HVAC - Climate Control System: Specifications Ford Mustang V рестайлинг

Automatic HVAC System 7 illustrations ~386 words

MATERIAL SPECIFICATIONS

ItemSpecificationFill Capacity
Motorcraft® PAG Refrigerant Compressor Oil YN-12-DWSH-M1C231-B118 ml (4 fl oz)
Motorcraft® R-134a Refrigerant YN-19 (US); CYN-16-R (Canada)WSH-M17B19-A0.60 kg (21 oz) (1.32 lb)

MATERIAL SPECIFICATIONS

GENERAL SPECIFICATIONS

ItemSpecification
Magnetic Clutch
Clutch air gap0.35-0.60 mm (0.014-0.024 in)

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

DescriptionNm
A/C clutch disc and hub bolt20
A/C compressor bolt25
A/C compressor fitting nuts (suction and discharge)15
A/C compressor nut25
A/C compressor stud4
A/C pressure relief valve10
A/C slim-line fittings15
Compressor-to-condenser discharge line bracket bolt20
Condenser inlet fitting nut15
Condenser outlet fitting nut15
Cross brace bolts35
Evaporator outlet line bracket bolt7
Evaporator outlet line fitting nut15
Exterior heater core and evaporator core housing nuts7
Ground strap bolts (at RH shock tower)10
High-pressure Schrader-type valve2.5
High-pressure service gauge port valve cap0.8
High-pressure service gauge port valve extension bracket bolt7
Interior heater core and evaporator core housing nut9
Junction box bolt8
Junction box nut8
Lower condenser nut9
Low-pressure Schrader-type valve1.8
Low-pressure service gauge port valve cap0.8
Lower underbody shield bolts10
PCM bracket bolts8
PCM bracket studs8
Positive battery cable nut (at junction box)10
Receiver/drier bolt9
Thermostatic Expansion Valve (TXV) bolts7
TXV fitting nut15
Upper condenser bolt9
Wire harness retainer bolt20

TORQUE SPECIFICATIONS

ItemSpecification
Motorcraft® PAG Refrigerant Compressor Oil YN-12-DWSH-M1C231-B

MATERIAL SPECIFICATIONS

ItemSpecification
Motorcraft® PAG Refrigerant Compressor Oil YN-12-DWSH-M1C231-B

MATERIAL SPECIFICATIONS

ItemSpecification
Motorcraft® PAG Refrigerant Compressor Oil YN-12-DWSH-M1C231-B

MATERIAL SPECIFICATIONS

Scheme 154

Scheme 154
Scheme 154
ItemPart NumberDescription
119D644A/C pressure relief valve
2O-ring seal (part of 19D644)

ITEM DESCRIPTION

  1. Recover the refrigerant. For additional information, refer to «HVAC - CLIMATE CONTROL SYSTEM - GENERAL INFORMATION & DIAGNOSTICS»(ref-439786) article.
  2. Remove the A/C compressor pressure relief valve and O-ring seal. To install, tighten to 10 Nm (89 lb-in).
  3. To install, reverse the removal procedure. Add the correct amount of clean PAG oil to the refrigerant system. For additional information, refer to the Refrigerant Oil Add procedure in «HVAC - CLIMATE CONTROL SYSTEM - GENERAL INFORMATION & DIAGNOSTICS»(ref-439786) article.
  4. Evacuate, leak test and charge the refrigerant system. For additional information, refer to «HVAC - CLIMATE CONTROL SYSTEM - GENERAL INFORMATION & DIAGNOSTICS»(ref-439786) article.

Scheme 155

Scheme 155: AMBIENT AIR TEMPERATURE SENSOR
Scheme 155: AMBIENT AIR TEMPERATURE SENSOR
ItemPart NumberDescription
1Ambient temperature sensor electrical connector (part of 14290)
212A647Ambient temperature sensor

ITEM DESCRIPTION

ItemSpecification
Motorcraft® PAG Refrigerant Compressor Oil YN-12-DWSH-M1C231-B

MATERIAL SPECIFICATIONS

Material Specification

ItemSpecification
Motorcraft® PAG Refrigerant Compressor Oil YN-12-DWSH-M1C231-B

MATERIAL SPECIFICATIONS

Scheme 156

Scheme 156
Scheme 156
ItemPart NumberDescription
1W705436Upper radiator air deflector pin-type retainer (8 required)
28C291Upper radiator air deflector
3W707257Radiator bracket bolt (4 required)
48A193Radiator bracket (2 required)
5W520413Condenser inlet fitting nut

ITEM DESCRIPTION

Scheme 157

Scheme 157
Scheme 157
ItemPart NumberDescription
6W704652Upper condenser bolt (2 require)
7N801169Lower radiator air deflector screw (9 required)
817626Lower radiator air deflector
9W520101Lower condenser nut (2 required)
10W520413Condenser outlet fitting nut
1119712Condenser core
1219B596O-ring seal and gasket seal kit (2 required)

ITEM DESCRIPTION

ItemSpecification
Motorcraft® PAG Refrigerant Compressor Oil YN-12-DWSH-M1C231-B

MATERIAL SPECIFICATIONS

ItemSpecification
Motorcraft® PAG Refrigerant Compressor Oil YN-12-DWSH-M1C231-B

MATERIAL SPECIFICATIONS

ItemSpecification
Motorcraft® PAG Refrigerant Compressor Oil YN-12-DWSH-M1C231-B

MATERIAL SPECIFICATIONS

Scheme 158

Scheme 158
Scheme 158
ItemPart NumberDescription
118472Heater hose (2 required)
2W520413Thermostatic Expansion Valve (TXV) fitting nut
319B596Gasket seal (2 pieces from kit required)
4W704904Exterior heater core and evaporator core housing nut (2 required)

ITEM DESCRIPTION

Scheme 159

Scheme 159
Scheme 159
ItemPart NumberDescription
5Antenna cable retainer (part of 14A005)
6W702751Interior heater core and evaporator core housing nut
719850Heater core and evaporator core housing

ITEM DESCRIPTION

ItemSpecification
Motorcraft® PAG Refrigerant Compressor Oil YN-12-DWSH-M1C231-B

MATERIAL SPECIFICATIONS

Scheme 160

Scheme 160
Scheme 160
ItemPart NumberDescription
1Receiver/drier bolt
219C836Receiver/drier
3Receiver/drier fitting O-ring seal (4 required)

ITEM DESCRIPTION

ItemSpecification
Motorcraft® PAG Refrigerant Compressor Oil YN-12-DWSH-M1C231-B

MATERIAL SPECIFICATIONS

All vehicles

  1. Recover the refrigerant. For additional information, refer to «HVAC - CLIMATE CONTROL SYSTEM - GENERAL INFORMATION & DIAGNOSTICS»(ref-439786) article.
  2. If equipped, remove the 4 nuts and the strut tower cross brace. 5.0L (4V) vehicles
  3. Remove the engine appearance cover. 5.4L (4V) vehicles
  4. Drain the engine coolant. For additional information, refer to «SUPERCHARGER COOLING»(ref-439831) article.
  5. Disconnect the heater hose fittings at the rear of the RH cylinder head and position the heater hoses aside.
  6. Remove the Exhaust Gas Recirculation (EGR) system module tube. For additional information, refer to «EMISSION CONTROL SYSTEM»(ref-439832) article. All vehicles
  7. Remove the Thermostatic Expansion Valve (TXV) fitting nut and disconnect the fitting. Discard the gasket seals. To install, tighten to 15 Nm (133 lb-in).
  8. Remove the 2 TXV bolts. To install, tighten to 7 Nm (62 lb-in).
  9. Remove the TXV . Discard the gasket seals.
  10. To install, reverse the removal procedure. Install new gasket seals. Add the correct amount of clean PAG oil to the refrigerant system. For additional information, refer to the Refrigerant Oil Adding procedure in «HVAC - CLIMATE CONTROL SYSTEM - GENERAL INFORMATION & DIAGNOSTICS»(ref-439786) article.
  11. Evacuate, leak test and charge the refrigerant system. For additional information, refer to «HVAC - CLIMATE CONTROL SYSTEM - GENERAL INFORMATION & DIAGNOSTICS»(ref-439786) article.
