Special Tool(s)
SPECIAL TOOLS Tool, A/C Clutch Holding 412-150 Protector, A/C Compressor Shaft 412-137 Remover, A/C Compressor Field Coil 412-067 (T89P-19623-FH) Remover, Compressor Pulley 412-001 (T71P-19703-B)
Scheme 192
Scheme 193
Scheme 194
| Item | Part Number | Description |
|---|---|---|
| 1 | A/C clutch disc and hub bolt (part of 19D784) | |
| 2 | A/C clutch disc and hub (part of 19D784) | |
| 3 | A/C clutch disc and hub spacer (part of 19D784) | |
| 4 | A/C compressor pulley snap ring (part of 19D784) | |
| 5 | A/C compressor pulley (part of 19D784) | |
| 6 | A/C clutch field coil screw (4 required) (part of 19D784) | |
| 7 | A/C clutch field coil (part of 19D784) |
ITEM DESCRIPTION
Scheme 195
Scheme 196
- Remove the A/C compressor. For additional information, refer to «AIR CONDITIONING (A/C) COMPRESSOR - 3.7L»(ref-439844-S40701902612011120900000) or «AIR CONDITIONING (A/C) COMPRESSOR - 5.0L (4V), 5.4L (4V)»(ref-439844-S40500609912011120900000) in this service information.
- Remove the A/C clutch disc and hub bolt. Using the A/C Clutch Holding Tool, hold the A/C clutch disc and hub. Remove the A/C clutch disc and hub bolt.
- Remove the A/C clutch disc and hub.
- Remove the A/C clutch disc and hub spacer(s).
- Remove the A/C compressor pulley snap ring.
- Remove the A/C compressor pulley. Install the A/C compressor shaft protector. Install a suitable 3-jaw puller on the A/C compressor shaft protector and A/C compressor pulley. Remove the A/C compressor pulley.
- Remove the 3 A/C clutch field coil screws.
- Detach the A/C clutch field coil electrical connector pin-type retainer and remove the A/C clutch field coil.
