Parking Aid System: Diagnosis Ford Mustang V рестайлинг 2

Inspection and Verification

1. Verify the customer concern.
2. Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Body Control Module (BCM) fuse 32 (10A) Wiring, terminals or connectors Parking aid sensors
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. NOTE: Make sure to use the latest scan tool software release. If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
5. NOTE: The Vehicle Communication Module (VCM) LED prove-out confirms power and ground from the DLC are provided to the VCM. If the scan tool does not communicate with the vehicle: Verify the ignition is ON. The air bag warning indicator prove-out confirms ignition ON (other indicators may NOT prove ignition is ON) confirms ignition ON. If ignition does not turn ON, refer to «STEERING COLUMN SWITCHES»(ref-574137) to diagnose no power in RUN. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-574111) , Inspection and Verification to establish a scan tool session.
6. NOTE: The ignition must be OFF to carry out the Remote Function Actuator (RFA) module self-test. Carry out the self-test diagnostics for the RFA module and Parking Aid Module (PAM).
7. If the DTCs retrieved are related to the concern, go to «DTC CHARTS»(ref-574192-S24823954902013082300000) . For all other DTCs, refer to the Diagnostic Trouble Code (DTC) Chart in «MULTIFUNCTION ELECTRONIC MODULES»(ref-574135) .
8. If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(ref-574192-S17398896252013082300000) .

PAM PID CHART

DTC Charts

Note. Refer to Description and Operation, Intelligent Access (IA) with Push Button Start ANTI-THEFT SYSTEM - PASSIVE ANTI-THEFT SYSTEM to review the procedures for achieving the various ignition states (ignition in accessory, on, start, off) on vehicles with this feature.

PARKING AID MODULE (PAM) DTC CHART

Symptom Chart

SYMPTOM CHART

PINPOINT TEST A: THE PARKING AID IS INOPERATIVE

1. A1 CHECK THE DTCs FROM THE PAM SELF-TEST Check the PAM DTCs from the self-test. Are any PAM DTCs recorded? Yes : REFER to «DTC CHARTS»(ref-574192-S14147795662013082300000) . No : GO to A2.
2. A2 CHECK THE MESSAGE CENTER FOR CORRECT OPERATION While observing the message center, disable and enable the parking aid system. Does the message center display PARK AID OFF when the parking aid system is disabled, and display PARK AID ON when the parking aid system is enabled? Yes : GO to A3. No : REFER to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-574138) .
3. A3 CHECK FOR CORRECT REVERSE GEAR INPUT Apply the parking brake. Ignition ON. Select REVERSE. Enter the following diagnostic mode on the scan tool: PAM DataLogger. Monitor the PAM transmission range PID (TRANSGR). Does the PID indicate YES (transmission in reverse)? Yes : GO to A4. No : REFER to «AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80»(ref-574115) .
4. A4 CHECK FOR CORRECT PAM OPERATION Ignition OFF. Disconnect the PAM connector. Check for: corrosion damaged pins pushed-out pins Connect the PAM connector and make sure it seats correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : INSTALL a new PAM. REFER to «PARKING AID MODULE (PAM)»(ref-574192-S29024297112013082300000) . TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test B: DTC B1B44:14, B1B46:14, B1B48:14 Or B1B50:14

Refer to SYSTEM WIRING DIAGRAMS , Parking Aid for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 1

Scheme 2

1. B1 RETRIEVE THE DTCs FROM THE PAM SELF-TEST Check the PAM DTCs from the self-test. Are multiple DTCs recorded? Yes : GO to B2. No : For DTC B1B44:14, B1B46:14, B1B48:14 or B1B50:14, GO to B3 . For all other DTCs, REFER to «DTC CHARTS»(ref-574192-S14147795662013082300000) .
2. B2 CHECK THE BUMPER WIRING HARNESS Inspect the bumper wiring harness for opens, shorts, grounds, or corrosion. Is the bumper wiring harness OK? Yes : GO to B3. No : REPAIR or INSTALL a new bumper wiring harness. CLEAR the DTCs. TEST the system for normal operation.
3. B3 CHECK THE SENSOR CIRCUITRY FOR OPENS Ignition OFF. Disconnect: Suspect Parking Aid Sensor C4009, C4010, C4011 or C4012. Disconnect: PAM C4014. Measure the resistance between the PAM C4014, harness side and the suspect parking aid sensor, harness side as follows: DTC Rear Sensor PAM Connector - Pin Sensor Connector - Pin Circuit B1B44:14 RH outer C4014-9 C4011-1 LMP07 (BU/WH) C4014-16 C4011-2 VMP17 (YE/OG) C4014-12 C4011-3 RMP07 (GN/WH) B1B46:14 RH inner C4014-9 C4012-1 LMP07 (BU/WH) C4014-13 C4012-2 VMP16 (YE/GY) C4014-12 C4012-3 RMP07 (GN/WH) B1B48:14 LH outer C4014-9 C4009-1 LMP07 (BU/WH) C4014-15 C4009-2 VMP15 (YE/GN) C4014-12 C4009-3 RMP07 (GN/WH) B1B50:14 LH inner C4014-9 C4010-1 LMP07 (BU/WH) C4014-14 C4010-2 VMP14 (WH/OG) C4014-12 C4010-3 RMP07 (GN/WH) Are the resistances less than 5 ohms? Yes : GO to B4. No : REPAIR the circuit in question. CLEAR the DTCs. TEST the system for normal operation.
4. B4 CHECK THE SENSOR CIRCUITRY FOR SHORTS TO GROUND Measure the resistance between the suspect parking aid sensor, harness side and ground as follows: DTC Rear Sensor Connector-Pin Circuit B1B44:14 RH outer C4011-2 VMP17 (YE/OG) B1B46:14 RH inner C4012-2 VMP16 (YE/GY) B1B48:14 LH outer C4009-2 VMP15 (YE/GN) B1B50:14 LH inner C4010-2 VMP14 (WH/OG) Is the resistance greater than 10, 000 ohms? Yes : If all of the parking aid sensors recorded DTCs, GO to B5. If one or more (but not all) parking aid sensor(s) recorded DTCs, INSTALL a new sensor(s) for the one(s) in question. REFER to «PARKING AID SENSOR»(ref-574192-S38745074582013082300000) . CLEAR the DTCs. TEST the system for normal operation. No : REPAIR the circuit in question. CLEAR the DTCs. TEST the system for normal operation.
5. B5 CHECK FOR CORRECT PAM OPERATION Connect: All Disconnected Connectors. Disconnect the PAM connector. Check for: corrosion damaged pins pushed-out pins Connect the PAM connector and make sure it seats correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : INSTALL a new PAM. REFER to «PARKING AID MODULE (PAM)»(ref-574192-S29024297112013082300000) . TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

Pinpoint Test C: DTCs B1B44:12, B1B46:12, B1B48:12 and B1B50:12

Refer to SYSTEM WIRING DIAGRAMS , Parking Aid for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 3

Scheme 4

1. C1 RETRIEVE THE DTCs FROM THE PAM SELF-TEST Check the PAM DTCs from the self-test. Are multiple DTCs recorded? Yes : GO to C2. No : For DTCs B1B44:12, B1B46:12, B1B48:12 and B1B50:12, GO to C3 . For all other DTCs, REFER to «DTC CHARTS»(ref-574192-S14147795662013082300000) .
2. C2 CHECK THE BUMPER WIRING HARNESS Inspect the bumper wiring harness for opens, shorts, grounds, or corrosion. Is the bumper wiring harness OK? Yes : GO to C3. No : REPAIR or INSTALL a new bumper wiring harness. CLEAR the DTCs. REPEAT the self-test.
3. C3 CHECK THE SENSOR CIRCUITRY FOR SHORTS TO VOLTAGE Ignition OFF. Disconnect: Suspect Parking Aid Sensor C4009, C4010, C4011 or C4012. Disconnect: PAM C4014. Ignition ON. Measure the voltage between the suspect parking aid sensor, harness side and ground as follows: DTC Rear Sensor Connector-Pin Circuit B1B44:12 RH outer C4011-2 VMP17 (YE/OG) B1B46:12 RH inner C4012-2 VMP16 (YE/GY) B1B48:12 LH outer C4009-2 VMP15 (YE/GN) B1B50:12 LH inner C4010-2 VMP14 (WH/OG) Is any voltage present? Yes : REPAIR the circuit in question. CLEAR the DTCs. TEST the system for normal operation. No : GO to C4.
4. C4 CHECK THE PARKING AID SENSOR CIRCUITRY FOR A SHORT TOGETHER Measure the resistance between the suspect parking aid sensor pins, harness side as follows: DTC Parking Aid Sensor Connector-Pin/Circuit Connector-Pin/Circuit B1B44:12 RH outer C4011-2 VMP17 (YE/OG) C4011-1 LMP07 (BU/WH) B1B46:12 RH inner C4012-2 VMP16 (YE/GY) C4012-1 LMP07 (BU/WH) B1B48:12 LH outer C4009-2 VMP15 (YE/GN) C4009-1 LMP07 (BU/WH) B1B50:12 LH inner C4010-2 VMP14 (WH/OG) C4010-1 LMP07 (BU/WH) Is the resistance greater than 10, 000 ohms? Yes : If all sensor DTCs are set, GO to C5. If one or more parking aid sensor(s) recorded DTCs, INSTALL a new sensor(s) for the one in question. REFER to «PARKING AID SENSOR»(ref-574192-S38745074582013082300000) . CLEAR the DTCs. TEST the system for normal operation. No : REPAIR the circuits in question. CLEAR the DTCs. TEST the system for normal operation.
5. C5 CHECK FOR CORRECT PAM OPERATION Connect: All Disconnected Connectors. Disconnect the PAM connector. Check for: corrosion damaged pins pushed-out pins Connect the PAM connector and make sure it seats correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : INSTALL a new PAM. REFER to «PARKING AID MODULE (PAM)»(ref-574192-S29024297112013082300000) . TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST D: DTCs B1B44:96, B1B46:96, B1B48:96 AND B1B50:96

1. D1 CHECK THE DTCs FROM THE PAM SELF-TEST Check the PAM DTCs from the self-test. Are parking aid DTCs other than B1B44:96, B1B46:96, B1B48:96 and B1B50:96 recorded? Yes : DIAGNOSE the other DTCs first. REFER to «DTC CHARTS»(ref-574192-S14147795662013082300000) . No : GO to D2.
2. D2 CHECK THE PARKING AID SENSOR OPERATION NOTE: Make sure the area around the vehicle is clear of anything that can activate the parking aid system. Clean the rear bumper and sensors with high-pressure water. Carry out the azimuth system check. Refer to «AZIMUTH SYSTEM CHECK»(ref-574192-S33543389722013082300000) . Carry out the elevation system check. Refer to «ELEVATION SYSTEM CHECK»(ref-574192-S00875643922013082300000) . Does the parking aid system pass both system checks? Yes : The system is operating correctly at this time. The concern may have been caused by a dirty or blocked parking aid sensor. CLEAR the DTCs. TEST the system for normal operation. No : GO to D3.
3. D3 CHECK THE PARKING AID SENSOR DISTANCE PIDs Make sure the suspect parking aid sensor(s) is flush-mounted in the bezel. Ignition ON. Enter the following diagnostic mode on the scan tool: PAM DataLogger. With the brake pedal applied, shift the transmission into reverse and monitor the parking aid sensor distance PID (LRI_DIST, LRO_DIST, RRI_DIST, RRO_DIST). The PID reads 255 cm (100 in or 8.4 ft) on a correctly functioning sensor. Does the PID read 255 cm (100 in or 8.4 ft)? Yes : GO to D5 . No : GO to D4.
4. D4 CHECK THE PARKING AID SENSORS Install a new sensor for the suspect parking aid sensor. Ignition ON. Clear the DTCs. Repeat the self-test. Operate the system and verify the concern is still present. Is the concern still present? Yes : GO to D5. No : The cause of the concern was an inoperative parking aid sensor. The system is now operating correctly.
5. D5 CHECK FOR CORRECT PAM OPERATION Disconnect the PAM connector. Check for: corrosion damaged pins pushed-out pins Connect the PAM connector and make sure it seats correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : INSTALL a new PAM. REFER to «PARKING AID MODULE (PAM)»(ref-574192-S29024297112013082300000) . TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

Pinpoint Test E: DTC B1B58:11

Refer to SYSTEM WIRING DIAGRAMS , Parking Aid for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 5

Scheme 6

1. E1 CHECK THE BUMPER WIRING HARNESS Inspect the bumper wiring harness for opens, shorts, grounds, or corrosion. Is the bumper wiring harness OK? Yes : GO to E2. No : REPAIR or INSTALL a new bumper wiring harness. CLEAR the DTCs. TEST the system for normal operation.
2. E2 CHECK THE LH OUTER PARKING AID SENSOR FOR AN INTERNAL SHORT Ignition OFF. Disconnect: Parking Aid Sensor C4009. Ignition ON. NOTE: It is normal for the sensor open signal DTC B1B48:14 to set when carrying out this step. It can be ignored. Clear the DTCs. Repeat the on-demand self-test. Is DTC B1B58:11 still present? Yes : GO to E3. No : INSTALL a new LH outer parking aid sensor. REFER to «PARKING AID SENSOR»(ref-574192-S38745074582013082300000) . CLEAR the DTCs. TEST the system for normal operation.
3. E3 CHECK THE RH OUTER PARKING AID SENSOR FOR AN INTERNAL SHORT Ignition OFF. Disconnect: Parking Aid Sensor C4011. Ignition ON. NOTE: It is normal for the sensor open signal DTC B1B44:14 to set when carrying out this step. It can be ignored. Clear the DTCs. Repeat the on-demand self-test. Is DTC B1B58:11 still present? Yes : GO to E4. No : INSTALL a new RH outer parking aid sensor. REFER to «PARKING AID SENSOR»(ref-574192-S38745074582013082300000) . CLEAR the DTCs. TEST the system for normal operation.
4. E4 CHECK THE LH INNER PARKING AID SENSOR FOR AN INTERNAL SHORT Ignition OFF. Disconnect: Parking Aid Sensor C4010. Ignition ON. NOTE: It is normal for the sensor open signal DTC B1B50:14 to set when carrying out this step. It can be ignored. Clear the DTCs. Repeat the on-demand self-test. Is DTC B1B58:11 still present? Yes : GO to E5. No : INSTALL a new LH inner parking aid sensor. REFER to «PARKING AID SENSOR»(ref-574192-S38745074582013082300000) . CLEAR the DTCs. TEST the system for normal operation.
5. E5 CHECK THE RH INNER PARKING AID SENSOR FOR AN INTERNAL SHORT Ignition OFF. Disconnect: Parking Aid Sensor C4012. Ignition ON. NOTE: It is normal for the sensor open signal DTC B1B46:14 to set when carrying out this step. It can be ignored. Clear the DTCs. Repeat the on-demand self-test. Is DTC B1B58:11 still present? Yes : GO to E6. No : INSTALL a new RH inner parking aid sensor. REFER to «PARKING AID SENSOR»(ref-574192-S38745074582013082300000) . CLEAR the DTCs. TEST the system for normal operation.
6. E6 CHECK THE PARKING AID SENSOR VOLTAGE SUPPLY CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect: PAM C4014. Measure the resistance between the PAM C4014-9, circuit LMP07 (BU/WH), harness side and ground. Is the resistance greater than 10, 000 ohms? Yes : GO to E7. No : REPAIR the circuit. CLEAR the DTCs. TEST the system for normal operation.
7. E7 CHECK THE PARKING AID SENSOR VOLTAGE SUPPLY CIRCUIT AND GROUND CIRCUIT FOR A SHORT TOGETHER Measure the resistance between the PAM C4014-9, circuit LMP07 (BU/WH), harness side and the PAM C4014-12, circuit RMP07 (GN/WH). Is the resistance greater than 10, 000 ohms? Yes : GO to E8. No : REPAIR the circuit in question. CLEAR the DTCs. TEST the system for normal operation.
8. E8 CHECK FOR CORRECT PAM OPERATION Connect: All Disconnected Connectors. Disconnect the PAM connector. Check for: corrosion damaged pins pushed-out pins Connect the PAM connector and make sure it seats correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : INSTALL a new PAM. REFER to «PARKING AID MODULE (PAM)»(ref-574192-S29024297112013082300000) . TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

Pinpoint Test F: DTCs B1B52:12 and B1B52:14

Refer to SYSTEM WIRING DIAGRAMS , Parking Aid for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. F1 CHECK THE RECORDED DTCs FROM THE PAM SELF-TEST Ignition ON. Check the recorded PAM DTCs from the self-test. Are parking aid DTCs other than B1B52:12 or B1B52:14 present? Yes : DIAGNOSE other DTCs first. REFER to «DTC CHARTS»(ref-574192-S14147795662013082300000) . No : GO to F2.
2. F2 MEASURE THE PARKING AID SPEAKER RESISTANCE Disconnect: Parking Aid Speaker C2024. Measure the resistance between the parking aid speaker pin 2, component side and the parking aid speaker pin 1, component side. Is the resistance between 40 and 60 ohms? Yes : For DTC B1B52:14, GO to F3. For DTC B1B52:12, GO to F7 . No : INSTALL a new parking aid speaker. REFER to «PARKING AID SPEAKER»(ref-574192-S18830003372013082300000) . CLEAR the DTCs. TEST the system for normal operation.
3. F3 CHECK THE PARKING AID SPEAKER (+) CIRCUIT FOR A SHORT TO GROUND Connect: Parking Aid Speaker C2024. Disconnect: PAM C4014. Measure the resistance between the PAM C4014-2, circuit VMP03 (VT/GN), harness side and ground. Is the resistance greater than 10, 000 ohms? Yes : GO to F5 . No : GO to F4.
4. F4 CHECK THE PARKING AID SPEAKER (+) CIRCUIT FOR A SHORT TO GROUND WITH THE PARKING AID SPEAKER DISCONNECTED Disconnect: Parking Aid Speaker C2024. Measure the resistance between the PAM C4014-2, circuit VMP03 (VT/GN), harness side and ground. Is the resistance greater than 10, 000 ohms? Yes : REPAIR circuit RMP09 (BU/GN). CLEAR the DTCs. TEST the system for normal operation. No : REPAIR circuit VMP03 (VT/GN). CLEAR the DTCs. TEST the system for normal operation.
5. F5 CHECK THE PARKING AID SPEAKER (+) CIRCUIT FOR AN OPEN Disconnect: Parking Aid Speaker C2024. Measure the resistance between the parking aid speaker C2024-2, circuit VMP03 (VT/GN), harness side and the PAM C4014-2, circuit VMP03 (VT/GN), harness side. Is the resistance less than 5 ohms? Yes : GO to F6. No : REPAIR the circuit. CLEAR the DTCs. TEST the system for normal operation.
6. F6 CHECK THE PARKING AID SPEAKER (-) CIRCUIT FOR AN OPEN Measure the resistance between the parking aid speaker C2024-1, circuit RMP09 (BU/GN), harness side and the PAM C4014-6, circuit RMP09 (BU/GN), harness side. Is the resistance less than 5 ohms? Yes : GO to F8 . No : REPAIR the circuit. CLEAR the DTCs. TEST the system for normal operation.
7. F7 CHECK THE PARKING AID SPEAKER CIRCUITRY FOR SHORTS TO VOLTAGE Ignition ON. Measure the voltage between the PAM C4014-2, circuit VMP03 (VT/GN), harness side and ground; and between the PAM C4014-6, circuit RMP09 (BU/GN), harness side and ground. Is any voltage present? Yes : REPAIR the circuit in question. CLEAR the DTCs. TEST the system for normal operation. No : GO to F8.
8. F8 CHECK FOR CORRECT PAM OPERATION Connect: All Disconnected Connectors. Disconnect the PAM connector. Check for: corrosion damaged pins pushed-out pins Connect the PAM connector and make sure it seats correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : INSTALL a new PAM. REFER to «PARKING AID MODULE (PAM)»(ref-574192-S29024297112013082300000) . CLEAR the DTCs. TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical and electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Spoiler and video camera Smart Junction Box (SJB) fuse(s): 14 (10A) 29 (5A) 41 (15A) (without navigation) Wiring, terminals and connectors Video camera Auto-dimming interior mirror (without navigation) Front Display Interface Module (FDIM) (with navigation)
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. NOTE: Make sure to use the latest scan tool software release. If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
5. NOTE: The Vehicle Communication Module (VCM) LED prove-out confirms power and ground from the DLC are provided to the VCM. If the scan tool still does not communicate with the VCM: Check the VCM connection to the vehicle. Check the scan tool connection to the VCM. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-574111) , No Power To The Scan Tool, to diagnose no power to the scan tool.
6. If the scan tool does not communicate with the vehicle: Verify the ignition key is in the RUN position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-574111) to diagnose no response from the PCM.
7. Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-574111) . If the network passes, retrieve and record the continuous memory DTCs.
8. Clear the continuous DTCs and carry out the self-test diagnostics for the ACM.
9. If the DTCs retrieved are related to the concern, go to «DTC CHARTS»(ref-574192-S14147795662013082300000) . For all other DTCs, refer to the Diagnostic Trouble Code (DTC) Chart in «MULTIFUNCTION ELECTRONIC MODULES»(ref-574135) .
10. If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(ref-574192-S30479108672013082300000) .

Note. This module utilizes a 5-character DTC followed by a 2-character failure-type code. The failure-type code provides information about specific fault conditions such as opens, or shorts to ground. Continuous memory DTCs have an additional 2-character DTC status code suffix to assist in determining DTC history.

AUDIO CONTROL MODULE (ACM) DTC CHART

SYMPTOM CHART

Pinpoint Test G: The Rear Video Is Inoperative

Refer to SYSTEM WIRING DIAGRAMS , Parking Aid for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. G1 CHECK AND CLEAN THE REAR VIDEO CAMERA LENS Clean and make sure that the video camera lens is clear of any debris. Test the video camera system and verify the camera image. Is the video camera concern still present? Yes : Vehicles equipped with navigation, GO to G8 . Vehicles equipped without navigation, GO to G2. No : The system is operating correctly at this time. The concern was caused by a dirty camera lens.
2. G2 CHECK THE REVERSING LAMPS OPERATION Check the operation of the reversing lamps. Do the reversing lamps operate correctly? Yes : GO to G3. No : REFER to «EXTERIOR LIGHTING»(ref-574136) .
3. G3 CHECK FOR A VIDEO CAMERA SIGNAL Ignition OFF. Apply the parking brake. Ignition ON. Select REVERSE. Observe the auto-dimming interior mirror. Does the auto-dimming interior mirror momentarily display a blue screen then turn off? Yes : The auto-dimming interior mirror is functional. There is no signal from the video camera. GO to G10 . No : GO to G4.
4. G4 CHECK THE AUTO-DIMMING INTERIOR MIRROR VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Select PARK. Ignition OFF. Disconnect: Auto-Dimming Interior Mirror C9039. Ignition ON. Measure the voltage between the auto-dimming interior mirror C9039-1, circuit CBP41 (BU), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to G5. No : VERIFY the Smart Junction Box (SJB) fuse 41 (15A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the «SYSTEM WIRING DIAGRAMS»(ref-541407) to identify the possible causes of the circuit short. TEST the system for normal operation.
5. G5 CHECK THE AUTO-DIMMING INTERIOR MIRROR REVERSE INPUT CIRCUIT Apply the parking brake. Select REVERSE. Measure the voltage between the auto-dimming interior mirror C9039-2, circuit CAT03 (GY/BN), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to G7 . No : GO to G6.
6. G6 CHECK THE AUTO-DIMMING INTERIOR MIRROR REVERSE INPUT CIRCUIT FOR AN OPEN Disconnect: Body Control Module B (BCM-B) C4368a. Measure the resistance between the BCM-B C4368a-6, circuit CAT03 (GY/BN), harness side and the auto-dimming interior mirror C9039-2, circuit CAT03 (GY/BN), harness side. Is the resistance less than 5 ohms? Yes : GO to G19 . No : REPAIR the circuit. TEST the system for normal operation.
7. G7 CHECK THE AUTO-DIMMING INTERIOR MIRROR GROUND CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: Negative Battery Cable. Measure the resistance between the auto-dimming interior mirror C9039-3, circuit GD139 (BK/YE), harness side and ground. Is the resistance less than 5 ohms? Yes : INSTALL a new auto-dimming interior mirror. REFER to «REAR VIEW MIRRORS»(ref-574191) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
8. G8 VERIFY THE REVERSE SIGNAL INPUT Apply the parking brake. Ignition ON. Select REVERSE. Check the IPC message center PRNDL indicator. Does REVERSE (R) appear in the message center? Yes : GO to G9. No : REFER to «AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80»(ref-574115) to diagnose the PRNDL.
9. G9 CHECK THE FDIM DISPLAY Select REVERSE. Observe the FDIM display. Does the FDIM display "PLEASE CHECK SURROUNDINGS FOR SAFETY" at the top of the display screen? Yes : The FDIM display is functional. There is no signal from the video camera. GO to G10. No : INSTALL a new FDIM. REFER to «INFORMATION AND ENTERTAINMENT SYSTEMS»(ref-574164) . TEST the system for normal operation.
10. G10 CHECK THE VIDEO SIGNAL CIRCUITS INTEGRITY Select PARK. Ignition OFF. Disconnect: Auto-Dimming Interior Mirror C9039 (Without Navigation) or FDIM C2123 (With Navigation). For vehicles without navigation, measure the resistance between the auto-dimming interior mirror C9039-8, circuit VMP19 (WH/GN), harness side and the auto-dimming interior mirror C9039-16, circuit RMP19 (BN/VT), harness side. For vehicles with navigation, measure the resistance between the FDIM C2123-3, circuit VMP19 (WH/GN), harness side and the FDIM C2123-9, circuit RMP19 (BN/VT), harness side. Is the resistance between 74 and 106 ohms? Yes : REMOVE the jumper wire. GO to G11. No : REMOVE the jumper wire. GO to G13 .
11. G11 CHECK THE VIDEO CAMERA VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Disconnect: Video Camera C4357. Ignition ON. Measure the voltage between the video camera C4357-1, circuit CBP29 (WH/VT), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to G12. No : VERIFY that the SJB fuse 29 (5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the «SYSTEM WIRING DIAGRAMS»(ref-541407) to identify the possible causes of the circuit short.
12. G12 CHECK THE VIDEO CAMERA GROUND CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: Negative Battery Cable. Measure the resistance between the video camera C4357-3, circuit GD116 (BK/VT), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to G18 . No : REPAIR the circuit. TEST the system for normal operation.
13. G13 CHECK THE VIDEO CAMERA VIDEO SIGNAL CIRCUITS FOR A SHORT TO GROUND Disconnect: Video Camera C4357. Measure the resistance between the video camera C4357-6, circuit VMP19 (WH/GN), harness side and ground; and between the video camera C4357-7, circuit RMP19 (BN/VT), harness side and ground. Are the resistances greater than 10, 000 ohms? Yes : GO to G14. No : REPAIR the circuit in question. TEST the system for normal operation.
14. G14 CHECK THE VIDEO CAMERA VIDEO SIGNAL CIRCUITS FOR A SHORT TO VIDEO SHIELD Measure the resistance between the video camera C4357-6, circuit VMP19 (WH/GN), harness side and the video camera C4357-4, circuit DMP19 (BARE), harness side. Measure the resistance between the video camera C4357-7, circuit RMP19 (BN/VT), harness side and the video camera C4357-4, circuit DMP19 (BARE), harness side. Are the resistances greater than 10, 000 ohms? Yes : GO to G15. No : REPAIR the circuit in question. TEST the system for normal operation.
15. G15 CHECK THE VIDEO CAMERA VIDEO SIGNAL CIRCUITS FOR A SHORT TO VOLTAGE Connect: Negative Battery Cable. Ignition ON. Measure the voltage between the video camera C4357-6, circuit VMP19 (WH/GN), harness side and ground. Measure the voltage between the video camera C4357-7, circuit RMP19 (BN/VT), harness side and ground. Is any voltage present? Yes : REPAIR the circuit in question. TEST the system for normal operation. No : GO to G16.
16. G16 CHECK VIDEO SIGNAL CIRCUITS FOR AN OPEN Ignition OFF. Connect a fused jumper wire between the video camera C4357-6, circuit VMP19 (WH/GN), harness side and the video camera C4357-7, circuit RMP19 (BN/VT), harness side. For vehicles without navigation, measure the resistance between the auto-dimming interior mirror C9039-8, circuit VMP19 (WH/GN), harness side and the auto-dimming interior mirror C9039-16, circuit RMP19 (BN/VT), harness side. For vehicles with navigation, measure the resistance between the FDIM C2123-3, circuit VMP19 (WH/GN), harness side and the FDIM C2123-9, circuit RMP19 (BN/VT), harness side. Is the resistance less than 5 ohms? Yes : REMOVE the jumper wire. GO to G18 . No : REMOVE the jumper wire. GO to G17.
17. G17 CHECK VIDEO SIGNAL CIRCUIT (+) FOR AN OPEN For vehicles without navigation, measure the resistance between the auto-dimming interior mirror C9039-8, circuit VMP19 (WH/GN), harness side and the video camera C4357-6, circuit VMP19 (WH/GN), harness side. For vehicles with navigation, measure the resistance between the FDIM C2123-3, circuit VMP19 (WH/GN), harness side and the video camera C4357-6, circuit VMP19 (WH/GN), harness side. Is the resistance less than 5 ohms? Yes : REPAIR circuit RMP19 (BN/VT). TEST the system for normal operation. No : REPAIR circuit VMP19 (WH/GN). TEST the system for normal operation.
18. G18 CHECK FOR CORRECT VIDEO CAMERA OPERATION Connect all disconnected connectors. Disconnect the video camera connector. Check for: corrosion damaged pins pushed-out pins Connect the video camera connector and make sure it seats correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new video camera. REFER to «VIDEO CAMERA»(ref-574192-S29981025562013082300000) . TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
19. G19 CHECK FOR CORRECT BCM-B OPERATION Connect: All Disconnected Connectors. Disconnect all the BCM-B connectors. Check for: corrosion damaged pins pushed-out pins Connect all the BCM-B connectors and make sure they seat correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : INSTALL a new BCM-B. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-574135) . TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

Pinpoint Test H: Poor Image Quality

Refer to SYSTEM WIRING DIAGRAMS , Parking Aid for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .

1. H1 CHECK AND CLEAN THE REAR VIDEO CAMERA LENS Clean and make sure that the video camera lens is clear of any debris. Test the video camera system and verify the video camera image. Is the video camera concern still present? Yes : GO to H2. No : The system is operating correctly at this time. The concern was caused by a dirty video camera lens.
2. H2 CHECK THE VIDEO SIGNAL CIRCUITS INTEGRITY Ignition OFF. Disconnect: Auto-Dimming Interior Mirror C9039 (Without Navigation) or FDIM C2123 (With Navigation). For vehicles without navigation, measure the resistance between the auto-dimming interior mirror C9039-8, circuit VMP19 (WH/GN), harness side and the auto-dimming interior mirror C9039-16, circuit RMP19 (BN/VT), harness side. For vehicles with navigation, measure the resistance between the FDIM C2123-3, circuit VMP19 (WH/GN), harness side and the FDIM C2123-9, circuit RMP19 (BN/VT), harness side. Is the resistance between 74 and 106 ohms? Yes : REMOVE the jumper wire. GO to H8 . No : REMOVE the jumper wire. GO to H3.
3. H3 CHECK THE VIDEO CAMERA GROUND CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: Negative Battery Cable. Disconnect: Video Camera C4357. Measure the resistance between the video camera C4357-3, circuit GD116 (BK/VT), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to H4. No : REPAIR the circuit. TEST the system for normal operation.
4. H4 CHECK THE VIDEO CAMERA VIDEO SIGNAL CIRCUITS FOR A SHORT TO GROUND Measure the resistance between the video camera C4357-6, circuit VMP19 (WH/GN), harness side and ground; and between the video camera C4357-7, circuit RMP19 (BN/VT), harness side and ground. Are the resistances greater than 10, 000 ohms? Yes : GO to H5. No : REPAIR the circuit in question. TEST the system for normal operation.
5. H5 CHECK THE VIDEO CAMERA VIDEO SIGNAL CIRCUITS FOR A SHORT TO VIDEO SHIELD Measure the resistance between the video camera C4357-6, circuit VMP19 (WH/GN), harness side and the video camera C4357-4, circuit DMP19 (BARE), harness side. Measure the resistance between the video camera C4357-7, circuit RMP19 (BN/VT), harness side and the video camera C4357-4, circuit DMP19 (BARE), harness side. Is the resistance greater than 10, 000 ohms? Yes : GO to H6. No : REPAIR the circuit in question. TEST the system for normal operation.
6. H6 CHECK VIDEO SIGNAL CIRCUITS FOR AN OPEN Ignition OFF. Disconnect: Auto-Dimming Interior Mirror C9039. Connect a fused jumper wire between the video camera C4357-6, circuit VMP19 (WH/GN), harness side and the video camera C4357-7, circuit RMP19 (BN/VT), harness side. For vehicles without navigation, measure the resistance between the auto-dimming interior mirror C9039-8, circuit VMP19 (WH/GN), harness side and the auto-dimming interior mirror C9039-16, circuit RMP19 (BN/VT), harness side. For vehicles with navigation, measure the resistance between the FDIM C2123-3, circuit VMP19 (WH/GN), harness side and the FDIM C2123-9, circuit RMP19 (BN/VT), harness side. Are the resistances less than 5 ohms? Yes : REMOVE the jumper wire. GO to H8 . No : REMOVE the jumper wire. GO to H7.
7. H7 CHECK VIDEO SIGNAL CIRCUIT (+) FOR AN OPEN For vehicles without navigation, measure the resistance between the auto-dimming interior mirror C9039-8, circuit VMP19 (WH/GN), harness side and the video camera C4357-6, circuit VMP19 (WH/GN), harness side. For vehicles with navigation, measure the resistance between the FDIM C2123-3, circuit VMP19 (WH/GN), harness side and the video camera C4357-6, circuit VMP19 (WH/GN), harness side. Is the resistance less than 5 ohms? Yes : REPAIR circuit RMP19 (BN/VT). TEST the system for normal operation. No : REPAIR circuit VMP19 (WH/GN). TEST the system for normal operation.
8. H8 CHECK FOR CORRECT VIDEO CAMERA OPERATION Connect all disconnected connectors. Disconnect the video camera connector. Check for: corrosion damaged pins pushed-out pins Connect the video camera connector and make sure it seats correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new video camera. REFER to «VIDEO CAMERA»(ref-574192-S29981025562013082300000) . TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

PINPOINT TEST I: THE REAR VIDEO MIRROR DISPLAY IS ALWAYS ON

1. I1 CHECK THE REVERSING LAMPS OPERATION Check the operation of the reversing lamps. Do the reversing lamps operate correctly? Yes : GO to I2. No : REFER to «EXTERIOR LIGHTING»(ref-574136) .
2. I2 CHECK FOR CORRECT AUTO-DIMMING INTERIOR MIRROR OPERATION Disconnect the auto-dimming interior mirror connector. Check for: corrosion damaged pins pushed-out pins Connect the auto-dimming interior mirror connector and make sure it seats correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : INSTALL a new auto-dimming interior mirror. REFER to «REAR VIEW MIRRORS»(ref-574191) . TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Scheme 28

Note. The object used in this system check can be fabricated from 9 cm O.D. (3 in I.D) plastic pipe 100 cm (39 in) in length (available as Polyvinyl Chloride (PVC) pipe, or similar from a hardware or plumbing supply).

Note. The following system check should be carried out with the vehicle on a level surface. The specified object locations are approximate, not absolute

Note. The parking aid system defaults to on when the ignition key is cycled from OFF to ON.

Note. The scan tool may be used to monitor distance PIDs. The distance PIDs read between 0 and 255 cm (0 and 8 ft) on a correctly functioning system.

1. Turn the ignition to the ON position, engine off.
2. Set the parking brake on.
3. Place the gear shift in REVERSE (R).
4. Verify that the parking aid system detects the specified object when placed within the 5 specified locations (P1, P2, P3, P4, P5). The pipe should be inside of these locations. The speaker should beep slowly when objects are detected on the outer edges of the detection zone, and increase as the object is moved closer to the vehicle. When the object is within 46 cm (18 in) of the rear bumper, the sounder should be on continuously. If the Parking Aid Module (PAM) does not detect the object above, refer to «PARKING AID»(ref-574192-S24110980932013082300000) .

Scheme 29

1. NOTE: The following system check should be carried out with the vehicle on a 3.0 m wide by 4.5 m deep (10 ft wide by 15 ft deep) smooth concrete surface, free of all obstacles and noise from fan and pneumatic tools. Turn the ignition to the ON position, engine off.
2. Set the parking brake.
3. Place the gear shift in REVERSE (R).
4. Verify that no audible alerts are heard. If audible alerts are heard, check to make sure the bumper is correctly installed and is not tilted downward so that the sensor is pointing at the ground. If the audible warning tone is heard, refer to «PARKING AID»(ref-574192-S24110980932013082300000) .

Scheme 30
