Parking Aid System: Other Ford Mustang V рестайлинг 2

Video

The rear video camera system consists of the following

1. Video camera (located in the rear spoiler)
2. Auto-dimming interior mirror (without navigation)
3. Front Display Interface Module (FDIM) (with navigation)

The video camera is activated when the transmission selector is in the REVERSE (R) position. The image from the rear video camera is displayed in the LH side of the auto-dimming interior mirror (without navigation) or the FDIM (with navigation).

SPECIAL TOOLS Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Flex Probe Kit NUD105-R025D or equivalent

Scheme 31

Scheme 32

Scheme 33

Parking Aid - Video

SPECIAL TOOLS Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Flex Probe Kit 300-NUD105-R025DE or equivalent

Parking Aid Module (PAM)

1. NOTE: If installing a new Parking Aid Module (PAM), it is necessary to upload the PAM configuration information to the scan tool. For additional information, refer to «MODULE CONFIGURATION»(ref-574112) . Refer to exploded view(s) and any Warnings, Notices, Notes, Materials, Specifications, and Special Tools. Items in the exploded views may not be listed in order of removal.
2. To install, reverse the removal procedure. If a new PAM was installed, download the PAM configuration information from the scan tool into the new PAM. For additional information, refer to «MODULE CONFIGURATION»(ref-574112) .

Parking Aid Speaker

1. Refer to exploded view(s) and any Warnings, Notices, Notes, Materials, Specifications, and Special Tools. Items in the exploded views may not be listed in order of removal.

Scheme 34

1. Remove the rear bumper cover. Refer to «BUMPERS»(ref-574147) .
