nut. Damage could occur to key and lug nut if held at an angle. DO NOT use a power impact wrench on the lug nut key.

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

Use Group BX-56 batteries on vehicles with 2.2L and 2.0L engines. Use Group BX-58R on vehicles with 3.0L and 2.5L engines.

SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG SYSTEM)

When performing maintenance on air bag equipped vehicles always observe proper safety precautions.

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See the appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section.
  1. AIR BAG RESTRAINT SYSTEM - 1993
  2. AIR BAG RESTRAINT SYSTEM - 1994
  3. AIR BAG RESTRAINT SYSTEM - 1995
  4. AIR BAG RESTRAINT SYSTEM - 1996
CAUTIONDisconnect negative battery cable before servicing any air bag system or steering column component. Check system operation after each repair; always turn the ignition switch to the ON position from passenger's side of vehicle.

AIR CONDITIONING SERVICING

CAUTIONAvoid breathing R-134a refrigerant and PAG lubricant vapors, exposure may irritate eyes, nose and throat. To remove R-134a from system use R-134a recycling equipment that meets SAE J2210 specifications. If accidental system discharge occurs, ventilate work area before resuming service.
WARNINGR-134a service equipment or vehicle A/C systems SHOULD NOT be pressure tested or leak tested with compressed air. Some mixtures of air/R134a have shown to be combustible at elevated pressures. These mixtures are dangerous and may cause fire and/or explosions. See the appropriate A/C SYSTEM GENERAL SERVICING article in AIR CONDITIONING & HEAT section.
  1. A/C SYSTEM GENERAL SERVICING - 1989-91
  2. A/C SYSTEM GENERAL SERVICING - 1993
  3. A/C SYSTEM GENERAL SERVICING - 1994
  4. A/C SYSTEM GENERAL SERVICING - 1995

ANTI-LOCK BRAKE SYSTEM

The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.

On models equipped with anti-lock brake systems, ALWAYS observe the following cautions

  1. DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
  2. ANTI-LOCK BRAKE SYSTEM - 1989-90
  3. ANTI-LOCK BRAKE SYSTEM - 1991
  4. ANTI-LOCK BRAKE SYSTEM - 1992
  5. ANTI-LOCK BRAKE SYSTEM - 1993
  6. ANTI-LOCK BRAKE SYSTEM - 1994
  7. ANTI-LOCK BRAKE SYSTEM - 1995
  8. ANTI-LOCK BRAKE SYSTEM - 1996
  9. DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
  10. Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.

REPLACING BLOWN FUSES

Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section.

BRAKE PAD WEAR INDICATOR

Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

To prevent catalytic converter overheating, DO NOT allow engine to idle for more than 20 minutes.

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

CAUTIONTo avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C).
CAUTIONPropylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C)
CAUTIONPropylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

FUEL PUMP SHUTOFF SWITCH

This switch stops the flow of fuel to the engine after a collision. The impact does not have to be great (minor parking lot bumping or severe road impacts) for the switch to be triggered. Once the shutoff switch is triggered, it must be reset by hand before the car can be started. To reset switch, press the reset button located on the left side of luggage compartment under the carpet and spare tire cover.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component.

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

METHANOL GASOLINE

CAUTIONFuel that is more than 5% methanol should not be used in this vehicle. It can corrode metal parts in the fuel system, and damage plastic and rubber parts. Even at 5% methanol or less, solvents and corrosion preventers must be used with this fuel to avoid these problems.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.

SPARK PLUGS

Note. Allow engine to cool before removing spark plugs from aluminum cylinder heads.

TURBO BOOST SYSTEM (TURBO MODELS)

Under normal operating conditions, turbo boost gauge pointer should only momentarily move into the OVERBOOST area. If overboost is sustained, have system serviced. Do not operate vehicle in Red zone of turbo boost gauge. DO NOT "rev" a turbocharged engine before shutting it off.

TURBOCHARGED MODELS

CAUTIONDo not race engine immediately after starting. When stopping engine, allow engine to idle for approximately 60 seconds before shutting it off. Failure to do so may cause turbocharger damage due to lack of oil flowing to the turbocharger bearings.

WARRANTY INFORMATION

CAUTIONDue to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options.

BASIC NEW CAR LIMITED WARRANTY

All parts of the vehicle, except tires, are covered against defects in factory-supplied materials and workmanship for 12 months or 12,000 miles, whichever occurs first.

POWERTRAIN WARRANTY

Note. Powertrain Warranty varies in coverage length (either 4 years/50,000 miles or 6 years/60,000 miles) depending on model year.

Under this warranty, certain parts of the engine, transmission, axle and driveline are warranted against defects in materials and workmanship. This coverage begins after 12 months or 12,000 miles. See copy of warranty for specific components covered and length of coverage.

BUMPER-TO-BUMPER COVERAGE

All 1992-93 vehicles have complete warranty coverage against defects in materials and workmanship for 3 years or 36,000 miles, whichever occurs first. There is no deductible with this warranty. Items not covered include tires and parts that are subject to normal wear and tear, such as windshield wiper blades, brake linings, brake pads, clutch linings and scheduled maintenance items. There is no extended powertrain coverage included in this warranty.

BATTERY COVERAGE

Begins at warranty start date and lasts up to 3 years or 36,000 miles, whichever occurs first. For the first 12 months in service (less than 36,000 miles), battery will be replaced at no charge. After that, battery will be replaced on a customer-participation basis: For the 13th-24th month in service, Ford will pay 50%; for the 25th-36th month, Ford will pay 25%. Labor is covered for 3 years or 36,000 miles, whichever occurs first.

SAFETY RESTRAINT SYSTEM COVERAGE

Begins at warranty start date and lasts for 5 years or 50,000 miles, whichever occurs first. Covers safety restraint problems not related to comfort or appearance. Coverage for model years earlier than 1990 is 3 years with unlimited miles.

CORROSION COVERAGE

Begins at warranty start date and lasts for 6 years or 60,000 miles, whichever occurs first. 1992-93 models are covered for 6 years or 100,000 miles, whichever occurs first. Covers any holes in body sheet metal caused by corrosion.

EMISSIONS DEFECT & PERFORMANCE WARRANTIES (EXCEPT CALIFORNIA)

Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.

The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed for the vehicle to pass a Federally required state or local emissions test.

Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered. Performance Warranty coverage is limited to fewer components after 2 years or 24,000 miles.

EMISSIONS PERFORMANCE WARRANTY (CALIFORNIA)

If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

EMISSIONS DEFECT WARRANTY (CALIFORNIA)

If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.

FUSE PANEL LOCATIONS

There are 2 fuse panels, one on the driver's side kick panel and the other under the hood, to the left of the battery. The turn signal and hazard flasher is located in the lower left-hand corner of the relay box.

Scheme 7

Scheme 7: INSTRUMENT PANEL FUSE IDENTIFICATION (1989-90)
Scheme 7: INSTRUMENT PANEL FUSE IDENTIFICATION (1989-90)

Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp RADIO - Remote Control Mirrors, Audio Power/Power Antenna, Up/Down Action When Radio is Turned Off)
  2. 2 - 15 Amp CIGAR - Cigarette Lighter
  3. 3 - 15 Amp ENGINE - Main Relay No. 1 No. 2, Fuel Pump Control Unit, Ignition Relay
  4. 4 - 15 Amp METER - Back-Up Lights, Radio & Power Antenna, Sound Warning System, Rear Window Defroster, 4EAT Control System, Cruise Control, Cooling Fan Control System
  5. 5 - 20 Amp COOLING FAN - Cooling Fan System
  6. 6 - 7.5 Amp MONITOR - VMM Display
  7. 7 - 10 Amp TURN - Power Steering Control, ABS System, Turn Signal & Hazard Flashers
  8. 8 - 30 Amp POWER WIND - Power Windows
  9. 9 - 10 Amp EIC - Instrument Cluster, VMM Display
  10. 10 - 10 Amp REAR WIPER - Rear Wiper & Washer
  11. 11 - 20 Amp WIPER - Front Wiper & Washer
  12. 12 - 30 Amp POWER SEAT - Power Seats
  13. 13 - 30 Amp DOOR LOCK
  14. 14 - 20 Amp STOP - Brakelights, High Mount Brakelight, Horns
  15. 15 - 15 Amp HAZARD - Turn Signals & Hazard Lights
  16. 16 - 10 Amp ROOM - Sound Warning System, 4EAT Control System, Luggage Compartment Light, Audio Illumination, Power Antenna, Engine Control System, VMM Display
  17. 17 - 15 Amp TAIL - Glove Compartment Light, Side Marker Lights, Taillights, License & Parking Lights, Illumination Lights
  18. 18 - 15 Amp FOG - Front Foglights
  19. 19 - 30 Amp DEFOG (Circuit Breaker) - Rear Window Defroster

Scheme 8

Scheme 8: INSTRUMENT PANEL FUSE IDENTIFICATION (1991-92)
Scheme 8: INSTRUMENT PANEL FUSE IDENTIFICATION (1991-92)
  1. 1 - 15 Amp REAR WIPER - Rear Wiper & Washer
  2. 2 - EMPTY
  3. 3 - 15 Amp ENGINE 2 - Engine Control System, HEGO, Engine Control System
  4. 4 - 10 Amp ROOM - Sound Warning System, 4EAT Control System, Luggage Compartment Light, Audio Illumination, Power Antenna, Engine Control System, VMM Display
  5. 5 - 15 Amp TAIL - Headlights, Illumination Lights, Taillights & License Lights, Side Marker & Parking Lights
  6. 6 - 30 Amp BELT - Passive Restraint System
  7. 7 - 15 Amp RADIO - Remote Control Mirrors, Audio Power/Power Antenna, Up/Down Action When Radio is Turned Off)
  8. 8 - 15 Amp COOLING FAN - Cooling Fan System
  9. 9 - 15 Amp METER - Back-Up Lights, Radio & Power Antenna, Sound Warning System, Rear Window Defroster, 4EAT Control System, Cruise Control, Cooling Fan Control System
  10. 10 - 20 Amp DOOR LOCK - Power Door Locks
  11. 11 - 30 Amp POWER SEAT - Power Seats
  12. 12 - 15 Amp CIGAR - Cigarette Lighter
  13. 13 - 30 Amp POWER WIND - Power Windows
  14. 14 - 15 Amp HAZARD - Turn Signals & Hazard Lights
  15. 15 - 10 Amp TURN - Power Steering Control, ABS System, Turn Signal & Hazard Flashers
  16. 16 - 20 Amp STOP - Brakelights, High Mount Brakelight, Horns
  17. 17 - 15 Amp ENGINE - Fuel Pump Relay, Cooling Fan System, A/C & Heating, Meter/Warning, ECA
  18. 18 - 7.5 Amp MONITOR - VMM Display
  19. 19 - 30 Amp DEFOG (Circuit Breaker) - Rear Window Defroster

Scheme 9

Scheme 9: UNDERHOOD FUSE BLOCK IDENTIFICATION (1989-92)
Scheme 9: UNDERHOOD FUSE BLOCK IDENTIFICATION (1989-92)
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Fuse Breaker Identification

  1. 1 - 30 Amp FUEL INJ - Emission & Fuel Injection, Control System
  2. 2 - 30 Amp RETRA - Headlight Retractor Motors
  3. 3 - 30 Amp HEAD - Headlights
  4. 4 - 80 Amp MAIN (2.2L) - 100 Amp (3.0L) - Charging System, Remote Control Mirrors, Audio System, Cigarette Lighter, A/C System, Programmed Ride Control System, Wipers & Washers, Back-Up Lights, Cruise Control, Warning Lights & Gauges, Electronic Power Steering, Emission & Fuel Control, Rear Window Defroster, Power Windows, Ignition System, VMM Control System
  5. 5 - 60 Amp BTN - Foglights, Glove Compartment Light, Parking Lights, Taillights & Marker Lights, License Lights, Illumination Lights, Cargo Lights, Stoplights, High Mounted Stoplight, Horn, Power Antenna, Turn & Hazard Flasher Lights, Power Seat & Door Locks, 4EAT Control System, Sound Warning System, Heating & A/C System
  6. 6 - 40 Amp COOLING FAN (2.2L) - 60 Amp (3.0L) - Cooling Fan Control System
  7. 7 - 60 Amp ABS PUMP - ABS Control System
  8. 8 - 40 Amp HEATER (1991-92) - 60 Amp (1989-90) - Heater Control System
  9. 9 - EMPTY (1991-92) - 15 Amp AIR COND (1989-90) - A/C Compressor Clutch System
  10. 10 - EMPTY (1991-92) - 10 Amp AUDIO (1989-90) - Audio System
  11. 11 - 15 Amp ST SIGN (GL & LX) - ECA, Fuel Pump Relay
  12. 12 - 15 Amp FOG (GT) - Foglights
  13. 13 - 20 Amp - Front Washer & Wiper (1991)
  14. 14 - 20 Amp AIR COND - Fuel Pump (1991-92), A/C Compressor Magnetic Clutch Control System
  15. 15 - 15 Amp AUDIO (1991-92) - Audio System 10 Amp AUDIO (1989-90)

Scheme 10

Scheme 10: INTERIOR FUSE PANEL IDENTIFICATION (1993-96)
Scheme 10: INTERIOR FUSE PANEL IDENTIFICATION (1993-96)

Fuse Identification

  1. 1 - 20 Amp (STOP) - Stoplights, High-Mount Brakelight, Horn, Shift Lock System
  2. 2 - 15 Amp (ROOM) - Illuminated & Keyless Entry System, Key Reminder, Audio System, Engine & Luggage Compartment Lights, Foot Lights, Dome & Map Lights, Visor Mirror, Ignition & Door Key Lights
  3. 3 - 30 Amp (DOOR LOCK) - Power Door Locks
  4. 4 - 15 Amp (RADIO) - Audio System, Power Mirrors
  5. 5 - 15 Amp (SUN ROOF) - Moon Roof
  6. 6 - 15 Amp (TURN) - Turn Signals
  7. 7 - 15 Amp (AUDIO) - Audio System, Cigarette Lighter
  8. 8 - 15 Amp (METER) - Back-Up Lights, Instrument Cluster, Keyless Entry, Power Antenna, Anti-Theft Warning, Shift Lock, Rear Window Defroster Switch Indicator, Power Window & Power Door Lock, Switch Illumination
  9. 9 - 15 Amp (HAZARD) - Hazard Warning Lights & Turn Signals
  10. 10 - 15 Amp (ENGINE) - Rear Window Defroster, Air Bag System, Anti-Lock Brake System, Cooling Fan, Speed Control System, Emission & Fuel Control System
  11. 11 - 30 Amp (POWER WINDOW) - Power Windows
  12. 12 - 15 Amp (AIR COND) - Air Conditioning, Daytime Running Lights (Canada)
  13. 13 - 20 Amp (WIPER) - Front Wiper/Washer
  14. 14 - 15 Amp (REAR WIPER) - Rear Wipers/Washer
  15. 15 - 15 Amp (SPARE)

Scheme 11

Scheme 11: UNDERHOOD FUSE PANEL IDENTIFICATION (1993-96)
Scheme 11: UNDERHOOD FUSE PANEL IDENTIFICATION (1993-96)
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
  1. 1 - Relay - Foglights
  2. 2 - Relay - Headlights
  3. 3 - 30 Amp (F/P INJ) - Emission & Fuel Controls, Air Bag System
  4. 4 - 40 Amp (DEFOG) - Rear Window Defroster
  5. 5 - 30 Amp (HEAD) - Headlights, Foglights, Daytime Running Lights (Canada)
  6. 6 - 100 Amp (MAIN) - Main Fuse: All Circuits
  7. 7 - Relay - Air Conditioning
  8. 8 - 40 Amp (AIR COND) - Air Conditioning
  9. 9 - 40 Amp (HEATER) - Heater & Air Conditioning
  10. 10 - 40 Amp (COOLING FAN) - Cooling Fan
  11. 11 - 60 Amp (ABS) - Anti-Lock Brake System
  12. 12 - 60 Amp (BTN) - Front & Rear Side Marker Lights, Tail & License Plate Lights, Glove Compartment Light, O/D OFF Indicator, Foglight Indicator, Rear Wiper/Washer Indicator, Rear Window Defroster Indicator, Headlight Retractor & A/C Indicators, Cigarette Lighter Switch Illumination Light, Power Seats, Lumbar Support, Engine & Luggage Compartment Lights, Foot, Dome & Map Lights, Visor Mirror Light, Ignition & Door Key Lights, Illuminated Entry System, Keyless Entry System, Key Reminder, Audio System, Brakelights, High-Mount Brakelight, Horn, Shift-Lock System, Power Door Locks, Hazard Warning Lights, Turn Signals, Cigarette Lighter
  13. 13 - 40 Amp (IG KEY) - Heater & A/C, Starting System, Power Windows & Mirrors, Front & Rear Wiper/Washer, Audio System, Rear Window Defroster, Air Bag System, Anti-Lock Brake System, Cooling Fan, Speed Control System, Emission & Fuel Control System, Back-Up Lights, Instrument Cluster, Rear Window Defroster Indicator, Power Window & Power Door Switch Illumination, Keyless Entry System, Power Antenna, Anti-Theft Warning System, Shift Lock System, Turn Signals, Moon Roof, A/C, Daytime Running Lights
  14. 14 - Blank
  15. 15 - 30 Amp (POWER SEAT) - Power Seats & Lumbar Support
  16. 16 - 20 Amp (RETRA) - Headlight Retractors
  17. 17 - 15 Amp (TAIL) - Front & Rear Side Marker Lights, Tail & License Plate Lights, Glove Compartment Light, Instrument Panel Indicator Lights, Rear Wiper/Washer & Defroster Switch Illumination, O/D Off, Fog Lights, Headlight Retractor, A/C & Cigar Lighter Switch Illumination
  18. 18 - Relay - Daytime Running Lights (DRL)
  19. 19 - 40 Amp - Rear Window Defroster
  20. 20 - Relay - Turn Signal/Parking Lights
  21. 21 - Relay - Fuel Pump
  22. 22 - Relay - Ignition Main (1993), Powertrain Control Module (PCM) Power (1994-96)
  23. 23 - Relay - Starter Interrupt

More articles — Maintenance
