Front Suspension: Specifications Ford Mustang V

Suspension Front 4 illustrations ~142 words

GENERAL SPECIFICATIONS

ItemSpecification
Lubricant
Silicone Spray Lubricant XL-6ESR-M13P4-A

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

DescriptionNm
Caliper anchor plate bolts133
Brake disc shield bolts20
Lower ball joint nut103
Lower control arm forward bolt175
Lower control arm rearward nuts175
Heat shield bolts7
Brake line bracket bolt20
Strut rod nut80
Strut-to-spindle bolts200
Strut upper mount nuts35
Wheel hub nut300
Stabilizer bar bracket nuts70
Stabilizer bar link nuts115
Wheel speed sensor bolt15
Tie-rod end nuts80
Steering gear bolts115

TORQUE SPECIFICATIONS

WARNINGAll vehicles are equipped with gas-pressurized shock absorbers which will extend unassisted. Do not apply heat or flame to the shock absorbers during removal or component servicing. Failure to follow these instructions can result in personal injury.
CAUTIONSuspension fasteners are critical parts because they affect performance of vital components and systems and their failure can result in major service expense. A new part with the same part number or an equivalent part must be installed, if installation is necessary. Do not use a part of lesser quality or substitute design. Torque values must be used as specified during reassembly to ensure correct retention of these parts. Never attempt to heat, quench or straighten any front suspension part. Install a new part.

The front suspension is a MacPherson strut design. The design consists of

  1. Front shock absorber
  2. Front wheel spindle
  3. Front suspension lower arm
  4. Front stabilizer bar
  5. Front stabilizer bar link
  6. Front coil spring

Refer to SUSPENSION SYSTEM-GENERAL INFORMATION .

Identifying Wheel Studs. Scheme 1

Scheme 1: Identifying Wheel Studs

Scheme 2

Scheme 2: Removal
  1. Remove the wheel bearing and hub assembly. For additional information, refer to «WHEEL BEARING AND WHEEL HUB»(ref-256456-S08158269202007061500000) in this article.
  2. Using a press, remove the wheel stud from the wheel bearing and hub assembly. (Scheme 2): Removing Wheel Stud From Wheel Bearing

Scheme 3

Scheme 3: Installation
  1. Using a press, install a new wheel stud. (Scheme 3): Installing Wheel Stud
  2. Install the wheel bearing and hub assembly. For additional information, refer to «WHEEL BEARING AND WHEEL HUB»(ref-256456-S08158269202007061500000) in this article.

Identifying Wheel Bearing And Wheel Hub Components. Scheme 4

Scheme 4: Identifying Wheel Bearing And Wheel Hub Components
