GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Base ignition timing | |
| Firing order | 1-4-2-5-3-6 |
| Spark plug gap | 1.32-1.42 mm (0.052-0.056 in) |
| Spark plug type | AGSF24N |
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Spark plugs | 17 |
| Ignition coil bolts | 6 |
| Ignition coil bracket-to-cylinder head bolt (M8) | 23 |
| Ignition coil bracket-to-cylinder head bolts (M12) | 80 |
| Ignition coil bracket-to-intake manifold bolts | 8 |
TORQUE SPECIFICATIONS
The ignition system consists of the
- crankshaft position (CKP) sensor.
- ignition coil.
- spark plug wire.
- spark plug.
The ignition system is
- an electronic distributorless ignition system (EDIS) controlled by an electronic engine control integrated into the powertrain control module (PCM).
- set at 10 degrees before top dead center (BTDC) for base timing, and is not adjustable.
The crankshaft position (CKP) sensor
- is a variable reluctance sensor.
- senses a missing tooth on the crankshaft damper pulse ring.
- generates a crankshaft position signal which is sent to the PCM. The PCM counts this signal for engine rpm.
The ignition coil
- changes low voltage pulses from the PCM to high voltage pulses.
- has 3 transformers.
- fires 2 spark plugs simultaneously.
Spark plug wires carry high voltage pulses from the ignition coil to the spark plugs.
The spark plugs
- change high voltage pulses to spark at the gap, which ignites the fuel and air mixture.
The firing order is: 1-4-2-5-3-6.
Scheme 1
Refer to the INTRODUCTION - GASOLINE article.
Scheme 2
- For additional information, refer to the appropriate procedure.
