Automatic Transmission External Controls: Removal & Installation Ford Mustang V рестайлинг 2

Automatic Trans 10 illustrations ~357 words

Removal and Installation

  1. NOTE: The Brake Shift Interlock Actuator (BSIA) is not serviced separately. If a new BSIA is required, install a new transmission selector lever assembly. For additional information, refer to «SELECTOR LEVER»(ref-574162-S15749856822013082300000) .

Removal

All vehicles

Pinpoint Test B

B2 Vehicles equipped with a 5.0L (4V) engine
  1. click to open the image
  2. Vehicles equipped with a 5.0L (4V) engine
B3 All vehicles
  1. click to open the image
  2. All vehicles

Installation

All vehicles

Pinpoint Test B

B3 Vehicles equipped with a 5.0L (4V) engine
  1. click to open the image
  2. Vehicles equipped with a 5.0L (4V) engine
B4 All vehicles
  1. click to open the image
  2. All vehicles

Scheme 2

Scheme 2: Removal

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6
  1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-574118) .
  2. Discard the specified component. Follow local disposal regulations.
  3. Interior trim remover.

Scheme 7

Scheme 7

Scheme 8

Scheme 8
  1. Tighten to 9 Nm (80 lb-in).
  2. Adjust the selector lever cable when a new selector lever is installed. Refer to «SELECTOR LEVER CABLE ADJUSTMENT»(ref-574162-S08633323882013082300000) .

Scheme 9

Scheme 9: Removal

Scheme 10

Scheme 10
  1. NOTE: The SelectShift ™ switch is part of the selector lever knob. To install a new SelectShift ™ switch, a new selector lever knob must be installed. Remove the selector lever. Refer to «SELECTOR LEVER»(ref-574162-S15749856822013082300000) .
  2. Interior trim remover.

Scheme 11

Scheme 11
  1. NOTE: Keep the SelectShift™ switch wire taught while installing the selector lever knob. Position the SelectShift™ switch wire towards the back right corner of the selector knob shroud. Route the SelectShift™ switch wire through the selector lever opening.
  2. NOTE: Tightening the transmission selector lever knob screws over 2 Nm (18 lb-in) may damage the selector lever assembly. Tighten to 2 Nm (18 lb-in).
  3. NOTE: Make sure the SelectShift™ switch wire is pulled taught prior to connecting the SelectShift™ switch.
  4. Install the selector lever. Refer to «SELECTOR LEVER»(ref-574162-S15749856822013082300000) .
