Evaporative Emissions System: Removal & Installation Ford Mustang V рестайлинг

Testing & Diagnostics 4 illustrations ~972 words

Removal and Installation

WARNINGDo not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGDo not carry personal electronic devices such as cell phones, pagers or audio equipment of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGAlways disconnect the battery ground cable at the battery when working on an evaporative emission (EVAP) system or fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.

5.0L vehicles

Scheme 115

Scheme 115
Scheme 115

Scheme 116

Scheme 116
Scheme 116
  1. If equipped, remove the 4 nuts and the strut tower cross brace. To install, tighten to 35 Nm (26 lb-ft).
  2. Remove the engine appearance cover. All vehicles
  3. Disconnect the battery ground cable. For additional information, refer to «BATTERY, BATTERY MOUNTING SYSTEM & BATTERY CABLES»(ref-439815) article.
  4. Disconnect the Evaporative Emission (EVAP) canister purge valve electrical connector.
  5. Disconnect the vapor tube-to- EVAP canister purge valve quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  6. Remove the 2 bolts and the EVAP canister purge valve. To install, tighten to 10 Nm (89 lb-in).
  7. To install, reverse the removal procedure. Carry out the Evaporative Emission System Leak Test. For additional information, refer to «EVAPORATIVE EMISSION SYSTEM LEAK TEST»(ref-439833-S13765298332011120900000) in this service information.
WARNINGDo not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGDo not carry personal electronic devices such as cell phones, pagers or audio equipment of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGAlways disconnect the battery ground cable at the battery when working on an evaporative emission (EVAP) system or fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
  1. Remove the Evaporative Emission (EVAP) canister. For additional information, refer to «EVAPORATIVE EMISSION CANISTER»(ref-439833-S08614659832011120900000) in this service information.
  2. Disconnect the EVAP canister vent solenoid electrical connector.
  3. Remove and discard the 3 EVAP canister nuts and 3 bolts. To install, tighten the new nuts and bolts to 7 Nm (62 lb-in).
  4. Separate the EVAP canister and tray to access the EVAP canister vent solenoid.
  5. Depress the locking tab outward, rotate the EVAP canister vent solenoid clockwise and remove it from the EVAP canister.
  6. To install, reverse the removal procedure. Carry out the Evaporative Emission System Leak Test. For additional information, refer to «EVAPORATIVE EMISSION SYSTEM LEAK TEST»(ref-439833-S13765298332011120900000) in this service information.

Removal

WARNINGDo not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGDo not carry personal electronic devices such as cell phones, pagers or audio equipment of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGAlways disconnect the battery ground cable at the battery when working on an evaporative emission (EVAP) system or fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.

All vehicles

Scheme 117

Scheme 117
Scheme 117
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-439777) article.
  2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, BATTERY MOUNTING SYSTEM & BATTERY CABLES»(ref-439815) article. Coupe vehicles
  3. Detach the fuel vapor tube retainer clip from the Evaporative Emission (EVAP) canister tray. Convertible vehicles
  4. Detach the 2 fuel vapor tube retainer clips from the rear body.
  5. Detach the 2 fresh air hose retainer clips from the rear body. All vehicles
  6. Disconnect the EVAP canister electrical connector and detach the wiring harness retainer from the EVAP canister tray.
  7. Disconnect the 2 fuel vapor tube quick connect couplings from the EVAP canister. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  8. Detach the fresh air hose from the 2 retainer clips.
  9. Remove the 2 EVAP canister assembly bolts.
  10. Remove the 2 nuts and the EVAP canister assembly.
  11. If the original EVAP canister assembly will be reinstalled, remove and discard any damaged tinnerman washers from the EVAP canister tray flange.

Installation

All vehicles

  1. If necessary, install new tinnerman washers onto the EVAP canister tray flange.
  2. Install the EVAP canister assembly and the 2 nuts. Tighten to 7 Nm (62 lb-in).
  3. Install the 2 EVAP canister assembly bolts. Tighten to 7 Nm (62 lb-in).
  4. Align the colored band on the fresh air hose with the retainer clip and attach the hose. Attach the fresh air hose to the remaining retainer clip.
  5. Connect the 2 fuel vapor tube quick connect couplings to the EVAP canister. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  6. Connect the EVAP canister electrical connector and attach the wiring harness retainer to the EVAP canister tray. Convertible vehicles
  7. Attach the 2 fresh air hose retainer clips to the rear body.
  8. Attach the 2 fuel vapor tube retainer clips to the rear body. Coupe vehicles
  9. Attach the fuel vapor tube retainer clip to the EVAP canister tray. All vehicles
  10. Connect the battery ground cable. For additional information, refer to «BATTERY, BATTERY MOUNTING SYSTEM & BATTERY CABLES»(ref-439815) article.
  11. Carry out the Evaporative Emission System Leak Test. For additional information, refer to «EVAPORATIVE EMISSION SYSTEM LEAK TEST»(ref-439833-S13765298332011120900000) in this service information.
WARNINGDo not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGDo not carry personal electronic devices such as cell phones, pagers or audio equipment of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGAlways disconnect the battery ground cable at the battery when working on an evaporative emission (EVAP) system or fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.

Scheme 118

Scheme 118
Scheme 118
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-439777) article.
  2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, BATTERY MOUNTING SYSTEM & BATTERY CABLES»(ref-439815) article.
  3. Detach the fuel vapor tube assembly from the retainer clip.
  4. Disconnect the fuel vapor tube assembly-to-Evaporative Emission (EVAP) canister vapor tube quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  5. Disconnect the fuel vapor tube assembly-to-fuel tank quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  6. Disconnect the fuel vapor tube assembly-to-fuel tank filler pipe recirculation tube quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  7. Release the fuel vapor tube assembly separator clips.
  8. Detach the fresh air hose from the 2 retainer clips.
  9. Disconnect the Fuel Tank Pressure (FTP) sensor electrical connector.
  10. Detach the fuel vapor tube assembly retainer clip from the rear body.
  11. Remove the bolt and the fuel vapor tube assembly.
  1. Install the fuel vapor tube assembly and the bolt. Tighten to 5 Nm (44 lb-in).
  2. Attach the fuel vapor tube assembly retainer clip to the rear body.
  3. Connect the FTP sensor electrical connector.
  4. Align the colored band on the fresh air hose with the retainer clip and attach the hose. Attach the fresh air hose to the remaining retainer clip.
  5. Attach the fuel vapor tube assembly separator clips.
  6. Connect the fuel vapor tube assembly-to-fuel tank filler pipe recirculation tube quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  7. Connect the fuel vapor tube assembly-to-fuel tank quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  8. Connect the fuel vapor tube assembly-to- EVAP canister vapor tube quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  9. Attach the fuel vapor tube assembly to the retainer clip.
  10. Connect the battery ground cable. For additional information, refer to «BATTERY, BATTERY MOUNTING SYSTEM & BATTERY CABLES»(ref-439815) article.
  11. Carry out the Evaporative Emission System Leak Test. For additional information, refer to «EVAPORATIVE EMISSION SYSTEM LEAK TEST»(ref-439833-S13765298332011120900000) in this service information.
