Engine - 4.6L (2V) - F150 Pickup: Specifications Ford Pickup F150

Mechanical 6 illustrations

GENERAL SPECIFICATIONS

ItemSpecification
Lubricants and Sealants
SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP or equivalentWSS-M2C153-H
Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B, in Canada VC-7-C) or equivalent (1)WSS-M97B51-A1 (yellow color)
Metal Surface Prep ZC-31
Silicone Gasket and Sealant F7AZ-19554-EA or equivalentWSE-M4G323-A4
Silicone Gasket Remover ZC-30
Engine
Displacement4.6L (281 CID)
Number of cylinders8
Bore90.2 mm (3.55 in)
Stroke90.0 mm (3.54 in)
Firing order1-3-7-2-6-5-4-8
Oil pressure (@ 2000 rpm - 93°C (200°F))275.8-417.1 kPa (40-75 psi)
Oil capacity (includes filter change)5.7 L (6.0 qts)
Compression ratio9.3:1
Cylinder Head and Valve Train
Combustion chamber volume51.5-52.5 cc (3.14-3.20 cu in)
Valve arrangement (front to rear) - LHE-I-E-I-E-I-E-I
Valve arrangement (front to rear) - RHI-E-I-E-I-E-I-E
Valve guide bore diameter7.044-7.015 mm (0.2773-0.2762 in)
Valve stem diameter - intake6.995-6.975 mm (0.2754-0.2746 in)
Valve stem diameter - exhaust6.970-6.949 mm (0.2744-0.2736 in)
Valve stem-to-guide clearance - intake0.020-0.069 mm (0.0008-0.0027 in)
Valve stem-to-guide clearance - exhaust0.045-0.095 mm (0.0018-0.0037 in)
Valve head diameter - intake44.5 mm (1.751 in)
Valve head diameter - exhaust34.0 mm (1.338 in)
Valve face runout0.05 mm (0.0019 in)
Valve face angle45.25-45.75 degrees
Valve seat width1.9-2.1 mm (0.0748-0.0827 in)
Valve seat runout (T.I.R.) max.0.025 mm (0.0010 in)
Valve seat angle45.50 degrees
Valve spring free length49.55 mm (1.9508 in)
Valve spring squareness2 degrees
Valve spring compression pressure587.14 N @ 28.02 mm (131.994 lb @ 1.1032 in)
Valve spring installed height39.7-40.3 mm (1.5630-1.5866 in)
Valve spring installed pressure - valve open587.165 N @ 27.99 mm (132 lb @ 1.102 in)
Valve spring installed pressure - valve closed244.652 N @ 39.98 mm (55 lb @ 1.574 in)
Roller follower ratio1.75:1
Hydraulic Lash Adjuster
Diameter16.000-15.9888 mm (0.6299-0.6295 in)
Clearance-to-bore0.018-0.069 mm (0.0007-0.0027 in)
Service limit0.016 mm (0.0006 in)
Hydraulic leakdown rate5-25 seconds (2)
Collapsed lash adjuster gap0.085-0.450 mm (0.0033-0.0177 in)
Camshaft
Theoretical valve lift @ 0 lash12.0 mm (0.472 in)
Lobe lift6.5 mm (0.2560 in)
Allowable lobe lift loss0
Journal diameter (all)26.962-26.936 mm (1.0615-1.0605 in)
Camshaft journal bore inside diameter (all)27.012-26.987 mm (1.0635-1.0625 in)
Camshaft journal-to-bearing clearance0.025-0.076 mm (0.0010-0.0030 in)
Runout0.05 mm (0.002 in)
End play0.09-0.19 mm (0.0035-0.0075 in)
Cylinder Block
Cylinder bore diameter - grade 190.200-90.213 mm (3.5512-3.5517 in)
Cylinder bore diameter - grade 290.213-90.226 mm (3.5517-3.5522 in)
Cylinder bore diameter - grade 390.226-90.239 mm (3.5522-3.5527 in)
Cylinder bore maximum taper0.006 mm (0.00023 in)
Cylinder bore maximum out-of-round0.020 mm (0.00079 in)
Main bearing bore inside diameter72.402-72.422 mm (2.850-2.851 in)
Cylinder bore diameter-surface finish (RMS)0.2-0.6 microns
Crankshaft
Main bearing journal diameter67.483-67.503 mm (2.65 in)
Main bearing journal maximum taper0.004 mm (0.0002 in)
Main bearing journal maximum out -of-round0.06 mm (0.002 in)
Main bearing journal-to-cylinder block clearance0.027-0.065 mm (0.0011-0.0026 in)
Connecting rod journal diameter52.983-53.003 mm (2.0859-2.0867 in)
Connecting rod journal maximum taper0.004 mm (0.0002 in)
Connecting rod journal maximum out-of -round0.006 mm (0.0002 in)
Crankshaft maximum end play0.130-0.301 mm (0.0051-0.012 in)
Piston and Connecting Rod
Piston diameter - coded red 190.177-90.197 mm (3.550-3.551 in)
Piston diameter - coded blue 290.190-90.210 mm (3.5507-3.5515 in)
Piston diameter - coded yellow 390.203-90.223 mm (3.513-3.5521 in)
Piston-to-cylinder bore clearance0.012-0.0026 mm (0.0005-0.0001 in)
Piston ring end gap - compression (top and bottom)0.23-0.49 mm (0.010-0.020 in)
Piston ring end gap - oil ring (steel rail)0.05-0.66 mm (0.006-0.026 in)
Piston ring groove width - compression (top)1.520-1.550 mm (0.002-0.610 in)
Piston ring groove width - compression (bottom)1.520-1.530 mm (0.060-0.0602 in)
Piston ring groove width - oil ring6.996-7.224 mm (0.275-0.2844 in)
Piston ring width - compression1.49-1.47 mm (0.0587-0.0579 in)
Piston ring width - oil ring rail (2)0.473-0.447 mm (0.0186-0.0176 in), 0.483 mm (0.0190 in) max. at ID
Piston ring width - oil ring expander2.038-1.960 mm (0.080-0.077 in)
Piston ring-to-groove clearance - compression0.030-0.070 mm (0.0012-0.0028 in)
Piston ring-to-groove clearance - oil ring assembly0.046-0.196 mm (0.0018-0.0077 in)
Piston pin bore diameter22.0015-22.004 mm (0.866-0.8663 in)
Piston pin diameter22.0 mm (0.866 in)
Piston pin length61.8 mm (2.433 in)
Piston pin-to-piston fit0.005-0.010 mm (0.0002-0.0004 in)
Connecting rod-to-pin clearance0.015-0.040 mm (0.0006-0.0016 in)
Connecting rod pin bore diameter21.959-21.979 mm (0.864-0.865 in)
Connecting rod length (center-to-center)150.7 mm (5.93 in)
Connecting rod maximum allowed bend0.038 mm per 25 mm (0.0015-0.984 in)
Connecting rod maximum allowed twist (3)0.050 mm per 25 mm (0.0015-0.984 in)
Connecting rod bearing bore diameter56.756-56.876 mm (2.234-2.24 in)
Connecting rod bearing-to-crankshaft clearance0.027-0.069 mm (0.001-0.0027 in)
Connecting rod side clearance (assembled to crank) - standard0.015-0.45 mm (0.0006-0.0177 in)
Connecting rod side clearance (assembled to crank) - service limit0.05 mm (0.002 in) max.
Accessory Drive Belt
Drive belt6 ribs
(1) The addition of Motorcraft Cooling System Stop Leak Pellets, VC-6, darkens Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
(2) Time required for the plunger to leak down 1.6 mm of travel with 222 N force and leak-down fluid in the lash adjuster.
(3) The pin bore and crank bearing bore must be parallel and in the same vertical plane within the specified total difference when measured at the ends of a 203 mm bar, 105.5 mm on each side of rod centerline.
(1)The addition of Motorcraft Cooling System Stop Leak Pellets, VC-6, darkens Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
(2)Time required for the plunger to leak down 1.6 mm of travel with 222 N force and leak-down fluid in the lash adjuster.
(3)The pin bore and crank bearing bore must be parallel and in the same vertical plane within the specified total difference when measured at the ends of a 203 mm bar, 105.5 mm on each side of rod centerline.

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

DescriptionNmLb-ftLb-in
Valve cover bolts1089
Camshaft bearing cap bolts1089
Camshaft sprocket bolts ()
Cylinder head temperature (CHT) sensor2619
Camshaft position (CMP) sensor bolt1089
Crankshaft position (CKP) sensor bolt1089
Connecting rod bolts (1)
Crankshaft damper pulley bolt (1)
Crankshaft main bearing bolts (cross-mounted) (1)
Crankshaft main bearing bolts (vertical) (1)
Cylinder head bolts (1)
Exhaust gas recirculation (EGR) system module-to-intake manifold bolts (1)
Exhaust manifold nuts2518
Accessory drive belt idler pulley bolt2518
Accessory drive belt tensioner pulley bolt2518
Flexplate bolts8059
Engine front cover bolts2518
Fuel injection supply manifold bracket bolts1089
Heater return tube studs2518
Ignition coil1089
Intake manifold bolts1089
Knock (KS) sensor2518
Oil filter1511
Oil filter adapter bolt2518
Oil level indicator tube bolt1089
Oil line connector adapter assembly bolt2518
Oil pan bolts (1)
Oil pan drain plug1410
Oil pressure switch1089
Oil pump bolts1089
Oil pump screen cover and tube bolts1089
Oil pump screen cover and tube spacer2518
Oil pump screen cover and tube spacer bolt2518
Power steering pump bolts2518
Crankshaft rear seal retainer plate bolts1089
Spark plugs1511
Thermostat housing bolts2518
Timing chain guide bolts1089
Timing chain hydraulic tensioner bolts2518
Coolant pump bolts2518
Coolant pump pulley bolts2518
EGR system module-to-exhaust manifold tube fittings4030
Power steering reservoir bracket-to-intake manifold bolt118
Power steering reservoir support bracket-to-intake manifold support bracket bolts1713
Power steering reservoir support bracket lower bolts4030
Accelerator control splash shield bolts1089
Motor mount-to-cylinder block bolts6346
Motor mount nut10376
Motor mount through bolt200148
(1) Refer to the procedure in this article.
(1)Refer to the procedure in this article.

TORQUE SPECIFICATIONS

Scheme 71

Scheme 71: Engine - Upper End

Scheme 72

Scheme 72

Scheme 73

Scheme 73: Engine Induction System

Scheme 74

Scheme 74: Engine - Lower End

Scheme 75

Scheme 75

Scheme 76

Scheme 76: Engine - Front End
WARNINGDo not operate the engine with the hood open until the fan blade has been first examined for possible cracks and separation.

The 4.6L (281 CID) is a V-8 engine with the following features

  1. Single overhead camshaft
  2. Two valves per cylinder
  3. Sequential multiport fuel injection (SFI)
  4. Aluminum cylinder heads
  5. Cast iron, 90-degree V-cylinder block
  6. Individually chain-driven camshafts with a hydraulic timing chain tensioner on each timing chain
  7. Electronic ignition system with eight ignition coils
  8. Electronic returnless fuel system
