Engine System - General Information: Specifications Ford Mustang V facelift

Material Specifications

MATERIAL SPECIFICATIONS

Torque Specifications

TORQUE SPECIFICATIONS

Note. When repairing engines, all parts must be contamination free. If contamination/foreign material is present when repairing an engine, premature engine failure may occur.

Note. Specifications show the expected minimum or maximum condition. Refer to appropriate Engine article(s) for the procedure.

Note. If a component fails to meet the specifications, it is necessary to refinish it or install a new component. Wear limits are provided as an aid to determine if the component can be refinished. A new component must be installed when any component fails to meet specifications and cannot be refinished.

Note. This service information contains information, steps and procedures that may not be specific to this engine.

This service information covers general procedures and diagnosis and testing of the engine system, except for exhaust emission control devices, which are covered in the INTRODUCTION article.

The engine incorporates the following features: Refer to the appropriate Engine article(s) for the procedure.

1. Crankcase ventilation or breather system
2. Exhaust emission control system
3. Evaporative Emission (EVAP) control system

Some engines incorporate a fail-safe cooling system. Refer to the appropriate Engine article(s) for the procedure.

The engine, fuel system, ignition system, emissions system and exhaust system all affect exhaust emission levels and must be maintained according to the maintenance schedule. Refer to the scheduled Maintenance Guide.

Correct engine identification is required to order parts. Refer to the appropriate Engine article(s) for the procedure.

For complete vehicle and engine identification codes, refer to IDENTIFICATION CODES article.

MATERIAL SPECIFICATIONS

There are 2 diagnostic paths that can be followed depending on the type of engine concern. Carry out Inspection and Verification - Engine Performance or Inspection and Verification - Engine NVH.

MATERIAL SPECIFICATIONS

1. Clean the cylinder bores with soap or detergent and water.
2. Thoroughly rinse with clean water and wipe dry with a clean, lint-free cloth.
3. Use a clean, lint-free cloth and lubricate the cylinder bores. Use clean engine oil meeting Ford specification.

MATERIAL SPECIFICATIONS

Note. It is necessary to use High Temperature Retaining Compound Loctite® 620™/Permatex® 62050 or equivalent on all 3 valve modular engine cylinder head cup plugs. If not used, the cylinder head cup plugs could leak or seep, causing serious engine damage.

Note. Use threadlock 262 on all other applications.

All core plugs

Scheme 2295

Scheme 2296

Scheme 2297

Scheme 2298

Scheme 2299

Scheme 2300

Scheme 2301

1. Inspect the spark plug for a bridged gap. Check for deposit build-up closing the gap between the electrodes. Deposits are caused by oil or carbon fouling. Install a new spark plug.
2. Check for oil fouling. Check for wet, black deposits on the insulator shell bore electrodes, caused by excessive oil entering the combustion chamber through worn rings and pistons, excessive valve-to-guide clearance or worn or loose bearings. Correct the oil leak concern. Install a new spark plug.
3. Inspect for carbon fouling. Look for black, dry, fluffy carbon deposits on the insulator tips, exposed shell surfaces and electrodes, caused by a spark plug with an incorrect heat range, dirty air cleaner, too rich a fuel mixture or excessive idling. Install new spark plugs.
4. Inspect for normal burning. Check for light tan or gray deposits on the firing tip.
5. Inspect for pre-ignition, identified by melted electrodes and a possibly damaged insulator. Metallic deposits on the insulator indicate engine damage. This may be caused by incorrect ignition timing, wrong type of fuel or the unauthorized installation of a heli-coil insert in place of the spark plug threads. Install a new spark plug.
6. Inspect for overheating, identified by white or light gray spots and a bluish-burnt appearance of electrodes. This is caused by engine overheating, wrong type of fuel, loose spark plugs, spark plugs with an incorrect heat range, low fuel pump pressure or incorrect ignition timing. Install a new spark plug.
7. Inspect for fused deposits, identified by melted or spotty deposits resembling bubbles or blisters. These are caused by sudden acceleration. Install new spark plugs.
