System Operation
Refer to ENGINE CONTROLS - INTRODUCTION (EXCEPT DIESEL & HYBRID) (SECTION 0) .
Component Description
Refer to the ENGINE CONTROLS - INTRODUCTION (EXCEPT DIESEL & HYBRID) (SECTION 0) .
Refer to the ENGINE CONTROLS - INTRODUCTION (EXCEPT DIESEL & HYBRID) (SECTION 0) .
Scheme 42
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | EGR system module electrical connector |
| 2 | 9E498 | Engine vacuum harness-to-EGR system module connector |
| 3 | EGR system module tube-to-EGR system module fitting (part of 9D477) | |
| 4 | 9F485 | EGR system module tube-to-exhaust manifold fitting |
| 5 | 9D477 | EGR system module tube |
| 6 | W701232 | EGR system module bolts (2 required) |
| 7 | 9Y456 | EGR system module |
| 8 | 9D476 | EGR system module gasket |
- Refer to the procedures and/or exploded views for any Warnings, Notices, Notes, Materials, Specifications, and Special Tools. Items in the exploded views may not be listed in order of removal.
Scheme 43
- Disconnect the EGR system module electrical connector.
- Disconnect the engine harness vacuum-to-EGR system module connector.
- Disconnect the EGR system module tube-to-EGR system module fitting. To install, tighten to 40 Nm (30 lb-ft).
- NOTE: Upon installation, make sure to install the correct EGR system module mounting gasket. Even though varying gaskets may be very similar, orifice sizes may differ thus causing performance issues. Remove the 2 bolts, the EGR system module and the gasket. Discard the gasket. To install, tighten to 25 Nm (18 lb-ft).
- NOTE: Do not use metal scrapers, wire brushes, power abrasive disc or other abrasive means to clean the sealing surfaces. These tools cause scratches and gouges which make leak paths. Use a plastic scraping tool to remove all traces of the old gasket. NOTE: The EGR system module sealing surfaces are soft metals. Carefully clean the EGR system module sealing surfaces.
- To install, reverse the removal procedure. Install a new gasket with the raised circle facing away from the EGR system module.
