Phase 1 - Leak Verification

  1. Run the EVAP Test with the scan tool.
  2. If the Evaporative Emission (EVAP) system failed the EVAP Test, then proceed to «PHASE 2»(ref-439833-S02811358932011120900000) .

Phase 2 - System Leak Check

  1. Disconnect the fuel vapor tube-to- EVAP canister purge valve quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  2. Connect the VACUTEC Smoke Machine Fuel EVAP Emissions System Tester to the fuel vapor tube quick connect coupling. For additional information, refer to the manufacturer's instructions.
  3. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-439777) article.
  4. Connect the battery ground cable. For additional information, refer to «BATTERY, BATTERY MOUNTING SYSTEM & BATTERY CABLES»(ref-439815) .
  5. Close the canister vent solenoid with the scan tool.
  6. Install the supplemental refueling adapter into the Easy Fuel ™ (capless) fuel tank filler pipe assembly.
  7. Introduce smoke from the VACUTEC Smoke Machine Fuel EVAP Emissions System Tester into the EVAP system and verify that smoke is exiting the fuel tank filler pipe neck area. For additional information, refer to the manufacturer's instructions.
  8. Remove the supplemental refueling adapter once smoke is observed exiting the fuel tank filler pipe neck area.
  9. Continue to enter smoke into the system for 60 seconds to obtain pressure.
  10. Press and release the remote start button in intervals of 15 seconds ON and 15 seconds OFF while checking for exiting smoke.
  11. Use the halogen light provided with the VACUTEC Smoke Machine Fuel EVAP Emissions System Tester to follow the EVAP system path and look for smoke exiting at the source of the leak(s).
  12. Repair any leaks as necessary.
  13. Repeat the leak test until the system passes.

Scheme 121

Scheme 121: Evaporative Emission (EVAP) Canister - Coupe
ItemPart NumberDescription
1W715191Evaporative Emission (EVAP) canister assembly bolt (2 required)
2N621906EVAP canister assembly nut (2 required)
314A464EVAP canister assembly electrical connector (part of 14A005)
4Wiring harness retainer (part of 14A005)
5EVAP canister fuel vapor tube quick connect coupling (part of 9E857)
6Fuel vapor tube assembly quick connect coupling (part of 9E325)
7Retainer clip (part of 9J279)
8Retainer clip (part of 9E325)
99S327Fresh air hose
10Retainer clip (part of 9E325)

DESCRIPTION CHART

Scheme 122

Scheme 122: Evaporative Emission (EVAP) Canister - Convertible
ItemPart NumberDescription
1W715191Evaporative Emission (EVAP) canister assembly bolt (2 required)
2N621906EVAP canister assembly nut (2 required)
314A464EVAP canister assembly electrical connector (part of 14A005)
4Wiring harness retainer (part of 14A005)
5EVAP canister fuel vapor tube quick connect coupling (part of 9E857)
6Fuel vapor tube assembly quick connect coupling (part of 9E325)
7Retainer clip (part of 9J279)
8Fresh air hose retainer (part of 9S327)
9Retainer clip (part of 9E325)
109S327Fresh air hose
11Retainer clip (part of 9E325)

DESCRIPTION CHART

Scheme 123

Scheme 123: Evaporative Emission (EVAP) Canister Vent Solenoid
ItemPart NumberDescription
1Fresh air hose-to-tray retainer (Coupe only) (part of 9S327)
2Evaporative Emission (EVAP) canister tray (Coupe) (part of 9E857)
3EVAP canister tray (Convertible) (part of 9E857)
4W715253Tinnerman washer (2 required)
514A411Electrical harness
614A464EVAP canister vent solenoid electrical connector (part of 14A411)
79F945EVAP canister vent solenoid
8EVAP canister (part of 9E857)
9W700430EVAP canister nut (3 required)
10W708029EVAP canister bolt (3 required)
119S327Fresh air hose (Convertible shown in illustration, Coupe similar)
12Fresh air hose retainer (part of 9S327)
13Fresh air hose retainer (Convertible only) (part of 9S327)

DESCRIPTION CHART

Scheme 124

Scheme 124: Fuel Vapor Tube Assembly
ItemPart NumberDescription
1Fuel vapor tube assembly-to-fuel tank quick connect coupling (part of 9E325)
2W504081Fuel vapor tube assembly bolt
3Retainer clip (part of 9E325)
49S327Fresh air hose
5Retainer clip (part of 9E325)
614A464Fuel Tank Pressure (FTP) sensor electrical connector (part of 14A005)
7Separator clip (part of 9J279)
89E325Fuel vapor tube assembly
9Fuel vapor tube assembly-to-fuel tank filler pipe recirculation tube quick connect coupling (part of 9E325)
10Fuel vapor tube assembly-to-Evaporative Emission (EVAP) canister vapor tube quick connect coupling (part of 9E325)
11Separator clip (part of 9J279)
12Separator clip (part of 9E325)
13Retainer clip (part of 9J279)

DESCRIPTION CHART

Scheme 125

Scheme 125: Evaporative Emission (EVAP) Canister Purge Valve - 3.7L
ItemPart NumberDescription
1W500015Evaporative Emission (EVAP) canister purge valve bolt (2 required)
29J280Fuel vapor tube
314A464EVAP canister purge valve electrical connector (part of 12C508)
49G866EVAP canister purge valve

DESCRIPTION CHART

Scheme 126

Scheme 126: Evaporative Emission (EVAP) Canister Purge Valve - 5.0L
ItemPart NumberDescription
114A464Evaporative Emission (EVAP) canister purge valve electrical connector (part of 12C508)
29G271Fuel vapor tube
3W503278EVAP canister purge valve bolt (2 required)
49G866EVAP canister purge valve

DESCRIPTION CHART

Scheme 127

Scheme 127: Evaporative Emission (EVAP) Canister Purge Valve - 5.4L
ItemPart NumberDescription
114A464Evaporative Emission (EVAP) canister purge valve electrical connector (part of 12C508)
29G271Fuel vapor tube
3N806154EVAP canister purge valve bolt (2 required)
49G866EVAP canister purge valve

DESCRIPTION CHART

  1. Refer to the appropriate procedures and/or exploded views in this service information for any Warnings, Notices, Notes, Materials, Specifications, and Special Tools. Items in the exploded views may not be listed in order of removal.
