Fluorescent Dye Injection - Using a Dye Injector Loop Kit Ford Mustang V

HVAC Control System - General Information and Diagnostics 6 illustrations ~427 words

Fluorescent Dye Injection - Using a Dye Injector Loop Kit

Note. Fluorescent refrigerant system dye is added to the refrigerant system at the factory to assist in refrigerant system leak diagnosis using a Rotunda-approved ultraviolet blacklight. It is not necessary to add additional dye to the refrigerant system before diagnosing leaks, even if a significant amount of refrigerant has been removed from the system. Replacement suction accumulators and receiver/driers are shipped with a fluorescent dye "wafer" included in the desiccant bag which will dissolve after approximately 30 minutes of continued A/C operation. It is not necessary to add dye after flushing or filtering the refrigerant system because a new suction accumulator or receiver/drier is installed as part of the flushing or filtering procedure. Additional refrigerant system dye should only be added if more than 50% of the refrigerant system lubricant capacity has been lost due to a fitting separation, hose rupture or other damage.

Note. Before using the R-134a fluorescent dye injector for the first time, refer to the equipment manufacturer's instructions on evacuation of non-condensable gasses from the hoses.

Note. Refrigerant system pressure should be between 413-551 kPa (60-80 psi) at 24°C (75°F).

Scheme 126

Scheme 126: Fluorescent Dye Injection - Using a Dye Injector Loop Kit
Scheme 126: Fluorescent Dye Injection - Using a Dye Injector Loop Kit

Scheme 127

Scheme 127
Scheme 127

Scheme 128

Scheme 128
Scheme 128

Scheme 129

Scheme 129
Scheme 129

Scheme 130

Scheme 130
Scheme 130

Scheme 131

Scheme 131
Scheme 131
  1. Verify that the valves on the deluxe injector loop kit are closed. (Scheme 112): Identifying Valves On Fluorescent Dye Injector
  2. Fill the deluxe injector loop kit reservoir with 7 ml (0.25 oz) of fluorescent dye. (Scheme 113): Locating Dye Injector Reservoir
  3. Install the deluxe injector loop kit between the high-pressure and low-pressure service gauge port valves. CAUTION: Make sure all tools and hoses are clear of the engine cooling fan and drive belt before starting the engine.
  4. Start the engine.
  5. Open the high-pressure service valve. (Scheme 114): Identifying High-Pressure Service Valve
  6. Open the deluxe injector loop kit valves and inject the fluorescent dye into the refrigerant system. (Scheme 115): Identifying Valves On Deluxe Injector Loop Kit
  7. Close the high-pressure service valve to allow the pressure inside the deluxe injector loop kit to equalize with the suction side of the refrigerant system. (Scheme 116): Identifying High-Pressure Service Valve NOTE: Close the valves on the deluxe injector loop kit while the A/C compressor is operating.
  8. Close the valves on the deluxe injector loop kit. (Scheme 117): Identifying Valves On Deluxe Injector Loop Kit NOTE: Leave all valves on the special tool closed when not in use.
  9. Disconnect the high-pressure and low-pressure service valves and remove the deluxe injector loop kit from the vehicle.
